Preventa XCS-DMC ATEX Magnetic Safety Switch, Coded Actuator, Plastic, 24 V dc. Safety Contacts: NC. Auxiliary Contacts: NO. IP Rating: IP66, IP67. Dimensions: 51 x 16 x 7 mm. Length: 51mm. Number of Approach Directions: 3. Depth: 7mm. Width: 16mm. MPN: XCSDMC59010EX, Telemecanique Sensors

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Differential Pressure Switch, Analogue. Pressure Range: 0 → 10bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 10bar. Analogue Output: 4 → 20 mA. Electrical Connection: 4-Pin Male Connector. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: ±0.5 %. Response Time: 2 ms. Maximum Current: 20 mA. Housing Material: FPM, Stainless Steel 316L. MPN: XMLP010BD21F

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Differential Pressure Switch, Analogue. Pressure Range: 0 → 250bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 250bar. Electrical Connection: 3-Pin Male Connector. Analogue Output: 4 → 20 mA. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: ±0.5 %. Response Time: 2 ms. Maximum Current: 20 mA. Housing Material: FPM, Stainless Steel 316L. MPN: XMLP250BC21F

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Differential Pressure Switch, Analogue. Pressure Range: 0 → 600psi. Supply Voltage: 5 V dc. Minimum Pressure Reading: 0psi. Maximum Pressure Reading: 600psi. Analogue Output: 0.5 → 4.5 V. Electrical Connection: 3-Pin Male Connector. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: ±0.5 %. Response Time: 2 ms. Housing Material: FPM, Stainless Steel 316L. IP Rating: IP65, IP67. MPN: XMLP600PP130

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 60bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 60bar. Process Connection: 7/16 - 20 UNF SAE. Analogue Output: 4 → 20 mA. Electrical Connection: EN 175301-803-A 3 Pin Male Connector. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 23 mA. Mounting Type: Thread Mount. MPN: XMLP060BC290

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: -1 → 9bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: -1bar. Maximum Pressure Reading: 9bar. Electrical Connection: EN 175301-803-A 3 Pin Male Connector. Analogue Output: 4 → 20 mA. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 23 mA. Housing Material: FPM, Stainless Steel 316L. IP Rating: IP65. MPN: XMLPM09BC21F

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 16bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 16bar. Process Connection: 7/16 - 20 UNF SAE. Electrical Connection: EN 175301-803-A 3 Pin Male Connector. Analogue Output: 4 → 20 mA. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 23 mA. IP Rating: IP65. MPN: XMLP016BC270

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 16bar. Supply Voltage: 5 V dc. Minimum Pressure Reading: 0bar. Process Connection: 7/16 - 20 UNF SAE. Maximum Pressure Reading: 16bar. Analogue Output: 0.5 → 4.5 V. Electrical Connection: 4 Pin M12 Male Connector. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 7 mA. IP Rating: IP65, IP67, IP69K. MPN: XMLP016BD190

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 100bar. Supply Voltage: 5 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 100bar. Electrical Connection: EN 175301-803-A 3 Pin Male Connector. Analogue Output: 0.5 → 4.5 V. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 7 mA. Housing Material: FPM, Stainless Steel 316L. IP Rating: IP65. MPN: XMLP100BC11F

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 600psi. Supply Voltage: 5 V dc. Minimum Pressure Reading: 0psi. Maximum Pressure Reading: 600psi. Electrical Connection: 4 Pin M12 Male Connector. Analogue Output: 0.5 → 4.5 V. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 7 mA. Housing Material: Stainless Steel 316L. IP Rating: IP65, IP67, IP69K. MPN: XMLP600PD130

Telemecanique Sensors Inductive Sensor. Body Style: Barrel. Thread Size: M12 x 1. Output Type: NC. Detection Range: 4 mm. Terminal Type: Cable. Supply Voltage: 12 → 24 V dc. Length: 36mm. Width: 17mm. Maximum DC Voltage: 24V. Mounting Type: Flush Mount. IP Rating: IP68, IP69K. Switching Current: 100 (DC) mA. Housing Material: Brass, Metal, PPS. Maximum Switching Frequency: 2000 (DC)Hz. Reverse Polarity Protection: Yes. MPN: XS612B3DBL2

IP65 Snap Action Limit Switch Metal, NO/NC, 600V. Pole and Throw Configuration: SP. Maximum Current: 10 A. Series: OsiSense XC. Terminal Type: Wire Lead. Length: 81mm. Width: 41mm. Depth: 40mm. Maximum Operating Temperature: +70°C. Minimum Operating Temperature: -25°C. Dimensions: 81 x 41 x 40 mm. MPN: XC2JC161, Telemecanique Sensors

Telemecanique Sensors Limit Switch Lever for use with T Series. MPN: 9007B7

IP66, IP67 Snap Action Limit Switch Lever Plastic, NO/NC, 240V. Pole and Throw Configuration: DP. Maximum Current: 10 A. Maximum DC Voltage: 250V. Series: OsiSense XC. Terminal Type: Screw. Length: 51mm. Width: 58mm. Minimum Operating Temperature: -25°C. Dimensions: 51 x 58 x 30 mm. MPN: XCKT2145P16, Telemecanique Sensors

IP66, IP67 Snap Action Limit Switch Plunger Zinc Alloy, NO/NC, 240V. Pole and Throw Configuration: DP. Maximum Current: 3 A. Maximum DC Voltage: 250V. Series: OsiSense XC. Terminal Type: Screw. Length: 73mm. Width: 30mm. Mechanical Life Minimum: 15000000 cycles. CAD Drawing: 3D CAD Model. MPN: XCKD2127P16, Telemecanique Sensors

IP66 Snap Action Limit Switch Plunger Zinc Alloy, NO/NC, 240V. Pole and Throw Configuration: 4P. Maximum Current: 10 A. Maximum DC Voltage: 250V. Series: OsiSense XC. Terminal Type: Screw. Length: 81mm. Width: 72mm. Minimum Operating Temperature: -25°C. Dimensions: 81 x 72 x 36 mm. MPN: XCKML102, Telemecanique Sensors

Telemecanique Sensors Limit Switch Head for use with XCJ2 Series. Series: OsiSense XC. MPN: ZC2JE70

IP54 Snap Action Limit Switch Lever Zinc Alloy, 2NO/2NC, 240V. Pole and Throw Configuration: 4P. Maximum Current: 3 A. Maximum DC Voltage: 250V. Series: OsiSense XC. Terminal Type: Screw. Length: 95mm. Width: 85mm. Minimum Operating Temperature: -25°C. Dimensions: 95 x 85 x 53 mm. MPN: XCRB11, Telemecanique Sensors

IP65 Slow Action Limit Switch Lever, NO/NC, 230V. Pole and Throw Configuration: DP. Maximum Current: 10 A. Series: OsiSense XC. Terminal Type: Screw. Length: 113mm. Width: 77mm. Maximum Operating Temperature: +70°C. Mechanical Life Minimum: 10000000 cycles. Dimensions: 113 x 77 x 44 mm. MPN: XC1AC127, Telemecanique Sensors

IP66 Snap Action Limit Switch Plunger Zinc Alloy, NO/NC, 240V. Pole and Throw Configuration: 4P. Maximum Current: 10 A. Maximum DC Voltage: 250V. Series: OsiSense XC. Terminal Type: Screw. Length: 81mm. Width: 72mm. Dimensions: 81 x 72 x 36 mm. Minimum Operating Temperature: -25°C. MPN: XCKML121, Telemecanique Sensors
