Components & parts from Triad Magnetics

Displaying 1921 - 1940 of 2268

STEP-UP/STEP-DOWN AUTO TRANSFORMER; Output Voltage:115V; Power Rating:150VA; Output Current:1.3A; Product Range:-; Features:6' cord and socket; Frequency:60Hz; Input Voltage Primary Max:230V; No. of Outputs:1Outputs ;RoHS Compliant: No

Datasheet

MET-05-T

Part Number : MET-05-T

Triad Magnetics

MET-05-T

Datasheet

WSU090-2500-13

Part Number : WSU090-2500-13

Triad Magnetics

WALL MOUNT ADAPTOR AC-DC 9V 2.5A; No. of Outputs:1 Output; Output Power Max:22.5W; Output Voltage - Output 1:9V; Output Current - Output 1:2.5A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-;RoHS Compliant: Yes

Datasheet

F6-20

Part Number : F6-20

Triad Magnetics

Power Transformers Chassis Mount, 30VA 20VDCout, 115VACin

Datasheet

CME375-9

Part Number : CME375-9

Triad Magnetics

INDUCTOR 176.1MH 0.087A; Product Range:CME Series; Inductance:176.1mH; Rated Current:870mA; Case Dimensions:38.1mm x 31.75mm x 29.97mm; DC Current Max:870mA; DC Current Rating:87mA; DC Resistance Max:1.98ohm; No. of Pins:4

Datasheet

SP-4

Part Number : SP-4

Triad Magnetics

RED SPEC Series 10 mW 200 kO /1 kO CT Through Hole Audio Transformer

Datasheet

SP-70

Part Number : SP-70

Triad Magnetics

SP-70 Series 50 mW 600 Ohm 300 Hz to 100 kHz High Reliability Audio Transformer

Datasheet

TY-303P

Part Number : TY-303P

Triad Magnetics

TRANSFORMER 4000OHM/600OHM; Current Rating:0mA; Primary Impedance:600ohm; Secondary Impedance:4kohm; Transformer Mounting:Through Hole; Product Range:-; Insertion Loss:1dB; Transformer Type:Coupling

Datasheet

RC-1

Part Number : RC-1

Triad Magnetics

INDUCTOR 5.6MH 250MA +10%; Product Range:RC Series; Inductance:5.6mH; Inductance Tolerance: 10%; DC Resistance Max:6.1ohm; RMS Current (Irms):250mA; Saturation Current (Isat):250mA; Packaging:Each; DC Current Rating:250mA

Datasheet

RC-7

Part Number : RC-7

Triad Magnetics

INDUCTOR 450UH 1A +10%; Product Range:RC Series; Inductance:450 H; RMS Current (Irms):1A; Saturation Current (Isat):1A; DC Resistance Max:0.42ohm; Inductance Tolerance: 10%; Packaging:Each; Case Dimensions:15.24mm x 23.62mm ;RoHS Compliant: Yes

Datasheet

RC-9

Part Number : RC-9

Triad Magnetics

INDUCTOR 200UH 1.6A +10%; Product Range:RC Series; Inductance:200 H; Inductance Tolerance: 10%; DC Resistance Max:0.18ohm; RMS Current (Irms):1.6A; Saturation Current (Isat):1.6A; Packaging:Each; Case Dimensions:15.24mm x 23.62mm

Datasheet

F-341X

Part Number : F-341X

Triad Magnetics

POWER TRANSFORMER; Power Rating:50.4VA; Isolation Transformer Primary Voltages:2 x 115V 2 x 230V; Secondary Voltages:25.2V; Current Rating:2A; Plug Type:-; Product Range:- ;RoHS Compliant: Yes

Datasheet

F-243U

Part Number : F-243U

Triad Magnetics

POWER TRANSFORMER; Power Rating:72VA; Isolation Transformer Primary Voltages:1 x 115V; Secondary Voltages:18V; Current Rating:4A; Plug Type:-; Product Range:-; Input Voltage:115VAC; Output Current:4A; Supply Voltage:115V ;RoHS Compliant: Yes

Datasheet

F-212Z

Part Number : F-212Z

Triad Magnetics

BOBBINS TRANSFORMER; Power Rating:24VA; Isolation Transformer Primary Voltages:1 x 230V 2 x 115V; Secondary Voltages:2 x 24V; Current Rating:1A; Plug Type:-; Product Range:F Series; Input Voltage:115VAC; Output Current:1A ;RoHS Compliant: Yes

Datasheet

F-138P

Part Number : F-138P

Triad Magnetics

ISOLATION TRANSFORMER; Power Rating:1.5VA; Isolation Transformer Primary Voltages:1 x 115V; Secondary Voltages:2 x 12.6V; Current Rating:120mA; Plug Type:-; Product Range:-; Input Voltage:115VAC; No. of Phases:Single ;RoHS Compliant: Yes

Datasheet

N-53MG

Part Number : N-53MG

Triad Magnetics

POWER XFMR 115V@0.740A 115V CHASSIS MT w/AC GROUND CORD & SOCKET

Datasheet

F-241U

Part Number : F-241U

Triad Magnetics

POWER TRANSFORMER; Power Rating:18VA; Isolation Transformer Primary Voltages:1 x 115V; Secondary Voltages:18V; Current Rating:1A; Plug Type:-; Product Range:-; External Depth:2.5"; External Height:2.5"; External Width:3" ;RoHS Compliant: Yes

Datasheet

F-26X

Part Number : F-26X

Triad Magnetics

POWER TRANSFORMER; Power Rating:31.5VA; Isolation Transformer Primary Voltages:1 x 115V; Secondary Voltages:12.6V; Current Rating:2.5A; Plug Type:-; Product Range:-; Drop Ship:Yes; Input Voltage:115VAC; Output Current:2.5A ;RoHS Compliant: Yes

Datasheet

FS36-170-C2

Part Number : FS36-170-C2

Triad Magnetics

POWER XFMR 36 Vct @ 170 mA UL/cUL - Class 3, TUV, 115

Datasheet

N-54M

Part Number : N-54M

Triad Magnetics

ISOLATION TRANSFORMER; Power Rating:150VA; Isolation Transformer Primary Voltages:1 x 115V; Secondary Voltages:115V; Current Rating:1.3A; Plug Type:-; Product Range:-

Datasheet
