SWITCH SIRIUS POSITION PLASTIC; Limit Switch Actuator:Plunger; Contact Configuration:1NO / 1NC; Contact Current AC Max:6A; Contact Voltage AC Max:230V; Operating Force Max:20N; Product Range:SIRIUS Series; Contact Current DC Max:3A; Contact Voltage DC Max:230V; SVHC:No SVHC (12-Jan-2017); Actuator Type:Pin Plunger; External Depth:33mm; External Length / Height:68mm; External Width:31mm; Height:68mm; IP / NEMA Rating:IP66 IP67; Insulation Voltage:400V; Switch Operation:Off-On; Switch Terminals:Screw

EMERGENCY MAIN SWITCH 3POLE; No. of Poles:3 Pole; Contact Voltage AC Max:690V; Contact Current AC Max:32A; Approvals / Standards:-; IP Rating:IP65; Product Range:3LD22 Series; SVHC:No SVHC (12-Jan-2017); Current Rating:32A; Insulation Resistance Voltage:690V; Operating Voltage:690VAC; Output Power Max:11.5kW; Power Rating:11.5kW; Voltage Rating:690V

SIRIUS SOFTSTARTER 3RW4028 38A; Supply Voltage Min:110VAC; Supply Voltage Max:230VAC; No. of Phases:Three; Power Rating:11kW; Current Rating:38A; Product Range:-; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CE EN EN IEC VDE; Control Voltage AC Max:230VAC; Control Voltage AC Min:110VAC; External Depth:149mm; External Length / Height:125mm; External Width:45mm; Input Voltage Max:480V; Input Voltage Min:200V; Load Current:38A; Load Current Max:38A; Load Current Min:23A; Output Power:11kW; Supply Voltage:220V; Supply Voltage Range:110V AC to 230V AC

SIRIUS SOFTSTARTER 22.5MM 3A 1.1KW; Supply Voltage Min:200VAC; Supply Voltage Max:480VAC; No. of Phases:Three; Power Rating:1.1kW; Current Rating:3A; Product Range:-; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CE CSA IEC UL; Control Voltage AC Max:230V; Control Voltage AC Min:110V; External Depth:120mm; External Length / Height:102mm; External Width:22.5mm; For Use With:Soft Starting of 3-phase Asynchronous Motor; Height:102mm; IP / NEMA Rating:IP20; Input Voltage Max:400V; Input Voltage Min:200V; Load Current:3A; Load Current Max:3A; Operating Temperature Max:60°C; Operating Temperature Min:-25°C; Operating Temperature Range:-25°C to +60°C; Output Power:1.1kW; Supply Voltage Range:200V AC to 480V AC

SIRIUS SOFTSTARTER S00 6.5A 3KW/400V; Supply Voltage Min:200VAC; Supply Voltage Max:480VAC; No. of Phases:Three; Power Rating:3kW; Current Rating:6.5A; Product Range:-; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CE CSA IEC UL; Control Voltage AC Max:230V; Control Voltage AC Min:110V; External Depth:93mm; External Length / Height:95mm; External Width:45mm; For Use With:Soft Starting of 3-phase Asynchronous Motor; IP / NEMA Rating:IP20; Input Voltage Max:480V; Input Voltage Min:200V; Load Current:6.5A; Load Current Max:6.5A; Operating Temperature Max:60°C; Operating Temperature Min:-25°C; Operating Temperature Range:-25°C to +60°C; Output Power:3kW; Supply Voltage Range:200V AC to 480V AC

PANEL MOUNT. DEVICE FOR ENERGY DISTR.; No. of Phases:Single Three; Supply Voltage:95VAC to 240VAC 110VDC to 340VDC; Energy Meter Mounting:Panel; Product Range:SENTRON PAC3200 Series; SVHC:No SVHC (12-Jan-2017); External Depth:56mm;;RoHS Compliant: Yes

AC/DC DIN Rail Power Supply SITOP Fixed 85 V 264 V 480 W 24 V 20 A ;RoHS Compliant: No

SPOOL OF CABLE 328 FT

CONTACTOR 12 AMP 120V COIL

RELAY 28-40 AMPS

Yellow Diffused T1 3/4 LED

HMI TOUCH PANEL 1280X800 PIXEL 15INCH; Meter Display Type:TFT; Display Size:331.2mm x 207mm; Display Resolution:1280 x 800 Pixels; Screen Size:15"; Supply Voltage Min:19.2VDC; Supply Voltage Max:28.8VDC; Operating Temperature Min:0°C; Operating Temperature Max:50°C; Product Range:SIMATIC TP1500 Comfort Series; SVHC:No SVHC (15-Jan-2018)

HMI TOUCH PANEL 1376X768 PIXEL 19INCH; Meter Display Type:TFT; Display Size:409.8mm x 230.4mm; Display Resolution:1366 x 768 Pixels; Screen Size:19"; Supply Voltage Min:19.2VDC; Supply Voltage Max:28.8VDC; Operating Temperature Min:0°C; Operating Temperature Max:45°C; Product Range:SIMATIC TP1900 Comfort Series; SVHC:No SVHC (15-Jan-2018)

TEXT DISPLAY 6 LINE 2 ETHERNET PORT; Current Rating:-; Product Range:-; SVHC:No SVHC (15-Jan-2018)

Siemens SIRIUS ACT 2 Position Key Switch Head Momentary. Cutout Diameter: 30mm. Key Type: Ronis. Key Withdrawal Position: Pos. O. IP Rating: IP20, IP66, IP67, IP69, IP69K. Angle of Throw: 45. MPN: 3SU1060-4LC01-0AA0

Siemens SIRIUS ACT 3 Position Key Switch Head Latching. Cutout Diameter: 30mm. Key Type: Ronis. Key Withdrawal Position: I, II, Pos. O. IP Rating: IP20, IP66, IP67, IP69, IP69K. Angle of Throw: 45. Number of Keys: 2. MPN: 3SU1060-4LL11-0AA0

Siemens SIRIUS ACT Series, Blue Push Button, Momentary, 30mm Cutout. Push Button Shape: Round. Push Button Style: Flush. Push Button Material: Plastic. IP Rating: IP66, IP67, IP69, IP69K. Push Button Marking: Unmarked. Push Button Diameter: 38mm. MPN: 3SU1061-0JB50-0AA0

Siemens SIRIUS ACT Series, Clear Push Button, Momentary, 30mm Cutout. Push Button Shape: Round. Push Button Style: Flush. Push Button Material: Plastic. IP Rating: IP66, IP67, IP69, IP69K. Push Button Marking: Unmarked. Push Button Diameter: 38mm. MPN: 3SU1061-0JB70-0AA0

Siemens SIRIUS ACT 3 Position Selector Switch Selector Switch Latching. Cutout Diameter: 30mm. IP Rating: IP66, IP67, IP69, IP69K. Angle of Throw: 45. Illuminated: Yes. MPN: 3SU1062-2DL60-0AA0

Siemens SIRIUS ACT Contact & Light Block NC 500 V ac/dc Screw terminal. Block Type: Contact Block. Current Rating: 10 A. MPN: 3SU1400-2AA10-1MA0
