AC-DC CONVERTER DIN RAIL 1 O/P 30W 1.3A 24V; Power Supply Output Type:Fixed; Input Voltage AC Min:85V; Input Voltage AC Max:264V; No. of Outputs:1; Output Current Max:1.3A; Output Power Max:30W; Approvals / Standards:-

AC-DC CONVERTER DIN RAIL 1 O/P 120W 5A 24V; No. of Outputs:1 Output; Output Power Max:120W; Output Voltage - Output 1:24VDC; Output Current - Output 1:5A; Output Voltage - Output 2:-; Output Current - Output 2:-; Product Range:-

LIMIT SWITCH ROLLER LEVER; Limit Switch Actuator:Roller Lever; Contact Configuration:1NO / 1NC; Contact Current AC Max:10A; Contact Voltage AC Max:240V; Operating Force Max:5N; Product Range:D4N Series; Contact Current DC Max:2.5A; Contact Voltage DC Max:250V; Actuator Type:Roller Lever; Approval Bodies:EIC EN IEC VDE; Colour:Black; Contact Current Rating:10A; Contact Resistance:25mohm; External Depth:31mm; External Length / Height:55mm; External Width:31mm; Fixing Centres LxW:47 x 22 mm; IP / NEMA Rating:IP67; Insulation Resistance:100Mohm; Insulation Voltage:300V; No. of Electrical Operations:500000; No. of Mechanical Operations:15000000; Operating Temperature Max:70°C; Operating Temperature Min:-30°C; Return Force Min:0.5N; Switch Operation:Off-On; Switch Terminals:Screw; Thermal Current Rating:10A

TOTALIZER DISPLAY PANEL; Supply Voltage Min:24VAC; Supply Voltage Max:240VAC; Time Min:0s; Time Max:999999.9h; Panel Cutout Height:22.2mm; Panel Cutout Width:45mm; Digit Height:8.6mm; IP / NEMA Rating:IP66 NEMA 4; Reset Time:20ms

DIGITAL GENERAL PURPOSE TIMER; No. of Digits / Alpha:-; Supply Voltage Min:-; Supply Voltage Max:24VDC; Panel Cutout Height:22.2mm; Panel Cutout Width:45mm; Operating Temperature Min:-10 C; Operating Temperature Max:55 C; Time Min:0s

PHOTOELECTRIC SENSOR; Sensing Range Max:15mm; Sensor Output:NPN; Supply Voltage DC Min:12V; Supply Voltage DC Max:24V; Output Current:50mA

RELAY SOCKET; Socket Mounting:DIN Rail Panel; Socket Terminals:Screw; No. of Pins:8; Accessory Type:Front Connecting Socket; Current Rating:6A; For Use With:Omron H3CR-F Series Solid State Twin Timers; Voltage Rating:240VAC

RELAY SOCKET; Socket Mounting:Panel; Socket Terminals:Screw; No. of Pins:8Pins; Voltage Rating:240VAC; Product Range:-; Accessory Type:Back Connecting Socket; For Use With:Omron E5C2 Series Temperature Controllers

PHOTOELECTRIC SENSOR; Fibre Optic Sensor Type:Standard Fibre Optic Sensor; Output Current:50mA; Sensor Output:NPN; Supply Voltage Max:24V; Supply Voltage Min:12V

RELAY DPDT 120VAC 28VDC 15A; Contact Configuration:DPDT; Coil Voltage:12VDC; Contact Current:15A; Product Range:LY Series; Relay Mounting:Panel; Coil Type:Non Latching; Contact Voltage VAC:120VAC; Relay Terminals:Solder

ENCODER ROTARY; Supply Voltage Min:4.5V; Supply Voltage Max:13.2V; No. of Channels:2Channels; Rotational Speed Max:5000rpm; Product Range:-; Body Diameter:25mm; Connector Type:Cable; Current Consumption:20mA; Encoder Resolution:100; External Length / Height:31mm; Lead Length:0.5m; No. of Pulses Per Revolution:100; Operating Temperature Max:55°C; Operating Temperature Min:-10°C; Operating Temperature Range:-10°C to +55°C; Pulse Output Count:100; Rotational Speed:5000rpm; Shaft Diameter:4mm; Shaft Length:8mm; Torque:1mN-m

PROXIMITY SWITCH M12 NPN; Sensing Range Max:5mm; Thread Size - Metric:-; Sensor Output:SPST-NO; Supply Voltage DC Min:10V; Supply Voltage DC Max:40V; Product Range:E2E Series; Frequency Response Max:0.4kHz; Sensing Range:0mm to 5mm; Sensor Input:Inductive; Supply Voltage Range DC:10V to 40V

PHOTOSWITCH PNP; Sensor Output:PNP; Sensing Range Max:0.1m; Supply Voltage DC Min:10V; Supply Voltage DC Max:30V; Output Current:100mA; Product Range:-; Approval Bodies:CSA UL; External Length / Height:65mm; IP / NEMA Rating:IP66; Operating Temperature Max:55°C; Operating Temperature Min:-25°C; Output Current Max:100mA; Response Time:2.5ms; Sensing Distance Max:100mm; Sensing Distance Min:0mm; Sensing Range:0mm to 100mm; Sensor Input:Optical; Supply Voltage AC Max:240V; Supply Voltage Range DC:10V to 30V; Thread Size:M18

PHOTOSWITCH DIFFUSE NPN; Sensing Range Max:100mm; Sensing Method:Diffuse; Sensor Output:NPN; Product Range:-; Connection Method:Cable; Supply Voltage DC Min:12V; Supply Voltage DC Max:24V; Approval Bodies:UL; Current Consumption:40mA; External Depth:50mm; External Length / Height:21mm; External Width:15mm; IP / NEMA Rating:IP65; Lead Length:2m; Load Current Max:80mA; Material:Plastic; Operating Temperature Max:55°C; Operating Temperature Min:-25°C; Output Current Max:0.08A; Response Time:1ms; Sensing Distance Max:100mm; Sensing Distance Min:0mm; Sensing Range:0mm to 100mm; Sensor Input:Optical; Supply Voltage Range DC:12V to 24V

PHOTOSWITCH POL REFLEX PNP; Sensing Range Max:2m; Sensing Method:Retroreflective; Sensor Output:PNP; Product Range:-; Connection Method:Cable; Supply Voltage DC Min:10V; Supply Voltage DC Max:30V; Current Consumption:30mA; External Depth:42.3mm; External Length / Height:22.3mm; External Width:12.4mm; IP / NEMA Rating:IP67; Lead Length:2m; Operating Temperature Max:55°C; Operating Temperature Min:-25°C; Output Current Max:100mA; Response Time:0.5ms; Sensing Distance Max:2m; Sensing Distance Min:0.1m; Sensing Range:0m to 2m; Sensor Input:Optical; Supply Voltage Range DC:10V to 30V

LEVEL CONTROLLER; Supply Voltage:110VAC; Response Time:80ms; Power Consumption:3.5VA; Product Range:-; Approval Bodies:CE CSA UL; Dielectric Strength VAC:2000VAC; External Depth:70mm; External Length / Height:50mm; External Width:38mm; Insulation Resistance:100Mohm; Operating Temperature Max:55°C; Operating Temperature Min:-10°C; Output Current Max:3A; Output Voltage Max:250VAC; Response Time Max:160ms; Response Time Min:80ms; Supply Voltage Max:240VAC; Supply Voltage Min:24VAC

PROXIMITY SENSOR M12 PLUG-IN PNP; Sensing Range Max:4mm; Thread Size - Metric:M12; Sensor Output:PNP; Supply Voltage DC Min:10V; Supply Voltage DC Max:32V; Product Range:E2A Series; Frequency Response Max:1000Hz; Sensing Range:0mm to 4mm; Sensor Input:Inductive; Supply Voltage Range DC:10V to 32V

PROXIMITY SENSOR M12 PLUG-IN NPN; Sensing Range Max:4mm; Thread Size - Metric:M12; Sensor Output:NPN; Supply Voltage DC Min:10V; Supply Voltage DC Max:32V; Product Range:E2A Series; Frequency Response Max:1000Hz; Sensing Range:0mm to 4mm; Sensor Input:Inductive; Supply Voltage Range DC:10V to 32V

RELAY DPDT 250VAC 30VDC 10A; Contact Configuration:DPDT; Coil Voltage:24VDC; Contact Current:10A; Product Range:MK-S Series; Relay Mounting:Socket; Coil Type:Non Latching; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect

CARD OPTION RS485; Thermocouple Type:-; Operating Temperature Max:55°C; Operating Temperature Min:-10°C; Temperature Accuracy ±:0.3%; Output Voltage Max:-; Output Voltage Min:-; Product Range:-; For Use With:E5CN-H Controller
