TRIAC AC 0.8A 600V SOT223; Peak Repetitive Off-State Voltage Vdrm:600V; On State RMS Current IT(rms):800mA; Triac Case Style:SOT-223; Gate Trigger Current Max (QI) Igt:5mA; Gate Trigger Voltage Max Vgt:900mV; Peak Gate Power:-; Peak Non Rep Surge Current Itsm 50Hz:8.8A; Holding Current Max Ih:20mA; No. of Pins:4Pins; Product Range:-; MSL:-; SVHC:No SVHC (17-Dec-2015); Holding Current Max Ih:20mA; Thyristor Case:SOT-223

TRIAC 4Q 12A 800V TO220AB; Peak Repetitive Off-State Voltage Vdrm:800V; On State RMS Current IT(rms):12A; Triac Case Style:TO-220AB; Gate Trigger Current Max (QI) Igt:25mA; Gate Trigger Voltage Max Vgt:1.5V; Peak Gate Power:5W; Peak Non Rep Surge Current Itsm 50Hz:105A; Holding Current Max Ih:30mA; No. of Pins:3Pins; Product Range:-; MSL:-; SVHC:No SVHC (17-Dec-2015); Holding Current Max Ih:30mA; Thyristor Case:TO-220AB

TRIAC 4Q 12A 600V TO220F; Peak Repetitive Off-State Voltage Vdrm:600V; On State RMS Current IT(rms):16A; Triac Case Style:TO-220F; Gate Trigger Current Max (QI) Igt:70mA; Gate Trigger Voltage Max Vgt:1.5V; Peak Gate Power:5W; Peak Non Rep Surge Current Itsm 50Hz:170A; Holding Current Max Ih:45mA; No. of Pins:3Pins; Product Range:-; MSL:-; SVHC:No SVHC (17-Dec-2015); Holding Current Max Ih:45mA; Thyristor Case:TO-220F

TRIAC HICOM 1A 800V TO92; Peak Repetitive Off-State Voltage Vdrm:800V; On State RMS Current IT(rms):1A; Triac Case Style:TO-92; Gate Trigger Current Max (QI) Igt:10mA; Gate Trigger Voltage Max Vgt:1.5V; Peak Gate Power:5W; Peak Non Rep Surge Current Itsm 50Hz:13.7A; Holding Current Max Ih:12mA; No. of Pins:3Pins; Operating Temperature Max:125°C; Product Range:-; MSL:-; SVHC:No SVHC (17-Dec-2015); Holding Current Max Ih:12mA; Thyristor Case:TO-92

TRIAC 4Q 1A 600V TO92; Peak Repetitive Off-State Voltage Vdrm:600V; On State RMS Current IT(rms):1A; Triac Case Style:TO-92; Gate Trigger Current Max (QI) Igt:3mA; Gate Trigger Voltage Max Vgt:1.3V; Peak Gate Power:2W; Peak Non Rep Surge Current Itsm 50Hz:13.8A; Holding Current Max Ih:7mA; No. of Pins:3Pins; Product Range:-; MSL:-; SVHC:No SVHC (17-Dec-2015); Holding Current Max Ih:7mA; Thyristor Case:TO-92

TRANSISTOR NPN 4A 1050V DPAK; Transistor Polarity:NPN; Collector Emitter Voltage V(br)ceo:400V; Transition Frequency ft:-; Power Dissipation Pd:80W; DC Collector Current:4A; DC Current Gain hFE:66hFE; Transistor Case Style:TO-252; No. of Pins:3Pins; Operating Temperature Max:150°C; Product Range:-; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (17-Dec-2015)

DIODE HYPERFAST 5A 500V TO220F; Repetitive Reverse Voltage Vrrm Max:500V; Forward Current If(AV):5A; Diode Configuration:Single; Forward Voltage VF Max:2V; Reverse Recovery Time trr Max:30ns; Forward Surge Current Ifsm Max:44A; Operating Temperature Max:150°C; Diode Case Style:TO-220F; No. of Pins:2 Pin; Packaging:Each; Product Range:BYC5D Series; Automotive Qualification Standard:-; SVHC:No SVHC (17-Dec-2015); Diode Type:Ultrafast Recovery; No. of Pins:2Pins

DIODE ULTRAFAST 5A 600V D2PAK; Repetitive Reverse Voltage Vrrm Max:600V; Forward Current If(AV):5A; Diode Configuration:Single; Forward Voltage VF Max:1.9V; Reverse Recovery Time trr Max:35ns; Forward Surge Current Ifsm Max:66A; Operating Temperature Max:150°C; Diode Case Style:TO-263; No. of Pins:3 Pin; Packaging:Each; Product Range:BYV25 Series; Automotive Qualification Standard:-; SVHC:No SVHC (17-Dec-2015); Diode Type:Ultrafast Recovery; MSL:MSL 1 - Unlimited; No. of Pins:3Pins

DIODE ULTRAFAST 5A 600V DPAK; Repetitive Reverse Voltage Vrrm Max:600V; Forward Current If(AV):5A; Diode Configuration:Single; Forward Voltage VF Max:1.9V; Reverse Recovery Time trr Max:35ns; Forward Surge Current Ifsm Max:66A; Operating Temperature Max:150°C; Diode Case Style:TO-252; No. of Pins:3 Pin; Packaging:Each; Product Range:BYV25 Series; Automotive Qualification Standard:-; SVHC:No SVHC (17-Dec-2015); Diode Type:Ultrafast Recovery; MSL:MSL 1 - Unlimited; No. of Pins:3Pins

TRIAC 1A 600V SOT-223; Peak Repetitive Off-State Voltage Vdrm:600V; On State RMS Current IT(rms):1A; Triac Case Style:SOT-223; Gate Trigger Current Max (QI) Igt:-; Gate Trigger Voltage Max Vgt:1.5V; Peak Gate Power:5W; Peak Non Rep Surge Current Itsm 50Hz:10A; Holding Current Max Ih:10mA; No. of Pins:4Pins; Operating Temperature Max:150°C; Product Range:-; MSL:-; SVHC:No SVHC (17-Dec-2015); Current Itsm:10A; Current Itsm @ 60Hz:11A; Current t2+g-:35mA; Current t2-g+:70mA; Current t2-g-:35mA; Gate Trigger Current Igt (Q1) t2+g+:35mA; Gate Trigger Current Max Igt:10mA; Holding Current Max Ih:10mA; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +150°C; Packaging:Cut Tape; Repetitive Reverse Voltage Vrrm Max:500V; Termination Type:Surface Mount Device; Thyristor Type:Triac

THYRISTOR 0.8A 400V TO-92; Peak Repetitive Off-State Voltage Vdrm:400V; Gate Trigger Current Max Igt:200µA; Current It av:0.5A; On State RMS Current IT(rms):0.8A; Thyristor Case Style:TO-92; No. of Pins:3Pins; Peak Non Rep Surge Current Itsm 50Hz:8A; Holding Current Max Ih:5mA; Gate Trigger Voltage Max Vgt:0.3V; Operating Temperature Max:150°C; Product Range:-; MSL:-; SVHC:No SVHC (17-Dec-2015); Current Itsm:8A; Igt Temperature:125°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +150°C; Repetitive Reverse Voltage Vrrm Max:400V; Termination Type:Through Hole; Thyristor Type:Thyristor

DIODE ULTRAFAST 2X10A; Repetitive Reverse Voltage Vrrm Max:150V; Forward Current If(AV):10A; Diode Configuration:Dual Common Cathode; Forward Voltage VF Max:1.15V; Reverse Recovery Time trr Max:25ns; Forward Surge Current Ifsm Max:125A; Operating Temperature Max:150°C; Diode Case Style:TO-220AB; No. of Pins:3 Pin; Packaging:Each; Product Range:BYV32 Series; Automotive Qualification Standard:-; SVHC:No SVHC (17-Dec-2015); Current Ifsm:125A; Diode Type:Soft Recovery; Forward Current If Max:8A; Forward Voltage:850mV; Junction Temperature Tj Max:150°C; No. of Pins:3Pins; Reverse Recovery Time trr Typ:20ns; Termination Type:Through Hole

DIODE ULTRAFAST 2X15A; Repetitive Reverse Voltage Vrrm Max:200V; Forward Current If(AV):30A; Diode Configuration:Dual Common Cathode; Forward Voltage VF Max:1.05V; Reverse Recovery Time trr Max:28ns; Forward Surge Current Ifsm Max:150A; Operating Temperature Max:150°C; Diode Case Style:TO-220AB; No. of Pins:3 Pin; Packaging:Each; Product Range:BYV42 Series; Automotive Qualification Standard:-; SVHC:No SVHC (17-Dec-2015); Current If @ Vf:15A; Current Ifsm:150A; Current Ir Max:1mA; Diode Type:Soft Recovery; Forward Voltage:1.05V; Junction Temperature Tj Max:150°C; No. of Pins:3Pins; Pin Configuration:1A1 2Kcom 3A2; Reverse Recovery Time trr Typ:20ns; Termination Type:Through Hole

Thyristor SCR 13A 3-Pin SOT-54 T/R

Thyristor TRIAC 600V 8.8A 4-Pin(3+Tab) SOT-223 T/R

Thyristor TRIAC 600V 13.8A 3-Pin SPT T/R

Thyristor TRIAC 800V 13.7A 3-Pin TO-92 Bulk

Thyristor TRIAC 800V 13.7A 3-Pin TO-92 Bulk

Thyristor TRIAC 800V 27A 3-Pin(3+Tab) TO-220AB Tube

Thyristor TRIAC 600V 71A 3-Pin(3+Tab) TO-220AB Tube
