Reverse Polarity SMA PCB THT Jack Straig. Gender: Female. Mounting Type: Through Hole. Body Orientation: Straight. Termination Method: Solder. Bulkhead: Yes. Operating Frequency: 18GHz. Body Plating: Gold over Nickel. Minimum Operating Temperature: -65°C. Maximum Operating Temperature: +165°C. Mating Type: Threaded. Series: WR-RPSMA. Size: Standard. Contact Material: Brass. Contact Plating: Gold over Nickel. MPN: 63012042124504, Wurth Elektronik

Wurth Elektronik 4012/4020 WE-LHMI SMD Power Inductor Kit. Maximum Operating Temperature: +125°C. Minimum Operating Temperature: -40°C. MPN: 7443732

Wurth Elektronik 0201 WE-MK Multilayer Ceramic SMD Inductor Kit. MPN: 744785

Wurth Elektronik 3583 Series 3.81mm Pitch Horizontal Pluggable Terminal Block, Plug, Plug-In, 6 Way. Gender: Female. Termination Method: IDC. Current Rating: 5A. Colour: Green, Orange. Voltage Rating: 300 V ac. Material: Nylon 66. Depth: 26.8mm. Width: 12.9mm. MPN: 691358310006

Wurth Elektronik REDCUBE Power Element, 50A, Press Fit, M3, Vertical. Contact Plating: Tin. Contact Material: Copper Zinc Alloy. Terminal Type: Bush Terminal. MPN: 7466103R

SMA PCB End Launch Jack Round Post Rear. Gender: Female. Mounting Type: Rear Mount. Body Orientation: Straight. Termination Method: Solder. Bulkhead: Yes. Operating Frequency: 18GHz. Body Plating: Gold over Nickel. Minimum Operating Temperature: -65°C. Maximum Operating Temperature: +165°C. Mating Type: Threaded. Series: WR-SMA. Size: Standard. Contact Material: Beryllium Copper. Contact Plating: Gold over Nickel. MPN: 60312242114510, Wurth Elektronik

Reverse Polarity SMA PCB End Launch Jack. Gender: Female. Mounting Type: Rear Mount. Body Orientation: Straight. Termination Method: Solder. Bulkhead: Yes. Operating Frequency: 18GHz. Body Plating: Gold over Nickel. Minimum Operating Temperature: -65°C. Maximum Operating Temperature: +165°C. Mating Type: Threaded. Series: WR-RPSMA. Size: Standard. Contact Material: Brass. Contact Plating: Gold over Nickel. MPN: 63012242124506, Wurth Elektronik

Wurth Elektronik Aluminium Electrolytic Capacitor 220μF 25V dc 8mm WCAP-ATG5 Series Aluminium, Through Hole. Capacitance: 220µF. Dimensions: 8 (Dia.) x 11.5mm. Height: 11.5mm. Maximum Operating Temperature: +105°C. Minimum Operating Temperature: -40°C. Lead Pitch: 3.5mm. Lead Diameter: 0.5mm. Lifetime: 2000h. Construction: Cylindrical. Ripple Current: 235mA. Leakage Current: 55 μA. MPN: 860020474012

Wurth Elektronik Aluminium Electrolytic Capacitor 3900μF 25V dc 16mm WCAP-ATG5 Series Aluminium, Through Hole. Capacitance: 3900µF. Dimensions: 16 (Dia.) x 31.5mm. Height: 31.5mm. Minimum Operating Temperature: -40°C. Maximum Operating Temperature: +105°C. Lead Pitch: 7.5mm. Lead Diameter: 0.8mm. Lifetime: 2000h. Construction: Cylindrical. Ripple Current: 1.67A. Leakage Current: 975 μA. MPN: 860020480025

Wurth Elektronik Aluminium Electrolytic Capacitor 68μF 35V dc 8mm WCAP-AT1H Series Aluminium, Through Hole Electrolytic. Capacitance: 68µF. Dimensions: 8 (Dia.) x 11.5mm. Height: 11.5mm. Maximum Operating Temperature: +105°C. Minimum Operating Temperature: -40°C. Lead Pitch: 3.5mm. Lead Diameter: 0.5mm. Lifetime: 8000h. Construction: Cylindrical. Ripple Current: 270mA. Leakage Current: 23.8 μA. MPN: 860240574005

Wurth Elektronik Aluminium Electrolytic Capacitor 220μF 25V dc 8mm WCAP-ATUL Series Aluminium, Through Hole. Capacitance: 220µF. Dimensions: 8 (Dia.) x 11.5mm. Height: 11.5mm. Minimum Operating Temperature: -40°C. Maximum Operating Temperature: +105°C. Lead Pitch: 3.5mm. Lead Diameter: 0.5mm. Lifetime: 7000h. Construction: Cylindrical. Ripple Current: 590mA. Leakage Current: 55 μA. MPN: 860040474004

Wurth Elektronik Aluminium Electrolytic Capacitor 680μF 35V dc 13mm WCAP-ATUL Series Aluminium, Through Hole. Capacitance: 680µF. Dimensions: 13 (Dia.) x 20mm. Height: 20mm. Minimum Operating Temperature: -40°C. Maximum Operating Temperature: +105°C. Lead Pitch: 5mm. Lead Diameter: 0.6mm. Lifetime: 10000h. Construction: Cylindrical. Ripple Current: 2.1A. Leakage Current: 238 μA. MPN: 860040578013

Wurth Elektronik Aluminium Electrolytic Capacitor 4700μF 16V dc 16mm WCAP-ATLI Series Aluminium, Through Hole. Capacitance: 4700µF. Dimensions: 16 (Dia.) x 31.5mm. Height: 31.5mm. Minimum Operating Temperature: -55°C. Maximum Operating Temperature: +105°C. Lead Pitch: 7.5mm. Lead Diameter: 0.8mm. Construction: Cylindrical. Lifetime: 5000h. Ripple Current: 3.77A. Leakage Current: 752 μA. MPN: 860080380028

Wurth Elektronik Aluminium Electrolytic Capacitor 39μF 25V dc 5mm WCAP-ATLI Series Aluminium, Through Hole Electrolytic. Capacitance: 39µF. Dimensions: 5 (Dia.) x 11mm. Height: 11mm. Minimum Operating Temperature: -55°C. Maximum Operating Temperature: +105°C. Lead Pitch: 2mm. Lead Diameter: 0.5mm. Construction: Cylindrical. Lifetime: 2000h. Ripple Current: 210mA. Leakage Current: 9.75 μA. MPN: 860080472001

Wurth Elektronik Aluminium Electrolytic Capacitor 56μF 25V dc 5mm WCAP-ATLI Series Aluminium, Through Hole Electrolytic. Capacitance: 56µF. Dimensions: 5 (Dia.) x 11mm. Height: 11mm. Minimum Operating Temperature: -55°C. Maximum Operating Temperature: +105°C. Lead Pitch: 2mm. Lead Diameter: 0.5mm. Lifetime: 2000h. Construction: Cylindrical. Ripple Current: 256mA. Leakage Current: 14 μA. MPN: 860080472003

Wurth Elektronik Aluminium Electrolytic Capacitor 4.7μF 50V dc 5mm WCAP-ATLL Series Aluminium, Through Hole. Capacitance: 4.7µF. Dimensions: 5 (Dia.) x 11mm. Height: 11mm. Minimum Operating Temperature: -55°C. Maximum Operating Temperature: +105°C. Lead Pitch: 2mm. Lead Diameter: 0.5mm. Lifetime: 4000h. Construction: Cylindrical. Ripple Current: 66mA. Leakage Current: 3 μA. MPN: 860160672005

Wurth Elektronik Aluminium Electrolytic Capacitor 33μF 50V dc 6.3mm WCAP-ATLL Series Aluminium, Through Hole. Capacitance: 33µF. Dimensions: 6.3 (Dia.) x 11mm. Height: 11mm. Minimum Operating Temperature: -55°C. Maximum Operating Temperature: +105°C. Lead Pitch: 2.5mm. Lead Diameter: 0.5mm. Lifetime: 3000h. Construction: Cylindrical. Ripple Current: 282mA. Leakage Current: 16.5 μA. MPN: 860160673013

Wurth Elektronik Aluminium Electrolytic Capacitor 100μF 10V dc 6.3mm WCAP-ATET Series Aluminium, Through Hole. Capacitance: 100µF. Dimensions: 6.3 (Dia.) x 11mm. Height: 11mm. Minimum Operating Temperature: -40°C. Maximum Operating Temperature: +125°C. Lead Pitch: 2.5mm. Lead Diameter: 0.5mm. Lifetime: 1000h. Construction: Cylindrical. Ripple Current: 145mA. Leakage Current: 10 μA. MPN: 860130273002

Wurth Elektronik Aluminium Electrolytic Capacitor 330μF 16V dc 10mm WCAP-ATET Series Aluminium, Through Hole. Capacitance: 330µF. Dimensions: 10 (Dia.) x 12.5mm. Height: 12.5mm. Minimum Operating Temperature: -40°C. Maximum Operating Temperature: +125°C. Lead Pitch: 5mm. Lead Diameter: 0.6mm. Lifetime: 2000h. Construction: Cylindrical. Ripple Current: 470mA. Leakage Current: 52.8 μA. MPN: 860130375006

Wurth Elektronik Aluminium Electrolytic Capacitor 100μF 25V dc 10mm WCAP-ATET Series Aluminium, Through Hole. Capacitance: 100µF. Dimensions: 10 (Dia.) x 12.5mm. Height: 12.5mm. Minimum Operating Temperature: -40°C. Maximum Operating Temperature: +125°C. Lead Pitch: 5mm. Lead Diameter: 0.6mm. Lifetime: 2000h. Construction: Cylindrical. Ripple Current: 250mA. Leakage Current: 25 μA. MPN: 860130475005
