CAS 50-NP
Part Number : CAS 50-NP
LEMCURRENT SENSOR 50A VOLTAGE O/P 5VDC; Sensor Output:Voltage; Supply Voltage DC Min:4.75V; Supply Voltage DC Max:5.25V; Current Measuring Range DC:-150A to 150A; Current Measuring Range AC:-150A to 150A; Response Time:300ns; ;RoHS Compliant: Yes
LA 55-P
Part Number : LA 55-P
LEMCURRENT TRANSDUCER 50A PCB; Sensor Output:Closed Loop; Supply Voltage DC Min:-15V; Supply Voltage DC Max:15V; Current Measuring Range DC:-70A to 70A; Current Measuring Range AC:-70A to 70A; Response Time:1µs; Accuracy %:0.9%; Product Range:LA 55-P Series; SVHC:No SVHC (12-Jan-2017); Current Range DC:50mA
HXS 20-NP
Part Number : HXS 20-NP
LEMCURRENT TRANSDUCER OPEN LOOP 20A; Sensor Output:Voltage; Supply Voltage DC Min:4.75V; Supply Voltage DC Max:5.25V; Current Measuring Range DC:-60A to 60A; Current Measuring Range AC:-60A to 60A; Response Time:5 s; Accuracy %:1% ;RoHS Compliant: Yes
HXS 50-NP
Part Number : HXS 50-NP
LEMCURRENT TRANSDUCER; Sensor Output:Voltage; Supply Voltage DC Min:4.75V; Supply Voltage DC Max:5.25V; Current Measuring Range DC:-150A to 150A; Current Measuring Range AC:-150A to 150A; Response Time:5 s; Accuracy %:1%; Product ;RoHS Compliant: Yes
HY 10-P
Part Number : HY 10-P
LEMCURRENT TRANSDUCER 10A; Sensor Output:Voltage; Supply Voltage DC Min:12V; Supply Voltage DC Max:15V; Current Measuring Range DC:-30A to 30A; Current Measuring Range AC:-30A to 30A; Response Time:3µs; Accuracy %:1%; Product Range:HY 5..25-P Series; SVHC:No SVHC (12-Jan-2017); Accuracy:1%; Current Consumption:10mA; Current Range AC:DC AC Pulsed Mixed; Current Range DC:DC AC Pulsed Mixed; Current Rating:10A; External Depth:12mm; External Length / Height:21mm; External Width:35mm; Flammability Rating:UL 94-V0; Frequency Max:50kHz; Frequency Min:0Hz; Operating Temperature Max:80°C; Operating Temperature Min:-10°C; Output Voltage:4V; Supply Voltage:15V; Transducer Function:Current
