SSR, 25A, 480VAC; Contact Configuration:SPST-NO; Load Current:25A; Operating Voltage Max:660Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:48Vrms; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CE, CSA, VDE; Approval Category:UL Recognised; Blocking voltage:1200V; Control Current Typ:10mA; Control Voltage DC Max:32VDC; Control Voltage DC Min:4VDC; Control Voltage Range:4V DC to 32V DC; Control Voltage Type:DC; External Depth:58.4mm; External Length / Height:33mm; External Width:45.7mm; I2t:1500s; Insulation Resistance:1000Mohm; Isolation Voltage:4kV; Leakage Current:1mA; Load Current Max:25A; Load Current Min:0.15A; Load Current RMS Max:25A; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Operating Voltage Range:48Vrms to 660Vrms; Output Type:SCR; RMS Load Current Min:0.15A; RMS Load Voltage Max:660V; RMS Load Voltage Min:48V; Surge Current:600A

SSR, 50A, 240VAC; Contact Configuration:SPST-NO; Load Current:50A; Operating Voltage Max:280Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:24Vrms; Control Voltage Min:90VAC; Control Voltage Max:280VAC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CE, CSA, VDE; Approval Category:UL Recognised; Blocking voltage:600V; Control Current Typ:6mA; Control Voltage AC Max:280Vrms; Control Voltage AC Min:90Vrms; Control Voltage Range:90Vrms to 280Vrms; Control Voltage Type:AC; External Depth:58.4mm; External Length / Height:33mm; External Width:45.7mm; I2t:3000s; Input Impedance:21.7kohm; Insulation Resistance:1000Mohm; Isolation Voltage:4kV; Leakage Current:1mA; Load Current Max:50A; Load Current Min:0.15A; Load Current RMS Max:50A; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Operating Voltage Range:24Vrms to 280Vrms; Output Type:SCR; RMS Load Current Min:0.15A; RMS Load Voltage Max:280V

Circuit Breaker Magnetic (Hydraulic Delay) AC DC Push-Pull Plunger Panel Mount

Rotary Encoder Incremental 600 Quadrature (Incremental) User Selectable

Rotary Encoder Optical Quadrature with Index (Incremental) User Selectable

Solid State SPST-NO (1 Form A) Hockey Puck

Resistive Sensor Linear Position Round Shaft Solder Lug

SSR RELAY SPST-NO 90A 48-140V

SSR RELAY SPST-NO 25A 48-140V

PROTECTIVE COVER ASSEMBLY

IC,Normally-Open Panel-Mount Solid-State Relay,1-CHANNEL,M:HL048HD4.3

IC,Normally-Open Panel-Mount Solid-State Relay,1-CHANNEL,M:HL048HD4.3

SSR RELAY PANEL MOUNT 60VDC5A

DIODE MODULE 600V 35A

SSR RELAY SPST-NO 20A 0-60V

RELAY SSR CONTACT 48VDC 40A 32V

SSR RELAY SPST-NO 50A 48-660V

I/O MODULE RACK 24 CHANNEL

SSR RELAY SPST-NO 1A 20-280V
