TRIAC 16A 800V TO-220AB; Peak Repetitive Off-State Voltage Vdrm:800V; On State RMS Current IT(rms):16A; Triac Case Style:TO-220AB; Gate Trigger Current Max (QI) Igt:25mA; Gate Trigger Voltage Max Vgt:1.5V; Peak Gate Power:5W; Peak Non Rep Surge Current Itsm 50Hz:170A; Holding Current Max Ih:45mA; No. of Pins:3Pins; Operating Temperature Max:125°C; Product Range:BT139 Series

TRIAC 16A 800V TO-220F; Peak Repetitive Off-State Voltage Vdrm:800V; On State RMS Current IT(rms):16A; Triac Case Style:TO-220F; Gate Trigger Current Max (QI) Igt:70mA; Gate Trigger Voltage Max Vgt:1V; Peak Gate Power:5W; Peak Non Rep Surge Current Itsm 50Hz:170A; Holding Current Max Ih:45mA; No. of Pins:3Pins; Operating Temperature Max:125°C; Product Range:BT139X Series

SCR THYRISTOR 25A 800V TO-220AB; Peak Repetitive Off-State Voltage Vdrm:800V; Gate Trigger Current Max Igt:35mA; Current It av:16A; On State RMS Current IT(rms):25A; Thyristor Case Style:TO-220AB; No. of Pins:3Pins; Peak Non Rep Surge Current Itsm 50Hz:330A; Holding Current Max Ih:60mA; Gate Trigger Voltage Max Vgt:1V; Operating Temperature Max:125°C; Product Range:BT145 Series

SCR THYRISTOR 12A 650V TO-252; Peak Repetitive Off-State Voltage Vdrm:650V; Gate Trigger Current Max Igt:15mA; Current It av:7.5A; On State RMS Current IT(rms):12A; Thyristor Case Style:TO-252; No. of Pins:3Pins; Peak Non Rep Surge Current Itsm 50Hz:132A; Holding Current Max Ih:20mA; Gate Trigger Voltage Max Vgt:1.5V; Operating Temperature Max:125°C; Product Range:BT151S Series; MSL:MSL 1 - Unlimited

SCR THYRISTOR 1A 600V SOT-223; Peak Repetitive Off-State Voltage Vdrm:600V; Gate Trigger Current Max Igt:200µA; Current It av:630mA; On State RMS Current IT(rms):1A; Thyristor Case Style:SOT-223; No. of Pins:4Pins; Peak Non Rep Surge Current Itsm 50Hz:9A; Holding Current Max Ih:5mA; Gate Trigger Voltage Max Vgt:800mV; Operating Temperature Max:125°C; Product Range:BT168W Series; MSL:MSL 1 - Unlimited

SCR THYRISTOR 5A 800V TO-220AB; Peak Repetitive Off-State Voltage Vdrm:800V; Gate Trigger Current Max Igt:200µA; Current It av:5A; On State RMS Current IT(rms):8A; Thyristor Case Style:TO-220AB; No. of Pins:3Pins; Peak Non Rep Surge Current Itsm 50Hz:82A; Holding Current Max Ih:6mA; Gate Trigger Voltage Max Vgt:1.5V; Operating Temperature Max:125°C; Product Range:BT258 Series

TRIAC 8A 800V TO-220AB; Peak Repetitive Off-State Voltage Vdrm:800V; On State RMS Current IT(rms):8A; Triac Case Style:TO-220AB; Gate Trigger Current Max (QI) Igt:50mA; Gate Trigger Voltage Max Vgt:1V; Peak Gate Power:5W; Peak Non Rep Surge Current Itsm 50Hz:71A; Holding Current Max Ih:60mA; No. of Pins:3Pins; Operating Temperature Max:125°C; Product Range:BTA208 Series

TRIAC 16A 600V TO-220AB; Peak Repetitive Off-State Voltage Vdrm:600V; On State RMS Current IT(rms):16A; Triac Case Style:TO-220AB; Gate Trigger Current Max (QI) Igt:10mA; Gate Trigger Voltage Max Vgt:1V; Peak Gate Power:5W; Peak Non Rep Surge Current Itsm 50Hz:150A; Holding Current Max Ih:15mA; No. of Pins:3Pins; Operating Temperature Max:150°C; Product Range:-

RECTIFIER SINGLE 9A 400V TO-220AC; Repetitive Reverse Voltage Vrrm Max:400V; Forward Current If(AV):9A; Diode Configuration:Single; Forward Voltage VF Max:1.25V; Reverse Recovery Time trr Max:60ns; Forward Surge Current Ifsm Max:110A; Operating Temperature Max:150°C; Diode Case Style:TO-220AC; No. of Pins:2 Pin; Product Range:BYV29 Series; Automotive Qualification Standard:-

RECTIFIER DUAL 30A 200V TO-220AB; Repetitive Reverse Voltage Vrrm Max:200V; Forward Current If(AV):-; Diode Configuration:Dual Common Cathode; Forward Voltage VF Max:1.2V; Reverse Recovery Time trr Max:28ns; Forward Surge Current Ifsm Max:160A; Operating Temperature Max:150°C; Diode Case Style:TO-220AB; No. of Pins:3 Pin; Product Range:BYV42E Series; Automotive Qualification Standard:-

RECTIFIER SINGLE 8A 200V TO-252; Repetitive Reverse Voltage Vrrm Max:200V; Forward Current If(AV):8A; Diode Configuration:Single; Forward Voltage VF Max:1.05V; Reverse Recovery Time trr Max:25ns; Forward Surge Current Ifsm Max:88A; Operating Temperature Max:150°C; Diode Case Style:TO-252; No. of Pins:2 Pin; Product Range:BYW29ED Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited

Triacs RAIL 3Q TRIAC

WeEn Semiconductors BYC30X-600P/TO-220F/STANDARD M

Rectifiers BYT79X-600/TO-220F/STANDARD MA

TRIAC 4Q 1A 600V SOT223; Peak Repetitive Off-State Voltage Vdrm:600V; On State RMS Current IT(rms):1A; Triac Case Style:SOT-223; Gate Trigger Current Max (QI) Igt:5mA; Gate Trigger Voltage Max Vgt:1.3V; Peak Gate Power:2W; Peak Non Rep Surge Current Itsm 50Hz:13.8A; Holding Current Max Ih:7mA; No. of Pins:4Pins; Operating Temperature Max:125°C; Product Range:-; MSL:-; SVHC:No SVHC (17-Dec-2015); Holding Current Max Ih:7mA; Thyristor Case:SOT-223

DIODE ULTRAFAST 2X5A 200V TO220AC; Repetitive Reverse Voltage Vrrm Max:200V; Forward Current If(AV):10A; Diode Configuration:Dual Common Cathode; Forward Voltage VF Max:1.25V; Reverse Recovery Time trr Max:25ns; Forward Surge Current Ifsm Max:55A; Operating Temperature Max:150°C; Diode Case Style:TO-220AB; No. of Pins:3 Pin; Product Range:BYQ28 Series; Automotive Qualification Standard:-; SVHC:No SVHC (17-Dec-2015); Diode Type:Ultrafast Recovery; No. of Pins:3Pins

TRIAC 4Q 1A 600V TO92; Peak Repetitive Off-State Voltage Vdrm:600V; On State RMS Current IT(rms):1A; Triac Case Style:TO-92; Gate Trigger Current Max (QI) Igt:3mA; Gate Trigger Voltage Max Vgt:1.3V; Peak Gate Power:2W; Peak Non Rep Surge Current Itsm 50Hz:13.8A; Holding Current Max Ih:7mA; No. of Pins:3Pins; Operating Temperature Max:125°C; Product Range:-; MSL:-; SVHC:No SVHC (17-Dec-2015); Holding Current Max Ih:7mA; Thyristor Case:TO-92

DIODE ULTRAFAST 2X10A; Repetitive Reverse Voltage Vrrm Max:150V; Forward Current If(AV):10A; Diode Configuration:Dual Common Cathode; Forward Voltage VF Max:1.15V; Reverse Recovery Time trr Max:25ns; Forward Surge Current Ifsm Max:125A; Operating Temperature Max:150°C; Diode Case Style:TO-220AB; No. of Pins:3 Pin; Product Range:BYV32 Series; Automotive Qualification Standard:-; SVHC:No SVHC (17-Dec-2015); Current Ifsm:125A; Diode Type:Soft Recovery; Forward Current If Max:8A; Forward Voltage:850mV; Junction Temperature Tj Max:150°C; No. of Pins:3Pins; Reverse Recovery Time trr Typ:20ns; Termination Type:Through Hole

THYRISTOR 13A 400V TO-220; Peak Repetitive Off-State Voltage Vdrm:450V; Gate Trigger Current Max Igt:32mA; Current It av:13A; On State RMS Current IT(rms):20A; Thyristor Case Style:TO-220AB; No. of Pins:3Pins; Peak Non Rep Surge Current Itsm 50Hz:200A; Holding Current Max Ih:60mA; Gate Trigger Voltage Max Vgt:2.5V; Operating Temperature Max:150°C; Product Range:-; MSL:-; SVHC:No SVHC (17-Dec-2015); Current Itsm:200A; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +150°C; Repetitive Reverse Voltage Vrrm Max:450V; Termination Type:Through Hole; Thyristor Type:Thyristor

Triacs RAIL 3Q TRIAC
