LED HIGH BRIGHTNESS GREEN 1W 53LM; Product Range:-; LED Color:Green; Wavelength Typ:550nm; Viewing Angle:110 ; Luminous Flux @ Test:53lm; Forward Current If Max:350mA; Forward Current @ Test:350mA; Forward Voltage @ Test:3.42V ;RoHS Compliant: Yes

LED SUPERFLUX RED/ORANGE; LED Colour:Red Orange; LED Mounting:Through Hole; Bulb Size:T-1 (3mm); Forward Current If:70mA; Forward Voltage:2.6V; Wavelength Typ:626nm; Luminous Intensity:600mcd; Viewing Angle:70°; Lens Shape:Round; Packaging:Each; Product Range:-; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (12-Jan-2017); Dominant Wavelength:620nm; Forward Current If Max:70mA; Forward Voltage VF Max:2.5V; LED / Lamp Size:7.6 x 7.6mm; LED Type:Multicolour; Luminous Intensity Typ:600mcd; No. of Pins:4Pins; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C; PIV Max:20V; Peak Wavelength:626nm; Voltage Rating V DC:3.03V; Voltage Vf Typ:2.5V

LED Uni-Color White 299lm 6500K Chip LED 3-Pin SMD T/R

LED Uni-Color White 299lm 5000K Chip LED 3-Pin SMD T/R

LED Uni-Color Blue 83lm Chip LED 3-Pin SMD T/R

LED Uni-Color Blue 41lm Chip LED 3-Pin SMD T/R

LED Uni-Color White 223lm 4000K Chip LED 2-Pin SMD T/R

LED Uni-Color White 103lm 4000K Chip LED 3-Pin 4530 T/R

LED Uni-Color White 292lm 4000K Chip LED 3-Pin SMD T/R

LED LUXEON K EC24 3000K CCT; Product Range:-; LED Colour:Warm White; Viewing Angle:100°; Luminous Flux @ Test:2250lm; CCT:3000K; Forward Current If Max:1.05A; Forward Voltage @ Test:63V; Forward Current @ Test:350mA; Packaging:Each; SVHC:No SVHC (12-Jan-2017); LED Mounting:Screw; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +125°C

LED LUXEON K EC8 4000K CCT; Product Range:LUXEON K Series; LED Colour:Neutral White; Viewing Angle:100°; Luminous Flux @ Test:815lm; CCT:4000K; Forward Current If Max:1.05A; Forward Voltage @ Test:21V; Forward Current @ Test:350mA; Packaging:Each; SVHC:No SVHC (12-Jan-2017); LED Mounting:Screw; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +125°C

LED LUXEON K EC16 4000K CCT; Product Range:-; LED Colour:Neutral White; Viewing Angle:100°; Luminous Flux @ Test:1650lm; CCT:4000K; Forward Current If Max:1.05A; Forward Voltage @ Test:42V; Forward Current @ Test:350mA; Packaging:Each; SVHC:No SVHC (12-Jan-2017); LED Mounting:Screw; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +125°C

LED 5630 MID POWER 3000K CCT; Product Range:-; LED Colour:Warm White; Viewing Angle:120°; Luminous Flux @ Test:30lm; CCT:3000K; Forward Current If Max:150mA; Forward Voltage @ Test:3.1V; Forward Current @ Test:100mA; Packaging:Each; SVHC:No SVHC (12-Jan-2017); LED Mounting:SMD; No. of Pins:4Pins; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +80°C

LED 5630 MID POWER 3500K CCT; Product Range:LUXEON Mid Power Series; LED Colour:Warm White; Viewing Angle:120°; Luminous Flux @ Test:31lm; CCT:3500K; Forward Current If Max:150mA; Forward Voltage @ Test:3.1V; Forward Current @ Test:100mA; Packaging:Each; SVHC:No SVHC (12-Jan-2017); LED Mounting:SMD; No. of Pins:4Pins; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +80°C

LED 5630 MID POWER 5000K CCT; Product Range:-; LED Colour:Cool White; Viewing Angle:120°; Luminous Flux @ Test:33lm; CCT:5000K; Forward Current If Max:150mA; Forward Voltage @ Test:3.1V; Forward Current @ Test:100mA; Packaging:Each; SVHC:No SVHC (12-Jan-2017); LED Mounting:SMD; No. of Pins:4Pins; Operating Temperature Max:80°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +80°C

LED LUXEON Z GREEN; Product Range:LUXEON Z Series; LED Colour:Green; Wavelength Typ:530nm; Viewing Angle:-; Luminous Flux @ Test:-; Forward Current If Max:-; Forward Current @ Test:-; Forward Voltage @ Test:-; Luminous Intensity @ Test:-; Packaging:Cut Tape; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (12-Jan-2017); Colour:Green; Forward Voltage:3.5V; Forward Voltage VF Max:3.5V; Lens Shape:Square; Luminous Flux Min:104lm

LED Uni-Color Red Orange 67lm Chip LED 3-Pin SMD T/R

REBEL ES REBEL ES; Product Range:-; LED Colour:Neutral White; Viewing Angle:-; Luminous Flux @ Test:190lm; CCT:4000K; Forward Current If Max:1A; Forward Voltage @ Test:3V; Forward Current @ Test:700mA; Packaging:Cut Tape; SVHC:No SVHC (12-Jan-2017); LED Mounting:SMD; MSL:MSL 1 - Unlimited; No. of Pins:3Pins; Operating Temperature Max:135°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +135°C

REBEL ES - 1/4 ANSI BIN - MIN CRI 90; Product Range:-; LED Colour:Warm White; Viewing Angle:-; Luminous Flux @ Test:135lm; CCT:2700K; Forward Current If Max:1A; Forward Voltage @ Test:3V; Forward Current @ Test:700mA; Packaging:Cut Tape; SVHC:No SVHC (12-Jan-2017); LED Mounting:SMD; MSL:MSL 1 - Unlimited; No. of Pins:3Pins; Operating Temperature Max:135°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +135°C

LED LUXEON K 16 WHITE 1530LM; Product Range:LUXEON K Series; LED Colour:White; Viewing Angle:100°; Luminous Flux @ Test:1395lm; CCT:2700K; Forward Current If Max:1.05A; Forward Voltage @ Test:42V; Forward Current @ Test:350mA; Packaging:Each; SVHC:No SVHC (12-Jan-2017); LED Mounting:Screw; Operating Temperature Max:125°C; Operating Temperature Min:-40°C
