DISC MAGNET STEPPERS Holding Torque Typical(mNm): 60

STEPPER LINEAR ACTUATORS Max. Travel @ 0.001inch (0.0254 mm) / Step(in): 1.9

STEPPER LINEAR ACTUATORS Max. Travel @ 0.001inch (0.0254 mm) / Step(in): 0.5

GEARHEAD Nominal Torque(mNm): 120

GEARHEAD Nominal Torque(mNm): 0.5

ENCODER Integrated magnetic encoder

DRIVE Logic Voltage (separate supply)(Vdc)12 to 45

DRIVE Logic Voltage (separate supply)(Vdc)10 to 36

Brushed DC Motor Standard 10000 RPM 24W 24VDC

ACTUATOR LINEAR 8.9N; Supply Voltage V DC:12V; No. of Phases:Four; Power Rating:-; Rotational Speed Max:-; Torque Max:8.9N-m; Product Range:26DBM Series; SVHC:No SVHC (12-Jan-2017); Body Diameter:12.03mm; External Depth:36.49mm; External Diameter:26mm; External Width:42.82mm; Fixing Centres:34.9mm; Fixing Hole Diameter:3.3mm; Holding Torque:2.8N-m; Stroke Length Max:48mm; Termination Type:Wire Leaded; Torque:8.9N-m; Voltage Rating V DC:12V

STEPPER MOTOR TIN CAN; Coil Type:-; Torque Max:-; Current Rating:-; No. of Phases:Four; Resistance:-; Inductance:36.5mH; Inertia:1.1g-cm²; Product Range:-; SVHC:No SVHC (12-Jan-2017); Current per Phase:100mA; External Depth:13.72mm; External Diameter:26.2mm; Fixing Centres:35mm; Fixing Hole Diameter:3.3mm; Flange Width:42.8mm; Holding Torque:0.9N-cm; Indexing Angle:7.5°; Phase Resistance:110ohm; Shaft Diameter:2mm; Shaft Length:11.3mm; Termination Type:Wire Leaded

STANDARD MOTOR 10000 RPM 6VDC

STANDARD MOTOR 8900 RPM 9VDC

STANDARD MOTOR 9700 RPM 12VDC

STANDARD MOTOR 10000 RPM 18VDC

STEPPER MOTOR PM BIPOLAR 5V

STEPPER MOTOR PM GEARED UNI 12V

Brush DC Motors No load speed(rpm): 11760

Brush DC Motors No load speed(rpm): 9640

Brush DC Motors No load speed(rpm): 6200
