SSR PANEL MOUNT 280VAC 32VDC 10A; Contact Configuration:SPST-NO; Load Current:10A; Operating Voltage Max:280Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24Vrms; Control Voltage Min:3VDC; Control Voltage Max:32VDC; Product Range:T Series; SVHC:No SVHC (07-Jul-2017); Blocking voltage:500V; Control Voltage DC Max:32VDC; Control Voltage DC Min:3VDC; Control Voltage Range:3V DC to 32V DC; Control Voltage Type:DC; External Depth:22.2mm; External Diameter:4.4mm; External Length / Height:57.2mm; External Width:44.4mm; Fixing Centres:47.6mm; Isolation Voltage:4kV; Load Current Min:50mA; Load Current RMS Max:10A; Must Release Voltage:1V; Operating Voltage Range:24Vrms to 280Vrms; Output Type:Triac; RMS Load Current Min:40mA; RMS Load Voltage Max:280V; RMS Load Voltage Min:40V; Rate of Voltage Change dv / dt:500V/µs; Resistance:1500ohm; Single Cycle Surge Current:70A; Surge Current:120A

SSR 3A 3-32VDC 24-280VAC ZERO CROSS; Contact Configuration:SPST-NO; Load Current:3A; Operating Voltage Max:280Vrms; Relay Mounting:PCB; Relay Terminals:Through Hole; Switching Mode:Zero Crossing; Operating Voltage Min:24Vrms; Control Voltage Min:3VDC; Control Voltage Max:32VDC; Product Range:D2W Series; SVHC:No SVHC (07-Jul-2017)

SSR 3-15VDC 12-280VAC 25A; Contact Configuration:SPST-NO; Load Current:25A; Operating Voltage Max:280VAC; Relay Mounting:PCB; Relay Terminals:Through Hole; Switching Mode:Zero Crossing; Operating Voltage Min:12VAC; Control Voltage Min:3VDC; Control Voltage Max:15VDC; Product Range:PowerFin / PF Series; SVHC:No SVHC (12-Jan-2017)

SSR 7A 200VDC; Contact Configuration:SPST-NO; Load Current:7A; Operating Voltage Max:200VDC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:DC Switch; Operating Voltage Min:0VDC; Control Voltage Min:3.5VDC; Control Voltage Max:32VDC; Product Range:1-DC Series; SVHC:No SVHC (12-Jan-2017); Control Current Max:28mA; Control Current Typ:1.6mA; Control Voltage DC Max:32VDC; Control Voltage DC Min:3.5VDC; Control Voltage Range:3.5V DC to 32V DC; Control Voltage Type:DC; Isolation Voltage:2.5kV; Load Current Min:20mA; Load Current RMS Max:7A; Load Voltage DC Max:200V; On State Resistance Max:0.29ohm; Operating Voltage Range:0V DC to 200V DC; Output Type:MOSFET; RMS Load Voltage Max:200VDC; Surge Current:22A; Turn Off Time:1ms; Turn On Time:0.1ms

SSR 10A 240VAC; Contact Configuration:SPST-NO; Load Current:10A; Operating Voltage Max:280Vrms; Relay Mounting:DIN Rail; Relay Terminals:Cage Clamp; Switching Mode:Zero Crossing; Operating Voltage Min:24Vrms; Control Voltage Min:110VAC; Control Voltage Max:280VAC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Blocking voltage:600V; Control Current Min:2mA; Control Current Typ:4mA; Control Voltage AC Max:280VAC; Control Voltage AC Min:90VAC; Control Voltage Range:90V AC to 280V AC; Control Voltage Type:AC; External Depth:99mm; External Length / Height:81.3mm; External Width:22.4mm; Input Voltage Max:280V; Input Voltage Min:24V; Leakage Current:10mA; Load Current Max:10A; Load Current Min:150mA; Load Current RMS Max:10A; Operating Voltage Range:24Vrms to 280Vrms; Output Type:SCR; Peak Surge Current:120A; RMS Load Current Min:0.15A; RMS Load Voltage Max:280V; RMS Load Voltage Min:24V; Rate of Voltage Change dv / dt:200V/s; Single Cycle Surge Current:120A; Surge Current:120A

SSR 1A 240VAC; Contact Configuration:SPST-NO; Load Current:1A; Operating Voltage Max:280Vrms; Relay Mounting:PCB; Relay Terminals:Through Hole; Switching Mode:Zero Crossing; Operating Voltage Min:24Vrms; Control Voltage Min:4VDC; Control Voltage Max:10VDC; Product Range:-; SVHC:No SVHC (07-Jul-2017); Blocking voltage:600V; Control Current Typ:10mA; Control Voltage DC Max:10VDC; Control Voltage DC Min:4VDC; Control Voltage Range:4V DC to 10V DC; Control Voltage Type:DC; External Depth:5.08mm; External Length / Height:12.7mm; External Width:24.9mm; Input Voltage:4V DC to 10V DC; Isolation Voltage:2.5kV; Load Current Max:1A; Load Current Min:25mA; Load Current RMS Max:1A; Load Voltage Range:24Vrms to 280Vrms; Output Type:Triac; RMS Load Current Min:0.025A; RMS Load Voltage Max:280V; RMS Load Voltage Min:24V; Rate of Voltage Change dv / dt:200V/s; Surge Current:40A

SSR 25A 800VDC; Contact Configuration:SPST-NO; Load Current:25A; Operating Voltage Max:800VDC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:DC Switch; Operating Voltage Min:0VDC; Control Voltage Min:8VDC; Control Voltage Max:16VDC; Product Range:SSC Series; SVHC:No SVHC (12-Jan-2017); Control Voltage DC Max:16VDC; Control Voltage DC Min:8VDC; Control Voltage Range:8V DC to 16V DC; Control Voltage Type:DC; Current Rating:25A; External Depth:22.9mm; External Length / Height:47.5mm; External Width:45.7mm; Insulation Resistance:1000Mohm; Isolation Voltage:2.5kV; Leakage Current:0.3mA; Load Current Min:20mA; Load Current RMS Max:25A; Load Voltage DC Max:16VDC; Load Voltage DC Min:8VDC; Operating Temperature Max:80°C; Operating Temperature Min:-30°C; Operating Voltage Range:0V DC to 800V DC; Output Type:IGBT; RMS Load Current Min:20mA; RMS Load Voltage Max:800VDC; Resistance:780ohm; Single Cycle Surge Current:75A; Surge Current:75A; Turn Off Time:1.5ms; Turn On Time:1.5ms

SSR PANEL MOUNT 530VAC 36VAC 50A; Control Voltage Range:18Vrms to 36Vrms; Operating Voltage Range:48Vrms to 530Vrms; Contact Configuration:SPST-NO; Load Current:50A; Switching Mode:Zero Crossing; Relay Terminals:Screw Clamp

SSR PANEL MOUNT 280VAC 32VDC 25A; Co; SSR PANEL MOUNT 280VAC 32VDC 25A; Contact Configuration:SPST-NO; Load Current:25A; Operating Voltage Max:280Vrms; Relay Mounting:Panel; Relay Terminals:Screw Clamp; Switching Mode:Zero Crossing; Operating Voltage Min:24Vrms

Unspecified

SSR PANEL MOUNT 60VDC 32VDC 3A; Contact Configuration:SPST-NC; Load Current:3A; Operating Voltage Max:60VDC; Relay Mounting:Panel; Relay Terminals:Screw Clamp; Switching Mode:DC Switch; Operating Voltage Min:3VDC

SSR GN IP20 50A/240VAC DC IN RN; Contact Configuration:-; Load Current:50A; Operating Voltage Max:280VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Random Turn On; Operating Voltage Min:24VAC; Control Voltage Min:3VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Control Voltage AC Max:32V; Control Voltage AC Min:3V; Control Voltage DC Max:32VDC; Control Voltage DC Min:3VDC; Control Voltage Range:3V DC to 32V DC; Control Voltage Type:DC; Isolation Voltage:4kV; Operating Voltage Range:24V AC to 280V AC

SSR 50A 240VAC; Contact Configuration:SPST-NO; Load Current:50A; Operating Voltage Max:280VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24VAC; Control Voltage Min:90VAC; Control Voltage Max:280VAC; Product Range:1 Series; SVHC:No SVHC (07-Jul-2017); Blocking voltage:600V; Control Voltage AC Max:280Vrms; Control Voltage AC Min:90Vrms; Control Voltage Range:90Vrms to 280Vrms; Control Voltage Type:AC; External Depth:22.2mm; External Diameter:4.4mm; External Length / Height:57.2mm; External Width:44.4mm; Fixing Centres:47.6mm; Isolation Voltage:4kV; Load Current Min:40mA; Load Current RMS Max:50A; Must Release Voltage:10V; Operating Voltage Range:24Vrms to 280Vrms; Output Type:Thyristor; RMS Load Current Min:40mA; RMS Load Voltage Max:280V; RMS Load Voltage Min:24V; Rate of Voltage Change dv / dt:500V/µs; Resistance:60kohm; Single Cycle Surge Current:625A; Surge Current:625A

SSR PANEL MOUNT 280VAC 15VDC 18A; Contact Configuration:SPST-NO; Load Current:18A; Operating Voltage Max:280Vrms; Relay Mounting:Panel; Relay Terminals:Quick Connect; Switching Mode:Zero Crossing; Operating Voltage Min:24Vrms; Control Voltage Min:3VDC; Control Voltage Max:15VDC; Product Range:EZ Series; SVHC:No SVHC (12-Jan-2017); Blocking voltage:600V; Control Current Typ:15mA; Control Voltage DC Max:15VDC; Control Voltage DC Min:3VDC; Control Voltage Range:3V DC to 15V DC; Control Voltage Type:DC; External Depth:24.1mm; External Length / Height:66.8mm; External Width:38mm; Input Impedance:300ohm; Isolation Voltage:4kV; Load Current Min:150mA; Load Current RMS Max:18A; Operating Voltage Range:24Vrms to 280Vrms; Output Type:SCR; RMS Load Current Min:150mA; RMS Load Voltage Max:280V; RMS Load Voltage Min:24V; Rate of Voltage Change dv / dt:500V/µs; Single Cycle Surge Current:200A; Surge Current:200A

SSR TIME DELAY 6A 280VAC DIN RAIL; Operating Voltage Min:24VAC; Operating Voltage Max:280VAC; Control Voltage AC Min:90VAC; Control Voltage AC Max:140VAC; Control Voltage DC Max:140VDC; Timer Functions:One Shot; Load Current:6A

SSR TIME DELAY 6A 280VAC DIN RAIL; Operating Voltage Min:24VAC; Operating Voltage Max:280VAC; Control Voltage AC Min:90VAC; Control Voltage AC Max:140VAC; Control Voltage DC Max:140VDC; Timer Functions:Interval; Load Current:6A

SSR TIME DELAY 6A 280VAC DIN RAIL; Operating Voltage Min:24VAC; Operating Voltage Max:280VAC; Control Voltage AC Min:180VAC; Control Voltage AC Max:240VAC; Control Voltage DC Max:240VDC; Timer Functions:Multifunction

SOLID-STATE RELAYS 3A 200 VAC to 265VAC; Control Voltage Range:208V AC to 240V AC; Operating Voltage Min:24V AC; Operating Voltage Max:280V AC; Contact Configuration:-; Load Current:3A; Switching Mode:Zero Voltage Turn On

SSR DIN 48-600VDC 3A 4-32VDC; Contact Configuration:-; Load Current:3A; Operating Voltage Max:600VAC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:Random Turn On; Operating Voltage Min:48VAC; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Control Voltage DC Max:32VDC; Control Voltage DC Min:4VDC; Control Voltage Range:4V DC to 32V DC

SSR PANEL MOUNT 600VAC 32VDC 25A; Co; SSR PANEL MOUNT 600VAC 32VDC 25A; Contact Configuration:-; Load Current:25A; Operating Voltage Max:600Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:48Vrms; Depth:58.42mm
