Electronic components & parts

RELAY 1NO 1NC 250VAC 20A; Contact Configuration:SPST-NO SPST-NC; Coil Voltage:24VDC; Contact Current:20A; Product Range:65 Series; Relay Mounting:Panel; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:-; Contact Material:Silver Cadmium Oxide; Coil Resistance:445ohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Approval Bodies:BSI CSA IMQ SEMKO SEV UL VDE; Case Material:Polycarbonate; Coil Current:54mA; Coil Operating Lower Percent Limit:85%; Coil Operating Upper Percent Limit:110%; Coil Voltage VDC Nom:24V; Contact Current AC Max:30A; Contact Current DC Max:20A; Contact Current Max:40A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:24V; DC Coil Power:1.3W; Dielectric Strength VDC:2000V; External Depth:42mm; External Height:36.5mm; External Length / Height:36.5mm; External Width:32.2mm; Fixing Centres:52.5mm; Nom Operating Power:1.3W; Operating Temperature Max:70°C; Operating Temperature Min:-40°C

Datasheet

90.26SMA

Part Number : 90.26SMA

Finder Plc

SOCKET DIN/SURFACE 8 PIN RELAY; Socket Mounting:DIN Rail Panel; Socket Terminals:Screw; No. of Pins:-; Current Rating:10A; Voltage Rating:250V; Product Range:-; SVHC:No SVHC (12-Jan-2017); Accessory Type:Socket; Colour:Blue; External Depth:23mm; External Length / Height:51mm; External Width:41mm; For Use With:60 Series Relay

Datasheet

55.32.8.230.0000

Part Number : 55.32.8.230.0000

Finder Plc

RELAY DPDT 250VAC 10A; Contact Configuration:DPDT; Coil Voltage:230VAC; Contact Current:10A; Product Range:55 Series; Relay Mounting:Socket; Coil Type:AC; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:17kohm; Approvals & Standards:CSA UL VDE; SVHC:No SVHC (12-Jan-2017); Approval Bodies:BEAB CSA IMQ SEMKO SEV UL VDE; Coil Current:6mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Power AC Max:5VA; Coil Power AC Min:1VA; Coil Voltage VAC Nom:230V; Contact Current AC Max:10A; Contact Current Max:20A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; DC Coil Power:1W; External Depth:33.5mm; External Height:27.5mm; External Length / Height:27.5mm; External Width:20.6mm; Nom Operating Power:1.5VA; Relay Type:Power - General Purpose

Datasheet

96.14SMA

Part Number : 96.14SMA

Finder Plc

SOCKET & CLIP PCB 4PCO RELAY; Socket Mounting:Through Hole; Socket Terminals:Quick Connect; No. of Pins:14Pins; Current Rating:12A; Voltage Rating:250V; Product Range:-; SVHC:No SVHC (12-Jan-2017); Accessory Type:Socket / Clip; Approval Category:UL and cUL Recognised; Colour:Blue; Dielectric Strength VAC:2kV; External Depth:29.5mm; External Length / Height:14.3mm; External Width:41.5mm; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Voltage Rating VAC:250V

Datasheet

56.44.9.024.0000

Part Number : 56.44.9.024.0000

Finder Plc

RELAY 4PDT 250VAC 12A; Contact Configuration:4PDT; Coil Voltage:24VDC; Contact Current:12A; Product Range:56 Series; Relay Mounting:Through Hole; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Contact Voltage VDC:-; Contact Material:Silver Nickel; Coil Resistance:490ohm; Approvals & Standards:CE CSA UL VDE; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CSA SEMKO SEV UL VDE; Coil Current:49mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VDC Nom:24V; Contact Current AC Max:12A; Contact Current DC Max:12A; Contact Current Max:20A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; DC Coil Power:1300mW; External Depth:35.5mm; External Height:27.6mm; External Length / Height:27.6mm; External Width:41mm; Lead Spacing:0.5mm; Nom Operating Power:1.3W; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Relay Type:Power; Row Pitch:2mm

Datasheet

56.42.9.012.0000

Part Number : 56.42.9.012.0000

Finder Plc

RELAY DPDT 250VAC 12A; Contact Configuration:DPDT; Coil Voltage:12VDC; Contact Current:12A; Product Range:56 Series; Relay Mounting:Through Hole; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Contact Voltage VDC:-; Contact Material:Silver Nickel; Coil Resistance:140ohm; Approvals & Standards:CE CSA UL VDE; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CSA SEMKO SEV UL VDE; Coil Current:86mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VDC Nom:12V; Contact Current AC Max:12A; Contact Current DC Max:12A; Contact Current Max:20A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; DC Coil Power:1000mW; External Depth:35.5mm; External Height:27.6mm; External Length / Height:27.6mm; External Width:20.6mm; Lead Spacing:0.5mm; Nom Operating Power:1W; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Relay Type:Power; Row Pitch:2mm

Datasheet
