PHOTOSWITCH PNP; Sensor Output:PNP; Sensing Range Max:4m; Supply Voltage DC Min:10V; Supply Voltage DC Max:30V; Output Current:100mA; Product Range:-; Approval Bodies:CSA UL; External Length / Height:65mm; IP / NEMA Rating:IP66; Operating Temperature Max:55°C; Operating Temperature Min:-25°C; Output Current Max:100mA; Response Time:2.5ms; Sensing Distance Max:2m; Sensing Distance Min:0mm; Sensing Range:100mm to 4m; Sensor Input:Optical; Supply Voltage AC Max:240V; Supply Voltage Range DC:10V to 30V; Thread Size:M18

PHOTOSWITCH NPN; Sensor Output:NPN; Sensing Range Max:0.1m; Supply Voltage DC Min:10V; Supply Voltage DC Max:30V; Output Current:100mA; Product Range:-; Approval Category:UL Listed; Sensing Range:0mm to 100mm; Supply Current:25mA; Supply Voltage AC Max:240V; Supply Voltage Range DC:10V to 30V

PHOTOSWITCH DIFFUSE PNP; Sensing Range Max:200mm; Sensing Method:Diffuse; Sensor Output:PNP; Product Range:E3S-A Series; Connection Method:Cable; Supply Voltage DC Min:10V; Supply Voltage DC Max:30V; Current Consumption:30mA; External Depth:40mm; External Length / Height:22.3mm; External Width:12.4mm; IP / NEMA Rating:IP67; Lead Length:2m; Operating Temperature Max:55°C; Operating Temperature Min:-25°C; Output Current Max:100mA; Response Time:0.5ms; Sensing Distance Max:200mm; Sensing Distance Min:0mm; Sensing Range:0mm to 200mm; Sensor Input:Optical; Supply Voltage Range DC:10V to 30V

LEVEL CONTROLLER; Supply Voltage:240VAC; Response Time:80ms; Power Consumption:3.5VA; Product Range:-; Approval Bodies:CE CSA UL; Dielectric Strength VAC:2000VAC; External Depth:70mm; External Length / Height:50mm; External Width:38mm; Insulation Resistance:100Mohm; Operating Temperature Max:55°C; Operating Temperature Min:-10°C; Output Current Max:3A; Output Voltage Max:250VAC; Response Time Max:160ms; Response Time Min:80ms; Supply Voltage Max:240VAC; Supply Voltage Min:24VAC

SOCKET DIN/SURFACE 61FGPN; Socket Mounting:DIN Rail Panel; Socket Terminals:Screw; No. of Pins:8Pins; Current Rating:10A; Voltage Rating:-; Product Range:-; Accessory Type:Socket; External Depth:51mm; External Length / Height:24mm; External Width:93mm; Type:Front Connecting Socket

ELECTRODE HOLDER; Current Rating:-; Product Range:-; Accessory Type:Electrode Holder; External Depth:80mm; External Length / Height:60mm; For Use With:Water Supply and Drainage Control in Buildings; Length:60mm; No. of Channels:3Channels; Operating Temperature Max:70°C; Operating Temperature Min:-10°C

ELECTRODE CONNECTOR; Current Rating:-; Product Range:-; Accessory Type:Electrode Connector; External Width:11.5mm; For Use With:Conductive Level Controllers; Length:20mm

PHOTOSWITCH FIBRE PNP; Sensing Range Max:-; Fibre Optic Sensor Type:Standard; Product Range:E3X-DA-S Series; Output Current:50mA; Response Time:1ms; Supply Voltage DC Max:24VDC

INDUCTIVE PROXIMITY SENSOR; Sensing Range Max:1.5mm; Thread Size - Metric:-; Sensor Output:SPST-NO; Supply Voltage DC Min:10V; Supply Voltage DC Max:30V; Product Range:E2EC Series; Load Current RMS Max:100mA; Sensor Input:Inductive

RELAY DPDT 120VAC 28VDC 15A; Contact Configuration:DPDT; Coil Voltage:120VAC; Contact Current:15A; Product Range:LY Series; Relay Mounting:Through Hole; Coil Type:Non Latching; Contact Voltage VAC:120VAC; Relay Terminals:Solder

STARTER KIT; Current Rating:-; Product Range:-; Accessory Type:Starter Kit; External Depth:85mm; External Length / Height:90mm; External Width:86mm; For Use With:CP1L Compact Machine Controller; Input:4 x Encoder 4 x Interrupts/Counters; No. of Inputs:8; No. of Outputs:6Outputs; Operating Temperature Max:55°C; Operating Temperature Min:0°C; Supply Voltage AC Max:264VAC; Supply Voltage AC Min:85VAC; Supply Voltage Max:24VDC

STARTER KIT; Current Rating:-; Product Range:-; Accessory Type:Starter Kit; External Depth:85mm; External Length / Height:90mm; External Width:86mm; For Use With:CP1L PLC; Input:4 x Encoder 4 x Interrupts/Counters; No. of Inputs:8; No. of Outputs:6Outputs; Operating Temperature Max:55°C; Operating Temperature Min:0°C; Supply Voltage DC Max:26.4VDC; Supply Voltage DC Min:20.4VDC

SENSOR PROXIMITY INDUCTIVE; Sensing Range Max:1mm; Thread Size - Metric:M5; Sensor Output:PNP; Supply Voltage DC Min:10V; Supply Voltage DC Max:30V; Product Range:E2E Series; Frequency Response Max:3kHz; Sensor Input:Inductive; Supply Voltage Range DC:10V to 30V

RELAY DPDT 250VAC 30VDC 10A; Contact Configuration:DPDT; Coil Voltage:120VAC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Contact Voltage VDC:30VDC

RELAY DPDT 250VAC 30VDC 10A; Contact Configuration:DPDT; Coil Voltage:120VAC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Contact Voltage VDC:30VDC

RELAY 3PDT 250VAC 30VDC 10A; Contact Configuration:3PDT; Coil Voltage:120VAC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Contact Voltage VDC:30VDC

RELAY 3PDT 250VAC 30VDC 10A; Contact Configuration:3PDT; Coil Voltage:120VAC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Contact Voltage VDC:30VDC

CONTROLLER TEMP CURRENT; Thermocouple Type:B E J K L N R S T W PLII; Operating Temperature Max:55°C; Operating Temperature Min:-10°C; Temperature Accuracy ±:-; Output Voltage Max:-; Output Voltage Min:-; Product Range:-; Accuracy:0.1%; Approval Bodies:CE; Approval Category:UL Recognised; Colour:Black; External Depth:91mm; External Length / Height:48mm; External Width:48mm; Input:Thermocouple PRT Current or Voltage; No. of Inputs:2; No. of Outputs:3Outputs; Output:2 x Auxiliary; Output Type:Current; Power Consumption:8.5VA; Storage Temperature Max:65°C; Storage Temperature Min:-25°C; Supply Voltage Max:240VAC; Supply Voltage Min:100VAC

CONTROLLER TEMP RELAY; Thermocouple Type:B E J K L N R S T W PLII; Operating Temperature Max:55°C; Operating Temperature Min:-10°C; Temperature Accuracy ±:-; Output Voltage Max:250VAC; Output Voltage Min:5V; Product Range:-; Accuracy:0.1%; Approval Bodies:CE; Approval Category:UL Recognised; Colour:Black; External Depth:91mm; External Length / Height:48mm; External Width:48mm; Input:Thermocouple PRT Current or Voltage; No. of Inputs:2; No. of Outputs:3Outputs; Output:2 x Auxiliary; Output Contact:SPST-NO 250V ac 3A; Output Type:Relay; Power Consumption:5.5VA; Storage Temperature Max:65°C; Storage Temperature Min:-25°C; Supply Voltage:24V

CONTROLLER TEMP CURRENT; Thermocouple Type:B E J K L N R S T W PLII; Operating Temperature Max:55°C; Operating Temperature Min:-10°C; Temperature Accuracy ±:-; Output Voltage Max:-; Output Voltage Min:-; Product Range:-; Accuracy:0.1%; Approval Bodies:CE; Approval Category:UL Recognised; Colour:Black; External Depth:91mm; External Length / Height:48mm; External Width:48mm; Input:Thermocouple PRT Current or Voltage; No. of Inputs:2; No. of Outputs:3Outputs; Output:2 x Auxiliary; Output Type:Current; Power Consumption:5.5VA; Storage Temperature Max:65°C; Storage Temperature Min:-25°C; Supply Voltage:24V
