OPTOCOUPLER DUAL 5KV TRANSTR O/P; No. of Channels:2 Channel; Optocoupler Case Style:DIP; No. of Pins:8Pins; Forward Current If Max:50mA; Isolation Voltage:5kV; CTR Min:50%; Collector Emitter Voltage V(br)ceo:55V; Packaging:Each; Product Range:-; SVHC:No SVHC (15-Jun-2015); Approval Bodies:UL; Current If CTR:5mA; Current Transfer Ratio Max:600%; Current Transfer Ratio Min:50%; Input Current:16mA; Lead Spacing:2.54mm; No. of Channels:2Channels; Operating Temperature Max:100°C; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +100°C; Optocoupler Output Type:Phototransistor; Output Voltage:55V

LED SMD 2125 YELLOW; LED Colour:Yellow; LED Mounting:SMD; Bulb Size:0.8mm x 1.2mm; Forward Current If:5mA; Forward Voltage:2V; Wavelength Typ:590nm; Luminous Intensity:25mcd; Viewing Angle:140°; Lens Shape:Rectangular; Packaging:Cut Tape; Product Range:-; Automotive Qualification Standard:-; MSL:-; Current If @ Vf:5mA; Current If Luminous Intensity:5mA; Dominant Wavelength:587nm; Dominant Wavelength Max:595nm; Dominant Wavelength Min:581nm; Dominant Wavelength Typ:587nm; Forward Current If Max:5mA; Forward Voltage VF Max:2.3V; LED / Lamp Size:1.2mm x 0.8mm; LED Type:Standard; Luminous Intensity Max:73.6mcd; Luminous Intensity Min:8.5mcd; Luminous Intensity Typ:25mcd; No. of Pins:2Pins; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C; PIV Max:4V; Voltage Vf Min:1.7V; Voltage Vf Typ:2V

OPTOCOUPLER TRANSISTOR O/P; No. of Channels:1 Channel; Optocoupler Case Style:DIP; No. of Pins:6Pins; Forward Current If Max:80mA; Isolation Voltage:2.5kV; CTR Min:20%; Collector Emitter Voltage V(br)ceo:30V; Packaging:Each; Product Range:-; SVHC:No SVHC (15-Jun-2015); Input Current:10mA; No. of Channels:1Channels; Operating Temperature Max:100°C; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +100°C; Optocoupler Output Type:Phototransistor; Output Voltage:30V

LED SMD ORANGE; LED Colour:Orange; LED Mounting:SMD; Bulb Size:1.25mm x 1.4mm; Forward Current If:20mA; Forward Voltage:2V; Wavelength Typ:612nm; Luminous Intensity:180mcd; Viewing Angle:125°; Lens Shape:Rectangular; Packaging:Cut Tape; Product Range:-; Automotive Qualification Standard:-; MSL:-; Current If Luminous Intensity:20mA; Dominant Wavelength:605nm; External Depth:1.1mm; External Length / Height:2mm; External Width:1.25mm; Forward Current If Max:20mA; Forward Voltage VF Max:2.4V; LED / Lamp Size:1.4mm x 1.25mm; LED Type:Standard; Luminous Intensity @ If Min:27.2mcd; Luminous Intensity Typ:60mcd; No. of Pins:2Pins; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +85°C; PIV Max:4V; Peak Wavelength:612nm; Voltage Vf Typ:2.4V

LED SMD PURE GREEN; LED Colour:Green; LED Mounting:SMD; Bulb Size:1.25mm x 1.4mm; Forward Current If:20mA; Forward Voltage:2.1V; Wavelength Typ:562nm; Luminous Intensity:6mcd; Viewing Angle:125°; Lens Shape:Rectangular; Packaging:Cut Tape; Product Range:-; Automotive Qualification Standard:-; MSL:-; Current If Luminous Intensity:20mA; Dominant Wavelength:557nm; External Depth:1.1mm; External Length / Height:2mm; External Width:1.25mm; Forward Current If Max:20mA; Forward Voltage VF Max:2.8V; LED / Lamp Size:1.4mm x 1.25mm; LED Type:Standard; Luminous Intensity @ If Min:1.53mcd; Luminous Intensity Typ:6mcd; No. of Pins:2Pins; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +85°C; PIV Max:4V; Peak Wavelength:562nm; Voltage Vf Typ:2.8V

LED SMD RED; LED Colour:Red; LED Mounting:SMD; Bulb Size:2.4mm; Forward Current If:20mA; Forward Voltage:1.9V; Wavelength Typ:623nm; Luminous Intensity:180mcd; Viewing Angle:120°; Lens Shape:Round; Packaging:Cut Tape; Product Range:-; Automotive Qualification Standard:-; MSL:-; Current If Luminous Intensity:20mA; Dominant Wavelength:613nm; External Depth:1.9mm; External Length / Height:3.2mm; External Width:2.8mm; Forward Current If Max:20mA; Forward Voltage VF Max:2V; LED / Lamp Size:2.4mm; LED Type:Standard; Luminous Intensity @ If Min:27.2mcd; Luminous Intensity Typ:80mcd; No. of Pins:2Pins; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C; PIV Max:4V; Peak Wavelength:636nm; Voltage Vf Typ:2V

DARLINGTON ARRAY 8NPN DIP18 50V; Transistor Polarity:NPN; Collector Emitter Voltage V(br)ceo:50V; Power Dissipation Pd:760mW; DC Collector Current:123mA; DC Current Gain hFE:1000hFE; Transistor Case Style:DIP; No. of Pins:18Pins; Operating Temperature Max:85°C; Product Range:-; Automotive Qualification Standard:-; MSL:-; Base Number:2803; Current Ic Continuous a Max:500mA; Device Marking:ULN2803APG; IC Generic Number:2803; Input Type:CMOS 5V TTL; Input Voltage Max:30V; Module Configuration:Eight; No. of Channels:8Channels; No. of Transistors:8; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +85°C; Output Current Max:500mA; Output Voltage Max:50V; Transistor Type:Power Darlington

V REG +12V SMD 78L12 SOT-89-3; Output Type:Fixed; Input Voltage Min:19V; Input Voltage Max:35V; Fixed Output Voltage Nom.:12V; Adjustable Output Voltage Min:-; Adjustable Output Voltage Max:-; Output Current:150mA; Linear Regulator Case Style:SOT-89; No. of Pins:3Pins; Operating Temperature Min:-30°C; Operating Temperature Max:85°C; Packaging:Each; Product Range:7812 Voltage Regulators; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (15-Jun-2015); Accuracy %:5%; Base Number:78; IC Generic Number:78L12; No. of Outputs:1Outputs; Operating Temperature Range:0°C to +125°C; Operating Voltage Tolerance +:5%; Output Current Max:0.15A; Output Voltage Max:12V; Output Voltage Nom.:12V; Primary Input Voltage:27V; Supply Voltage Min:14.5V; Termination Type:Surface Mount Device; Voltage Regulator Type:Positive Fixed

CONTROLLER MOT 3PHASE SMD 6537; Motor Type:Three Phase DC Brushless; No. of Outputs:6Outputs; Output Current:20mA; Output Voltage:5.5V; Driver Case Style:SSOP; No. of Pins:24Pins; Supply Voltage Min:4.5V; Supply Voltage Max:5.5V; Operating Temperature Min:-30°C; Operating Temperature Max:85°C; Packaging:Each; Product Range:-; Automotive Qualification Standard:-; MSL:-; Base Number:6537; Controller Type:Motor; Drive Configuration:3 Phase; IC Generic Number:6537; Logic Function Number:6537; Operating Temperature Range:-30°C to +85°C; Supply Voltage Range:4.5V to 5.5V; Termination Type:Surface Mount Device

Optocoupler Logic-Out Push-Pull DC-IN 1-CH 8-Pin PDIP

PHOTOCOUPLER GAA AS IRED & PHOTO-IC; No. of Channels:1 Channel; Optocoupler Case Style:Surface Mount DIP; No. of Pins:6Pins; Isolation Voltage:5kV; Packaging:Each; Product Range:-; SVHC:No SVHC (15-Jun-2015); Input Current:15mA; No. of Channels:1Channels; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C; Optocoupler Output Type:Gate Drive; Output Voltage:20V

LED WHITE 0.5W SLIM 6500K; LED Colour:Cool White; LED Mounting:SMD; Bulb Size:0.8mm x 2mm x 4.5mm; Forward Current If:180mA; Forward Voltage:-; Luminous Intensity:-; Viewing Angle:-; Lens Shape:-; Packaging:Each; Product Range:-; Automotive Qualification Standard:-; MSL:-; Forward Voltage VF Max:3.8V; LED / Lamp Size:4.5mm x 2mm x 0.8 mm; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C

LED PURE GREEN PLCC2 35 MCD; LED Colour:Green; LED Mounting:SMD; Bulb Size:2.4mm; Forward Current If:20mA; Forward Voltage:2.15V; Wavelength Typ:564nm; Luminous Intensity:35mcd; Viewing Angle:120°; Lens Shape:Round; Packaging:Each; Product Range:-; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (15-Jun-2015); Dominant Wavelength:558nm; Dominant Wavelength Typ:558nm; Forward Current If Max:20mA; Forward Voltage VF Max:2.5V; LED / Lamp Size:PLCC-2; LED Type:Standard; Luminous Intensity Typ:35mcd; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C; Voltage Vf Typ:2.15V

OPTOCOUPLER TR O/P VDE; No. of Channels:1 Channel; Optocoupler Case Style:DIP; No. of Pins:4Pins; Forward Current If Max:25mA; Isolation Voltage:5kV; CTR Min:100%; Collector Emitter Voltage V(br)ceo:80V; Packaging:Each; Product Range:-; SVHC:No SVHC (15-Jun-2015); Input Current:16mA; No. of Channels:1Channels; Operating Temperature Max:110°C; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +110°C; Optocoupler Output Type:Phototransistor; Output Voltage:80V

LED PLCC2 630NM RED; LED Colour:Red; LED Mounting:SMD; Bulb Size:2.4mm; Forward Current If:20mA; Forward Voltage:2.1V; Wavelength Typ:638nm; Luminous Intensity:300mcd; Viewing Angle:120°; Lens Shape:Round; Packaging:Cut Tape; Product Range:-; Automotive Qualification Standard:-; MSL:-; Dominant Wavelength:630nm; Forward Current If Max:20mA; Forward Voltage VF Max:2.5V; LED / Lamp Size:PLCC-2; LED Type:Standard; Luminous Intensity Typ:300mcd; No. of Pins:2Pins; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C

LED PLCC2 626NM RED; LED Colour:Red; LED Mounting:SMD; Bulb Size:2.4mm; Forward Current If:20mA; Forward Voltage:2.1V; Wavelength Typ:634nm; Luminous Intensity:400mcd; Viewing Angle:120°; Lens Shape:Round; Packaging:Cut Tape; Product Range:-; Automotive Qualification Standard:-; MSL:-; Dominant Wavelength:626nm; Forward Current If Max:20mA; Forward Voltage VF Max:2.5V; LED / Lamp Size:PLCC-2; LED Type:Standard; Luminous Intensity Typ:400mcd; No. of Pins:2Pins; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C

MOSFET N CH 8A 1000V TO3P; Transistor Polarity:N Channel; Continuous Drain Current Id:8A; Drain Source Voltage Vds:1kV; On Resistance Rds(on):1.7ohm; Rds(on) Test Voltage Vgs:10V; Threshold Voltage Vgs:4V; Power Dissipation Pd:150W; Transistor Case Style:TO-3P; No. of Pins:3Pins; Operating Temperature Max:150°C; Product Range:-; MSL:-; Current Id Max:8A; Termination Type:Through Hole; Transistor Type:Power MOSFET; Voltage Vds Typ:1kV; Voltage Vgs Max:30V; Voltage Vgs Rds on Measurement:10V

MOSFET P CH 5A 60V DPAK; Transistor Polarity:P Channel; Continuous Drain Current Id:5A; Drain Source Voltage Vds:-60V; On Resistance Rds(on):170mohm; Rds(on) Test Voltage Vgs:-10V; Threshold Voltage Vgs:2V; Power Dissipation Pd:20W; Transistor Case Style:TO-252; No. of Pins:3Pins; Operating Temperature Max:150°C; Product Range:-; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (15-Jun-2015); Current Id Max:-5A; Packaging:Cut Tape; Termination Type:Surface Mount Device; Transistor Type:Power MOSFET; Voltage Vds Typ:60V; Voltage Vgs Max:-20V; Voltage Vgs Rds on Measurement:10V

MOSFET N CH 3.9A 40V TSOP6; Transistor Polarity:N Channel; Continuous Drain Current Id:3.9A; Drain Source Voltage Vds:40V; On Resistance Rds(on):75mohm; Rds(on) Test Voltage Vgs:10V; Threshold Voltage Vgs:2.3V; Power Dissipation Pd:2.2W; Transistor Case Style:TSOP; No. of Pins:6Pins; Operating Temperature Max:150°C; Product Range:-; Automotive Qualification Standard:-; MSL:-; Current Id Max:3.9A; Termination Type:Surface Mount Device; Transistor Type:Power MOSFET; Voltage Vds Typ:40V; Voltage Vgs Max:20V; Voltage Vgs Rds on Measurement:10V

BRUSHLESS DC MOTOR DRIVER 18V 0.2MA; Motor Type:PWM; No. of Outputs:1Outputs; Output Current:5mA; Output Voltage:5V; Driver Case Style:QFP; No. of Pins:52Pins; Supply Voltage Min:6.5V; Supply Voltage Max:16.5V; Operating Temperature Min:-30°C; Operating Temperature Max:115°C; Packaging:Each; Product Range:-; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (15-Jun-2015); Base Number:6582; Device Type:Motor; Operating Temperature Range:-30°C to +115°C; Supply Voltage Range:6.5V to 16.5V; Termination Type:Surface Mount Device
