Bimetal Thermostat, Stainless Steel Probe, Hermetically Sealed , SPST, Isolated Case

Bimetal Thermostat, Stainless Steel Probe, Hermetically Sealed , SPST, Isolated Case

Bimetal Thermostat, Stainless Steel Probe, Hermetically Sealed , SPST, Isolated Case

Bimetal Thermostat, Stainless Steel Probe, Hermetically Sealed , SPST, Isolated Case

Bimetal Thermostat, Stainless Steel Probe, Hermetically Sealed , SPST, Isolated Case

Bimetal Thermostat, Stainless Steel Probe, Hermetically Sealed , SPST, Isolated Case

Bimetal Thermostat, Stainless Steel Probe, Hermetically Sealed , SPST, Isolated Case

Bimetal Thermostat, Stainless Steel Probe, Hermetically Sealed , SPST, Isolated Case

SSR 7A 100VDC; Load Current:7A; SVHC:No SVHC (19-Dec-2011); Control Current Max:28mA; Control Current Typ:1.6mA; Control Voltage DC Max:32V; Control Voltage DC Min:3.5V; Isolation Voltage:2.5kV; Load Current Min:20mA; Load Voltage DC Max:100V; On State Resistance Max:0.29ohm; Output Type:MOSFET; RMS Load Voltage Max:100VDC; RMS Load Voltage Min:0VDC; Single Cycle Surge Current:15A; Surge Current:15A; Turn Off Time:1ms; Turn On Time:0.1ms

SSR 1A 20-280VAC ZERO CROSSING; Contact Configuration:SPST-NO; Load Current:1A; Operating Voltage Max:280VAC; Relay Mounting:PCB; Relay Terminals:Through Hole; Switching Mode:Zero Crossing; Operating Voltage Min:20VAC; Control Voltage Min:3.5VDC; Control Voltage Max:10VDC; Product Range:DPA Series; SVHC:No SVHC (12-Jan-2017)

SOLID STATE RELAY 45A 4-32V DIN RAIL; SVHC:No SVHC (07-Jul-2017)

SSR 30A 240VAC; Contact Configuration:SPST-NO; Load Current:30A; Operating Voltage Max:280Vrms; Relay Mounting:DIN Rail; Relay Terminals:Cage Clamp; Switching Mode:Zero Crossing; Operating Voltage Min:24Vrms; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Blocking voltage:600V; Control Current Min:15mA; Control Current Typ:20mA; Control Voltage DC Max:32VDC; Control Voltage DC Min:4VDC; Control Voltage Range:4V DC to 32V DC; Control Voltage Type:DC; External Depth:99mm; External Length / Height:81.3mm; External Width:22.4mm; Input Voltage Max:280V; Input Voltage Min:24V; Leakage Current:10mA; Load Current Max:30A; Load Current Min:150mA; Load Current RMS Max:30A; Operating Voltage Range:24Vrms to 280Vrms; Output Type:SCR; Peak Surge Current:1.2kA; RMS Load Current Min:0.15A; RMS Load Voltage Max:280V; RMS Load Voltage Min:24V; Rate of Voltage Change dv / dt:500V/s; Single Cycle Surge Current:625A; Surge Current:625A

SSR SIP 200VDC/3A 3-10VDC IN; Contact Configuration:SPST-NO; Load Current:3A; Operating Voltage Max:200VDC; Relay Mounting:PCB; Relay Terminals:Through Hole; Switching Mode:DC Switch; Operating Voltage Min:0VDC; Control Voltage Min:3VDC; Control Voltage Max:10VDC; Product Range:CMX Series; SVHC:No SVHC (12-Jan-2017); Control Voltage DC Max:10VDC; Control Voltage DC Min:3VDC; Control Voltage Range:3V DC to 10V DC; Control Voltage Type:DC; Forward Current If:15mA; Input Current:15mA; Input Voltage:3V DC to 10V DC; Isolation Voltage:2.5kV; Load Current Min:0mA; Load Voltage Max:200VDC; Load Voltage Range:0V DC to 200V DC; On State Resistance Max:0.2ohm; Output Type:MOSFET

SSR 100A 3.5-32VDC 0-60VDC; Contact Configuration:SPST-NO; Load Current:100A; Operating Voltage Max:60VDC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:DC Switch; Operating Voltage Min:0VDC; Control Voltage Min:3.5VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017)

SSR PANEL MOUNT 100VDC 32VDC 60A; Contact Configuration:SPST-NO; Load Current:60A; Operating Voltage Max:100VDC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:DC Switch; Operating Voltage Min:0VDC; Depth:22.9mm

SSR 10A; Contact Configuration:-; Load Current:10A; Operating Voltage Max:280Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:-; Operating Voltage Min:24Vrms; Control Voltage Min:3VDC; Control Voltage Max:32VDC; Product Range:1 Series; SVHC:No SVHC (12-Jan-2017); Blocking voltage:600V; Control Voltage DC Max:32VDC; Control Voltage DC Min:3VDC; Control Voltage Range:3V DC to 32V DC; Control Voltage Type:DC; External Depth:22.2mm; External Diameter:4.4mm; External Length / Height:57.2mm; External Width:44.4mm; Fixing Centres:47.6mm; Input Voltage Max:32VDC; Input Voltage Min:4.5VDC; Isolation Voltage:4kV; Load Current Min:40mA; Load Current RMS Max:10A; Must Release Voltage:1V; Operating Voltage Range:24Vrms to 280Vrms; Output Type:Thyristor; RMS Load Current Min:40mA; RMS Load Voltage Max:280V; RMS Load Voltage Min:48V; Rate of Voltage Change dv / dt:500V/µs; Resistance:1500ohm; Single Cycle Surge Current:120A; Surge Current:120A

SSR 2A 24-280VAC 3-32VDC; Contact Configuration:SPST-NO; Load Current:2A; Operating Voltage Max:280VAC; Relay Mounting:PCB; Relay Terminals:Through Hole; Switching Mode:Zero Crossing; Operating Voltage Min:24VAC; Control Voltage Min:3VDC; Control Voltage Max:32VDC; Product Range:D2W Series; SVHC:No SVHC (07-Jul-2017); Blocking voltage:600V; Control Current @ 5VDC:3mA; Control Voltage DC Max:28VDC; Control Voltage DC Min:20VDC; Control Voltage Range:20V DC to 28V DC; Control Voltage Type:DC; External Depth:12mm; External Length / Height:30mm; External Width:43mm; Input Voltage:3V DC to 32V DC; Isolation Voltage:4kV; Load Current Max:2A; Load Current Min:60mA; Load Current RMS Max:2A; Load Voltage Range:24Vrms to 280Vrms; Operating Voltage Range:0V DC to 100V DC; Output Type:Triac; RMS Load Current Min:0.06A; RMS Load Voltage Max:280V; RMS Load Voltage Min:24V; Rate of Voltage Change dv / dt:200V/s; Surge Current:28A

SSR 40A 480VAC; Contact Configuration:SPST-NO; Load Current:40A; Operating Voltage Max:530Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:80Vrms; Control Voltage Min:3VDC; Control Voltage Max:32VDC; Product Range:D48 Series; SVHC:No SVHC (07-Jul-2017); Blocking voltage:800V; Control Voltage DC Max:32VDC; Control Voltage DC Min:3VDC; Control Voltage Range:3V DC to 32V DC; Control Voltage Type:DC; External Depth:22.2mm; External Diameter:4.4mm; External Length / Height:57.2mm; External Width:44.4mm; Fixing Centres:47.6mm; Isolation Voltage:4kV; Load Current Min:40mA; Load Current RMS Max:40A; Must Release Voltage:1V; Operating Voltage Range:80Vrms to 530Vrms; Output Type:Thyristor; RMS Load Current Min:40mA; RMS Load Voltage Max:530V; RMS Load Voltage Min:80V; Rate of Voltage Change dv / dt:500V/µs; Resistance:1500ohm; Single Cycle Surge Current:625A; Surge Current:625A

SOLID STATE RELAY 25A 3-32VDC PANEL; Contact Configuration:-; Load Current:25A; Operating Voltage Max:660VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Voltage Turn On; Operating Voltage Min:48VAC; Control Voltage Min:3VDC; Control Voltage Max:32VDC; Product Range:GN Series; SVHC:No SVHC (07-Jul-2017)

SOLID STATE RELAY 25A 18-36VAC PANEL; Contact Configuration:-; Load Current:25A; Operating Voltage Max:660VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Voltage Turn On; Operating Voltage Min:48VAC; Control Voltage Min:18VAC; Control Voltage Max:36VAC; Product Range:GN Series; SVHC:No SVHC (07-Jul-2017)
