Displaying 41 - 60 of 20164572

Parts

DC1780A-B

Part Number : DC1780A-B

Analog Devices Inc.
Dual 13A or Single 26A DC/DC Module (Power Module) Regulator Features: Complete Standalone Dual Output Power Supply Dual 13A or Single 26A Output Wide Input Voltage Range: 4.5V to 16V Output Voltage Range: 0.6V to 2.5V ±1.5% Maximum Total DC Output Error Multiphase Current Sharing with Multiple LTM4620s Up to 100A Differential Remote Sense Amplifier Current Mode Control/Fast Transient Response Adjustable Switching Frequency Overcurrent Foldback Protection Frequency Synchronization Internal Temperature Monitor Output Overvoltage Protection SnPb or RoHS Compliant Finish Thermally Enhanced (15mm × 15mm × 4.41mm) LGA Package and (15mm × 15mm × 5.01mm) BGA Package

DC208A-A

Part Number : DC208A-A

Analog Devices Inc.
Backup Battery Controller with Fixed Output Features: Not Recommended For New Designs. Contact Analog Devices for Potential Replacement. Complete Battery Backup System in an SO-8, 16-Pin GN or SO Package Generates Fixed Backup Voltage (3.07V/4.63V) from a Single 1.2V NiCd Button Cell Automatic Main Supply to Backup Switching Minimum 100mW Output Power Automatic Fast Recharge of NiCd Battery Programmable NiCd Trickle Charge Current Smart NiCd Charger Minimizes Recharge Time and Maximizes System Efficiency After Backup Onboard Power-Up and Push-Button Reset Generator Performs VCC Supervisory Functions Reset Assertion Guaranteed at VCC = 1V Short-Circuit Protection Thermal Limiting

ADUM6211ARSZ-RL7

Part Number : ADUM6211ARSZ-RL7

Analog Devices Inc.
Dual-Channel Isolators with Integrated DC-to-DC Converter (1/1 Channel Directionality) Features: isoPower integrated, isolated dc-to-dc converter Regulated 3.135 V to 5.25 V output Up to 150 mW output power Dual dc-to-100 Mbps (NRZ) signal isolation channels Soft start power supply 20-lead SSOP package with 5.3 mm creepage Supports SPI up to 15 MHz High temperature operation: 105°C High common-mode transient immunity: >25 kV/μs Safety and regulatory approvals UL recognition 3750 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A VDE certificate of conformity DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 849 V peak

ADUM6421ABRNZ3

Part Number : ADUM6421ABRNZ3

Analog Devices Inc.
Quad-Channel Isolators with Integrated DC-to-DC Converter (3:1 directionality) Features: isoPower integrated, isolated dc-to-dc converter 100 mA output supply AEC-Q100 qualified for automotive applications ADuM6421AW (ADuM6423AW pending) Meets CISPR 32/EN55032 Class B emission limits up to 5 Mbps at a full load on a 2-layer PCB Quad dc to 100 Mbps signal isolation channels 28-lead, fine pitch, SOIC with 8.3 mm minimum creepage High temperature operation: 125°C maximum High common-mode transient immunity: 100 kV/μs Safety and regulatory approvals (pending) UL recognition (pending) 5000 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE V 0884-11 certificate of conformity (pending) VIORM = 566 V peak CQC certification per GB4943.1-2011 (pending)

DC1130A

Part Number : DC1130A

Analog Devices Inc.
3A, DC/DC Converter with Dual Rail-to-Rail Current Sense Features: Dual 100mV Rail-to-Rail Current Sense Amplifiers Wide Input Voltage Range: 2.5V to 25V 3A, 42V Internal Switch High Efficiency Power Conversion: Up to 93% Drives LEDs in Boost, Buck-Boost or Buck Mode Frequency Set by External Resistor: 200kHz to 3.5MHz Programmable Soft-Start Low VCESAT Switch: 0.3V at 2.5A Capable of Positive and Negative Output Voltages (Boost, Inverting, SEPIC, Flyback) Available in Thermally Enhanced 20-Lead (4mm × 4mm) QFN and 20-Lead TSSOP Packages

DC1144A-B

Part Number : DC1144A-B

Analog Devices Inc.
Boost/Inverting DC/DC Converter with 2A Switch, Soft-Start, and Synchronization Features: 2A Internal Power Switch Adjustable Switching Frequency Single Feedback Resistor Sets VOUT Synchronizable to External Clock High Gain SHDN Pin Accepts Slowly Varying Input Signals Wide Input Voltage Range: 2.5V to 32V Low VCESAT Switch: 300mV at 1.5A (Typical) Integrated Soft-Start Function Easily Configurable as a Boost or Inverting Converter User Configurable Undervoltage Lockout (UVLO) Tiny 8-Lead 3mm × 3mm DFN and 8-Lead MSOP Packages

DC1370A-H

Part Number : DC1370A-H

Analog Devices Inc.
12-Bit, 105Msps Ultralow Power 1.8V ADCs Features: 70.8dB SNR 85dB SFDR Low Power: 124mW/103mW/87mW Single 1.8V Supply CMOS, DDR CMOS or DDR LVDS Outputs Selectable Input Ranges: 1VP-P to 2VP-P 800MHz Full-Power Bandwidth S/H Optional Data Output Randomizer Optional Clock Duty Cycle Stabilizer Shutdown and Nap Modes Serial SPI Port for Configuration Pin Compatible 14-Bit and 12-Bit Versions 40-Pin (6mm × 6mm) QFN Package

ADUM1401WTRWZ-RL

Part Number : ADUM1401WTRWZ-RL

Analog Devices Inc.
Quad-Channel Digital Isolator (3/1 Channel Directionality) Features: Qualified for automotive applications Low power operation Bidirectional communication 3 V/5 V level translation High temperature operation: 125°C High data rate: dc to 90 Mbps (NRZ) Precise timing characteristics High common-mode transient immunity: >25 kV/μs See data sheet for additional features

ADCMP609BRMZ-REEL

Part Number : ADCMP609BRMZ-REEL

Analog Devices Inc.
Rail-to-Rail, Fast, Low Power 2.5 V to 5.5 V, Single-Supply TTL/CMOS Comparator Features: Fully specified rail-to-rail at VCC = 2.5 V to 5.5 V Input common-mode voltage from −0.2 V to VCC + 0.2 V Low glitch TTL-/CMOS-compatible output stage 40 ns propagation delay Low power 1 mW at 2.5 V Shutdown pin Programmable hysteresis Power supply rejection > 60 dB −40°C to +125°C operation

ADCMP609BRMZ-REEL7

Part Number : ADCMP609BRMZ-REEL7

Analog Devices Inc.
Rail-to-Rail, Fast, Low Power 2.5 V to 5.5 V, Single-Supply TTL/CMOS Comparator Features: Fully specified rail-to-rail at VCC = 2.5 V to 5.5 V Input common-mode voltage from −0.2 V to VCC + 0.2 V Low glitch TTL-/CMOS-compatible output stage 40 ns propagation delay Low power 1 mW at 2.5 V Shutdown pin Programmable hysteresis Power supply rejection > 60 dB −40°C to +125°C operation

ADF5904WCCPZ-RL7

Part Number : ADF5904WCCPZ-RL7

Analog Devices Inc.
4-Channel, 24 GHz, Receiver Downconverter Features: Integrated baluns for single-ended receiver (Rx) inputs and local oscillator (LO) input Rx channel gain: 22 dB Noise figure (NF): 10 dB P1dB: −10 dBm LO input range: −8 dBm to +5 dBm Rx to IF isolation: 30 dB RF signal bandwidth: 250 MHz Rx output impedance: 900 Ω differential LO input buffer: 24 GHz RF and LO S11 at 50 Ω: −5 dB Temperature sensor with analog output: ±5° Electrostatic discharge (ESD) performance Human body model (HBM): 2000 V Charged device model (CDM): 500 V Qualified for automotive applications

ADP150AUJZ-2.0-R7

Part Number : ADP150AUJZ-2.0-R7

Analog Devices Inc.
Ultralow Noise, 150 mA CMOS Linear Regulator Features: Chinese data sheet available Ultralow noise: 9 μV rms, independent of VOUT No additional noise bypass capacitor required Stable with 1 μF ceramic input and output capacitors Maximum output current: 150 mA Input voltage range: 2.2 V to 5.5 V Low quiescent current IGND = 10 μA with zero load Low shutdown current: <1 μA Low dropout voltage: 105 mV at 150 mA load Initial output voltage accuracy: ±1% Up to 14 fixed output voltage options: 1.8 V to 3.3 V PSRR performance of 70 dB at 10 kHz Current limit and thermal overload protection Logic-controlled enable 5-lead TSOT package 4-ball, 0.8 mm × 0.8 mm, 0.4 mm pitch WLCSP AEC-Q100 qualified for automotive applications

ADM2867EBRNZ-RL7

Part Number : ADM2867EBRNZ-RL7

Analog Devices Inc.
5.7 kV RMS Signal and Power Isolated RS-485 Transceiver with 15 kV IEC ESD Features: 5.7 kV rms isolated RS-485/RS-422 transceiver Low radiated emissions, integrated, isolated dc-to-dc converter Passes EN 55032 Class B with margin on a 2-layer PCB Cable invert smart feature Correct reversed cable connection on A, B, Y, and Z bus pins while maintaining full receiver fail-safe feature ESD protection on RS-485 A, B, Y, and Z pins 12 kV IEC61000-4-2 contact discharge 15 kV IEC61000-4-2 air discharge High speed 25 Mbps data rate (ADM2865E/ADM2867E) Low speed 500 kbps data rate for EMI control (ADM2861E/ADM2863E) Flexible power supplies Input VCC supply of 3 V to 5.5 V Logic VIO supply of 1.7 V to 5.5 V VSEL pin to select VISO supply of 5 V (VCC > 4.5 V) or 3.3 V PROFIBUS compliant for 5 V VISO Wide operating temperature range: −40°C to +105°C High common-mode transient immunity: 250 kV/μs Short-circuit, open-circuit, and floating input receiver fail-safe Supports 192 bus nodes (72 k receiver input impedance) Full hot swap support (glitch free power-up/power-down) Safety and regulatory approvals (pending) CSA Component Acceptance Notice 5A, DIN V VDE V 0884-11, UL 1577, CQC11-471543-2012, IEC 61010-1 Complies with ANSI/TIA/EIA-485-A-98 and ISO 8482:1987(E) 28-lead, fine pitch SOIC_W package (10.15 mm 10.05 mm) with >8.0 mm creepage and clearance

LTM4620AIY

Part Number : LTM4620AIY

Analog Devices Inc.
Non-Isolated PoL Module DC DC Converter 2 Output 0.6 ~ 5.3V 0.6 ~ 5.3V - 13A, 13A 4.5V - 16V Input

LT1213CS8

Part Number : LT1213CS8

Analog Devices Inc.
General Purpose Amplifier 2 Circuit 8-SO

LTC1069-6IS8

Part Number : LTC1069-6IS8

Analog Devices Inc.
Elliptic, Low Pass Switched Capacitor Filter IC Elliptic, Low Pass Switched Capacitor 8th Order 14kHz/20kHz 8-SO

LTM8057IY

Part Number : LTM8057IY

Analog Devices Inc.
Isolated Module DC DC Converter 1 Output 2.5 ~ 12V 440mA 3.1V - 31V Input

AD5664RBRMZ-5REEL7

Part Number : AD5664RBRMZ-5REEL7

Analog Devices Inc.
Quad, 16-Bit nanoDAC with 5ppm/C On-Chip Reference Features: Low power, smallest pin-compatible, quad nanoDACs  AD5664R: 16 bits AD5644R: 14 bits AD5624R: 12 bits User selectable external or internal reference External reference default On-chip 1.25 V/2.5 V, 5 ppm/°C reference 10-lead MSOP; 10-lead, 3 mm × 3 mm LFCSP_WD; and 12-ball, 1.665 mm × 2.245 mm WLCSP 2.7 V to 5.5 V power supply Guaranteed monotonic by design Power-on reset to zero scale Per channel power-down Serial interface, up to 50 MHz

AD22293Z-RL7

Part Number : AD22293Z-RL7

Analog Devices Inc.
Precision 1.7 g, 5 g, 18 g Dual-Axis iMEMS Accelerometer Features: High performance dual-axis accelerometer on a single IC chip 5 mm × 5 mm × 2 mm LCC package 1 mg resolution at 60 Hz Low power: 700 µA at VS = 5 V (typical) High zero g bias stability High sensitivity accuracy –40°C to +125°C temperature range X and Y axes aligned to within 0.1° (typical) BW adjustment with a single capacitor Single-supply operation 3500 g shock survival RoHS-compliant Compatible with Sn/Pb- and Pb-free solder processes

AD2S83IPZ-REEL

Part Number : AD2S83IPZ-REEL

Analog Devices Inc.
Variable Resolution Resolver-to-Digital Converter Features: Tracking R/D Converter High Accuracy Velocity Output High Max Tracking Rate 1040 RPS (10 Bits) 44-Lead PLCC Package 10-, 12-, 14-, or 16-Bit Resolution Set by User Ratiometric Conversion Stabilized Velocity Reference Dynamic Performance Set by User Industrial Temperature Range
