GROMMET FOR 40-A35 PIN LARGE BORE; Accessory Type:Grommet; For Use With:ABCIRP Size 12 Contacts; Product Range:-

PLUG FREE SIZE 28-21 SKT; Product Range:-; Circular Connector Shell Style:Straight Plug; No. of Contacts:37Contacts; Circular Contact Type:Crimp Socket - Contacts Not Supplied; Coupling Style:Bayonet; Insert Arrangement:28-21; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Black Chromate over Zinc Cobalt; Contact Material:Copper Alloy; Contact Plating:Silver; Insert Rotation:N; Service Class:Environmentally Sealed; Equivalent Military Specification:MIL-DTL-5015 Series; Approval Category:NF F 61 030

PLUG FREE SIZE 36-A22 SKT; Product Range:-; Circular Connector Shell Style:Straight Plug; No. of Contacts:22Contacts; Circular Contact Type:Crimp Socket - Contacts Not Supplied; Coupling Style:Bayonet; Insert Arrangement:36A-22; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Black Chromate over Zinc Cobalt; Contact Material:Copper Alloy; Contact Plating:Silver; Insert Rotation:N; Service Class:Environmentally Sealed; Equivalent Military Specification:MIL-DTL-5015 Series; Approval Category:NF F 61 030

CIRCULAR CONNECTOR RCPT 4-20 FLANGE; Product Range:MIL-PP; Circular Connector Shell Style:Box Mount Receptacle; No. of Contacts:20Contacts; Circular Contact Type:Solder Socket; Coupling Style:Push-Pull; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Non-reflective Black; Contact Material:Copper Alloy; Contact Plating:Gold; Connector Mounting:Flange Mount; Connector Shell Size:4; Connector Type:Circular Military; Contact Gender:Socket; Contact Plating:Gold Plated Contacts; Contact Termination:Solder; Contact Termination Type:Solder; Gender:Receptacle; Insert Arrangement:4-20

CIRCULAR CONNECTOR PLUG 2-10 CABLE; Product Range:MIL-PP; Circular Connector Shell Style:Cable Mount Plug; No. of Contacts:10Contacts; Circular Contact Type:Solder Socket; Coupling Style:Push-Pull; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Non-reflective Black; Contact Material:Copper Alloy; Contact Plating:Gold; Connector Mounting:Cable Mount; Connector Shell Size:2; Connector Type:Circular Military; Contact Gender:Socket; Contact Plating:Gold Plated Contacts; Contact Termination:Solder; Contact Termination Type:Solder; Gender:Plug; Insert Arrangement:2-10

CIRCULAR CONNECTOR RCPT 6-30 FLANGE; Product Range:MIL-PP; Circular Connector Shell Style:Recessed Box Mount Receptacle; No. of Contacts:30Contacts; Circular Contact Type:PCB Socket; Coupling Style:Push-Pull; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Non-reflective Black; Contact Material:Copper Alloy; Contact Plating:Gold; Connector Mounting:Flange Mount; Connector Shell Size:6; Connector Type:Circular Military; Contact Gender:Socket; Contact Plating:Gold Plated Contacts; Contact Termination:Through Hole Vertical; Contact Termination Type:Through Hole; Gender:Receptacle; Insert Arrangement:6-30

BACKSHELL 38999 SIZE 9 STRAIGHT; Accessory Type:Backshell; For Use With:MIL-DTL-38999 Series III Connectors; Connector Shell Size:9; Cable Exit Angle:180°; Connector Body Material:Aluminium Body; Product Range:-; Cable Diameter Max:4.7mm

BACKSHELL 38999 SIZE 19 STRAIGHT; Accessory Type:Backshell; For Use With:MIL-DTL-38999 Series III Connectors; Connector Shell Size:19; Cable Exit Angle:180°; Connector Body Material:Aluminium Body; Product Range:-; Cable Diameter Max:23.8mm

PLUG FREE 26WAY; Product Range:AB05 Series; Circular Connector Shell Style:Straight Plug; No. of Contacts:26Contacts; Circular Contact Type:Solder Pin; Coupling Style:Bayonet; Insert Arrangement:16-26; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Equivalent Military Specification:MIL-DTL-26482 Series I; Cable Diameter Max:12.95mm; Colour:Olive; Contact Gender:Pin; Contact Resistance:5mohm; Coupling Diameter:33.3mm; Current Rating:10A; External Length / Height:53.36mm; IP / NEMA Rating:IP67; No. of Mating Cycles:500; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Voltage Rating VAC:700V; Working Voltage:700V

PLUG PANEL 10WAY; Product Range:AB05 Series; Circular Connector Shell Style:Wall Mount Receptacle; No. of Contacts:10Contacts; Circular Contact Type:Solder Pin; Coupling Style:Bayonet; Insert Arrangement:12-10; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Equivalent Military Specification:MIL-DTL-26482 Series I; Colour:Olive; Contact Gender:Pin; Contact Resistance:5mohm; Current Rating:5A; External Length / Height:26.4mm; External Width:26.6mm; IP / NEMA Rating:IP67; No. of Mating Cycles:500; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Panel Cutout Diameter:21.95mm; Panel Cutout Size:20.62 mm; Voltage Rating VAC:700V; Working Voltage:700V

SOCKET PANEL 7WAY; Product Range:AB05 Series; Circular Connector Shell Style:Wall Mount Receptacle; No. of Contacts:7Contacts; Circular Contact Type:Solder Socket; Coupling Style:Bayonet; Insert Arrangement:10-7; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Equivalent Military Specification:MIL-DTL-26482 Series I; Approval Bodies:BS; Colour:Olive; Contact Resistance:5mohm; Current Rating:5A; External Length / Height:26.4mm; External Width:24.3mm; IP / NEMA Rating:IP67; No. of Mating Cycles:500; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Panel Cutout Diameter:17.4mm; Panel Cutout Size:18.26 mm; Voltage Rating VAC:700V; Working Voltage:700V

SOCKET PANEL 12WAY; Product Range:AB05 Series; Circular Connector Shell Style:Wall Mount Receptacle; No. of Contacts:12Contacts; Circular Contact Type:Solder Socket; Coupling Style:Bayonet; Insert Arrangement:14-12; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Equivalent Military Specification:MIL-DTL-26482 Series I; Colour:Olive; Contact Resistance:5mohm; External Length / Height:26.4mm; External Width:29mm; IP / NEMA Rating:IP67; No. of Mating Cycles:500; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Panel Cutout Diameter:25.12mm; Panel Cutout Size:23.01 mm; Voltage Rating VAC:700V

SOCKET PANEL 32WAY; Product Range:AB05 Series; Circular Connector Shell Style:Wall Mount Receptacle; No. of Contacts:32Contacts; Circular Contact Type:Solder Socket; Coupling Style:Bayonet; Insert Arrangement:18-32; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Equivalent Military Specification:MIL-DTL-26482 Series I; Colour:Olive; Contact Resistance:5mohm; Current Rating:5A; External Length / Height:26.4mm; External Width:33.8mm; IP / NEMA Rating:IP67; No. of Mating Cycles:500; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Panel Cutout Diameter:31.45mm; Panel Cutout Size:26.97 mm; Voltage Rating VAC:700V; Working Voltage:700V

RECEPT PANEL SIZE 14 2WAY PIN; Product Range:AB05 Series MIL-DTL-26482 Series I Equivalent; Circular Connector Shell Style:Wall Mount Receptacle; No. of Contacts:2Contacts; Circular Contact Type:Solder Pin; Coupling Style:Bayonet; Insert Arrangement:14-2; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Contact Gender:Pin

RECEPT PANEL SIZE 14 4WAY PIN; Product Range:-; Circular Connector Shell Style:Wall Mount Receptacle; No. of Contacts:4Contacts; Circular Contact Type:Solder Pin; Coupling Style:Bayonet; Insert Arrangement:14-4; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Equivalent Military Specification:MIL-DTL-26482 Series I; Contact Gender:Pin

RECEPT PANEL SIZE 14 2WAY SKT; Product Range:-; Circular Connector Shell Style:Wall Mount Receptacle; No. of Contacts:2Contacts; Circular Contact Type:Solder Socket; Coupling Style:Bayonet; Insert Arrangement:14-2; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Equivalent Military Specification:MIL-DTL-26482 Series I; Contact Gender:Socket

RECEPT PANEL SIZE 14 5WAY SKT; Product Range:-; Circular Connector Shell Style:Wall Mount Receptacle; No. of Contacts:5Contacts; Circular Contact Type:Solder Socket; Coupling Style:Bayonet; Insert Arrangement:14-5; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Equivalent Military Specification:MIL-DTL-26482 Series I; Contact Gender:Socket

RECEPT PANEL SIZE 20 41WAY PIN; Product Range:-; Circular Connector Shell Style:Wall Mount Receptacle; No. of Contacts:41Contacts; Circular Contact Type:Solder Pin; Coupling Style:Bayonet; Insert Arrangement:20-41; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Equivalent Military Specification:MIL-DTL-26482 Series I; Contact Gender:Pin

PLUG FREE EMI SIZE 8 3WAY PIN; Product Range:-; Circular Connector Shell Style:Straight Plug; No. of Contacts:3Contacts; Circular Contact Type:Solder Pin; Coupling Style:Bayonet; Insert Arrangement:8-33; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Equivalent Military Specification:MIL-DTL-26482 Series I; Contact Gender:Pin

PLUG FREE EMI SIZE 12 3WAY PIN; Product Range:-; Circular Connector Shell Style:Straight Plug; No. of Contacts:3Contacts; Circular Contact Type:Solder Pin; Coupling Style:Bayonet; Insert Arrangement:12-3; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Equivalent Military Specification:MIL-DTL-26482 Series I; Contact Gender:Pin
