Q4006L4
Part Number : Q4006L4
LittelfuseTRIAC 400V 6A TO-220; Peak Repetitive Off-State Voltage Vdrm:400V; On State RMS Current IT(rms):6A; Triac Case Style:TO-220; Gate Trigger Current Max (QI) Igt:25mA; Gate Trigger Voltage Max Vgt:1.3V; Peak Gate Power:500mW; MSL:-;RoHS Compliant: Yes
Q8004L4
Part Number : Q8004L4
LittelfuseTRIAC 800V 4A TO-220; Peak Repetitive Off-State Voltage Vdrm:800V; On State RMS Current IT(rms):4A; Triac Case Style:TO-220; Gate Trigger Current Max (QI) Igt:25mA; Gate Trigger Voltage Max Vgt:1.3V; Peak Gate Power:300mW; MSL:-;RoHS Compliant: Yes
Q8008L5
Part Number : Q8008L5
LittelfuseTRIAC 800V 8A TO-220; Peak Repetitive Off-State Voltage Vdrm:800V; On State RMS Current IT(rms):8A; Triac Case Style:TO-220; Gate Trigger Current Max (QI) Igt:50mA; Gate Trigger Voltage Max Vgt:1.3V; Peak Gate Power:500mW; MSL:-;RoHS Compliant: Yes
S6065JTP
Part Number : S6065JTP
LittelfuseSCR THYRISTOR 41A 600V TO-218X-3; Peak Repetitive Off-State Voltage Vdrm:600V; Gate Trigger Current Max Igt:50mA; Current It av:41A; On State RMS Current IT(rms):65A; Thyristor Case Style:TO-218X; No. of Pins:3Pins; MSL:- ;RoHS Compliant: Yes
V275LT10P
Part Number : V275LT10P
LittelfuseMETAL OXIDE VARISTOR 369V 710V RAD; Product Range:LA Series; Voltage Rating VDC:369V; Peak Surge Current @ 8/20 S:2.5kA; Varistor Case Style:Disc 10mm; Clamping Voltage Vc Max:710V; Peak Energy (10/1000uS):45J; MSL:- ;RoHS Compliant: Yes
V510LA80CP
Part Number : V510LA80CP
LittelfuseMETAL OXIDE VARISTOR 510V 1350V RADIAL; Product Range:C-III Series; Voltage Rating VDC:-; Peak Surge Current @ 8/20 S:9kA; Varistor Case Style:Disc 20mm; Clamping Voltage Vc Max:1.35kV; Peak Energy (10/1000uS):-; MSL:- ;RoHS Compliant: Yes
V575LA80CP
Part Number : V575LA80CP
LittelfuseMETAL OXIDE VARISTOR 730V 1500V RADIAL; Product Range:C-III Series; Voltage Rating VDC:-; Peak Surge Current @ 8/20 S:9kA; Varistor Case Style:Disc 20mm; Clamping Voltage Vc Max:1.5kV; Peak Energy (10/1000uS):-; MSL:- ;RoHS Compliant: Yes
V8ZT1P
Part Number : V8ZT1P
LittelfuseMETAL OXIDE VARISTOR 5.5V 22V RAD FULL REEL; Product Range:ZT Series; Voltage Rating VDC:5.5V; Peak Surge Current @ 8/20 S:100A; Varistor Case Style:Disc 7mm; Clamping Voltage Vc Max:22V; Peak Energy (10/1000uS):400mJ; MSL:- ;RoHS Compliant: Yes
V8ZT2P
Part Number : V8ZT2P
LittelfuseMETAL OXIDE VARISTOR 5.5V 20V RAD FULL REEL; Product Range:ZT Series; Voltage Rating VDC:5.5V; Peak Surge Current @ 8/20 S:250A; Varistor Case Style:Disc 10mm; Clamping Voltage Vc Max:20V; Peak Energy (10/1000uS):800mJ; MSL:- ;RoHS Compliant: Yes
V82ZT4P
Part Number : V82ZT4P
LittelfuseZA Series 68 VDC 50 Vrms 135 V Clamp 2500 A 1485 pF Radial Metal Oxide Varistor
0AGC02.5V
Part Number : 0AGC02.5V
LittelfuseFUSE CARTRIDGE 2.5A 6.3X32MM FST ACT; Voltage Rating VAC:32V; Fuse Current:2.5A; Breaking Capacity Current AC:-; Fuse Size Metric:6.3mm x 32mm; Fuse Size Imperial:1/4" x 1-1/4"; Blow Characteristic:-; Product Range:AGC Series ;RoHS Compliant: No
