Hot Swap Controller and Digital Power and Energy Monitor with PMBus Interface Features: ±0.3% accurate, 12-bit ADC for IOUT, VIN, VOUT, and temperature 320 ns response time to short circuit Shutdown on detection of FET health fault Constant power foldback for tighter FET SOA protection Remote temperature sensing with programmable warning and shutdown thresholds Resistor-programmable 5 mV to 25 mV VSENSE current limit Programmable start-up current limit 1% accurate UV, OV, and PWRGD thresholds Split hot swap and power monitor inputs to allow additional external ADC filtering Reports power and energy consumption over time Peak detect registers for current, voltage, and power PROCHOT power throttling capability PMBus fast mode compliant interface 5 mm × 5 mm, 32-lead LFCSP

Digital Power Monitor with PMBus Interface Features: Monitor current and two voltages High accuracy current monitoring at low sense voltage 0.33% accurate at ±20 mV sense voltage over temperature Support high side and low side current sensing Integrated shunt regulator for wide supply input Reports current, voltage and power Power accumulation for energy metering Bidirectional current sensing Digital programmable over current alert See datasheet for additional features

Digital Power Monitor with PMBus Interface Features: Monitor current and two voltages High accuracy current monitoring at low sense voltage 0.33% accurate at ±20 mV sense voltage over temperature Support high side and low side current sensing Integrated shunt regulator for wide supply input Reports current, voltage and power Power accumulation for energy metering Bidirectional current sensing Digital programmable over current alert See datasheet for additional features

EMI/EMC Compliant, 15kV Protected, RS-232 230kBPS Transceiver with 4 Drivers, 5 Receivers and Shutdown and Enable Pins Features: Complies with 89/336/EEC EMC directive ESD protection to IEC 1000-4-2 (801-2) Contact discharge: ±8 kV Air-gap discharge: ±15 kV Human body model: ±15 kV EFT/burst immunity (IEC 1000-4-4) Low EMI emissions (EN 55022) Eliminates need for TransZorb® suppressors 230 kbps data rate guaranteed Single 5 V power supply Shutdown mode 1 μW Plug-in upgrade for MAX2xxE Space saving TSSOP package available

5 kV Signal Isolated, High Speed (16 Mbps), ESD Protected, Full/Half Duplex RS-485 Transceiver Features: Isolated, RS-485/RS-422 transceiver, configurable as half- or full-duplex ±8 kV ESD protection on RS-485 input/output pins 16 Mbps data rate Complies with ANSI TIA/EIA RS-485-A-1998 and ISO 8482: 1987(E) Suitable for 5 V or 3.3 V operation (VDD1) High common-mode transient immunity: >25 kV/µs Receiver has open-circuit, fail-safe design 32 nodes on the bus Thermal shutdown protection Safety and regulatory approvals UL recognition: 5000 V rms isolation voltage for 1 minute, per UL 1577 VDE certificate of conformity DIN V VDE V 0884-10 (VDE V 0884-10): 2006-12 Reinforced insulation, VIORM = 849 V peak See data sheet for additional features

3 kV RMS Signal and Power Isolated RS-485 Transceiver with 15 kV IEC ESD Features: 3 kV rms isolated RS-485/RS-422 transceiver Low radiated emissions, integrated, isolated dc-to-dc converter Passes EN 55032 Class B with margin on a 2-layer PCB Cable invert smart feature Correct reversed cable connection on A, B, Y, and Z bus pins while maintaining full receiver fail-safe feature ESD protection on RS-485 A, B, Y and Z pins ≥±12 kV IEC61000-4-2 contact discharge ≥±15 kV IEC61000-4-2 air discharge High speed 25 Mbps data rate (ADM2565E/ADM2567E) Low speed 500 kbps data rate for EMI control (ADM2561E/ADM2563E) Flexible power supplies Input VCC supply of 3 V to 5.5 V Logic VIO supply of 1.7 V to 5.5 V VSEL pin to select VISO supply of 5 V (VCC > 4.5 V) or 3.3 V PROFIBUS compliant for 5 V VISO Wide operating temperature range: −40°C to +105°C High common-mode transient immunity: 250 kV/µs Short-circuit, open-circuit, and floating input receiver fail-safe Supports 196 bus nodes (72 kΩ receiver input impedance) Full hot swap support (glitch free power-up/power-down) Safety and regulatory approvals (pending) CSA Component Acceptance Notice 5A, DIN V VDE V 0884-11, UL 1577, CQC11-471543-2012, IEC 61010-1 Complies with ANSI/TIA/EIA-485-A-98 and ISO 8482:1987(E) 28-lead, fine pitch SOIC_W package (10.15 mm 10.05 mm) with >8.0 mm creepage and clearance

3 kV RMS Signal and Power Isolated RS-485 Transceiver with 15 kV IEC ESD Features: 3 kV rms isolated RS-485/RS-422 transceiver Low radiated emissions, integrated, isolated dc-to-dc converter Passes EN 55032 Class B with margin on a 2-layer PCB Cable invert smart feature Correct reversed cable connection on A, B, Y, and Z bus pins while maintaining full receiver fail-safe feature ESD protection on RS-485 A, B, Y and Z pins ≥±12 kV IEC61000-4-2 contact discharge ≥±15 kV IEC61000-4-2 air discharge High speed 25 Mbps data rate (ADM2565E/ADM2567E) Low speed 500 kbps data rate for EMI control (ADM2561E/ADM2563E) Flexible power supplies Input VCC supply of 3 V to 5.5 V Logic VIO supply of 1.7 V to 5.5 V VSEL pin to select VISO supply of 5 V (VCC > 4.5 V) or 3.3 V PROFIBUS compliant for 5 V VISO Wide operating temperature range: −40°C to +105°C High common-mode transient immunity: 250 kV/µs Short-circuit, open-circuit, and floating input receiver fail-safe Supports 196 bus nodes (72 kΩ receiver input impedance) Full hot swap support (glitch free power-up/power-down) Safety and regulatory approvals (pending) CSA Component Acceptance Notice 5A, DIN V VDE V 0884-11, UL 1577, CQC11-471543-2012, IEC 61010-1 Complies with ANSI/TIA/EIA-485-A-98 and ISO 8482:1987(E) 28-lead, fine pitch SOIC_W package (10.15 mm 10.05 mm) with >8.0 mm creepage and clearance

3 kV RMS Signal and Power Isolated RS-485 Transceiver with 15 kV IEC ESD Features: 3 kV rms isolated RS-485/RS-422 transceiver Low radiated emissions, integrated, isolated dc-to-dc converter Passes EN 55032 Class B with margin on a 2-layer PCB Cable invert smart feature Correct reversed cable connection on A, B, Y, and Z bus pins while maintaining full receiver fail-safe feature ESD protection on RS-485 A, B, Y and Z pins ≥±12 kV IEC61000-4-2 contact discharge ≥±15 kV IEC61000-4-2 air discharge High speed 25 Mbps data rate (ADM2565E/ADM2567E) Low speed 500 kbps data rate for EMI control (ADM2561E/ADM2563E) Flexible power supplies Input VCC supply of 3 V to 5.5 V Logic VIO supply of 1.7 V to 5.5 V VSEL pin to select VISO supply of 5 V (VCC > 4.5 V) or 3.3 V PROFIBUS compliant for 5 V VISO Wide operating temperature range: −40°C to +105°C High common-mode transient immunity: 250 kV/µs Short-circuit, open-circuit, and floating input receiver fail-safe Supports 196 bus nodes (72 kΩ receiver input impedance) Full hot swap support (glitch free power-up/power-down) Safety and regulatory approvals (pending) CSA Component Acceptance Notice 5A, DIN V VDE V 0884-11, UL 1577, CQC11-471543-2012, IEC 61010-1 Complies with ANSI/TIA/EIA-485-A-98 and ISO 8482:1987(E) 28-lead, fine pitch SOIC_W package (10.15 mm 10.05 mm) with >8.0 mm creepage and clearance

5.7 kV RMS Isolated, High Working Voltage, RS-485 Transceiver with 15 kV IEC ESD Features: 5.7 kV rms, signal isolated RS-485 transceiver 1500 V peak and dc working voltage to DIN V VDE 0884-11 Low radiated emissions: passes EN 55032, Class B with margin on a 2-layer PCB Receiver cable inversion smart feature Correction for reversed cable connection on A and B bus pins while maintaining full receiver fail-safe feature ESD protection on the RS-485 A, B, Y, and Z bus pins ≥ ±12 kV IEC 61000-4-2 contact discharge ≥ ±15 kV IEC 61000-4-2 air discharge Low speed 500 kbps data rate for EMI control Flexible power supply inputs Primary VDD1 supply of 1.7 V to 5.5 V Isolated VDD2 supply of 3.0 V to 5.5 V Profibus® Compliant for 5V VDD2 Wide −40°C to +125°C operating temperature range High common-mode transient immunity: >250 kV/μs Short-circuit, open-circuit, and floating input receiver fail-safe Supports 192 bus nodes (72 kΩ receiver input impedance) Full hot swap support (glitch free power-up and power-down) Safety and regulatory approvals (pending) CSA Component Acceptance Notice 5A, DIN V VDE 0884-11, UL 1577, CQC11-471543-2012, IEC 61010-1 16-lead, wide-body, SOIC_W package with 8.3 mm creepage and clearance in standard pinout

5.7 kV RMS 500kbps Full Duplex Signal and Power Isolated RS-485 Transceiver with 15 kV IEC ESD Features: 5.7 kV rms isolated RS-485/RS-422 transceiver Low radiated emissions, integrated, isolated dc-to-dc converter Passes EN 55032 Class B with margin on a 2-layer PCB Cable invert smart feature Correct reversed cable connection on A, B, Y, and Z bus pins while maintaining full receiver fail-safe feature ESD protection on RS-485 A, B, Y, and Z pins 12 kV IEC61000-4-2 contact discharge 15 kV IEC61000-4-2 air discharge High speed 25 Mbps data rate (ADM2865E/ADM2867E) Low speed 500 kbps data rate for EMI control (ADM2861E/ADM2863E) Flexible power supplies Input VCC supply of 3 V to 5.5 V Logic VIO supply of 1.7 V to 5.5 V VSEL pin to select VISO supply of 5 V (VCC > 4.5 V) or 3.3 V PROFIBUS compliant for 5 V VISO Wide operating temperature range: −40°C to +105°C High common-mode transient immunity: 250 kV/μs Short-circuit, open-circuit, and floating input receiver fail-safe Supports 192 bus nodes (72 k receiver input impedance) Full hot swap support (glitch free power-up/power-down) Safety and regulatory approvals (pending) CSA Component Acceptance Notice 5A, DIN V VDE V 0884-11, UL 1577, CQC11-471543-2012, IEC 61010-1 Complies with ANSI/TIA/EIA-485-A-98 and ISO 8482:1987(E) 28-lead, fine pitch SOIC_W package (10.15 mm 10.05 mm) with >8.0 mm creepage and clearance

5.7 kV rms, Signal Isolated, Basic CAN FD Transceiver Features: 5.7 kV rms signal isolated CAN FD transceiver 1.7 V to 5.5 V supply and logic side levels 4.5 V to 5.5 V supply on bus side ISO 11898-2:2016-compliant CAN FD Data rates up to 12 Mbps for CAN FD Low maximum loop propagation delay: 150 ns Extended common-mode range: ±25 V Bus fault protection (CANH, CANL): ±40 V Passes EN 55022, Class B by 6 dB Safety and regulatory approvals VDE certificate of conformity, VDE V 0884-10 (pending) UL: 5700 V rms for 1-minute duration per UL 1577 (pending) CSA component acceptance 5A at 5.7 kV rms IEC 60950, IEC 61010 (pending) High common-mode transient immunity: >75 kV/µs Industrial operating temperature range: −40°C to +125°CADM3050E-EP Supports defense and aerospace applications (AQEC standard) Download ADM3050E-EP Data Sheet (PDF) Full military temperature range: −55°C to +125°C Controlled manufacturing baseline 1 assembly/test site 1 fabrication site Product change notification Qualification data available on request V62/19605 DSCC Drawing Number

5.7 kV rms, Signal Isolated, Basic CAN FD Transceiver Features: 5.7 kV rms signal isolated CAN FD transceiver 1.7 V to 5.5 V supply and logic side levels 4.5 V to 5.5 V supply on bus side ISO 11898-2:2016-compliant CAN FD Data rates up to 12 Mbps for CAN FD Low maximum loop propagation delay: 150 ns Extended common-mode range: ±25 V Bus fault protection (CANH, CANL): ±40 V Passes EN 55022, Class B by 6 dB Safety and regulatory approvals VDE certificate of conformity, VDE V 0884-10 (pending) UL: 5700 V rms for 1-minute duration per UL 1577 (pending) CSA component acceptance 5A at 5.7 kV rms IEC 60950, IEC 61010 (pending) High common-mode transient immunity: >75 kV/µs Industrial operating temperature range: −40°C to +125°CADM3050E-EP Supports defense and aerospace applications (AQEC standard) Download ADM3050E-EP Data Sheet (PDF) Full military temperature range: −55°C to +125°C Controlled manufacturing baseline 1 assembly/test site 1 fabrication site Product change notification Qualification data available on request V62/19605 DSCC Drawing Number

5.7 kV rms, Signal Isolated, High Working Voltage, CAN FD Transceiver with 15kV IEC ESD Features: 5.7 kV rms signal isolated CAN FD transceiver 1500 V peak and dc working voltage to DIN VDE 0884-11 1.7 V to 5.5 V supply and logic side levels 4.5 V to 5.5 V supply on bus side ISO 11898-2:2016-compliant CAN FD Data rates up to 12 Mbps for CAN FD Low maximum loop propagation delay: 155 ns Extended common-mode range: 25 V Bus fault protection (CANH, CANL): 40 V ESD protection on the CANH and CANL bus pins 8 kV IEC 61000-4-2 contact discharge 15 kV IEC 61000-4-2 air discharge Passes EN 55022, Class B by 6 dB Safety and regulatory approvals (pending) UL: 5700 V rms for 1-minute per UL 1577 CSA Component Acceptance 5A at 5.7 kV rms IEC 60601 and IEC 61010 VDE Certificates of Conformity DIN VDE V 0884-11 (VDE V 0884-11):2017-01 VIORM = 1500 V peak High common-mode transient immunity: >50 kV/s Industrial operating temperature range: 40C to +125C

3.0 V to 5.5 V, 12 kV IEC ESD Protected, Half Duplex 500 kbps RS-485 Transceiver Features: TIA/EIA RS-485 compliant over full supply range 3.0 V to 5.5 V operating voltage range on VCC 1.62 V to 5.5 V VIO logic supply option available ESD protection on the bus pins IEC 61000-4-2 ±12 kV contact discharge IEC 61000-4-2 ≥ ±12 kV air discharge HBM: ≥ ±30 kV Full hot swap support (glitch free power-up/power-down) High speed 50 Mbps data rate (ADM3065E/ADM3066E/ADM3067E/ADM3068E) Low speed 500 kbps data rate for long cables (ADM3061E/ADM3062E/ADM3063E) Full receiver short-circuit, open circuit, and bus idle fail-safe Extended temperature range up to 125°C PROFIBUS compliant at VCC ≥ 4.5 V Half duplex and full duplex models available Allows connection of up to 128 transceivers onto the bus Space-saving package options 10-lead, 3 mm × 3 mm LFCSP 8-lead and 10-lead, 3 mm × 3 mm MSOP 8-lead and 14-lead, narrow body SOIC

3.0 V to 5.5 V, 12 kV IEC ESD Protected, Half Duplex 500 kbps RS-485 Transceiver Features: TIA/EIA RS-485 compliant over full supply range 3.0 V to 5.5 V operating voltage range on VCC 1.62 V to 5.5 V VIO logic supply option available ESD protection on the bus pins IEC 61000-4-2 ±12 kV contact discharge IEC 61000-4-2 ≥ ±12 kV air discharge HBM: ≥ ±30 kV Full hot swap support (glitch free power-up/power-down) High speed 50 Mbps data rate (ADM3065E/ADM3066E/ADM3067E/ADM3068E) Low speed 500 kbps data rate for long cables (ADM3061E/ADM3062E/ADM3063E) Full receiver short-circuit, open circuit, and bus idle fail-safe Extended temperature range up to 125°C PROFIBUS compliant at VCC ≥ 4.5 V Half duplex and full duplex models available Allows connection of up to 128 transceivers onto the bus Space-saving package options 10-lead, 3 mm × 3 mm LFCSP 8-lead and 10-lead, 3 mm × 3 mm MSOP 8-lead and 14-lead, narrow body SOIC

3.0 V to 5.5 V, 12 kV IEC ESD Protected, 500 kbps/50 Mbps RS-485 Transceivers Features: TIA/EIA RS-485 compliant over full supply range 3.0 V to 5.5 V operating voltage range on VCC 1.62 V to 5.5 V VIO logic supply option available ESD protection on the bus pins IEC 61000-4-2 ≥ ±12 kV contact discharge IEC 61000-4-2 ≥ ±12 kV air discharge HBM ≥ ±30 kV Full hot swap support (glitch free power-up/power-down) High speed 50 Mbps data rate (ADM3065E/ADM3066E/ADM3067E/ADM3068E) Low speed 500 kbps data rate for long cables (ADM3061E/ADM3062E/ADM3063E/ADM3064E) Full receiver short-circuit, open circuit, and bus idle fail-safe Extended temperature range up to 125°C PROFIBUS compliant at VCC ≥ 4.5 V Half duplex and full duplex models available Allows connection of up to 128 transceivers onto the bus Space-saving package options 10-lead, 3 mm × 3 mm LFCSP 8-lead and 10-lead, 3 mm × 3 mm MSOP 8-lead and 14-lead, narrow body SOIC

3.0 V to 5.5 V, 12 kV IEC ESD Protected, 500 kbps/50 Mbps RS-485 Transceivers Features: TIA/EIA RS-485 compliant over full supply range 3.0 V to 5.5 V operating voltage range on VCC 1.62 V to 5.5 V VIO logic supply option available ESD protection on the bus pins IEC 61000-4-2 ≥ ±12 kV contact discharge IEC 61000-4-2 ≥ ±12 kV air discharge HBM ≥ ±30 kV Full hot swap support (glitch free power-up/power-down) High speed 50 Mbps data rate (ADM3065E/ADM3066E/ADM3067E/ADM3068E) Low speed 500 kbps data rate for long cables (ADM3061E/ADM3062E/ADM3063E/ADM3064E) Full receiver short-circuit, open circuit, and bus idle fail-safe Extended temperature range up to 125°C PROFIBUS compliant at VCC ≥ 4.5 V Half duplex and full duplex models available Allows connection of up to 128 transceivers onto the bus Space-saving package options 10-lead, 3 mm × 3 mm LFCSP 8-lead and 10-lead, 3 mm × 3 mm MSOP 8-lead and 14-lead, narrow body SOIC

3.0 V to 5.5 V, 12 kV IEC ESD Protected, Full Duplex 50 Mbps RS-485 Transceiver Features: TIA/EIA RS-485 compliant over full supply range 3.0 V to 5.5 V operating voltage range on VCC 1.62 V to 5.5 V VIO logic supply option available ESD protection on the bus pins IEC 61000-4-2 ±12 kV contact discharge IEC 61000-4-2 ≥ ±12 kV air discharge HBM: ≥ ±30 kV Full hot swap support (glitch free power-up/power-down) High speed 50 Mbps data rate (ADM3065E/ADM3066E/ADM3067E/ADM3068E) Low speed 500 kbps data rate for long cables (ADM3061E/ADM3062E/ADM3063E) Full receiver short-circuit, open circuit, and bus idle fail-safe Extended temperature range up to 125°C PROFIBUS compliant at VCC ≥ 4.5 V Half duplex and full duplex models available Allows connection of up to 128 transceivers onto the bus Space-saving package options 10-lead, 3 mm × 3 mm LFCSP 8-lead and 10-lead, 3 mm × 3 mm MSOP 8-lead and 14-lead, narrow body SOIC Supports defense and aerospace applications (AQEC standard) Download ADM3065E-EP/ADM3066E-EP/ADM3067E-EP Data Sheet (PDF) Extended industrial temperature range: −55°C to +125°C Controlled manufacturing baseline 1 assembly/test site 1 fabrication site Product change notification Qualification data available on request

3.0 V to 5.5 V, 12 kV IEC ESD Protected, 500 kbps/50 Mbps RS-485 Transceiver Features: TIA/EIA RS-485 compliant over full supply range 3.0 V to 5.5 V operating voltage range on VCC 1.62 V to 5.5 V VIO logic supply option available ESD protection on the bus pins IEC 61000-4-2 ±12 kV contact discharge IEC 61000-4-2 ≥ ±12 kV air discharge HBM: ≥ ±30 kV Full hot swap support (glitch free power-up/power-down) High speed 50 Mbps data rate (ADM3065E/ADM3066E/ADM3067E/ADM3068E) Low speed 500 kbps data rate for long cables (ADM3061E/ADM3062E/ADM3063E) Full receiver short-circuit, open circuit, and bus idle fail-safe Extended temperature range up to 125°C PROFIBUS compliant at VCC ≥ 4.5 V Half duplex and full duplex models available Allows connection of up to 128 transceivers onto the bus Space-saving package options 10-lead, 3 mm × 3 mm LFCSP 8-lead and 10-lead, 3 mm × 3 mm MSOP 8-lead and 14-lead, narrow body SOIC

+2.7V Serial Port RS-232 Transceiver (5 Drivers / 3 Receivers) with 15kV ESD (TTL & RS-232) Features: Green Idle power-saving mode Single 2.7 V to 3.6 V power supply Operates with 3 V logic 0.1 µF to 1 µF charge pump capacitors Low EMI Low power shutdown: 20 nA Full RS-232 compliance 460 kb/s data rate One receiver active in shutdown  (ADM3307E/ADM3311E/ADM3312E/ADM3315E) Two receivers active in shutdown (ADM3310E) ESD >15 kV IEC 1000-4-2 on RS-232 I/Os ESD >15 kV IEC 1000-4-2 on CMOS and RS-232 I/Os (ADM3307E) Qualified for automotive applications
