SSR 60VDC/12A 4-32VDC IN 18MM; Contact Configuration:-; Load Current:12A; Operating Voltage Max:60VDC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:1VDC; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Control Voltage DC Max:32VDC; Control Voltage DC Min:4VDC; Control Voltage Range:4V DC to 32V DC; Control Voltage Type:DC; Operating Voltage Range:1V DC to 60V DC; Peak Surge Current:100A

SSR 48-600VAC 30A DIN RAIL; Contact Configuration:SPST-NO; Load Current:30A; Operating Voltage Max:600VAC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:Random Turn On; Operating Voltage Min:48VAC; Control Voltage Min:90VDC; Control Voltage Max:280VDC; Product Range:DR22 Series; SVHC:No SVHC (12-Jan-2017)

SSR DIN RAIL MOUNT 24VDC 12VDC 3.5A; Contact Configuration:SPST-NO; Load Current:3.5A; Operating Voltage Max:24VDC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:0VDC

SSR PANEL MOUNT 660VAC 32VDC 50A; Contact Configuration:SPST-NO; Load Current:50A; Operating Voltage Max:660VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:48VAC; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:H12WD Series; SVHC:No SVHC (07-Jul-2017); Blocking voltage:1200V; Control Voltage DC Max:32VDC; Control Voltage DC Min:4VDC; Control Voltage Range:4V DC to 32V DC; Control Voltage Type:DC; External Depth:22.2mm; External Diameter:4.4mm; External Length / Height:57.2mm; External Width:44.4mm; Fixing Centres:47.6mm; Isolation Voltage:4kV; Load Current Min:150mA; Load Current RMS Max:50A; Must Release Voltage:1V; Operating Voltage Range:48Vrms to 660Vrms; Output Type:Thyristor; RMS Load Current Min:150mA; RMS Load Voltage Max:660V; RMS Load Voltage Min:48V; Rate of Voltage Change dv / dt:500V/µs; Resistance:1500ohm; Single Cycle Surge Current:625A; Surge Current:625A

SSR 4-32VDC 48-530VAC 50A; Contact Configuration:SPST-NO; Load Current:50A; Operating Voltage Max:530VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Random Turn On; Operating Voltage Min:48VAC; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017)

SSR PANEL MOUNT 530VAC 32VDC 90A; Contact Configuration:SPST-NO; Load Current:90A; Operating Voltage Max:530Vrms; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Crossing; Operating Voltage Min:48Vrms; Control Voltage Min:4VDC; Control Voltage Max:32VDC; Product Range:HD Series; SVHC:No SVHC (12-Jan-2017); Blocking voltage:1200V; Control Voltage DC Max:32VDC; Control Voltage DC Min:3VDC; Control Voltage Range:3V DC to 32V DC; Control Voltage Type:DC; External Depth:22.2mm; External Diameter:4.4mm; External Length / Height:57.2mm; External Width:44.4mm; Fixing Centres:47.6mm; Isolation Voltage:4kV; Load Current Min:40mA; Load Current RMS Max:90A; Must Release Voltage:1V; Operating Voltage Range:48Vrms to 530Vrms; Output Type:Thyristor; RMS Load Current Min:40mA; RMS Load Voltage Max:530V; RMS Load Voltage Min:48V; Rate of Voltage Change dv / dt:500V/µs; Resistance:1500ohm; Single Cycle Surge Current:1200A; Surge Current:1200A

THERMAL TRANSFER PAD; Thickness:0.076mm; Conductive Material:-; Thermal Conductivity:1W/m.K; Thermal Impedance:0.03°C/W; Volume Resistivity:-; External Length:44.5mm; External Width:56.6mm; Product Range:HEAT SINKS HS Series; SVHC:No SVHC (12-Jan-2017); Operating Temperature Max:150°C; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +150°C

SSR 2A 12-280VAC RANDOM; Contact Configuration:SPST-NO; Load Current:2A; Operating Voltage Max:280Vrms; Relay Mounting:PCB; Relay Terminals:Through Hole; Switching Mode:Zero Crossing; Operating Voltage Min:24Vrms; Control Voltage Min:4VDC; Control Voltage Max:10VDC; Product Range:ASO Series; SVHC:No SVHC (07-Jul-2017); Blocking voltage:600V; Control Current Typ:10mA; Control Voltage DC Max:10VDC; Control Voltage DC Min:4VDC; Control Voltage Range:4V DC to 10V DC; Control Voltage Type:DC; External Depth:5.08mm; External Length / Height:12.7mm; External Width:24.9mm; Input Voltage:4V DC to 10V DC; Isolation Voltage:2.5kV; Load Current Max:2A; Load Current Min:60mA; Load Current RMS Max:2A; Load Voltage Range:12Vrms to 280Vrms; Output Type:Thyristor; RMS Load Current Min:0.06A; RMS Load Voltage Max:280V; RMS Load Voltage Min:12V; Rate of Voltage Change dv / dt:200V/s; Surge Current:120A

THYRISTOR MODULE; SCR Module Type:Bridge Rectifier Single Phase - SCR; Peak Repetitive Off-State Voltage Vdrm:600V; Gate Trigger Current Max Igt:60mA; Current It av:25A; On State RMS Current IT(rms):25A; Peak Non Rep Surge Current Itsm 50Hz:-; Holding Current Max Ih:-; Gate Trigger Voltage Max Vgt:2.5V; Operating Temperature Max:125°C; Product Range:-; SVHC:No SVHC (12-Jan-2017); Current Itsm:250A; No. of Pins:6Pins; Operating Temperature Min:-40°C; Repetitive Reverse Voltage Vrrm Max:600V; Thyristor Case:Module; Thyristor Case Style:Module; Thyristor Type:Thyristor / Diode Module

SSR 5A 380VAC; Contact Configuration:SPST-NO; Load Current:5A; Operating Voltage Max:530Vrms; Relay Mounting:PCB; Relay Terminals:Through Hole; Switching Mode:Zero Crossing; Operating Voltage Min:48Vrms; Control Voltage Min:15VDC; Control Voltage Max:32VDC; Product Range:CX Series; SVHC:No SVHC (07-Jul-2017); Approval Bodies:CSA VDE; Approval Category:UL Recognised; Blocking voltage:1200V; Control Current Typ:15mA; Control Voltage DC Max:32VDC; Control Voltage DC Min:15VDC; Control Voltage Range:15V DC to 32V DC; Control Voltage Type:DC; Current Load AC Max:5A; Dielectric Strength VAC:4000V; External Depth:7.6mm; External Length / Height:25.4mm; External Width:43.1mm; I2t:260s; Input Impedance:1500ohm; Input Voltage:15V DC to 32V DC; Leakage Current:0.1mA; Load Current Min:0.06A; Load Current RMS Max:5A; Load Voltage Range:48Vrms to 530Vrms; No. of Pins:4Pins; Operating Temperature Max:80°C; Operating Temperature Min:-30°C; Output Type:SCR; Pin Length:7.6mm; Surge Current:250A

SSR 7A 100VDC; Contact Configuration:SPST-NO; Load Current:7A; Operating Voltage Max:100VDC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:DC Switch; Operating Voltage Min:0VDC; Control Voltage Min:3.5VDC; Control Voltage Max:32VDC; Product Range:1-DC Series; SVHC:No SVHC (07-Jul-2017); Control Current Max:28mA; Control Current Typ:1.6mA; Control Voltage DC Max:32VDC; Control Voltage DC Min:3.5VDC; Control Voltage Range:3.5V DC to 32V DC; Control Voltage Type:DC; Isolation Voltage:2.5kV; Load Current Min:20mA; Load Current RMS Max:7A; Load Voltage DC Max:100V; On State Resistance Max:0.29ohm; Operating Voltage Range:0V DC to 100V DC; Output Type:MOSFET; RMS Load Voltage Max:100VDC; Single Cycle Surge Current:15A; Surge Current:15A; Turn Off Time:1ms; Turn On Time:0.1ms

SSR 100A 100V SIP; Contact Configuration:SPST-NO; Load Current:100A; Operating Voltage Max:100VDC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:DC Switch; Operating Voltage Min:0VDC; Control Voltage Min:3.5VDC; Control Voltage Max:32VDC; Product Range:1-DC Series; SVHC:No SVHC (12-Jan-2017); Control Current Max:28mA; Control Current Typ:1.6mA; Control Voltage DC Max:32VDC; Control Voltage DC Min:3.5VDC; Control Voltage Range:3.5V DC to 32V DC; Control Voltage Type:DC; Isolation Voltage:2.5kV; Load Current Min:20mA; Load Current RMS Max:100A; Load Voltage DC Max:100V; On State Resistance Max:0.005ohm; Operating Voltage Range:0V DC to 100V DC; RMS Load Voltage Max:100VDC; Single Cycle Surge Current:330A; Surge Current:330A; Turn Off Time:1ms; Turn On Time:0.1ms

RELAY SSR 40A; Contact Configuration:SPST-NO; Load Current:40A; Operating Voltage Max:100VDC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:DC Switch; Operating Voltage Min:0VDC; Control Voltage Min:3.5VDC; Control Voltage Max:32VDC; Product Range:1-DCL Series; SVHC:No SVHC (12-Jan-2017); Control Current @ 5VDC:10mA; Control Voltage DC Max:32VDC; Control Voltage DC Min:3.5VDC; Control Voltage Range:3.5V DC to 32V DC; Control Voltage Type:DC; External Depth:58.4mm; External Length / Height:23mm; External Width:45.7mm; Isolation Voltage:2.5kV; Leakage Current:0.3mA; Load Current RMS Max:40A; Load Voltage DC Max:100VDC; Load Voltage DC Min:0VDC; Operating Voltage Range:0V DC to 100V DC; RMS Load Current Min:0A; RMS Load Voltage Max:100VDC; Surge Current:106A

SSR CONTACTOR 530V 5A DIN RAIL; Load; SSR CONTACTOR 530V 5A DIN RAIL; Load Current:5A; Operating Voltage Max:530V; Control Voltage Max:140VAC; Switching Mode:Random Turn On; Contactor Mounting:DIN Rail Panel; Contactor Terminals:Screw; Operating Voltage Min:48V

SSR PANEL MOUNT 660VAC 32VDC 10A; Contact Configuration:-; Load Current:10A; Operating Voltage Max:660VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Random Turn On; Operating Voltage Min:48VAC; Product Ran

SSR Relay Panel Mount IP00 660VAC/50A DC In Zero Cross w/Standoffs RoHS Compliant: Yes

SSR PANEL MOUNT 280VAC 32VDC 25A; Contact Configuration:SPST-NO; Load Current:25A; Operating Voltage Max:280VAC; Relay Mounting:Panel; Relay Terminals:Quick Connect; Switching Mode:Zero Crossing; Operating Voltage Min:24VAC RoHS Compliant: Yes

IC Normally-Open Panel-Mount Solid-State Relay 1-CHANNEL M:HL063HD4.3

SOLID STATE RELAY SPST 4-32VDC PANEL; Contact Configuration:SPST-NO; Load Current:50A; Operating Voltage Max:660VAC; Relay Mounting:Panel; Relay Terminals:Screw; Switching Mode:Zero Voltage Turn On; Operating Voltage Min:48VAC RoHS Compliant: Yes

SOLID STATE RELAY 35A 90-140VAC DIN; Contact Configuration:SPST-NO; Load Current:35A; Operating Voltage Max:530VAC; Relay Mounting:DIN Rail; Relay Terminals:Cage Clamp; Switching Mode:Zero Voltage Turn On RoHS Compliant: Yes
