EVAL-AD5413SDZ
Analog Devices Inc.The AD5413 is a single-channel, 14-bit voltage and current output, digital-to-analog converter (DAC) that operates within a power supply range from a ?33 V minimum on the AVSS pin to a +33 V maximum on the AVDD1 pin. The CHART pin enables a highway addressable remote transducer (HART?) signal to be ac-coupled on the current output.The AD5413 uses a versatile, 4-wire serial peripheral interface (SPI) that operates at clock rates of up to 50 MHz and is compatible with standard SPI, QSPI?, MICROWIRE?, digital signal processor (DSP), and microcontroller interface standards. The SPI interface has an optional SPI cyclic redundancy check (CRC). The AD5413 implements improved diagnostic features from earlier versions of similar DACs.APPLICATIONS Process control Actuator control Channel isolated analog outputs Programmable logic controller (PLC) and distributed control systems (DCS) applications HART network connectivity
EVAL-AD5422LFEBZ
Analog Devices Inc.The AD5412/AD5422 are low cost, precision, fully integrated12-/16-bit digital-to-analog converters (DAC) offering a programmable current source and programmable voltage output designed to meet the requirements of industrial process control applications.The output current range is programmable at 4 mA to 20 mA, 0 mA to 20 mA, or an overrange function of 0 mA to 24 mA.The LFCSP version of this product has a CAP2 pin so that the HART signals can be coupled onto the current output of the AD5412/AD5422.Voltage output is provided from a separate pin that can be configured to provide 0 V to 5 V, 0 V to 10 V, ?5 V, or ?10 V output ranges; an overrange of 10% is available on all ranges.Analog outputs are short and open-circuit protected and can drive capacitive loads of 1 ?F.The device operates with an AVDD power supply range from 10.8 V to 40 V. Current loop compliance voltage is 0 V to AVDD ? 2.5 V.The flexible serial interface is SPI- and MICROWIRE?-compatible and can be operated in 3-wire mode to minimize the digital isolation required in isolated applications.The device also includes a power-on-reset function, ensuring that the device powers up in a known state. The part also includes an asynchronous clear pin (CLEAR) that sets the outputs to zero-scale/midscale voltage output or the low end of the selected current range.The total output error is typically ?0.01% in current mode and ?0.01% in voltage mode.Applications Process controls Actuator controls PLC HART network connectivity (LFCSP package only)
EVAL-AD5423SDZ
Analog Devices Inc.The AD5423 is a single-channel, voltage and current output digital-to-analog converter (DAC) that operates with a power supply range from ?33 V minimum on AVSS to +33 V maximum on AVDD1. The CHART pin enables a Highway Addressable Remote Transducer? (HART) signal to be coupled on the current output. The AD5423 uses a versatile, 4-wire, serial peripheral interface (SPI) that operates at clock rates of up to 50 MHz and is compatible with standard SPI, QSPI?, MICROWIRE?, digital signal processor (DSP), and microcontroller interface standards. The interface also features an optional SPI cyclic redundancy check (CRC) and a watchdog timer (WDT). The AD5423 offers improved diagnostic features from earlier versions of similar DACs, such as an integrated, 12-bit diagnostic analog-to-digital converter (ADC).Product Highlights 16-bit performance. Range of diagnostic features. Integrated 12-bit monitoring ADC. HART compliant.Applications Process control Actuator control Channel isolated analog outputs Programmable logic controller (PLC) and distributed control systems (DCS) applications HART network connectivity
EVAL-AD5445SDZ
Analog Devices Inc.The AD5424?/?AD5433?/ AD5445 are CMOS 8-, 10-, and 12-bitcurrent output digital-to-analog converters (DACs), respectively.These devices operate from a 2.5 V to 5.5 V power supply,making them suitable for battery-powered applications andmany other applications. These DACs utilize data readback,allowing the user to read the contents of the DAC register viathe DB pins. On power-up, the internal register and latches arefilled with 0s and the DAC outputs are at zero scale.As a result of manufacturing with a CMOS submicron process,they offer excellent 4-quadrant multiplication characteristics,with large signal multiplying bandwidths of up to 10 MHz.The applied external reference input voltage (VREF) determines thefull-scale output current. An integrated feedback resistor (RFB)provides temperature tracking and full-scale voltage outputwhen combined with an external I-to-V precision amplifier.While these devices are upgrades of the AD5424 / AD5433 /AD5445 in multiplying bandwidth performance, they have alatched interface and cannot be used in transparent mode.The AD5424 is available in a small, 20-lead LFCSP and a small,16-lead TSSOP, while the AD5433 and AD5445 DACs are availablein a small, 20-lead LFCSP and a small, 20-lead TSSOP.The EVAL-AD5445SDZ evaluation board is available forevaluating DAC performance. For more information, see theUG-333 evaluation board user guide.APPLICATIONS Portable battery-powered applications Waveform generators Analog processing Instrumentation applications Programmable amplifiers and attenuators Digitally controlled calibration Programmable filters and oscillators Composite video Ultrasound Gain, offset, and voltage trimming
EVAL-AD5590EBZ
Analog Devices Inc.The AD5590 is a 16-channel input and 16-channel output analog I/O port with eight uncommitted amplifiers, operating from a single 4.5 V to 5.25 V supply. The AD5590 comprises 16 input channels multiplexed into a 1 MSPS, 12-bit successive approximation ADC with a sequencer to allow a preprogrammed selection of channels to be converted sequentially. The ADC contains a low noise, wide bandwidth track-and-hold amplifier that can handle input frequencies in excess of 1 MHz.The conversion process and data acquisition are controlled using ASYNC and the serial clock signal, allowing the device to easily interface with microprocessors or DSPs. The input signal is sampled on the falling edge of ASYNC and conversion is also initiated at this point. There are no pipeline delays associated with the ADC. By setting the relevant bits in the control register, the analog input range for the ADC can be selected to be a 0 V to VREFA input or a 0 V to 2 ? VREFA with either straight binary or twos complement output coding. The conversion time is determined by the ASCLK frequency because it is also used as the master clock to control the conversion.The DAC section of the AD5590 comprises sixteen 12-bit DACs divided into two groups of eight. Each group has an on-chip reference. The on-board references are off at power-up, allowing the use of external references. The internal references are enabled via a software write.The AD5590 incorporates a power-on reset circuit that ensures that the DAC outputs power up to 0 V and remain powered up at this level until a valid write takes place. The DAC contains a power-down feature that reduces the current consumption of the device and provides software-selectable output loads while in power-down mode for any or all DAC channels. The outputs of all DACs can be updated simultaneously using the LDAC function, with the added functionality of user-selectable DAC channels to simultaneously update. There is also an asynchronous CLR that updates all DACs to a user-programmable code: zero scale, midscale, or full scale.The AD5590 contains eight low noise, single-supply amplifiers. These amplifiers can be used for signal conditioning for the ADCs, DACs, or other independent circuitry, if required.APPLICATIONS Optical Line Cards (Monitoring and Control) Base Stations General Purpose Analog I/O Monitoring and control
EVAL-AD5593RSDZ
Analog Devices Inc.The AD5593R has eight input/output (I/O) pins, which can beindependently configured as digital-to-analog converter (DAC)outputs, analog-to-digital converter (ADC) inputs, digital outputs,or digital inputs. When an I/O pin is configured as an analogoutput, it is driven by a 12-bit DAC. The output range of theDAC is 0 V to VREF or 0 V to 2 ? VREF. When an I/O pin isconfigured as an analog input, it is connected to a 12-bit ADCvia an analog multiplexer. The input range of the ADC is 0 V toVREF or 0 V to 2 ? VREF. The I/O pins can also be configured tobe general-purpose, digital input or output (GPIO) pins. Thestate of the GPIO pins can be set or read back by accessing theGPIO write data register and GPIO read configuration registers,respectively, via an I2C write or read operation.The AD5593R has an integrated 2.5 V, 20 ppm/?C reference thatis turned off by default and an integrated temperature indicatorthat gives an indication of the die temperature. The temperaturevalue is read back as part of an ADC read sequence.The AD5593R is available in 16-lead TSSOP and LFCSP, as wellas a 16-ball WLCSP, and operates over a temperature range of?40?C to +105?C.Applications Control and monitoring General-purpose analog and digital I/O
EVAL-AD5668SDCZ
Analog Devices Inc.The AD5668 device is a low power, octal, 16-bit, buffered voltage-output DAC. All devicesoperate from a single 2.7 V to 5.5 V supply and are guaranteedmonotonic by design. The AD5668 and AD5628 are available inboth a 4 mm ? 4 mm LFCSP and a 16-lead TSSOP, while theAD5648 is available in both a 14-lead and 16-lead TSSOP.The AD5628/AD5648/AD5668 have an on-chip reference withan internal gain of 2. The AD5628-1/AD5648-1/AD5668-1 havea 1.25 V 5 ppm/?C reference, giving a full-scale output rangeof 2.5 V; the AD5628-2/AD5648-2/AD5668-2 and AD5668-3 havea 2.5 V 5 ppm/?C reference, giving a full-scale output range of5 V. The on-board reference is off at power-up, allowing the useof an external reference. The internal reference is enabled via asoftware write.The part incorporates a power-on reset circuit that ensures that theDAC output powers up to 0 V (AD5628-1/AD5648-1/AD5668-1,AD5628-2/AD5648-2/AD5668-2) or midscale (AD5668-3) andremains powered up at this level until a valid write takes place.The part contains a power-down feature that reduces the currentconsumption of the device to 400 nA at 5 V and provides software-selectable output loads while in power-down mode for any or allDAC channels. The outputs of all DACs can be updated simultaneouslyusing the LDAC function, with the added functionalityof user-selectable DAC channels to simultaneously update. Thereis also an asynchronous CLR that updates all DACs to a userprogrammablecode?zero scale, midscale, or full scale.The AD5628/AD5648/AD5668 utilize a versatile 3-wire serialinterface that operates at clock rates of up to 50 MHz and iscompatible with standard SPI?, QSPI?, MICROWIRE?, andDSP interface standards. The on-chip precision output amplifierenables rail-to-rail output swing.Product Highlights Octal, 12-/14-/16-bit DAC. On-chip 1.25 V/2.5 V, 5 ppm/?C reference. Available in 14-lead/16-lead TSSOP, 16-lead LFCSP, and 16-ball WLCSP. Power-on reset to 0 V or midscale. Power-down capability. When powered down, the DAC typically consumes 200 nA at 3 V and 400 nA at 5 V. Applications Process control Data acquisition systems Portable battery-powered instruments Digital gain and offset adjustment Programmable voltage and current sources Programmable attenuators
EVAL-AD5675RSDZ
Analog Devices Inc.The AD5671R/AD5675R are low power, octal, 12-/16-bit buffered voltage output digital-to-analog converters (DACs). They include a 2.5 V, 2 ppm/?C internal reference (enabled by default) and a gain select pin giving a full-scale output of 2.5 V (gain = 1) or 5 V (gain = 2). The devices operate from a single 2.7 V to 5.5 V supply and are guaranteed monotonic by design. The AD5671R/AD5675R are available in a 20-lead TSSOP and in a 20-lead LFCSP and incorporate a power-on reset circuit and a RSTSEL pin that ensures the DAC outputs power up to zero scale or midscale and remain there until a valid write. The AD5671R/AD5675R contain a power-down mode, reducing the current consumption to 1 ?A typical while in power-down mode.Product Highlights High Relative Accuracy (INL). AD5671R (12-bit): ?1 LSB maximum AD5675R (16-bit): ?3 LSB maximum Low Drift 2.5 V On-Chip ReferenceApplications Optical transceivers Base-station power amplifiers Process control (PLC input/output cards) Industrial automation Data acquisition systems
EVAL-ADG2128EBZ
Analog Devices Inc.The ADG2128?is an analog cross point switch with an array size of 8 ? 12. The switch array is arranged so that there are eight columns by 12 rows, for a total of 96 switch channels. The array is bidirectional, and the rows and columns can be configured as either inputs or outputs. Each of the 96 switches can be addressed and configured through the I2C compatible interface. Standard, full speed, and high speed (3.4 MHz) I2C interfaces are supported. Any simultaneous switch combination is allowed. An additional feature of the ADG2128 is that switches can be updated simultaneously, using the LDSW command. In addition, a RESET option allows all of the switch channels to be reset/off. At power-on, all switches are in the off condition. The device is packaged in a 32-lead, 5 mm ? 5 mm LFCSP_VQ.APPLICATIONS AV switching in TV Automotive infotainment AV receivers CCTV Ultrasound applications KVM switching Telecom applications Test equipment/instrumentation PBX systems
EVAL-ADG772EBZ
Analog Devices Inc.The ADG772 is a low voltage CMOS device that contains two independently selectable single-pole, double throw (SPDT) switches. It is designed as a general-purpose switch and can be used for routing both USB 1.1 and USB 2.0 signals.This device offers a data rate of 1260 Mbps, making the part suitable for high frequency data switching. Each switch conducts equally well in both directions when on and has an input signal range that extends to the supplies. The ADG772 exhibits break-before-make switching action.The ADG772 is available in a 12-lead LFCSP and a 10-lead mini LFCSP. These packages make the ADG772 the ideal solution for space-constrained applications.Product Highlights 1.6 mm ? 1.3 mm mini LFCSP package. USB 1.1 (12 Mbps) and USB 2.0 (480 Mbps) compliant. Single 2.7 V to 3.6 V operation. 1.8 V logic compatible. RoHS compliant. Applications USB 2.0 signal switching circuits Cellular phones PDAs MP3 players Battery-powered systems Headphone switching Audio and video signal routing Communications systems
EVAL-ADGM1001SDZ
Analog Devices Inc.The ADGM1001/ADGM1002/ADGM1003 is a wideband, single-pole, two-throw (SP2T) switch, fabricated using Analog Devices, Inc., micro-electromechanical system (MEMS) switch technology. This technology enables a small form factor, wide RF bandwidth, highly linear, low insertion loss switch that is operational down to 0 Hz/dc, making it an ideal solution for a wide range of RF and precision equipment switching needs. The device is packaged in a 24-lead, 5.00 mm ? 4.00 mm ? 0.90 mm, land grid array (LGA) package.An integrated control chip generates the high voltage necessary to electrostatically actuate the switch via a complementary metal-oxide semiconductor (CMOS)-/low voltage transistor-transistor logic (LVTTL)-compatible parallel interface. All switches are independently controllable.Multifunction pin names may be referenced by their relevant function only. ADGM1001/ADGM1002/ADGM1003 Key Specifications Model Bandwidth Maximum RF Power (dBm) DC Signal Range (V) Maximum DC Current (mA) ADGM1001 DC to 34 GHz 33 ?6 200 ADGM1002 DC to 20 GHz 30 ?5 150 ADGM1003? DC to 16 GHz 27 ?3 75 APPLICATIONS ATE load and probe boards DC and high speed loop back testing Relay replacements Reconfigurable filters and attenuators Military and microwave radios Cellular infrastructure: 5G mmWave Supports digital standards: PCIe Gen4/Gen5/Gen6, USB 3 and USB 4, and PAM 4
EVAL-ADGS1208SDZ
Analog Devices Inc.The ADGS1208/ADGS1209 are analog multiplexers comprisingeight single channels and four differential channels, respectively. Aserial peripheral interface (SPI) controls the switches. The SPIinterface has robust error detection features, such as cyclicredundancy check (CRC) error detection, invalid read/writeaddress detection, and SCLK count error detection.It is possible to daisy-chain multiple ADGS1208/ADGS1209devices together. Daisy-chain mode enables the configuration ofmultiple devices with a minimal amount of digital lines. TheADGS1208/ADGS1209 can also operate in burst mode todecrease the time between SPI commands.iCMOS? construction ensures ultralow power dissipation,making the devices ideally suited for portable and batterypoweredinstruments.Each switch conducts equally well in both directions when on,and each switch has an input signal range that extends to thesupplies. In the off condition, signal levels up to the suppliesare blocked. The ultralow on capacitance (CON) and exceptionally low chargeinjection (QINJ) of these multiplexers make them ideal solutionsfor data acquisition and sample-and-hold applications, wherelow glitch and fast settling are required.Product Highlights SPI interface removes the need for parallel conversion, logic traces and reduces GPIO channel count. Daisy-chain mode removes additional logic traces when multiple devices are used. CRC error detection, invalid read/write address detection, and SCLK count error detection ensures a robust digital interface. CRC and Error detection capabilities allows for the use of the ADGS1208/ADGS1209 in safety critical systems.Applications Audio and video routing Automatic test equipment Data-acquisition systems Battery-powered systems Sample-and-hold systems Communication systems
EVAL-ADGS1209SDZ
Analog Devices Inc.The ADGS1208/ADGS1209 are analog multiplexers comprisingeight single channels and four differential channels, respectively. Aserial peripheral interface (SPI) controls the switches. The SPIinterface has robust error detection features, such as cyclicredundancy check (CRC) error detection, invalid read/writeaddress detection, and SCLK count error detection.It is possible to daisy-chain multiple ADGS1208/ADGS1209devices together. Daisy-chain mode enables the configuration ofmultiple devices with a minimal amount of digital lines. TheADGS1208/ADGS1209 can also operate in burst mode todecrease the time between SPI commands.iCMOS? construction ensures ultralow power dissipation,making the devices ideally suited for portable and batterypoweredinstruments.Each switch conducts equally well in both directions when on,and each switch has an input signal range that extends to thesupplies. In the off condition, signal levels up to the suppliesare blocked. The ultralow on capacitance (CON) and exceptionally low chargeinjection (QINJ) of these multiplexers make them ideal solutionsfor data acquisition and sample-and-hold applications, wherelow glitch and fast settling are required.Product Highlights SPI interface removes the need for parallel conversion, logic traces and reduces GPIO channel count. Daisy-chain mode removes additional logic traces when multiple devices are used. CRC error detection, invalid read/write address detection, and SCLK count error detection ensures a robust digital interface. CRC and Error detection capabilities allows for the use of the ADGS1208/ADGS1209 in safety critical systems.Applications Audio and video routing Automatic test equipment Data-acquisition systems Battery-powered systems Sample-and-hold systems Communication systems
EVAL-ADIN1200FMCZ
Analog Devices Inc.The ADIN1200 is a low power, single-port, 10 Mbps and 100 Mbps Ethernet transceiver with low latency specifications designedfor industrial Ethernet applications.This design integrates an energy efficient Ethernet (EEE) physical layer device (PHY) core with all associated common analog circuitry, input and output clock buffering, management interface and subsystem registers, and media access control (MAC) interface and control logic to manage the reset, clock control and pin configuration.The ADIN1200 is available in a 5 mm ? 5 mm, 32-lead leadframe chip scale package (LFCSP) and can operate with a single3.3 V supply, assuming the use of a 3.3 V MAC interface supply.For maximum flexibility in system level design, a separate VDDIOsupply enables the management data input/output (MDIO) andMAC interface supply voltages to be configured independentlyof the other circuitry on the ADIN1200 allowing operation at1.8 V, 2.5 V, or 3.3 V. At power-up, the ADIN1200 is held inhardware reset until each of the supplies has crossed its minimumrising threshold value and the power is considered good. Brownoutprotection is provided by monitoring the supplies to detect ifone or more of them drops below a minimum falling thresholdand holding the device in hardware reset until the power suppliesreturn and satisfy the power-on-reset (POR) circuit.The MII management interface (also referred to as MDIOinterface) provides a 2-wire serial interface between a hostprocessor or MAC and the ADIN1200, allowing access tocontrol and status information in the PHY core managementregisters. The interface is compatible with both IEEE? 802.3?Standard Clause 22 and Clause 45 management framestructures.The ADIN1200 can support cable lengths up to 180 meters.Note that throughout this data sheet, multifunction pins, such as XTAL_I/CLK_IN/REF_CLK, are referred to either by the entire pin name or by a single function of the pin, for example, XTAL_I, when only that function is relevant.Applications Industrial automation Process control Factory automation Robotics and motion Control Building automation Test and Measurement Industrial internet of things (IoT)
EVAL-ADIN1300FMCZ
Analog Devices Inc.The ADIN1300 is a low power, single port, Gigabit Ethernet transceiver with low latency and power consumption specifications primarily designed for industrial Ethernet applications.This design integrates an energy efficient Ethernet (EEE) physical layer device (PHY) core with all associated common analog circuitry, input and output clock buffering, management interface and subsystem registers, and MAC interface and control logic to manage the reset and clock control and pin configuration.The ADIN1300 is available in a 6 mm ? 6 mm, 40-lead lead frame chip scale package (LFCSP). The device operates with a minimum of 2 power supplies, 0.9 V and 3.3 V, assuming the use of a 3.3 V MAC interface supply. For maximum flexibility in system level design, a separate VDDIO supply enables the management data input/output (MDIO) and MAC interface supply voltages to be configured independently of the other circuitry on the ADIN1300, allowing operation at 1.8 V, 2.5 V, or 3.3 V. At power-up, the ADIN1300 is held in hardware reset until each of the supplies has crossed its minimum rising threshold value. Brown-out protection is provided by monitoring the supplies to detect if one or more supply drops below a minimum falling threshold (see Table 17 on the datasheet), and holding the device in hardware reset until the power supplies return and satisfy the power-on reset (POR) circuit.The MII management interface (also referred to as MDIO interface) provides a 2-wire serial interface between a host processor or MAC (also known as management station (STA)) and the ADIN1300, allowing access to control and status information in the PHY core management registers. The interface is compatible with both the IEEE 802.3 Standard Clause 22 and Clause 45 management frame structures.The ADIN1300 can support cable lengths up to 150 meters at Gigabit speeds and 180 meters when operating at 100 Mbps or 10 Mbps.Applications Industrial automation Process control Factory automation Robotics/Motion Control Building automation Test and Measurement Industrial IoT
ADL5902 Arduino Shield Board with PC-Based Software GUI
Analog Devices Inc.The EVAL-ADL5902-ARDZ shield illustrates the functionality of the ADL5902, a 50 MHz to 9 GHz 65 dB TruPwr™ RMS responding RF power detector. The voltage outputs of the ADL5902 are routed to the ANALOG IN connector of the Arduino base board. This allows the RF power detector’s output voltage to be easily digitized and processed by the Arduino base board’s integrated six-channel ADC. The output of the ADL5902’s on-board temperature sensor is also routed to one of the ANALOG IN pins.
EVAL-ADM1063TQEBZ
Analog Devices Inc.The ADM1063 is a configurable supervisory/sequencing device that offers a single-chip solution for supply monitoring and sequencing in multiple supply systems. In addition to these functions, the ADM1063 integrates a 12-bit ADC that can be used to accurately read back up to 12 separate voltages.The device also provides up to 10 programmable inputs for monitoring under, over, or out-of-window faults on up to 10 supplies. In addition, 10 programmable outputs can be used as logic enables. Six of these programmable outputs can provide up to a 12 V output for driving the gate of an n-FET that can be placed in the path of a supply.ApplicationsCentral office systems Servers/routers Multivoltage system line cards DSP/FPGA supply sequencing In-circuit testing of margined supplies
EVAL-ADM1066TQEBZ
Analog Devices Inc.The ADM1066 Super Sequencer? is a configurable supervisory/ sequencing device that offers a single-chip solution for supply monitoring and sequencing in multiple-supply systems. In addition to these functions, the ADM1066 integrates a 12-bit ADC and six 8-bit voltage output DACs. These circuits can be used to implement a closed-loop margining system that enables supply adjustment by altering either the feedback node or reference of a dc-to-dc converter using the DAC outputs. Supply margining can be performed with a minimum of external components. The margining loop can be used for in-circuit testing of a board during production (for example, to verify board functionality at ?5% of nominal supplies), or it can be used dynamically to accurately control the output voltage of a dc-to-dc converter.APPLICATIONS Central office systems Servers/routers Multivoltage system line cards DSP/FPGA supply sequencing In-circuit testing of margined supplies
EVAL-ADM1169LQEBZ
Analog Devices Inc.The ADM1169 Super Sequencer? is a configurable supervisory/ sequencing device that offers a single-chip solution for supply monitoring and sequencing in multiple supply systems. In addition to these functions, the ADM1169 integrates a 12-bit ADC and four 8-bit voltage output DACs. These circuits can be used to implement a closed-loop margining system that enables supply adjustment by altering either the feedback node or reference of a dc-to-dc converter using the DAC outputs. Supply margining can be performed with a minimum of external components. The margining loop can be used for in-circuit testing of a board during production (for example, to verify board functionality at ?5% of nominal supplies), or it can be used dynamically to accurately control the output voltage of a dc-to-dc converter. The device also provides up to eight programmable inputs for monitoring undervoltage faults, overvoltage faults, or out-of-window faults on up to eight supplies. In addition, there are eight programmable outputs that can be used as logic enables. Six of these programmable outputs can also provide up to a 12 V output for driving the gate of an N-FET that can be placed in the path of a supply. The logical core of the device is a sequencing engine (SE). This state machine-based construction provides up to 63 different states. This design enables very flexible sequencing of the outputs, based on the condition of the inputs. A block of nonvolatile EEPROM is available that can be used to store user-defined information and may also be used to hold a number of fault records that are written by the sequencing engine defined by the user when a particular fault or sequence occurs. The ADM1169 is controlled via configuration data that can be programmed into an EEPROM. The entire configuration can be programmed using an intuitive GUI-based software package provided by Analog Devices, Inc.
EVAL-ADM1170EBZ
Analog Devices Inc.The ADM1170 is a Hot Swap controller that allows a board to be safely inserted and removed from a live backplane. This is achieved using a pass FET with a current control loop that monitors the input current using a sense resistor. An internal charge pump is used to enhance the gate of theexternal high side N-channel FET. When an over current condition is detected the gate voltage of the FET is reduced to limit the current flowing through the sense resistor. The ADM1170 operates with a supply voltage ranging from 2.7V to 16.5V. Using separate SENSE pins from VCC the ADM1170 allows for the hot swap of supplies ranging down to 1.6V. During an overcurrent condition the timer cap determines the amount of time the FET will remain in this condition. The ON (ON-CLR) pin is the enable input for the device and also acts as a latched fault reset for the ADM1170-2 model. The SS pin is used to control the inrush current profile by ramping up the current sense limit at a rate set by the SS capacitor. This device is available in two options: the ADM1170-1 will automatic retry for over-current fault and the ADM1170-2 will latch-off for an over-current fault. The ADM1170 is packaged in an 8-lead TSOT packageAPPLICATIONS Hot Swap Board Insertion ? Line Cards, Raid Systems Electronic Circuit Breaker Industrial High Side Switch/Circuit Breaker
