SOCKET FREE 19WAY; Product Range:ABCIRH Series; Circular Connector Shell Style:Straight Plug; No. of Contacts:19Contacts; Circular Contact Type:Crimp Socket - Contacts Not Supplied; Coupling Style:Bayonet; Insert Arrangement:22-14; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Copper Alloy; Contact Plating:Silver; Insert Rotation:N; Service Class:Environmentally Sealed; Equivalent Military Specification:MIL-DTL-5015 Series; Current Rating:10A; IP / NEMA Rating:IP67; No. of Mating Cycles:500; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Shock Resistance:75g; Standard:MIL-C-5015 BS9522 FOO32 VG95234 NF F 16-101 BS6853; Voltage Rating V DC:350V; Working Voltage:700V

RECEPTACLE PANEL SIZE 32-A13 PIN; Product Range:-; Circular Connector Shell Style:Wall Mount Receptacle; No. of Contacts:13Contacts; Circular Contact Type:Crimp Pin - Contacts Not Supplied; Coupling Style:Bayonet; Insert Arrangement:32A-13; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Black Chromate over Zinc Cobalt; Contact Material:Copper Alloy; Contact Plating:Silver; Insert Rotation:N; Service Class:Environmentally Sealed; Equivalent Military Specification:MIL-DTL-5015 Series; Approval Category:NF F 61 030

RECEPTACLE PANEL SIZE 36-A22 PIN; Product Range:-; Circular Connector Shell Style:Wall Mount Receptacle; No. of Contacts:22Contacts; Circular Contact Type:Crimp Pin - Contacts Not Supplied; Coupling Style:Bayonet; Insert Arrangement:36A-22; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Black Chromate over Zinc Cobalt; Contact Material:Copper Alloy; Contact Plating:Silver; Insert Rotation:N; Service Class:Environmentally Sealed; Equivalent Military Specification:MIL-DTL-5015 Series; Approval Category:NF F 61 030

CRIMP CONTACT PIN 16-20 AWG GOLD; Product Range:-; Contact Gender:Pin; Contact Termination Type:Crimp; For Use With:ABCIRP Connectors; Wire Size AWG Max:16AWG; Wire Size AWG Min:20AWG; Current Rating:22A; Contact Material:Copper; Contact Plating:Gold Plated Contacts; Contact Size:16; Contact Termination:Crimp

GROMMET FOR 18-19 PIN LARGE BORE; Accessory Type:Grommet; For Use With:ABCIRP Size 16 Contacts; Product Range:-

GROMMET FOR 40-A35 PIN LARGE BORE; Accessory Type:Grommet; For Use With:ABCIRP Size 12 Contacts; Product Range:-

PLUG FREE SIZE 28-21 SKT; Product Range:-; Circular Connector Shell Style:Straight Plug; No. of Contacts:37Contacts; Circular Contact Type:Crimp Socket - Contacts Not Supplied; Coupling Style:Bayonet; Insert Arrangement:28-21; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Black Chromate over Zinc Cobalt; Contact Material:Copper Alloy; Contact Plating:Silver; Insert Rotation:N; Service Class:Environmentally Sealed; Equivalent Military Specification:MIL-DTL-5015 Series; Approval Category:NF F 61 030

PLUG FREE SIZE 36-A22 SKT; Product Range:-; Circular Connector Shell Style:Straight Plug; No. of Contacts:22Contacts; Circular Contact Type:Crimp Socket - Contacts Not Supplied; Coupling Style:Bayonet; Insert Arrangement:36A-22; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Black Chromate over Zinc Cobalt; Contact Material:Copper Alloy; Contact Plating:Silver; Insert Rotation:N; Service Class:Environmentally Sealed; Equivalent Military Specification:MIL-DTL-5015 Series; Approval Category:NF F 61 030

CIRCULAR CONNECTOR RCPT 4-20 FLANGE; Product Range:MIL-PP; Circular Connector Shell Style:Box Mount Receptacle; No. of Contacts:20Contacts; Circular Contact Type:Solder Socket; Coupling Style:Push-Pull; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Non-reflective Black; Contact Material:Copper Alloy; Contact Plating:Gold; Connector Mounting:Flange Mount; Connector Shell Size:4; Connector Type:Circular Military; Contact Gender:Socket; Contact Plating:Gold Plated Contacts; Contact Termination:Solder; Contact Termination Type:Solder; Gender:Receptacle; Insert Arrangement:4-20

CIRCULAR CONNECTOR PLUG 2-10 CABLE; Product Range:MIL-PP; Circular Connector Shell Style:Cable Mount Plug; No. of Contacts:10Contacts; Circular Contact Type:Solder Socket; Coupling Style:Push-Pull; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Non-reflective Black; Contact Material:Copper Alloy; Contact Plating:Gold; Connector Mounting:Cable Mount; Connector Shell Size:2; Connector Type:Circular Military; Contact Gender:Socket; Contact Plating:Gold Plated Contacts; Contact Termination:Solder; Contact Termination Type:Solder; Gender:Plug; Insert Arrangement:2-10

CIRCULAR CONNECTOR RCPT 6-30 FLANGE; Product Range:MIL-PP; Circular Connector Shell Style:Recessed Box Mount Receptacle; No. of Contacts:30Contacts; Circular Contact Type:PCB Socket; Coupling Style:Push-Pull; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Non-reflective Black; Contact Material:Copper Alloy; Contact Plating:Gold; Connector Mounting:Flange Mount; Connector Shell Size:6; Connector Type:Circular Military; Contact Gender:Socket; Contact Plating:Gold Plated Contacts; Contact Termination:Through Hole Vertical; Contact Termination Type:Through Hole; Gender:Receptacle; Insert Arrangement:6-30

SENSOR PRESSURE 0-20BAR G 1/4" E; Operating Pressure Max:20bar; Sensor Output:Current / Voltage; Pressure Measurement Type:Gauge; Voltage Rating:-; Port Style:G1/4 (1/4" BSP); Supply Current:-; Product Range:96705 Series; Operating Temperature Range:-40°C to +105°C; Pressure Max:2000bar

SENSOR PRESSURE 0-10BAR M18; Operating Pressure Max:10bar; Sensor Output:Analogue; Pressure Measurement Type:Gauge; Voltage Rating:-; Port Style:M18; Supply Current:-; Product Range:-; Operating Temperature Range:-40°C to +125°C; Pressure Max:10bar

PLUG PANEL 19WAY; Product Range:AB05 Series; Circular Connector Shell Style:Wall Mount Receptacle; No. of Contacts:19Contacts; Circular Contact Type:Solder Pin; Coupling Style:Bayonet; Insert Arrangement:14-19; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Equivalent Military Specification:MIL-DTL-26482 Series I; Colour:Olive; Contact Gender:Pin; Contact Resistance:5mohm; Current Rating:5A; External Length / Height:26.4mm; External Width:29mm; IP / NEMA Rating:IP67; No. of Mating Cycles:500; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Panel Cutout Diameter:25.12mm; Panel Cutout Size:23.01 mm; Voltage Rating VAC:700V; Working Voltage:700V

PLUG FREE 6WAY; Product Range:AB05 Series; Circular Connector Shell Style:Straight Plug; No. of Contacts:6Contacts; Circular Contact Type:Solder Pin; Coupling Style:Bayonet; Insert Arrangement:10-6; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Equivalent Military Specification:MIL-DTL-26482 Series I; Approval Bodies:BS; Cable Diameter Max:5.02mm; Colour:Olive; Contact Gender:Pin; Contact Resistance:5mohm; Coupling Diameter:21.8mm; Current Rating:5A; External Length / Height:51.33mm; IP / NEMA Rating:IP67; No. of Mating Cycles:500; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Voltage Rating VAC:700V; Working Voltage:700V

SOCKET FREE 19WAY; Product Range:AB05 Series; Circular Connector Shell Style:Straight Plug; No. of Contacts:19Contacts; Circular Contact Type:Solder Socket; Coupling Style:Bayonet; Insert Arrangement:14-19; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Equivalent Military Specification:MIL-DTL-26482 Series I; Cable Diameter Max:9.77mm; Colour:Olive; Contact Gender:Socket; Contact Resistance:5mohm; Coupling Diameter:30mm; Current Rating:5A; External Length / Height:51.33mm; IP / NEMA Rating:IP67; No. of Mating Cycles:500; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Voltage Rating VAC:700V; Working Voltage:700V

SOCKET FREE 32WAY; Product Range:AB05 Series; Circular Connector Shell Style:Straight Plug; No. of Contacts:32Contacts; Circular Contact Type:Solder Socket; Coupling Style:Bayonet; Insert Arrangement:18-32; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass; Contact Plating:Gold; Insert Rotation:N; Service Class:Corrosion Resistant; Equivalent Military Specification:MIL-DTL-26482 Series I; Cable Diameter Max:16.12mm; Colour:Olive; Contact Gender:Socket; Contact Resistance:5mohm; Coupling Diameter:35.6mm; Current Rating:5A; External Length / Height:56.93mm; IP / NEMA Rating:IP67; No. of Mating Cycles:500; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Voltage Rating VAC:700V; Working Voltage:700V

PLUG FREE 3WAY; Product Range:ABB Series; Circular Connector Shell Style:Straight Plug; No. of Contacts:3Contacts; Circular Contact Type:Solder Pin; Coupling Style:Bayonet; Insert Arrangement:10SL-3; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Copper Alloy; Contact Plating:Silver; Insert Rotation:N; Service Class:Environmentally Sealed; Equivalent Military Specification:MIL-DTL-5015 Series; Approval Bodies:BS; Cable Diameter Max:2.77mm; Cable Diameter Min:1.68mm; Colour:Olive; Coupling Diameter:24.2mm; Current Rating:10A; Current per Power Contact Max:10A; External Length / Height:29.95mm; IP / NEMA Rating:IP67; No. of Mating Cycles:500; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Voltage Rating VAC:350V; Working Voltage:350V

TRANSISTOR NPN TO-126; Transistor Polarity:NPN; Collector Emitter Voltage V(br)ceo:300V; Transition Frequency ft:-; Power Dissipation Pd:20W; DC Collector Current:500mA; DC Current Gain hFE:25hFE; Transistor Case Style:TO-126; No. of Pins:3Pins; Operating Temperature Max:150°C; Product Range:-; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (15-Jan-2018); Av Current Ic:250mA; Collector Emitter Saturation Voltage Vce(on):1V; Continuous Collector Current Ic Max:500mA; Current Ic Continuous a Max:500mA; Current Ic hFE:150mA; Full Power Rating Temperature:25°C; Hfe Min:20; No. of Transistors:1; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +150°C; Power Dissipation Ptot Max:11W; Termination Type:Through Hole; Voltage Vcbo:500V
