Power Supply, Ac-Dc, 24V, 33A; Power Supply Applications:Ite & Industrial; No. Of Outputs:1Outputs; Output Power Max:792W; Output Voltage - Output 1:24Vdc; Output Current - Output 1:33A; Output Voltage - Output 2:- Rohs Compliant: Yes |Traco Power TXN 800-124

Enclosed AC DC Converters 1 Output 5V 3A 85 ~ 264 VAC, 100 ~ 240 VAC, 120 ~ 370 VDC Input

10 µH Unshielded Inductor 1.44 A 100mOhm Nonstandard

POWER SUPPLY, AC-DC, 15V, 12A;

DC-DC CONVERTER, 3.3V, 3A;

Isolated Module DC DC Converter 2 Output 15V -15V 200mA, 200mA 18V - 75V Input

AC/DC POWER SUPPLY, FIXED, 24V, 6.25A;

AC/DC POWER SUPPLY, FIXED, 24V, 6.25A;

AC/DC POWER SUPPLY, FIXED, 24V, 12.08A;

POWER SUPPLY, AC-DC, 48V, 0.94A;

POWER SUPPLY, AC-DC, 48V, 1.25A;

CONVERTER DC/DC 3W +/-12V; No. of Outputs:2 Output; Output Power Max:3W; Output Voltage - Output 1:12V; Output Current - Output 1:125mA; Output Voltage - Output 2:-12V; Output Current - Output 2:125mA; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:TEL 3 Series; Input Voltage DC Min:36V; Input Voltage DC Max:75V; DC / DC Converter Output Type:Fixed; DC / DC Converter Type:DIP; DC / DC Converter Mounting:Through Hole; Approvals & Standards:CSA IEC UL; Width:20mm; Height:10.2mm; Depth:32mm; SVHC:No SVHC (17-Dec-2015); Approval Bodies:CSA EN IEC UL; Efficiency:81%; External Depth:20mm; External Length / Height:10.2mm; External Width:32mm; Flammability Rating:UL94V-0; Isolation Voltage:1.5kV; Line Regulation:0.5%; Load Regulation:1%; No. of Outputs:2Outputs; Operating Temperature Max:75°C; Operating Temperature Min:-25°C; Output Ripple Voltage pk-pk:60mV; Output Voltage +:12VDC; Output Voltage -:-12VDC; Power Rating:3W; Supply Voltage:48V

CONVERTER DC/DC 15W 5V; No. of Outputs:1 Output; Output Power Max:15W; Output Voltage - Output 1:5V; Output Current - Output 1:3A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:-; Input Voltage DC Min:36V; Input Voltage DC Max:75V; DC / DC Converter Output Type:Fixed; DC / DC Converter Type:DIP; DC / DC Converter Mounting:Through Hole; Approvals & Standards:IEC UL; Width:25.4mm; Height:10.2mm; Depth:50.8mm; SVHC:No SVHC (17-Dec-2015); Approval Bodies:cUL EN IEC UL; Efficiency:83%; External Depth:25.4mm; External Length / Height:10.2mm; External Width:50.8mm; Isolation Voltage:1.5kV; Line Regulation:1%; Load Regulation:0.5%; No. of Outputs:1Outputs; Operating Temperature Max:+85°C; Operating Temperature Min:-40°C; Output Ripple Voltage pk-pk:50mV; Power Rating:15W; Supply Voltage:48V

PSU DIN RAIL 500W 24V; No. of Outputs:1 Output; Output Power Max:500W; Output Voltage - Output 1:24VDC; Output Current - Output 1:20A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:187VAC; Input Voltage AC Max:264VAC; Power Supply Output Type:Fixed; Product Range:TIS Series; SVHC:No SVHC (17-Dec-2015); Applications:Industrial; Approval Bodies:CE UL; External Depth:83mm; External Length / Height:130mm; External Width:220mm; Height:130mm; Input Frequency:63Hz; Length:83mm; Line Regulation:0.2%; Load Regulation:1%; No. of Outputs:1Outputs; Operating Temperature Max:70°C; Operating Temperature Min:-25°C; Output Current:20A; Output Power:500W; Output Ripple Voltage pk-pk:50mV; Output Voltage:24V; Power Rating:500W; Power Supply Type:Switch Mode; Supply Frequency Max:63Hz; Supply Frequency Min:47Hz; Supply Voltage:230V; Supply Voltage Max:264V; Width:220mm

PSU ENCAPSULATED 15W 5V +/-15V; No. of Outputs:3Outputs; Output Power Max:15W; Output Voltage - Output 1:5V; Output Current - Output 1:150mA; Output Voltage - Output 2:15V; Output Current - Output 2:150mA; Output Voltage - Output 3:-15V; Output Current - Output 3:150mA; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Power Supply Output Type:Fixed; Product Range:TML Series; SVHC:No SVHC (17-Dec-2015); Applications:General Purpose; Approval Bodies:CE UL; Efficiency:80%; External Depth:27mm; External Length / Height:96mm; External Width:54mm; Height:26.5mm; Input Frequency:440Hz; Isolation Voltage:3000VAC; Length:96mm; Line Regulation:0.3%; Load Regulation:1%; Operating Temperature Max:60°C; Operating Temperature Min:25°C; Output Power:15W; Power Rating:15W; Power Supply Type:Switch Mode; Supply Voltage:264V; Supply Voltage Max:264V; Supply Voltage Min:85V; Supply Voltage Typ:110V AC 230V AC; Width:54mm

PSU DIN RAIL 120W 24V; No. of Outputs:1 Output; Output Power Max:120W; Output Voltage - Output 1:24VDC; Output Current - Output 1:5A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:85VAC; Input Voltage AC Max:264VAC; Power Supply Output Type:Adjustable Fixed; Product Range:-; SVHC:No SVHC (17-Dec-2015); Applications:Industrial; Approval Bodies:CB cUL EN IEC UL; External Depth:100mm; External Length / Height:75mm; External Width:85mm; Height:75mm; Input Frequency:63Hz; Length:100mm; No. of Outputs:1Outputs; Output Current:5A; Output Power:120W; Output Voltage:24V; Power Rating:120W; Power Supply Type:Switch Mode; Supply Frequency Max:60Hz; Supply Frequency Min:50Hz; Supply Voltage:264V; Supply Voltage Max:264V; Supply Voltage Min:85V; Supply Voltage Typ:110V AC 230V AC; Width:85mm

POWER SUPPLY ENCL +/-15V 2.4A/1.5A; No. of Outputs:2Outputs; Output Power Max:35W; Output Voltage - Output 1:15V; Output Current - Output 1:2.4A; Output Voltage - Output 2:-15V; Output Current - Output 2:1.5A; Output Voltage - Output 3:-; Output Current - Output 3:-; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Power Supply Output Type:Adjustable Fixed; Product Range:TXL Series; SVHC:No SVHC (17-Dec-2015); Approval Bodies:CE UL; Approval Category:cUL/UL (E188913); External Depth:35mm; External Length / Height:99mm; External Width:82mm; Power Supply Type:Switch Mode

PSU ENCLOSED 220W 12V; No. of Outputs:1Outputs; Output Power Max:220W; Output Voltage - Output 1:12V; Output Current - Output 1:18.4A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Output Voltage - Output 4:-; Current Output 4:-; Input Voltage AC Min:85V; Input Voltage AC Max:264V; Power Supply Output Type:Adjustable Fixed; Product Range:-; SVHC:No SVHC (17-Dec-2015); Approval Bodies:CE UL; Approval Category:cUL/UL (E188913); External Depth:45mm; External Length / Height:198mm; External Width:99mm; Frequency Max:63Hz; Frequency Min:47Hz; Line Regulation:0.5%; Load Regulation:1%; No. of Outputs:1 Output; Operating Temperature Max:70°C; Operating Temperature Min:-10°C; Output Current Max:18.4A; Output Ripple and Noise Voltage pk-pk:<1% V out; Power Supply Type:Switch Mode; Supply Voltage Typ:110V AC 230V AC

CONVERTER DC TO DC 12V 3.3A 40W; No. of Outputs:1 Output; Output Power Max:40W; Output Voltage - Output 1:12V; Output Current - Output 1:3.3A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:TEN 40 Series; Input Voltage DC Min:18V; Input Voltage DC Max:36V; DC / DC Converter Output Type:Fixed; DC / DC Converter Type:DIP; DC / DC Converter Mounting:Through Hole; Approvals & Standards:IEC UL; Width:50.8mm; Height:10.2mm; Depth:50.8mm; SVHC:No SVHC (17-Dec-2015); Approval Bodies:cUL EN IEC UL; No. of Outputs:1Outputs

PSU ENCAPSULATED 10W 5V/2A; No. of Outputs:1 Output; Output Power Max:10W; Output Voltage - Output 1:5V; Output Current - Output 1:2A; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Power Supply Output Type:Fixed; Input Voltage AC Min:90V; Input Voltage AC Max:264V; Width:27.2mm; Height:23.5mm; Depth:52.4mm; Product Range:TML Series; SVHC:No SVHC (17-Dec-2015); Applications:General Purpose; Approval Bodies:EN IEC UL; External Length / Height:23mm; Input Frequency:440Hz; Length:52.5mm; No. of Outputs:1Outputs; Output Current Max:2A; Power Rating:10W; Power Supply Type:Switch Mode; Supply Voltage:264V; Supply Voltage Typ:110V AC 230V AC
