IP67 Snap Action Limit Switch Lever Die Cast Zinc, NO/NC, 240V. Pole and Throw Configuration: SPDT. Maximum Current: 10 A. Maximum DC Voltage: 28V. Series: 9007. Terminal Type: Wire Lead. Length: 63.25mm. Maximum Operating Temperature: +105°C. Depth: 34.89mm. Minimum Operating Temperature: -40°C. MPN: 9007MS04S0200, Telemecanique Sensors

Preventa XCS Safety Hinge Switch, NO/NC, PG11. Maximum Current: 6 A. Maximum AC Voltage: 240V. Maximum DC Voltage: 250V. Shaft Length: 72.5mm. Trigger Angle Range: 5. Minimum Operating Temperature: -25°C. Maximum Operating Temperature: +70°C. MPN: XCSPL561, Telemecanique Sensors

Telemecanique Sensors Air, Fresh Water, Sea Water Differential Pressure Switch, 3NC. Pressure Range: 0.2 → 4.8 (Falling) bar, 1 → 6 (Rising) bar. Minimum Pressure Reading: 0.2 (Falling) bar, 1 (Rising) bar. Process Connection: G3/8. Maximum Pressure Reading: 4.8 (Falling) bar, 6 (Rising) bar. Electrical Connection: Screw Clamp. Minimum Operating Temperature: -25°C. Maximum Operating Temperature: +70°C. Accuracy:

Telemecanique Sensors Differential Pressure Switch, 2 N/C, G1/4 process connection. Minimum Pressure Reading: 1.3bar. Maximum Pressure Reading: 12bar. Electrical Connection: Screw Terminals. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +100°C. Accuracy: ±0.5 %. MPN: XMPA12B2144C243

Telemecanique Sensors, M18 x 1, PNP-NO/NC Inductive Sensor 41mm Length, 12 → 24 V dc supply voltage. Body Style: Barrel. Detection Range: 5 mm. Terminal Type: Cable. Maximum DC Voltage: 24V. Mounting Type: Flush Mount. Switching Current: ≤200 mA. IP Rating: IP68. Housing Material: Brass. Minimum Operating Temperature: -40°C. Maximum Switching Frequency: 2kHz. Reverse Polarity Protection: Yes. MPN: XS1N18PC410TF

Telemecanique Sensors, M18 x 1, PNP-NO/NC Inductive Sensor 51mm Length, 12 → 24 V dc supply voltage. Body Style: Barrel. Detection Range: 5 mm. Terminal Type: M12 - 4 Pin. Maximum DC Voltage: 24V. Mounting Type: Flush Mount. Switching Current: ≤200 mA. IP Rating: IP65, IP67, IP69K. Housing Material: Brass. Minimum Operating Temperature: -25°C. Maximum Switching Frequency: 2kHz. Reverse Polarity Protection: Yes. MPN: XS1N18PC410DSCV

Telemecanique Sensors Air, Hydraulic Oil, Non-Corrosive Gas, Non-Corrosive Liquids Differential Pressure Switch. Pressure Range: 10 → 49 (Differential) psi, 5 → 250 (Decreasing) psi. Output Type: SPDT-NO/NC. Supply Voltage: 240 V ac, 250 V dc. Minimum Pressure Reading: 10 (Differential) psi, 5 (Decreasing) psi. Maximum Pressure Reading: 250 (Decreasing) psi, 49 (Differential) psi. Process Connection: 0.25 in NPTF. Electrical Connection: 0.5 in NPT. Minimum Operating Temperature: -10°F. Maximum Operating Temperature: +185°F. Accuracy:

Telemecanique Sensors, M18 x 1, NPN-NO Inductive Sensor 41mm Length, 12 → 24 V dc supply voltage. Body Style: Barrel. Detection Range: 16 mm. Terminal Type: Cable. Maximum DC Voltage: 24V. Mounting Type: Non Flush. IP Rating: IP65, IP67, IP69K. Switching Current: ≤200 mA. Housing Material: Brass (Case), PPS (Sensing Face). Minimum Operating Temperature: -25°C. Maximum Switching Frequency: 1kHz. Reverse Polarity Protection: Yes. MPN: XS218B4NAL2

Telemecanique Sensors Fresh Water, Sea Water Pressure Switch, 1 C/O 0 → 70bar, 240 V ac, 250 V dc. Electrical Connection: PG 13.5. Minimum Operating Temperature: -13°C. Maximum Operating Temperature: +158°C. Accuracy: 2 %. Maximum Current: 100 mA @ 250 V dc, 3 A @ 120 V ac. Housing Material: Zinc Alloy. Mounting Type: Panel Mount. IP Rating: IP65, IP66. MPN: XMLA070E2S11

TRANSM. CON D 10BAR 4-20. Accuracy: ±0.1 %. Output Type: Analogue. Media Measured: Air, Corrosive Fluid, Fresh Water, Hydraulic Oil, Sea Water. Electrical Connection: M12 3-Pin Connector. Analogue Output: 4 → 20 mA. Response Time:

Telemecanique Sensors Corrosive Fluid Pressure Switch, 1 C/O 0 → 10bar, 240 V ac, 250 V dc. Electrical Connection: PG 13.5. Minimum Operating Temperature: -13°C. Maximum Operating Temperature: +158°C. Accuracy: 2 %. Maximum Current: 100 mA @ 250 V dc, 3 A @ 120 V ac. Mounting Type: Panel Mount. IP Rating: IP65, IP66. Housing Material: Zinc Alloy. MPN: XMLB010C2S11

SAFETY SW 6PST-NC 0.75A 240V SCREW; Product Range:Preventa XCS Series; Contact Configuration:6PST-NC; Switch Terminals:Screw; Contact Voltage AC Max:240V; Contact Current AC Max:750mA; IP Rating:IP66 IP67; Contact Voltage DC Max:24V; Contact Current DC Max:550mA; SVHC:No SVHC (15-Jan-2018)

SAFETY SW DPST-NC SPST-NO 3A 240V; Product Range:Preventa XCS Series; Contact Configuration:DPST-NC SPST-NO; Switch Terminals:Screw; Contact Voltage AC Max:240V; Contact Current AC Max:3A; IP Rating:IP67; Contact Voltage DC Max:250V; Contact Current DC Max:100mA; SVHC:No SVHC (15-Jan-2018)

LIMIT SWITCH PLUNGER SPDT 5A 250V; Limit Switch Actuator:Plunger; Contact Configuration:SPDT; Contact Current AC Max:5A; Contact Voltage AC Max:250V; Operating Force Max:20N; Product Range:OsiSense XC Series; Contact Current DC Max:-; Contact Voltage DC Max:-; SVHC:No SVHC (15-Jan-2018)

PRESSURE SWITCH 0.4-4BAR SPDT PANEL; Pressure Fitting Style:G 1/4" BSP; Operating Pressure Min:400mbar; Operating Pressure Max:4bar; Contact Configuration:SPDT; Sensor Mounting:Panel / Chassis; Electrical Connection:Screw Clamp Terminals; Switching Voltage DC Resistive:250V; Switching Current DC Resistive:100mA; Product Range:OsiSense XM Series; SVHC:No SVHC (15-Jan-2018)

PRESSURE SWITCH 0.6-10BAR SPDT PANEL; Pressure Fitting Style:G 1/4" BSP; Operating Pressure Min:600mbar; Operating Pressure Max:10bar; Contact Configuration:SPDT; Sensor Mounting:Panel / Chassis; Electrical Connection:Screw Clamp Terminals; Switching Voltage DC Resistive:250V; Switching Current DC Resistive:100mA; Product Range:OsiSense XM Series; SVHC:No SVHC (15-Jan-2018)

PRESSURE SWITCH 1.3-20BAR SPDT PANEL; Pressure Fitting Style:G 1/4" BSP; Operating Pressure Min:1.3bar; Operating Pressure Max:20bar; Contact Configuration:SPDT; Sensor Mounting:Panel / Chassis; Electrical Connection:Screw Clamp Terminals; Switching Voltage DC Resistive:250V; Switching Current DC Resistive:100mA; Product Range:OsiSense XM Series; SVHC:No SVHC (15-Jan-2018)

PRESSURE SENSOR 6BAR 4-20MA G1/4A; Operating Pressure Max:6bar; Sensor Output:Analogue; Pressure Measurement Type:Differential; Voltage Rating:24V; Port Style:G1/4; Supply Current:20mA; Product Range:OsiSense XM Series; SVHC:No SVHC (15-Jan-2018)

PRESSURE SENSOR 250BAR 4-20MA G1/4A; Operating Pressure Max:250bar; Sensor Output:Analogue; Pressure Measurement Type:-; Voltage Rating:24V; Port Style:G1/4; Supply Current:20mA; Product Range:OsiSense XM Series; SVHC:No SVHC (15-Jan-2018)

PRESSURE TRANSMITTER 1BAR 24VDC; Operating Pressure Max:1bar; Sensor Output:Analogue; Pressure Measurement Type:-; Voltage Rating:24VDC; Port Style:7/16" - 20 UNF; Supply Current:23mA; Product Range:OsiSense XM Series; SVHC:No SVHC (15-Jan-2018)
