Unregulated DC/DC Power 1W Isolation 2kV dual output SIP7 Case

Unregulated DC/DC Power 1W Isolation 2kV dual output SIP7 Case

DC-DC CONVERTER MEDICAL 2 O/P 1W; No. of Outputs:2 Output; Output Power Max:1W; Output Voltage - Output 1:15V; Output Current - Output 1:33mA; Output Voltage - Output 2:-15V; Output Current - Output 2:33mA; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:RB Series; Input Voltage DC Min:4.5V; Input Voltage DC Max:5.5V; DC / DC Converter Output Type:Fixed; DC / DC Converter Type:SIP; DC / DC Converter Mounting:Through Hole; Approvals & Standards:CB IEC UL; Width:6mm; Height:10.2mm; Depth:19.6mm; SVHC:No SVHC (12-Jan-2017)

Unregulated DC/DC Power 1W Isolation 2kV dual output SIP7 Case

RB Series 1 W Dual Output -15 / 15 V DC/DC Converter - SIP-7

Unregulated DC/DC Power 1W Isolation 2kV dual output SIP7 Case

Unregulated DC/DC Power 1W Isolation 1kV dual output SIP7 Case

Unregulated DC/DC Power 1W Isolation 2kV dual output SIP7 Case

DC/DC CONVERTER 1W DUAL 5V; No. of Outputs:2 Output; Output Power Max:1W; Output Voltage - Output 1:5V; Output Current - Output 1:100mA; Output Voltage - Output 2:-5V; Output Current - Output 2:100mA; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:RB Series; Input Voltage DC Min:21.6V; Input Voltage DC Max:26.4V; DC / DC Converter Output Type:Fixed; DC / DC Converter Type:SIP; DC / DC Converter Mounting:Through Hole; Approvals & Standards:CSA IEC 60601 UL; Width:6mm; Height:10.2mm; Depth:19.6mm; SVHC:No SVHC (17-Dec-2015); Approval Bodies:EN UL; Isolation Voltage:1kV; No. of Outputs:2Outputs; Power Rating:1W

Unregulated DC/DC Power 1W Isolation 2kV dual output SIP7 Case

DC-DC CONVERTER MEDICAL 2 O/P 1W SIP; No. of Outputs:2 Output; Output Power Max:1W; Output Voltage - Output 1:15V; Output Current - Output 1:33mA; Output Voltage - Output 2:-15V; Output Current - Output 2:33mA; Width:-; Height:- ;RoHS Compliant: Yes

Unregulated DC/DC Power 1W Isolation 2kV dual output SIP7 Case

DC-DC CONVERTER MEDICAL 15V 0.066A; No. of Outputs:1 Output; Output Power Max:1W; Output Voltage - Output 1:15V; Output Current - Output 1:66mA; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:RBM Series; Input Voltage DC Min:4.5V; Input Voltage DC Max:5.5V; DC / DC Converter Output Type:Fixed; DC / DC Converter Type:SIP; DC / DC Converter Mounting:Through Hole; Approvals & Standards:-; Width:6mm; Height:7.7mm; Depth:16.55mm; SVHC:No SVHC (17-Dec-2015); Input Voltage:5V; MSL:MSL 1 - Unlimited

DC-DC CONVERTER MEDICAL 5V 0.2A; No. of Outputs:1 Output; Output Power Max:1W; Output Voltage - Output 1:5V; Output Current - Output 1:200mA; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:RBM Series; Input Voltage DC Min:10.8V; Input Voltage DC Max:13.2V; DC / DC Converter Output Type:Fixed; DC / DC Converter Type:SIP; DC / DC Converter Mounting:Through Hole; Approvals & Standards:-; Width:6mm; Height:7.7mm; Depth:16.55mm; SVHC:No SVHC (17-Dec-2015); Input Voltage:12V; MSL:MSL 1 - Unlimited

Unregulated DC/DC Power 1W Isolation 3kV dual output SIP6 Micro Case (Short Circuit Protection)

DC-DC CONVERTER MEDICAL 2 O/P 1W; No. of Outputs:2 Output; Output Power Max:1W; Output Voltage - Output 1:5V; Output Current - Output 1:100mA; Output Voltage - Output 2:-5V; Output Current - Output 2:100mA; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:RBM Series; Input Voltage DC Min:10.8V; Input Voltage DC Max:13.2V; DC / DC Converter Output Type:Fixed; DC / DC Converter Type:SIP; DC / DC Converter Mounting:Through Hole; Approvals & Standards:IEC 60601; Width:6mm; Height:7.7mm; Depth:16.55mm; SVHC:No SVHC (17-Dec-2015); Approval Bodies:EN 60601; Isolation Voltage:3kV; No. of Outputs:2Outputs; Power Rating:1W

Unregulated DC/DC Power 1W Isolation 2kV single output SIP7 Case

DC-DC CONVERTER MEDICAL 5V 0.2A SIP; DC / DC Converter Output Type:Fixed; No. of Outputs:1 Output; Input Voltage DC Min:2.97V; Input Voltage DC Max:3.63V; Output Power Max:1W; Output Voltage - Output 1:5V; Approvals & Standards:-;RoHS Compliant: Yes

Unregulated DC/DC Power 2W Isolation 2kV dual output SIP7 Case

Unregulated DC/DC Power 2W Isolation 2kV dual output SIP7 Case
