SSR PANEL MOUNT 200VDC 32VDC 10A; Co; SSR PANEL MOUNT 200VDC 32VDC 10A; Contact Configuration:-; Load Current:10A; Operating Voltage Max:200VDC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:-; Operating Voltage Min:1VDC; Control Voltage Min:3VDC

SSR 660VAC 25A DC IN W/ LED ZC; Contact Configuration:-; Load Current:25A; Operating Voltage Max:660VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:48VAC; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Control Voltage DC Max:32VDC; Control Voltage DC Min:4VDC; Operating Temperature Max:80°C; Operating Temperature Min:-40°C

SSR PANEL MOUNT 660VAC 32VDC 125A; C; SSR PANEL MOUNT 660VAC 32VDC 125A; Contact Configuration:-; Load Current:125A; Operating Voltage Max:660VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Random Turn On; Operating Voltage Min:48VAC; Product Range:-

SOLID-STATE PANEL MOUNT RELAY 10-14VDC 10A; Contact Configuration:-; Load Current:10A; Operating Voltage Max:100VDC; Relay Mounting:Panel; Relay Terminals:Quick Connect; Switching Mode:DC Switch; Operating Voltage Min:3VDC

SOLID-STATE PANEL MOUNT RELAY 4-8VDC 5A; Contact Configuration:-; Load Current:5A; Operating Voltage Max:100VDC; Relay Mounting:Panel; Relay Terminals:Quick Connect; Switching Mode:DC Switch; Operating Voltage Min:3VDC

SSR PANEL MOUNT 280VAC 32VDC 25A; Contact Configuration:-; Load Current:25A; Operating Voltage Max:280VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24VAC; Product Range:-

SSR PANEL MOUNT 280VAC 280VAC 25A; Contact Configuration:-; Load Current:25A; Operating Voltage Max:280VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24VAC; Product Range:-

SSR DIN RAIL MOUNT 24VDC 30VDC 3.5A; Contact Configuration:SPST-NO; Load Current:3.5A; Operating Voltage Max:24VDC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:0VDC

SSR DIN RAIL MOUNT 280VAC 32VDC 5A; Contact Configuration:SPST-NO; Load Current:5A; Operating Voltage Max:280VAC; Relay Mounting:DIN Rail; Relay Terminals:Cage Clamp; Switching Mode:Random Turn On; Operating Voltage Min:12VAC

SSR DIN RAIL MOUNT 48VDC 30VDC 100mA; Contact Configuration:SPST-NO; Load Current:100mA; Operating Voltage Max:48VDC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:0VDC

SSR PANEL MOUNT 660VAC 32VDC 50A; Contact Configuration:-; Load Current:50A; Operating Voltage Max:660VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:48VAC; Product Range:-

SSR DIN RAIL MOUNT 280VAC 32VDC 5A; Contact Configuration:SPST-NO; Load Current:5A; Operating Voltage Max:280VAC; Relay Mounting:DIN Rail; Relay Terminals:Cage Clamp; Switching Mode:Zero Crossing; Operating Voltage Min:12VAC

SSR 530VAC/65A 3-32VDC IN RN; Contact Configuration:-; Load Current:65A; Operating Voltage Max:530Vrms; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:Random Turn On; Operating Voltage Min:48Vrms; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Blocking voltage:1200V; Control Current Typ:14mA; Control Voltage DC Max:32VDC; Control Voltage DC Min:4VDC; Control Voltage Range:4V DC to 32V DC; Control Voltage Type:DC; Operating Voltage Range:48Vrms to 530Vrms; Output Type:SCR; Peak Surge Current:1.2kA

SSR SIP 100VDC/6A 20-28VDC IN; Contact Configuration:-; Load Current:6A; Operating Voltage Max:-; Relay Mounting:PCB; Relay Terminals:Through Hole; Switching Mode:-; Operating Voltage Min:-; Control Voltage Min:-; Control Voltage Max:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Control Voltage Type:DC; Forward Current If:12mA; Input Current:12mA; Input Voltage:20V DC to 28V DC; Isolation Voltage:2.5kV; Load Current Min:0mA; Load Voltage Max:100VDC; Load Voltage Range:0V DC to 100V DC; On State Resistance Max:0.04ohm; Output Type:MOSFET

SSR SIP 60VDC/10A 20-28VDC IN; Contact Configuration:-; Load Current:10A; Operating Voltage Max:60VDC; Relay Mounting:PCB; Relay Terminals:Through Hole; Switching Mode:-; Operating Voltage Min:0VDC; Control Voltage Min:20VDC; Control Voltage Max:28VDC; Product Range:CMX Series; SVHC:No SVHC (07-Jul-2017); Control Voltage Type:DC; Forward Current If:12mA; Input Current:12mA; Input Voltage:20V DC to 28V DC; Isolation Voltage:2.5kV; Load Current Min:0mA; Load Voltage Max:60VDC; Load Voltage Range:0V DC to 60V DC; On State Resistance Max:0.018ohm; Output Type:MOSFET

SSR SIP 60VDC/5A 20-28VDC IN; Contact Configuration:-; Load Current:5A; Operating Voltage Max:60VDC; Relay Mounting:PCB; Relay Terminals:Through Hole; Switching Mode:-; Operating Voltage Min:0VDC; Control Voltage Min:20VDC; Control Voltage Max:28VDC; Product Range:CMX Series; SVHC:No SVHC (07-Jul-2017); Control Voltage Type:DC; Forward Current If:12mA; Input Current:12mA; Input Voltage:20V DC to 28V DC; Isolation Voltage:2.5kV; Load Current Min:0mA; Load Voltage Max:60VDC; Load Voltage Range:0V DC to 60V DC; On State Resistance Max:0.1ohm; Output Type:MOSFET

SSR 280VAC/125A 3-32VDC IN ZC OVP; Contact Configuration:-; Load Current:125A; Operating Voltage Max:280Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:-; Operating Voltage Min:24Vrms; Control Voltage Min:3VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Blocking voltage:600V; Control Voltage DC Max:32VDC; Control Voltage DC Min:3VDC; Control Voltage Range:3V DC to 32V DC; Control Voltage Type:DC; Isolation Voltage:4kV; Operating Voltage Range:24Vrms to 280Vrms; Output Type:SCR; Single Cycle Surge Current:1750A

SSR 60VDC/7A 90-280VAC NC; Contact Configuration:SPST-NC; Load Current:7A; Operating Voltage Max:60VDC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:AC Switch; Operating Voltage Min:3VDC; Control Voltage Min:90VAC; Control Voltage Max:280VAC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Control Current Typ:2mA; Control Voltage AC Max:280VAC; Control Voltage AC Min:90VAC; Control Voltage DC Max:280VDC; Control Voltage DC Min:90VDC; Control Voltage Range:90V DC to 280V DC 90V AC to 280V AC; Control Voltage Type:AC DC; Isolation Voltage:4kV; Operating Voltage Range:3V DC to 60V DC; Output Type:Bipolar Transistor; Surge Current:14A

SSR 660VAC/50A DC IN RN; Contact Configuration:-; Load Current:50A; Operating Voltage Max:660Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:-; Operating Voltage Min:48Vrms; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Blocking voltage:1200V; Control Voltage DC Max:32VDC; Control Voltage DC Min:4VDC; Control Voltage Range:4V DC to 32V DC; Control Voltage Type:DC; Isolation Voltage:4kV; Operating Voltage Range:48Vrms to 660Vrms; Output Type:SCR; Single Cycle Surge Current:625A

SSR PANEL MOUNT 530VAC 32VDC 75A; Contact Configuration:SPST-NO; Load Current:75A; Operating Voltage Max:530Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:48Vrms; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Blocking voltage:1200V; Control Voltage DC Max:32VDC; Control Voltage DC Min:3VDC; Control Voltage Range:3V DC to 32V DC; Control Voltage Type:DC; Isolation Voltage:4kV; Operating Voltage Range:48Vrms to 530Vrms; Output Type:SCR; Single Cycle Surge Current:1000A
