Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 40bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 40bar. Process Connection: 7/16 - 20 UNF SAE. Electrical Connection: 4 Pin M12 Male Connector. Analogue Output: 4 → 20 mA. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 23 mA. Housing Material: Stainless Steel 303. MPN: XMLP040BD290

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 160bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 160bar. Electrical Connection: EN 175301-803-A 3 Pin Male Connector. Analogue Output: 4 → 20 mA. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 23 mA. Housing Material: FPM, Stainless Steel 316L. IP Rating: IP65. MPN: XMLP160BC21F

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 1000psi. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0psi. Maximum Pressure Reading: 1000psi. Analogue Output: 4 → 20 mA. Electrical Connection: 3 Pin Male Connector. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 23 mA. Mounting Type: Thread Mount. Housing Material: Stainless Steel 316L. MPN: XMLP1K0PP230

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 300psi. Supply Voltage: 24 V dc. Minimum Pressure Reading: 0psi. Maximum Pressure Reading: 300psi. Electrical Connection: 4 Pin M12 Male Connector. Analogue Output: 0 → 10 V. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 7 mA. Housing Material: Stainless Steel 316L. IP Rating: IP65, IP67, IP69K. MPN: XMLP300PD730

Telemecanique Sensors Fresh Water, Sea Water Pressure Switch, 1 C/O 0 → 70bar, 240 V ac, 250 V dc. Electrical Connection: PG 13.5. Minimum Operating Temperature: -13°C. Maximum Operating Temperature: +158°C. Accuracy: 2 %. Maximum Current: 100 mA @ 250 V dc, 3 A @ 120 V ac. Housing Material: Zinc Alloy. Mounting Type: Panel Mount. IP Rating: IP65, IP66. MPN: XMLA070E2S11

TRANSM. CON D 10BAR 4-20. Accuracy: ±0.1 %. Output Type: Analogue. Media Measured: Air, Corrosive Fluid, Fresh Water, Hydraulic Oil, Sea Water. Electrical Connection: M12 3-Pin Connector. Analogue Output: 4 → 20 mA. Response Time:

Telemecanique Sensors Corrosive Fluid Pressure Switch, 1 C/O 0 → 10bar, 240 V ac, 250 V dc. Electrical Connection: PG 13.5. Minimum Operating Temperature: -13°C. Maximum Operating Temperature: +158°C. Accuracy: 2 %. Maximum Current: 100 mA @ 250 V dc, 3 A @ 120 V ac. Mounting Type: Panel Mount. IP Rating: IP65, IP66. Housing Material: Zinc Alloy. MPN: XMLB010C2S11

White LED Colour Ethernet PNP/NPN Vision Sensor, 6 → 350 mm. Imaging Technology: CMOS. Resolution: 736 x 480 pixels. Electrical Connection: 12-Pin M12 Male Connector, 4-Pin M12 Female Connector. Supply Voltage: 24 V dc. Maximum Current: ≤200 (No Load) mA. Terminal Type: M12 Female Connector, M12 Male Connector. Housing Material: ABS (Enclosure), Aluminium, PMMA (Lens). IP Rating: IP65, IP67. Minimum Operating Temperature: 0°C. Maximum Operating Temperature: +50°C. MPN: XUWSA06W, Telemecanique Sensors

Telemecanique Sensors, M30 x 1.5, PNP-NO Inductive Sensor 74mm Length, 12 → 48 V dc supply voltage. Body Style: Barrel. Detection Range: 30 mm. Terminal Type: M12 - 4 Pin. Maximum DC Voltage: 58V. Mounting Type: Non Flush. Switching Current: 10 (No Load) mA, 200 (Switching) mA. IP Rating: IP65, IP67, IP69K. Housing Material: Nickel Plated Brass. Minimum Operating Temperature: -25°C. Reverse Polarity Protection: Yes. Maximum Operating Temperature: +70°C. MPN: XS630B5PAM12

Telemecanique Sensors Absolute Encoder 6000rpm PROFIBUS-DP Solid 24 V dc. Output Signal Type: PROFIBUS-DP 25-bit. Resolution: 8192 (Point). IP Rating: IP64. Overall Height: 86mm. Overall Width: 60mm. Overall Depth: 110mm. Minimum Operating Temperature: -40°C. Maximum Operating Temperature: +85°C. Current Rating: 100 (No Load) mA. Series: XCC. MPN: XCC3510PV84FBN

Telemecanique Sensors, M12 x 1, PNP-NO Inductive Sensor 53mm Length, 12 → 48 V dc supply voltage , IP69K Rating. Body Style: Barrel. Detection Range: 2 mm. Terminal Type: Cable. Maximum DC Voltage: 58V. Mounting Type: Flush Mount. Switching Current: 200 mA. Housing Material: Nickel Plated Brass. Maximum Switching Frequency: 5kHz. Maximum Operating Temperature: +70°C. Reverse Polarity Protection: Yes. MPN: XS512BLPAL2

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Differential Pressure Switch, Analogue. Pressure Range: 0 → 100bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 100bar. Analogue Output: 4 → 20 mA. Electrical Connection: 3-Pin Male Connector. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: ±0.5 %. Response Time: 2 ms. Maximum Current: 20 mA. Housing Material: FPM, Stainless Steel 316L. MPN: XMLP100BC21F

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Differential Pressure Switch, Analogue. Pressure Range: 0 → 600bar. Supply Voltage: 12 → 24 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 600bar. Electrical Connection: 3-Pin Male Connector. Analogue Output: 4 → 20 mA. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: ±0.5 %. Response Time: 2 ms. Maximum Current: 20 mA. Housing Material: FPM, Stainless Steel 316L. MPN: XMLP600BC21F

Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 100bar. Supply Voltage: 5 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 100bar. Analogue Output: 0.5 → 4.5 V. Electrical Connection: 4 Pin M12 Male Connector. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 7 mA. Mounting Type: Thread Mount. IP Rating: IP65, IP67, IP69K. MPN: XMLP100BD11F

Telemecanique Sensors Pressure Sensor. Pressure Reading Type: Differential. Accuracy: ±1 %. Output Type: Analogue. Media Measured: Fluid. Process Connection: G1/4. Electrical Connection: EN 175301-803-A Male Connector. Analogue Output: 4 → 20 mA. Response Time: 5 ms. Maximum Current: 20 mA. Supply Voltage: 24 V dc. Housing Material: Ceramic, Nitrile (NBR), Stainless Steel. IP Rating: IP65. Minimum Pressure Setting: 0bar. Maximum Operating Temperature: +80°C. Maximum Pressure Setting: 6bar. MPN: XMLK200P2C23

Telemecanique Sensors Photoelectric Sensor. Accessory Type: Fixing Kit. For Use With: XUM Miniature Sensor. MPN: XUZASM001

Telemecanique Sensors Air, Fresh Water, Sea Water Differential Pressure Switch, 3NC. Pressure Range: 0.2 → 4.8 (Falling) bar, 1 → 6 (Rising) bar. Minimum Pressure Reading: 0.2 (Falling) bar, 1 (Rising) bar. Process Connection: G3/8. Maximum Pressure Reading: 4.8 (Falling) bar, 6 (Rising) bar. Electrical Connection: Screw Clamp. Minimum Operating Temperature: -25°C. Maximum Operating Temperature: +70°C. Accuracy:

Telemecanique Sensors Differential Pressure Switch, 2 N/C, G1/4 process connection. Minimum Pressure Reading: 1.3bar. Maximum Pressure Reading: 12bar. Electrical Connection: Screw Terminals. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +100°C. Accuracy: ±0.5 %. MPN: XMPA12B2144C243

Telemecanique Sensors, M18 x 1, PNP-NO/NC Inductive Sensor 41mm Length, 12 → 24 V dc supply voltage. Body Style: Barrel. Detection Range: 5 mm. Terminal Type: Cable. Maximum DC Voltage: 24V. Mounting Type: Flush Mount. Switching Current: ≤200 mA. IP Rating: IP68. Housing Material: Brass. Minimum Operating Temperature: -40°C. Maximum Switching Frequency: 2kHz. Reverse Polarity Protection: Yes. MPN: XS1N18PC410TF

Telemecanique Sensors, M18 x 1, PNP-NO/NC Inductive Sensor 51mm Length, 12 → 24 V dc supply voltage. Body Style: Barrel. Detection Range: 5 mm. Terminal Type: M12 - 4 Pin. Maximum DC Voltage: 24V. Mounting Type: Flush Mount. Switching Current: ≤200 mA. IP Rating: IP65, IP67, IP69K. Housing Material: Brass. Minimum Operating Temperature: -25°C. Maximum Switching Frequency: 2kHz. Reverse Polarity Protection: Yes. MPN: XS1N18PC410DSCV
