MTG 12.7/PMS VKA 12.85 BLACK

MTG CAP CONNECTOR

PMS IP40 KURZ/SHORT

LSH 6X6 SHORT TRAVEL SWITCH 5.0MM

LSH 6X6 SHORT TRAVEL SWITCH 9.50MM

LSH 6X6 SHORT TRAVEL SWITCH 12.5MM

FUSE 0.5A 600VAC SMT; Product Range:-; Fuse Current:500mA; Voltage Rating VAC:600VAC; Voltage Rating V DC:125VDC; Blow Characteristic:Time Delay; Fuse Case Style:SMD; Breaking Capacity Current AC:60A; Breaking Capacity Current DC:60A; SVHC:No SVHC (12-Jan-2017); Approval Category:UL Recognised; Breaking Capacity:60A @ 600V AC / 125V DC; Case Material:Ceramic; External Depth:10.1mm; External Length / Height:3.22mm; External Width:3.22mm; Flammability Rating:UL94V-1; Fuse Type Blowing Characteristic:Time Lag T; Internal Resistance:210mohm; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Standard:IEC 60127-4 UL 248-14 CSA C22.2 Telcordia GR-1089 UL 60950 / IEC 60950 IT-UT K.20 and K.21 TIA-968-A; Voltage Drop @ Rated Current:107mV

FUSE 1.25A 250VAC SMT; Product Range:UMT 250 Series; Fuse Current:1.25A; Voltage Rating VAC:250VAC; Voltage Rating V DC:125VDC; Blow Characteristic:Time Delay; Fuse Case Style:SMD; Breaking Capacity Current AC:200A; Breaking Capacity Current DC:100A; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CCC JET KTL PSE UMF VDE; Approval Category:UL Recognised; Breaking Capacity:200A @ 250V AC 100A @ 125V DC; Breaking Capacity Current UL:200A; Case Material:Ceramic; External Depth:3mm; External Length / Height:3mm; External Width:10.1mm; Flammability Rating:UL 94V - 1; Fuse Breaking Capacity Voltage AC:250VAC; Fuse Type Blowing Characteristic:Time Lag T; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Standard:IEC 60127-4 UL 248-14- CSA C22.2 no. 248.14; Voltage Drop @ Rated Current:300mV

FUSE 3.15A 250VAC SMT; Product Range:UMT 250 Series; Fuse Current:3.15A; Voltage Rating VAC:250VAC; Voltage Rating V DC:125VDC; Blow Characteristic:Time Delay; Fuse Case Style:SMD; Breaking Capacity Current AC:200A; Breaking Capacity Current DC:100A; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CCC JET KTL PSE UMF VDE; Approval Category:UL Recognised; Breaking Capacity:200A @ 250V AC 100A @ 125V DC; Breaking Capacity Current UL:200A; Case Material:Ceramic; External Depth:3mm; External Length / Height:3mm; External Width:10.1mm; Flammability Rating:UL 94V - 1; Fuse Breaking Capacity Voltage AC:250VAC; Fuse Type Blowing Characteristic:Time Lag T; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Standard:IEC 60127-4 UL 248-14- CSA C22.2 no. 248.14; Voltage Drop @ Rated Current:300mV

FUSE 4A 250VAC SMT; Product Range:UMT 250 Series; Fuse Current:4A; Voltage Rating VAC:250VAC; Voltage Rating V DC:125VDC; Blow Characteristic:Time Delay; Fuse Case Style:SMD; Breaking Capacity Current AC:200A; Breaking Capacity Current DC:100A; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CCC JET KTL PSE UMF VDE; Approval Category:UL Recognised; Breaking Capacity:200A @ 250V AC 100A @ 125V DC; Breaking Capacity Current UL:200A; Case Material:Ceramic; External Depth:3mm; External Length / Height:3mm; External Width:10.1mm; Flammability Rating:UL 94V - 1; Fuse Breaking Capacity Voltage AC:250VAC; Fuse Type Blowing Characteristic:Time Lag T; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Standard:IEC 60127-4 UL 248-14- CSA C22.2 no. 248.14; Voltage Drop @ Rated Current:300mV

FUSE PCB 1A 250V TIME DELAY; Fuse Current:1A; Voltage Rating VAC:250VAC; Product Range:MSU 250 Series; Voltage Rating VDC:125VDC; Blow Characteristic:Time Delay; Fuse Case Style:Radial Leaded; Breaking Capacity Current AC:35A ;RoHS Compliant: Yes

CIRCUIT BREAKER THERMAL 2P 240V 5A; Product Range:TA45 Series; Voltage Rating VAC:240VAC; Voltage Rating VDC:60VDC; Current Rating:5A; No. of Poles:2 Pole; Circuit Breaker Mounting:Panel; Operating Voltage:240V; Voltage AC:240V ;RoHS Compliant: Yes

IEC STYLE I (C20) REWIREABLE CONNECTOR

6100 APPLIANCE INLET 10A 70°C

6610 APPLIANCE OUTLET 10A 70°

Circuit Breaker Thermal 2Pole 8A 240VAC/60VDC

SWITCH SPNO SQUARE RED; Illumination:Non Illuminated; Contact Voltage DC Nom:48V; Contact Current Max:125mA; Operating Force:3N; Switch Terminals:Solder; Product Range:MCS18 Series; SVHC:No SVHC (12-Jan-2017); Actuation Type:Top; Actuator / Cap Colour:Red; Colour:Red; Contact Configuration:SPST-NO; Contact Current @ Contact Voltage DC Max:125mA; Contact Current DC Max:125mA; Contact Resistance:115mohm; Contact Voltage DC Max:48V; External Depth:18mm; External Length / Height:4.2mm; External Width:18mm; Lead Spacing:7.62mm; No. of Mechanical Operations:1000000; Operating Temperature Max:60°C; Operating Temperature Min:-25°C; Panel Cutout Diameter:13mm; Switch Operation:Off-(On)

SWITCH SPNO ROUND BLACK; Illumination:Non Illuminated; Contact Voltage DC Nom:48V; Contact Current Max:125mA; Operating Force:3N; Switch Terminals:Solder; Product Range:MCS18 Series; SVHC:No SVHC (12-Jan-2017); Actuation Type:Top; Actuator / Cap Colour:Black; Bezel Diameter:18mm; Colour:Black; Contact Configuration:SPST-NO; Contact Current @ Contact Voltage DC Max:125mA; Contact Current DC Max:125mA; Contact Resistance:115mohm; Contact Voltage DC Max:48V; External Depth:16mm; External Length / Height:4.2mm; Lead Spacing:7.62mm; No. of Mechanical Operations:1000000; Operating Temperature Max:60°C; Operating Temperature Min:-25°C; Panel Cutout Diameter:13mm; Switch Operation:Off-(On)

ADAPTOR STEREO PLUG TO STEREO RCPT; Audio Video Connector A:Stereo Plug - 3.5mm; Audio Video Connector B:Stereo Receptacle - 6.35mm; Product Range:-; SVHC:No SVHC (12-Jan-2017); Connector Colour:Black; Convert From Positions:3Ways; Convert To Positions:3Ways; External Length / Height:53mm

PLUG DIN SPEAKER ELBOW 2POLE; No. of Contacts:2Contacts; Gender:Plug; Connector Mounting:Cable Mount; Contact Plating:-; Connector Body Material:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Cable Diameter Max:6.3mm; Colour:Black; Connector Colour:Black; Connector Type:DIN Audio; Contact Resistance:4mohm; Contact Termination:Screw; DC Current Max:2A; External Length / Height:28.5mm; External Width:15mm; Operating Temperature Max:90°C; Operating Temperature Min:-25°C; Voltage Rating VAC:34V
