Components & parts from Powerex

SINGLE IGBT 1.2KV 600A; Transistor Polarity:N Channel; DC Collector Current:600A; Collector Emitter Saturation Voltage Vce(on):1.2kV; Power Dissipation Pd:3.785kW; Collector Emitter Voltage V(br)ceo:2.6V; No. of Pins:11 ;RoHS Compliant: Yes

Datasheet

T9K7400803DH

Part Number : T9K7400803DH

Powerex

THYRISTOR; SCR Module Type:Single SCR; Peak Repetitive Off-State Voltage Vdrm:4kV; Gate Trigger Current Max Igt:300mA; Current It av:800A; On State RMS Current IT(rms):1.25kA; Gate Trigger Voltage Max Vgt:4.5V; Product Range:- ;RoHS Compliant: Yes

Datasheet

R6000630XXYA

Part Number : R6000630XXYA

Powerex

DIODE MODULE SINGLE 600V 300A; Repetitive Reverse Voltage Vrrm Max:600V; Forward Current If(AV):300A; Forward Voltage VF Max:1.4V; Diode Module Configuration:Single; Packaging:Each; Product Range:- ;RoHS Compliant: Yes

Datasheet

PS22054

Part Number : PS22054

Powerex

INTELLIGENT POWER MODULE IGBT 15A 1.2KV DIP; IPM Power Device:IGBT; Voltage Rating (Vces / Vdss):-; Current Rating (Ic / Id):15A; Isolation Voltage:2.5kV; IPM Case Style:DIP; IPM Series:Intellimod; Product Range:- ;RoHS Compliant: Yes

Datasheet

CM100TU-12F

Part Number : CM100TU-12F

Powerex

IGBT MODULE 600V 100A; Transistor Polarity:N Channel; DC Collector Current:100A; Collector Emitter Saturation Voltage Vce(on):600V; Power Dissipation Pd:350W; Collector Emitter Voltage V(br)ceo:600V; No. of Pins:17; Packaging:Each ;RoHS Compliant: Yes

Datasheet

PM100RSD060

Part Number : PM100RSD060

Powerex

IGBT MODULE 600V 100A; Transistor Polarity:-; DC Collector Current:100A; Collector Emitter Saturation Voltage Vce(on):600V; Power Dissipation Pd:328W; Collector Emitter Voltage V(br)ceo:600V; No. of Pins:25Pins; Product Range:- ;RoHS Compliant: Yes

Datasheet

R7000205XXUA

Part Number : R7000205XXUA

Powerex

RECTIFIER STANDARD SINGLE 200V 500A DO-205AD; Repetitive Reverse Voltage Vrrm Max:200V; Forward Current If(AV):500A; Forward Voltage VF Max:1.2V; Diode Module Configuration:-; Packaging:Each; Product Range:-; No. of Pins:2Pins ;RoHS Compliant: Yes

Datasheet

TA20181803DH

Part Number : TA20181803DH

Powerex

THYRISTOR SCR 1.8KA 1.8KV TO-200AD; SCR Module Type:Single SCR; Peak Repetitive Off-State Voltage Vdrm:1.8kV; Gate Trigger Current Max Igt:3mA; Current It av:1.8kA; On State RMS Current IT(rms):2.82kA; Product Range:- ;RoHS Compliant: Yes

Datasheet

CM400DY-24A

Part Number : CM400DY-24A

Powerex

IGBT MODULE 1.2KV 400A; Transistor Polarity:N Channel; DC Collector Current:400A; Collector Emitter Saturation Voltage Vce(on):1.2kV; Power Dissipation Pd:2.71kW; Collector Emitter Voltage V(br)ceo:1.2kV; No. of Pins:7 ;RoHS Compliant: Yes

Datasheet

ND430821

Part Number : ND430821

Powerex

THYRISTOR SCR 210A 800V MODULE; SCR Module Type:Series Connected - SCRs; Peak Repetitive Off-State Voltage Vdrm:800V; Gate Trigger Current Max Igt:150mA; Current It av:210A; On State RMS Current IT(rms):330A; Product Range:-

Datasheet

CM600HU-24H

Part Number : CM600HU-24H

Powerex

IGBT MODULE 1.2KV 600A; Transistor Polarity:N Channel; DC Collector Current:600A; Collector Emitter Saturation Voltage Vce(on):2.9V; Power Dissipation Pd:3.1kW; Collector Emitter Voltage V(br)ceo:1.2kV; No. of Pins:4 ;RoHS Compliant: Yes

Datasheet

C152PB

Part Number : C152PB

Powerex

SILICON CONTROLLED RECTIFIER 1.2kV V(DRM) 70A I(T) TO-208AD ;RoHS Compliant: Yes

Datasheet

T600121804BT

Part Number : T600121804BT

Powerex

THYRISTOR 275A 1.2kV TO-93; SCR Module Type:Single SCR; Peak Repetitive Off-State Voltage Vdrm:1.2kV; Gate Trigger Current Max Igt:150mA; Current It av:175A; On State RMS Current IT(rms):275A; Gate Trigger Voltage Max Vgt:3V ;RoHS Compliant: Yes

Datasheet
