Converter DC/DC 1W 24VIN 5VOUT DIP DL

CONVERTER DC/DC SIL 1W 15V; No. of Outputs:2 Output; Output Power Max:1W; Output Voltage - Output 1:5V; Output Current - Output 1:100mA; Output Voltage - Output 2:15V; Output Current - Output 2:34mA; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:NMD Series; Input Voltage DC Min:4.5V; Input Voltage DC Max:5.5V; DC / DC Converter Output Type:Fixed; DC / DC Converter Type:SIP; DC / DC Converter Mounting:Through Hole; Approvals & Standards:-; Width:19.8mm; Height:10mm; Depth:6mm; SVHC:No SVHC (17-Dec-2015); Efficiency:80%; External Depth:9.8mm; External Length / Height:6.8mm; External Width:19.8mm; Flammability Rating:UL94V-0; Input Voltage:5VDC; Input Voltage Tolerance +:10%; Isolation Voltage:1kV; Load Regulation:10%; No. of Outputs:2Outputs; Output Ripple Voltage pk-pk:75mV; Output Voltage Tolerance +:10%; Output Voltage Tolerance -:7.5%; Power Density:0.85W/cm³; Power Rating:1W; Supply Voltage:5V

Isolated Board Mount DC/DC Converter DIP Fixed Through Hole 1 W 12 V 83 mA ;RoHS Compliant: Yes

Isolated Board Mount DC/DC Converter DIP Fixed Through Hole 1 W 12 V 83 mA ;RoHS Compliant: Yes

Isolated Board Mount DC/DC Converter SIP Fixed Through Hole 1 W 5 V 100 mA ;RoHS Compliant: Yes

Isolated Board Mount DC/DC Converter SIP Fixed Through Hole 1 W 12 V 83 mA ;RoHS Compliant: Yes

CONVERTER DC/DC SIL 2W 12V; No. of Outputs:1 Output; Output Power Max:2W; Output Voltage - Output 1:12V; Output Current - Output 1:167mA; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:Murata PS NMG 2 Watt Series; Input Voltage DC Min:4.5V; Input Voltage DC Max:5.5V; DC / DC Converter Output Type:Fixed; DC / DC Converter Type:SIP; DC / DC Converter Mounting:Through Hole; Approvals & Standards:-; Width:7.65mm; Height:10.15mm; Depth:19.5mm; SVHC:No SVHC (17-Dec-2015); Efficiency:87.5%; External Depth:7.5mm; External Length / Height:10mm; External Width:19.5mm; Input Voltage:5V; Isolation Voltage:1kV; Load Regulation:3.8%; No. of Outputs:1Outputs; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Output Ripple Voltage pk-pk:18mV; Power Rating:2W; Supply Voltage:5V; Weight:2.8g

DC/DC CONVERTER 2W 5V 0.4A; No. of Outputs:1 Output; Output Power Max:2W; Output Voltage - Output 1:5V; Output Current - Output 1:400mA; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:Murata PS NMG 2 Watt Series; Input Voltage DC Min:13.5V; Input Voltage DC Max:16.5V; DC / DC Converter Output Type:Fixed; DC / DC Converter Type:SIP; DC / DC Converter Mounting:Through Hole; Approvals & Standards:-; Width:7.65mm; Height:10.15mm; Depth:19.65mm; SVHC:No SVHC (17-Dec-2015); No. of Outputs:1Outputs

DC/DC Converter 9V 222MA 2W

DC/DC Converter 9V 222MA 2W

Isolated Board Mount DC/DC Converter DIP Through Hole Fixed 13.2 V 10.8 V 2 ;RoHS Compliant: Yes

Isolated Board Mount DC/DC Converter DIP Through Hole Fixed 26.4 V 21.6 V 2 ;RoHS Compliant: Yes

Isolated Board Mount DC/DC Converter SIP Through Hole Fixed 26.4 V 21.6 V 2 ;RoHS Compliant: Yes

NMH Series 2 W Dual Output ?15 V Isolated Through Hole DC/DC Converter

Isolated Board Mount DC/DC Converter SIP Through Hole Fixed 13.2 V 10.8 V 2 ;RoHS Compliant: Yes

DC-DC CONVERTER ISO POL 1 O/P 1W 111mA 9V; No. of Outputs:1 Output; Output Power Max:1W; Output Voltage - Output 1:9V; Output Current - Output 1:111mA; Output Voltage - Output 2:-; Output Current - Output 2:-; Width:9.8mm ;RoHS Compliant: Yes

CONVERTER DC/DC SIL 1W 5V; No. of Outputs:1 Output; Output Power Max:1W; Output Voltage - Output 1:5V; Output Current - Output 1:200mA; Output Voltage - Output 2:-; Output Current - Output 2:-; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:NMJ Series; Input Voltage DC Min:4.5V; Input Voltage DC Max:5.5V; DC / DC Converter Output Type:Fixed; DC / DC Converter Type:SIP; DC / DC Converter Mounting:Through Hole; Approvals & Standards:-; Width:9.8mm; Height:12.5mm; Depth:19.5mm; SVHC:No SVHC (17-Dec-2015); Approval Bodies:BS EN 60950; Efficiency Min:60%; External Depth:9.8mm; External Length / Height:12.5mm; External Width:19.5mm; Flammability Rating:UL94V-0; Input Voltage:5V; Isolation Voltage:5.2kV; No. of Outputs:1Outputs; Output Voltage +:5V; Power Density:0.42W/cm³; Power Rating:1W; Supply Voltage:5V

CONVERTER DC/DC SIL 1W +/-5V; DC / DC Converter Type:Isolated POL; DC / DC Converter Mounting:Through Hole; DC / DC Converter Output Type:Fixed; Input Voltage DC Max:5.5V; Input Voltage DC Min:4.5V; No. of Outputs:2; Output ;RoHS Compliant: Yes

CONVERTER DC/DC SIL 1W +/-9V; No. of Outputs:2 Output; Output Power Max:1W; Output Voltage - Output 1:9V; Output Current - Output 1:55mA; Output Voltage - Output 2:-9V; Output Current - Output 2:55mA; Output Voltage - Output 3:-; Output Current - Output 3:-; Product Range:-; Input Voltage DC Min:4.5V; Input Voltage DC Max:5.5V; DC / DC Converter Output Type:Fixed; DC / DC Converter Type:SIP; DC / DC Converter Mounting:Through Hole; Approvals & Standards:-; Width:9.8mm; Height:12.5mm; Depth:19.5mm; SVHC:No SVHC (17-Dec-2015); Approval Bodies:BS EN 60950; Efficiency:80%; External Depth:9.8mm; External Length / Height:12.5mm; External Width:19.5mm; Flammability Rating:UL94V-0; Input Voltage:5VDC; Isolation Voltage:5.2kV; No. of Outputs:2Outputs; Power Density:0.42W/cm³; Power Rating:1W; Supply Voltage:5V

NMK Series 2 W Single Output 12 V 3 kVDC Isolated DC/DC Converter
