Low Power Video Difference Amplifier Features: Differential or Single-Ended Gain Block (Adjustable) -3dB Bandwidth, AV = ±10: 35MHz Slew Rate: 220V/µs Low Supply Current: 13mA Output Current: ± 20mA CMRR at 10MHz: 48dB LT1193 Pin Out Low Cost Single 5V Operation Drives Cables Directly Output Shutdown

Low Power Video Difference Amplifier Features: Differential or Single-Ended Gain Block (Adjustable) -3dB Bandwidth, AV = ±10: 35MHz Slew Rate: 220V/µs Low Supply Current: 13mA Output Current: ± 20mA CMRR at 10MHz: 48dB LT1193 Pin Out Low Cost Single 5V Operation Drives Cables Directly Output Shutdown

Ultrahigh Speed Operational Amplifier Features: Gain Bandwidth Product, AV = 1: 50MHz Slew Rate: 450V/µs Low Cost Output Current: ±50mA Settling Time: 140ns to 0.1% Differential Gain Error: 0.1%, (RL = 1k) Differential Phase Error: 0.06°, (RL = 1k) High Open-Loop Gain: 10V/mV Min Single Supply +5V Operation Output Shutdown

Ultrahigh Speed Operational Amplifier Features: Gain Bandwidth Product, AV = 1: 90MHz Slew Rate: 450V/µs Low Cost Output Current: ±50mA Settling Time: 110ns to 0.1% Differential Gain Error: 0.07%, (RL = 1k) Differential Phase Error: 0.02°, (RL = 1k) High Open-Loop Gain 20V/mV Min Single Supply +5V Operation Output Shutdown

Ultrahigh Speed Operational Amplifier Features: Gain Bandwidth Product, AV= 5: 350MHz Slew Rate: 450V/µs Low Cost Output Current: ±50mA Settling Time: 90ns to 0.1% Differential Gain Error: 0.1% (RL = 1k) Differential Phase Error: 0.01° (RL = 1k) High Open-Loop Gain: 100V/mV Min Single Supply +5V Operation Output Shutdown

1.1A, 35MHz Current Feedback Amplifier Features:1.1A Minimum Output Drive Current35MHz Bandwidth, AV = 2, RL = 10Ω900V/μs Slew Rate, AV = 2, RL = 10ΩHigh Input Impedance: 10MΩWide Supply Range: ± 5V to ±15V (TO-220 and DD Packages)Enhanced θJA SO-16 Package for ±5V OperationShutdown Mode: IS < 200μAAdjustable Supply CurrentStable with CL = 10,000pFOperating Temperature Range: –40°C to 85°CAvailable in 7-Lead DD, TO-220 and 16-Lead SO Packages

1.1A, 35MHz Current Feedback Amplifier Features:1.1A Minimum Output Drive Current35MHz Bandwidth, AV = 2, RL = 10Ω900V/μs Slew Rate, AV = 2, RL = 10ΩHigh Input Impedance: 10MΩWide Supply Range: ± 5V to ±15V (TO-220 and DD Packages)Enhanced θJA SO-16 Package for ±5V OperationShutdown Mode: IS < 200μAAdjustable Supply CurrentStable with CL = 10,000pFOperating Temperature Range: –40°C to 85°CAvailable in 7-Lead DD, TO-220 and 16-Lead SO Packages

14MHz, 7V/s, Single Supply Dual and Quad Precision Op Amps Features: Slew Rate: 7V/µs Typ Gain-Bandwidth Product: 14MHz Typ Fast Settling to 0.01% 2V Step to 200µV: 900ns Typ 10V Step to 1mV: 2.2µs Typ Excellent DC Precision in All Packages Input Offset Voltage: 275µV Max Input Offset Voltage Drift: 6µV/°C Max Input Offset Current: 30nA Max Input Bias Current: 125nA Max Open-Loop Gain: 1200V/mV Min Single Supply Operation Input Voltage Range Includes Ground Output Swings to Ground While Sinking Current Low Input Noise Voltage: 12nV/√Hz Typ Low Input Noise Current: 0.2pA/√Hz Typ Specified on 3.3V, 5V and ±15V Large Output Drive Current: 20mA Min Low Supply Current per Amplifier: 1.8mA Max Dual in 8-Pin DIP and SO8 Quad in 14-Pin DIP and NARROW SO16 Note: For applications requiring higher slew rate, see the LT1213/LT1214 and LT1215/LT1216 data sheets

28MHz, 12V/s, Single Supply Dual Precision Op Amps Features: Slew Rate: 12V/µs Typ Gain-Bandwidth Product: 28MHz Typ Fast Settling to 0.01% 2V Step to 200µV: 500ns Typ 10V Step to 1mV: 1.1µs Typ Excellent DC Precision in All Packages Input Offset Voltage: 275µV Max Input Offset Voltage Drift: 6µV/°C Max Input Offset Current: 40nA Max Input Bias Current: 200nA Max Open-Loop Gain: 1200V/mV Min Single Supply Operation Input Voltage Range Includes Ground Output Swings to Ground While Sinking Current Low Input Noise Voltage: 10nV/√Hz Typ Low Input Noise Current: 0.2pA/√Hz Typ Specified at 3.3V, 5V and ±15V Large Output Drive Current: 30mA Min Low Supply Current per Amplifier: 3.5mA Max Dual in 8-Pin DIP and SO-8 Quad in 14-Pin DIP and NARROW SO-16

Precision Rail-to-Rail Input and Output Op Amps Features: Rail-to-Rail Input and Output 90µV VOS(MAX) for VCM = V- to V+ High Common Mode Rejection Ratio: 97dB Min C-Load™ Stable Version (LT1219) High AVOL: 500V/mV Minimum Driving 10k Load Wide Supply Range: 2V to ±15V (LT1218/LT1219) 2V to ±5V (LT1218L/LT1219L) Shutdown Mode: IS < 30µA Low Supply Current: 420µA Max Low Input Bias Current: 18nA Typical 300kHz Gain-Bandwidth Product (LT1218) Slew Rate: 0.10V/µs (LT1218)

Precision Rail-to-Rail Input and Output Op Amp Features: Rail-to-Rail Input and Output 90µV VOS(MAX) for VCM = V– to V+ High Common Mode Rejection Ratio: 97dB Min C-Load™ Stable Version (LT1219) High AVOL: 500V/mV Minimum Driving 10kΩ Load Wide Supply Range: 2V to ±15V (LT1218/LT1219) 2V to ±5V (LT1218L/LT1219L) Shutdown Mode: IS < 30µA Low Supply Current: 420µA Max Low Input Bias Current: 18nA Typical 300kHz Gain-Bandwidth Product (LT1218) Slew Rate: 0.10V/µs (LT1218)

Precision Rail-to-Rail Input and Output Op Amps Features: Rail-to-Rail Input and Output 90µV VOS(MAX) for VCM = V- to V+ High Common Mode Rejection Ratio: 97dB Min C-Load™ Stable Version (LT1219) High AVOL: 500V/mV Minimum Driving 10k Load Wide Supply Range: 2V to ±15V (LT1218/LT1219) 2V to ±5V (LT1218L/LT1219L) Shutdown Mode: IS < 30µA Low Supply Current: 420µA Max Low Input Bias Current: 18nA Typical 300kHz Gain-Bandwidth Product (LT1218) Slew Rate: 0.10V/µs (LT1218)

150MHz, 250V/s, AV 4 Operational Amplifier Features: Gain-Bandwidth: 150MHz Gain of 4 Stable Slew Rate: 250V/µs Input Noise Voltage: 6nV/√Hz C-Load™ Op Amp Drives Capacitive Loads Maximum Input Offset Voltage: 600µV Maximum Input Bias Current: 300nA Maximum Input Offset Current: 300nA Minimum Output Swing Into 500Ω: ±12V Minimum DC Gain: 50V/mV, RL = 500Ω Settling Time to 0.1%: 65ns, 10V Step Settling Time to 0.01%: 85ns, 10V Step Differential Gain: 0.08%, AV = 4, RL = 150Ω Differential Phase: 0.2°, AV = 4, RL = 150Ω

500MHz, 3nV/Hz, AV 10 Operational Amplifier Features: Gain-Bandwidth: 500MHz Gain of 10 Stable Uncompensated Slew Rate: 200V/μs Input Noise Voltage: 3nV/√Hz C-Load™ Op Amp Drives Capacitive Loads External Compensation Pin Maximum Input Offset Voltage: 300μV Maximum Input Bias Current: 300nA Maximum Input Offset Current: 300nA Minimum Output Swing Into 500Ω: ±12V Minimum DC Gain: 100V/mV, RL = 500Ω Settling Time to 0.1%: 75ns, 10V Step Settling Time to 0.01%: 120ns, 10V Step Differential Gain: 0.4%, AV = 2, RL = 150Ω Differential Phase: 0.1°, AV = 2, RL = 150Ω

100MHz Current Feedback Amplifier Features: 100MHz Bandwidth at AV = 1 1000V/µs Slew Rate Wide Supply Range: ±5V to ±15V 1mV Input Offset Voltage 1µA Input Bias Current 5MΩ Input Resistance 75ns Settling Time to 0.1% 50mA Output Current 6mA Quiescent Current Available in 8-Lead Plastic DIP and SO Packages

Very High Speed Operational Amplifier Features: Unity-Gain Stable 45MHz Gain-Bandwidth 400V/µs Slew Rate 7V/mV DC Gain: RL = 500Ω Maximum Input Offset Voltage: 2mV ±12V Minimum Output Swing into 500Ω Wide Supply Range: ±2.5V to ±15V 7mA Supply Current 90ns Settling Time to 0.1%, 10V Step Drives All Capacitive Loads

140MHz Video Current Feedback Amplifier Features: 140MHz Bandwidth: AV = 2, RL = 150 1100V/µs Slew Rate Low Cost 30mA Output Drive Current 0.01% Differential Gain 0.01° Differential Phase High Input Impedance: 14M, 3pF Wide Supply Range: ±2V to ±15V Shutdown Mode: IS <250µA Low Supply Current: IS = 10mA Inputs Common Mode to Within 1.5V of Supplies Outputs Swing Within 0.8V of Supplies

Precision Reference Features: Ultra-Low Drift: 5ppm/°C Max Trimmed to High Accuracy: 0.05% Max Industrial Temperature Range SO Package Operates in Series or Shunt Mode Pin Compatible with AD586, AD587 Output Sinks and Sources in Series Mode Very Low Noise < 1ppm P-P (0.1Hz to 10Hz) 100% Noise Tested > 100dB Ripple Rejection

High Speed Current Mode Pulse Width Modulators Features: Low Start-Up Current: <250µA 50ns Current Sense Delay Current Mode Operation: To 500kHz Pin Compatible with UC1842 Series Undervoltage Lockout with Hysteresis No Cross-Conduction Current Trimmed Bandgap Reference 1A Totem Pole Output Trimmed Oscillator Frequency and Sink Current Active Pull-Down on Reference and Output During Undervoltage Lockout High Level Output Clamp: 18V Current Sense Leading Edge Blanking

High Speed Current Mode Pulse Width Modulators Features: Low Start-Up Current: <250µA 50ns Current Sense Delay Current Mode Operation: To 500kHz Pin Compatible with UC1842 Series Undervoltage Lockout with Hysteresis No Cross-Conduction Current Trimmed Bandgap Reference 1A Totem Pole Output Trimmed Oscillator Frequency and Sink Current Active Pull-Down on Reference and Output During Undervoltage Lockout High Level Output Clamp: 18V Current Sense Leading Edge Blanking
