Dual N-Channel 40 V 8.2 mOhm 39 nC OptiMOS? Power Mosfet - TDSON-8-4

IPU60R2K0 - 600V CoolMOS N-Channel Power MOSFET

Trans IGBT Chip N-CH 1.2KV 30A 3-Pin TO-247 Tube

IKW20N60T Series 600 V 40 A Through Hole TRENCHSTOP? IGBT -PG-TO247-3

Diode PIN Attenuator/Switch 150V 2-Pin SC-79 T/R

PIN DIODE 150V 0.1A SOT-23; Diode Configuration:Dual Common Cathode; Resistance @ If:1.35ohm; Breakdown Voltage Vbr:150V; Diode Case Style:SOT-23; No. of Pins:3 Pin; Total Capacitance Ct:0.35pF; Forward Current If(AV):100mA; Packaging:Cut Tape; Operating Temperature Max:125°C; Product Range:BAR64 Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (12-Jan-2017); No. of Pins:3Pins

BAT15 - RF DIODES

DIODE STD RECOVERY 50A 1.2KV TO-220; Repetitive Reverse Voltage Vrrm Max:1.2kV; Forward Current If(AV):50A; Diode Configuration:Single; Forward Voltage VF Max:2.15V; Reverse Recovery Time trr Max:380ns; Forward Surge Current Ifsm Max:102A; Operating Temperature Max:150°C; Diode Case Style:TO-220; No. of Pins:2 Pin; Packaging:Each; Product Range:IDP30 Series; Automotive Qualification Standard:-; SVHC:No SVHC (12-Jan-2017); No. of Pins:2Pins

Motor/Motion/Ignition Controllers & Drivers AUTOMOTIVE MOTOR DRIVER

Motor/Motion/Ignition Controllers & Drivers POWERTRAIN

IN STOCK SHIP TODAY

Single N-Channel 60 V 5.1 mOhm 88 nC HEXFET? Power Mosfet - TO-220-3

Single N-Channel 60V 2.4 mOhm 186 nC HEXFET? Power Mosfet - D2PAK

MOSFET N TO-220; Transistor Polarity:N Channel; Continuous Drain Current Id:6.9A; Drain Source Voltage Vds:900V; On Resistance Rds(on):800mohm; Rds(on) Test Voltage Vgs:10V; Threshold Voltage Vgs:3V; Power Dissipation Pd:104W; Transistor Case Style:TO-220; No. of Pins:3Pins; Operating Temperature Max:150°C; MSL:-; SVHC:No SVHC (12-Jan-2017); Current Id Max:6.9A; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +150°C; Termination Type:Through Hole; Transistor Type:Power MOSFET; Voltage Vds Typ:900V; Voltage Vgs Max:20V; Voltage Vgs Rds on Measurement:10V

Trans MOSFET N-CH 30V 3.5A 8-Pin SOIC

MOSFET N D-PAK; Transistor Polarity:N Channel; Continuous Drain Current Id:65A; Drain Source Voltage Vds:30V; On Resistance Rds(on):10mohm; Rds(on) Test Voltage Vgs:10V; Threshold Voltage Vgs:1V; Power Dissipation Pd:75W; Transistor Case Style:TO-252; No. of Pins:3Pins; Operating Temperature Max:175°C; Product Range:-; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (12-Jan-2017); Alternate Case Style:D-PAK; Current Id Max:65A; Current Temperature:25°C; Full Power Rating Temperature:25°C; Junction Temperature Tj Max:150°C; Junction Temperature Tj Min:-55°C; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +175°C; Pulse Current Idm:260A; SMD Marking:IRLR7821; Voltage Vds Typ:30V; Voltage Vgs Max:1V; Voltage Vgs Rds on Measurement:10V; Voltage Vgs th Min:1V

MOSFET N FETKY SO-8; Transistor Polarity:N Channel; Continuous Drain Current Id:6.4A; Drain Source Voltage Vds:30V; On Resistance Rds(on):35mohm; Rds(on) Test Voltage Vgs:10V; Threshold Voltage Vgs:4V; Power Dissipation Pd:2.5W; Transistor Case Style:SOIC; No. of Pins:8Pins; Operating Temperature Max:150°C; Product Range:-; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (12-Jan-2017); Current Id Max:33A; Current Temperature:25°C; External Length / Height:1.75mm; External Width:4.05mm; Forward Current If(AV):4A; Forward Surge Current Ifsm Max:15A; Forward Voltage VF Max:0.42V; Full Power Rating Temperature:25°C; Junction Temperature Tj Max:150°C; Junction Temperature Tj Min:-55°C; No. of Transistors:1; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +150°C; Pulse Current Idm:46A; SMD Marking:F7421D1; Voltage Vds Typ:30V; Voltage Vgs Max:1V; Voltage Vgs Rds on Measurement:10V; Voltage Vgs th Max:4V

MOSFET N LOGIC MICRO-6; Transistor Polarity:N Channel; Continuous Drain Current Id:3.2A; Drain Source Voltage Vds:30V; On Resistance Rds(on):100mohm; Rds(on) Test Voltage Vgs:10V; Threshold Voltage Vgs:1V; Power Dissipation Pd:1.7W; Transistor Case Style:µSOIC; No. of Pins:6Pins; Operating Temperature Max:150°C; Product Range:-; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (12-Jan-2017); Capacitance Ciss Typ:210pF; Charge Qrr @ Tj = 25°C Typ:39nC; Current Id Max:3.2A; Current Temperature:25°C; External Depth:3mm; External Length / Height:1.45mm; External Width:3mm; Full Power Rating Temperature:25°C; Junction Temperature Tj Max:150°C; Junction Temperature Tj Min:-55°C; N-channel Gate Charge:6.4nC; No. of Transistors:1; Operating Temperature Min:-55°C; Pulse Current Idm:18A; Rate of Voltage Change dv / dt:5V/ns; Reverse Recovery Time trr Typ:36ns; SMD Marking:2B; Voltage Vds:30V; Voltage Vds Typ:30V; Voltage Vgs Rds on Measurement:10V; Voltage Vgs th Min:1V

MOSFET Transistor N Channel 5.7 A 20 V 35 mohm 4.5 V 700 mV ;RoHS Compliant: Yes

MOSFET P LOGIC SOT-23; Transistor Polarity:P Channel; Continuous Drain Current Id:600mA; Drain Source Voltage Vds:-20V; On Resistance Rds(on):600mohm; Rds(on) Test Voltage Vgs:-4.5V; Threshold Voltage Vgs:-1.5V; No. of Pins:3Pins ;RoHS Compliant: Yes
