Telemecanique Sensors Air, Fresh Water, Gas, Hydraulic Oil, Refrigeration Fluid Pressure Switch, Analogue. Pressure Range: 0 → 250bar. Supply Voltage: 5 V dc. Minimum Pressure Reading: 0bar. Maximum Pressure Reading: 250bar. Electrical Connection: EN 175301-803-A 3 Pin Male Connector. Analogue Output: 0.5 → 4.5 V. Minimum Operating Temperature: -30°C. Maximum Operating Temperature: +85°C. Accuracy: 0.1 %, ±0.5 (Measurement) %. Response Time: 2 ms. Maximum Current: 7 mA. Housing Material: FPM, Stainless Steel 316L. IP Rating: IP65. MPN: XMLP250BC11F

Telemecanique Sensors Differential for Air, Fresh Water, Sea Water Pressure Sensor, 6bar Max Pressure Reading. Minimum Pressure Reading: 1bar. Accuracy: 3.5 %. Output Type: Relay. Process Connection: G1/4. Electrical Connection: Screw Terminals. Maximum Current: 3 A ac, 100 mA dc. Supply Voltage: 120 → 240 V ac, 250 V dc. Housing Material: PC. IP Rating: IP54. Maximum Operating Temperature: +70°C. Minimum Operating Temperature: -25°C. MPN: XMAV06L2135

Telemecanique Reflective Tape, For Use With XU Series. MPN: XUZB05, Telemecanique Sensors

Telemecanique Sensors Differential for Various Media Pressure Sensor, 35bar Max Pressure Reading. Minimum Pressure Reading: 3.5bar. Accuracy: 2 %. Output Type: Relay. Media Measured: Air, Fresh Water, Hydraulic Fluid, Sea Water. Process Connection: G1/4. Electrical Connection: PG13.5 Cable Gland. Maximum Current: 3 A ac, 100 mA dc. Supply Voltage: 120 → 240 V ac, 250 V dc. Housing Material: Zinc Alloy. IP Rating: IP66. Minimum Operating Temperature: -25°C. CAD Drawing: 3D CAD Model. Maximum Operating Temperature: +70°C. MPN: XMLB035A2S11

IP67 Snap Action Limit Switch Rotary Lever Zamak® Zinc Alloy, NO/NC, 600V. Pole and Throw Configuration: SPDT. Maximum Current: 10 A. Connection Type: Cable. Series: 9007. Terminal Type: Plug In. Length: 80mm. Width: 39mm. Maximum Operating Temperature: +85°C. Depth: 45mm. MPN: 9007C52B2, Telemecanique Sensors

Snap Action Limit Switch Zamak, NO/2NC, 400V. Pole and Throw Configuration: 3P. Connection Type: Cable. Series: OsiSense XC. Terminal Type: 2 m Cable. Length: 50mm. Width: 30mm. Maximum Operating Temperature: +70°C. Mounting Orientation: Side. Dimensions: 50 x 30 x 16 mm. Depth: 16mm. Minimum Operating Temperature: -40°C. MPN: ZCMD39L2, Telemecanique Sensors

IP67 Snap Action Limit Switch Rotary Lever Zamak® Zinc Alloy, 2NO/2NC, 600V. Pole and Throw Configuration: SPDT. Maximum Current: 10 A. Connection Type: Cable. Series: 9007. Terminal Type: Plug In. Length: 102mm. Width: 39mm. Mounting Orientation: Side. Depth: 45mm. MPN: 9007C62B2, Telemecanique Sensors

Preventa XCS Safety Limit Switch, NO/NC, 1/2 in NPT. Lock Style: Elbowed Flush Lever. Maximum Current: 6 A. Maximum AC Voltage: 240V. Maximum DC Voltage: 250V. Trigger Angle Range: 5. Minimum Operating Temperature: -25°C. Maximum Operating Temperature: +70°C. MPN: XCSPL783, Telemecanique Sensors

Telemecanique Sensors XY2CZ9320 Rope Pull Kit, For Use With XY2C Rope Pull Switch. Size: 20.5m.

Telemecanique Sensors, M18 x 1, NO Inductive Sensor 55mm Length. Body Style: Barrel. Detection Range: 5 mm. Terminal Type: Cable. Supply Voltage: 24 → 210 V dc, 24 → 240 V ac. Maximum AC Voltage: 264V. Maximum DC Voltage: 264V. Mounting Type: Flush Mount. Switching Current: 200 (dc) mA, 300 (ac) mA. IP Rating: IP68. Housing Material: Nickel Plated Brass. Maximum Operating Temperature: +70°C. Maximum Switching Frequency: 2kHz. MPN: XS1M18MA250

Telemecanique Sensors Air, Fresh Water, Sea Water Differential Pressure Switch, 3NC. Pressure Range: 0.2 → 4.8 (Falling) bar, 1 → 6 (Rising) bar. Minimum Pressure Reading: 0.2 (Falling) bar, 1 (Rising) bar. Process Connection: G1/4. Maximum Pressure Reading: 4.8 (Falling) bar, 6 (Rising) bar. Electrical Connection: Screw Clamp. Minimum Operating Temperature: -25°C. Maximum Operating Temperature: +70°C. Accuracy:

PHOTOELECTRIC SENSOR, 120MM, NPN/PNP; Sensing Range Max:120mm; Sensing Method:Through Beam; Sensor Output:NPN / PNP; Product Range:OsiSense XU Series; Connection Method:M8 Connector; Supply Voltage DC Min:12V; Supply Voltage DC Max:24V; SVHC:No SVHC (15-Jan-2019)

PRESSURE SWITCH, DPDT-DB, 2000PSI, PANEL; Pressure Fitting Style:1/4"-18 NPTF; Operating Pressure Min:0psi; Operating Pressure Max:2000psi; Contact Configuration:DPDT-DB; Sensor Mounting:Panel Mount; Electrical Connection:Screw Clamp Terminals; Switching Voltage DC Resistive:250V; Switching Current DC Resistive:110mA; Product Range:9012G Series; SVHC:No SVHC (15-Jan-2019)

PRESSURE SWITCH, 2NC, 7BAR, PANEL; Pressure Fitting Style:G 1/4" BSP; Operating Pressure Min:2.8bar; Operating Pressure Max:7bar; Contact Configuration:2NC; Sensor Mounting:Panel Mount; Electrical Connection:Screw Clamp Terminals; Switching Voltage DC Resistive:250V; Switching Current DC Resistive:10A; Product Range:OsiSense XM Series; SVHC:No SVHC (15-Jan-2019)

INDUCTIVE PROXIMITY SENSOR, 5MM, 210V; Sensing Range Max:5mm; Thread Size - Metric:M18; Sensor Output:SPST-NO; Supply Voltage DC Min:24V; Supply Voltage DC Max:210V; Product Range:OsiSense XS Series; SVHC:No SVHC (15-Jan-2019)

INDUCTIVE PROXIMITY SENSOR, 4MM, 210V; Sensing Range Max:4mm; Thread Size - Metric:M12; Sensor Output:SPST-NO; Supply Voltage DC Min:24V; Supply Voltage DC Max:210V; Product Range:OsiSense XS Series; SVHC:No SVHC (15-Jan-2019)

INDUCTIVE PROXIMITY SENSOR, 8MM, 24V; Sensing Range Max:8mm; Thread Size - Metric:M18; Sensor Output:PNP; Supply Voltage DC Min:12V; Supply Voltage DC Max:24V; Product Range:OsiSense XS Series; SVHC:No SVHC (15-Jan-2019)

INDUCTIVE PROXIMITY SENSOR, 8MM, 48V; Sensing Range Max:8mm; Thread Size - Metric:M18; Sensor Output:PNP; Supply Voltage DC Min:12V; Supply Voltage DC Max:48V; Product Range:OsiSense XS Series; SVHC:No SVHC (15-Jan-2019)

SENSOR, INDUCT SN5MM; Sensing Range Max:5mm; Thread Size - Metric:-; Sensor Output:PNP; Supply Voltage DC Min:10V; Supply Voltage DC Max:36V; Product Range:OsiSense XS Series; SVHC:No SVHC (15-Jan-2019)

INDUCTIVE PROXIMITY SENSOR, 15MM, 36V; Sensing Range Max:15mm; Thread Size - Metric:-; Sensor Output:NPN; Supply Voltage DC Min:10V; Supply Voltage DC Max:36V; Product Range:OsiSense XS Series; SVHC:No SVHC (15-Jan-2019)
