Telemecanique Sensors Air, Fresh Water, Sea Water Pressure Switch, 1 C/O 3.5 → 25bar, 240 V ac, 250 V dc. Minimum Pressure Reading: 3.5bar. Maximum Pressure Reading: 250bar. Electrical Connection: Screw Clamp. Minimum Operating Temperature: -25°C. Maximum Operating Temperature: +70°C. Maximum Current: 100 mA @ 250 V dc, 3 A @ 120 V ac. IP Rating: IP54. Mounting Type: Panel Mount. Housing Material: Glass Fibre Reinforced Polycarbonate. MPN: XMXA25L2135

Telemecanique Sensors Air, Hydraulic Oil, Non-Corrosive Fluid Pressure Switch, 1CO 0.07 → 5.2bar, 500 V, 600 V. Minimum Pressure Reading: 0.07bar. Process Connection: G1/4. Electrical Connection: M20 x 1.5 mm Cable Gland. Minimum Operating Temperature: -56°C. Maximum Operating Temperature: +85°C. Maximum Current: 5 A @ 24 V. Mounting Type: Cable Mount. IP Rating: IP65. Housing Material: Zinc Alloy. MPN: ACW5M119012

Telemecanique Sensors Air, Hydraulic Oil, Non-Corrosive Fluid Pressure Switch, 2CO 0.07 → 5.2bar, 500 V, 600 V. Minimum Pressure Reading: 0.07bar. Process Connection: G1/4. Electrical Connection: M20 x 1.5 mm Cable Gland. Minimum Operating Temperature: -56°C. Maximum Operating Temperature: +85°C. Maximum Current: 5 A @ 24 V. Mounting Type: Cable Mount. IP Rating: IP65. Housing Material: Zinc Alloy. MPN: ACW5M129012

White LED Colour Vision Sensor, 12-Pin M12 Male Connector, ≤390 (No Load) mA, 24 V dc. Housing Material: Aluminium (Box), PMMA (Front Face). IP Rating: IP65. Minimum Operating Temperature: 0°C. Maximum Operating Temperature: +50°C. MPN: XUZLW002, Telemecanique Sensors

Telemecanique Sensors, M30 x 1.5, PNP-NC Inductive Sensor 64mm Length, 12 → 48 V dc supply voltage. Body Style: Barrel. Detection Range: 30 mm. Terminal Type: Cable. Maximum DC Voltage: 58V. Mounting Type: Non Flush. IP Rating: IP65, IP67, IP69K. Switching Current: ≤10 (No Load) mA, ≤200 (Switching) mA. Housing Material: Nickel Plated Brass. Maximum Operating Temperature: +70°C. Standards Met: CSA, E2, EN/ISO 13849-1, IEC 60068-2-27, IEC 60068-2-6, IEC 60529, IEC 62061, TUV, UL. Shielding: Unshielded. MPN: XS630B5PBL2

Telemecanique Sensors, M30 x 1.5, PNP-NC Inductive Sensor 74mm Length, 12 → 48 V dc supply voltage. Body Style: Barrel. Detection Range: 30 mm. Terminal Type: M12 - 4 Pin. Maximum DC Voltage: 58V. Mounting Type: Non Flush. IP Rating: IP65, IP67, IP69K. Switching Current: 10 (No Load) mA, 200 (Switching) mA. Housing Material: Nickel Plated Brass. Maximum Operating Temperature: +70°C. Standards Met: CSA, E2, EN/ISO 13849-1, IEC 60068-2-27, IEC 60068-2-6, IEC 60529, IEC 62061, TUV, UL. Shielding: Unshielded. MPN: XS630B5PBM12

Telemecanique Sensors Mounting Hardware for use with OsiSense XUW Sensor. Accessory Type: Fixing Bracket. MPN: XUZASW009

IP67 Single Break Limit Switch Roller Plunger Zamak® Zinc Alloy, NO/NC, 125 V, 240 V. Pole and Throw Configuration: SPDT. Maximum Current: 10 A. Maximum DC Voltage: 28V. Connection Type: M12. Series: 9007. Terminal Type: 4 Pin. Length: 44.4mm. Width: 40.1mm. Maximum Operating Temperature: +105°C. MPN: 9007MS02S0084, Telemecanique Sensors

IP67 Snap Action Limit Switch Coil Spring Zamak® Zinc Alloy, NO/NC, 600V. Pole and Throw Configuration: SPDT. Maximum Current: 10 A. Connection Type: 1/2-14 NPT Conduit. Series: 9007. Terminal Type: Wire Lead. Length: 102mm. Width: 39mm. Dimensions: 102 x 39 x 45 mm. Maximum Operating Temperature: +85°C. MPN: 9007C54F, Telemecanique Sensors

Telemecanique Sensors Limit Switch for use with XCKL Series, XCKM Series. Accessory Type: Contact Block. Series: OsiSense XC. MPN: ZCKM9

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 16bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 16bar. Process Connection: 7/16 - 20 UNF SAE. Analogue Output: 4 → 20 mA. Electrical Connection: 4 Pin M12 Male Connector. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 23 mA. Mounting Type: Thread Mount. MPN: XMLP016BD270

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 25bar. Supply Voltage: 5 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 25bar. Electrical Connection: EN 175301-803-A 3 Pin Male Connector. Analogue Output: 0.5 → 4.5 V. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 7 mA. Housing Material: FPM, Stainless Steel 316L. IP Rating: IP65. MPN: XMLP025BC11F

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 30bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 30bar. Process Connection: 7/16 - 20 UNF SAE. Electrical Connection: 4 Pin M12 Male Connector. Analogue Output: 4 → 20 mA. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 23 mA. Housing Material: Stainless Steel 303. MPN: XMLP030BD290

Telemecanique Sensors Mounting Bracket for use with OsiSense XM XML F. MPN: XMAZL001

Telemecanique Sensors Inductive Sensor. Housing Material: Stainless Steel. MPN: XSZBS30

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 150psi. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0psi. Maximum Pressure Reading: 150psi. Electrical Connection: 3 Pin Male Connector. Analogue Output: 4 → 20 mA. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 23 mA. Housing Material: Stainless Steel 316L. IP Rating: IP65, IP67. MPN: XMLP150PP230

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 300psi. Supply Voltage: 5 V dc. Minimum Pressure Reading: 0psi. Maximum Pressure Reading: 300psi. Analogue Output: 0.5 → 4.5 V. Electrical Connection: 4 Pin M12 Male Connector. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 7 mA. IP Rating: IP65, IP67, IP69K. Mounting Type: Thread Mount. MPN: XMLP300PD130

Telemecanique Sensors, M30 x 1.5, PNP-NO Inductive Sensor 62mm Length, 12 → 48 V dc supply voltage. Body Style: Barrel. Detection Range: 10 mm. Terminal Type: Cable. Maximum DC Voltage: 58V. Mounting Type: Flush Mount. IP Rating: IP69K. Switching Current: 200 mA. Housing Material: Nickel Plated Brass. Maximum Switching Frequency: 1kHz. Short Circuit Overload Protection: Yes. Maximum Operating Temperature: +70°C. MPN: XS530BLPAL2

Telemecanique Sensors M12 5m Connector for use with XUM Series. MPN: XZCPA1164L5

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 60bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 60bar. Analogue Output: 4 → 20 mA. Electrical Connection: 4 Pin M12 Male Connector. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 23 mA. IP Rating: IP65, IP67, IP69K. Mounting Type: Thread Mount. MPN: XMLP060BD21F
