RF Amplifier DC-5GHz SSG 13.5dB NF 4dB SiGe

TRX, FSK, 2.4GHZ, 2.0MBPS, 32TQFP; Data Rate:2.048Mbps; RF / IF Modulation:FSK; Frequency Min:2.4GHz; Frequency Max:2.485GHz; Receiving Current:55mA; RF IC Case Style:TQFP; No. of Pins:32Pins; Supply Voltage Min:2.7V; Supply Voltage Max:4.5V; Transmitting Current:50mA; Output Power (dBm):3dBm; Sensitivity dBm:-80dBm; RF Transceiver Applications:Digital Cordless Telephones, Wireless Game Controllers, PC Peripherals & Streaming Media; Operating Temperature Min:-10°C; Operating Temperature Max:60°C; MSL:-; Frequency Range:2.4GHz to 2.485GHz; Modulation Type:FSK; Operating Temperature Range:-10°C to +60°C; Output Power:3dBm; Sensitivity:-89dBm; Supply Voltage Range:2.7V to 4.5V; Termination Type:Surface Mount Device

AMP, MMIC, GAAS, DC-12GHZ, 4MICRO-X; Frequency Min:0Hz; Frequency Max:12GHz; Gain:13dB; Noise Figure Typ:4.9dB; RF IC Case Style:Micro-X; No. of Pins:4Pins; Supply Voltage Min:4.4V; Supply Voltage Max:4.9V; Operating Temperature Min:-45°C; Operating Temperature Max:85°C; MSL:-; Frequency Range:0Hz to 12GHz; I/P VSWR:2; O / P VSWR:2; Operating Temperature Range:-45°C to +85°C; Power Dissipation Pd:350mW; RF Type:Cellular, DWDM, LMDS, PMP, PTP, UNII, VSAT, WLAN; Supply Current:50mA; Supply Voltage Range:4.4V to 4.9V; Termination Type:Surface Mount Device

AMP, MMIC, GAAS, DC-6GHZ, 4MICRO-X; Frequency Min:0Hz; Frequency Max:6GHz; Gain:17dB; Noise Figure Typ:4.1dB; RF IC Case Style:Micro-X; No. of Pins:4Pins; Supply Voltage Min:3.6V; Supply Voltage Max:4.2V; Operating Temperature Min:-45°C; Operating Temperature Max:85°C; MSL:-; Frequency Range:0Hz to 6GHz; I/P VSWR:1.75; O / P VSWR:2.2; Operating Temperature Range:-45°C to +85°C; Power Dissipation Pd:300mW; RF Type:Cellular, DWDM, LMDS, PMP, PTP, UNII, VSAT, WLAN; Supply Current:47mA; Supply Voltage Range:3.6V to 4.2V; Termination Type:Surface Mount Device

SWITCH, SPDT, GAAS, HI-PWR, 12QFN; Frequency Min:500MHz; Frequency Max:2.5GHz; RF IC Case Style:QFN; No. of Pins:12Pins; Supply Voltage Min:2.5V; Supply Voltage Max:5V; Operating Temperature Min:-40°C; Operating Temperature Max:100°C; MSL:-; Frequency Range:500MHz to 2.5GHz; Operating Temperature Range:-40°C to +100°C; RF Type:DCS, GSM, PCS; Supply Voltage Range:2.5V to 5V; Switch Operation:On-Off; Switching Speed:1µs; Termination Type:Surface Mount Device

AMP, CLASS AB, 3-3.8GHZ, 2W, 6SOF-26; Frequency Min:3GHz; Frequency Max:3.8GHz; Gain:12dB; Noise Figure Typ:5.1dB; RF IC Case Style:-; No. of Pins:6Pins; Supply Voltage Min:3V; Supply Voltage Max:6V; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; MSL:-; Frequency Range:3GHz to 3.8GHz; O / P VSWR:10; Operating Temperature Range:-40°C to +85°C; Power Dissipation Pd:6W; RF Type:IEEE802.16 WiMAX, WLL; Supply Current:326mA; Termination Type:Surface Mount Device

FRONT-END MODULE, RF, 802.11B/G, 16QFN; Frequency Min:2.4GHz; Frequency Max:2.5GHz; Supply Voltage Min:3V; Supply Voltage Max:5V; RF IC Case Style:QFN; No. of Pins:16Pins; MSL:-; Frequency Range:2.4GHz to 2.5GHz; RF Type:WLAN; Supply Voltage Range:3V to 5V; Termination Type:Surface Mount Device

Qorvo Parts replaced with ACT2802QL-T1026 or ACT2802CQL-T. 2.1A PowerPack with 0.55 MHz Boost switching

Signal Conditioning 70MHz BW 7MHz SAW Filter

RF Amplifier DC-4GHz SSG 20.8dB NF 3.4dB SiGe

Signal Conditioning 1950/60MHz SAW Filter

RF Amplifier 50-1200MHz NF 3.0dB OutLR15.5dB

Signal Conditioning 970MHz BW=18MHz SAW -40C +85C

RF Amplifier 12.5 - 17 GHz Ku Band 2W HPA

Signal Conditioning 1280 MHz BAW LAD Filter

RF Amplifier 40.5-43.5GHz Gn 23dB Pout 28.5 dBm

RF Amplifier .05-4GHz P1dB= 22dB Gain 26.4dB 5Volts

RF Amplifier 50-1000MHz 6 bit DSA

RF Amplifier DC to 4 GHz 120 W, 13 dBm, 48V

Signal Conditioning 140MHz BW 0.8MHz SAW Filter
