HAN-MAX RJ45 PLUG CAT5 8P SHIELDED

HAN C F CRIMP CONTACT 2 5MM AU/HMC

RJ45 MODULAR PLUG 8 POSITION 1 PORT; Connector Type:RJ45; Product Range:-; Gender:Plug; No. of Contacts:8Contacts; No. of Positions:8Positions; No. of Ports:1Ports; LAN Category:-; Contact Termination Type:Crimp; Contact Plating:- ;RoHS Compliant: Yes

SOCKET IDC WITH S/RELIEF 16WAY; Pitch Spacing:2.54mm; No. of Contacts:16Contacts; Gender:Receptacle; Product Range:SEK 18 Series; Contact Termination Type:IDC / IDT; No. of Rows:2Rows; Contact Plating:Gold Plated Contacts; Contact Material:Brass; SVHC:No SVHC (12-Jan-2017); Approval Bodies:BS BT DIN F MIL Spec NFC; Colour:Grey; Connector Mounting Orientation:Cable; Contact Current Rating:1A; Contact Resistance:20mohm; Contact Termination:IDC / IDT; Flammability Rating:UL94V-0; IDC Cable Pitch:0.05"; Insulation Resistance:1Gohm; Lead Spacing:2.54mm; No. of Mating Cycles:100; Operating Temperature Max:105°C; Operating Temperature Min:-40°C; Row Pitch:2.54mm; Termination Method:IDC; Voltage Rating V DC:350V; Voltage Rating VAC:350V; Withstand Voltage:1050V

HOOD TOP ENTRY 24B M32 1LEVER; Product Range:Han B HMC Series; Cable Exit Angle:180 ; Connector Body Material:Aluminium Body; For Use With:Harting Han 24B Inserts & Modules; Locking Type:1 Lever; Rectangular Shell Size:24B; ;RoHS Compliant: Yes

Han B Hood Top Entry HC 2 Pegs PG 29 ;RoHS Compliant: NA

Han EMC 64 Base Panel ;RoHS Compliant: NA

RECTANGULAR HAN INSERT PLUG 6WAY SCREW; Product Range:Staf Series; Gender:Plug; Rectangular Shell Size:3A; No. of Contacts:6Contacts; Heavy Duty Contact Type:Screw Pin; Current Rating:10A; Wire Size AWG Max:16AWG; No. of Rows:2Rows

RECTANGULAR HAN INSERT FEM 12 POSITION CRIMP; Product Range:Han Com Series; Connector Mounting:Cable Mount; Gender:Receptacle; No. of Contacts:12Contacts; Contact Gender:Socket; No. of Rows:3Rows; Contact Termination Type:Crimp ;RoHS Compliant: NA

HOOD 6B TOP ENTRY ALUMINIUM PG21; Product Range:Han B Series; Cable Exit Angle:180 ; Rectangular Shell Size:6B; For Use With:Han 6B Inserts & Bases; Connector Body Material:Aluminium Body; Locking Type:1 Lever

HOUSING FREE HANR15; Product Range:R15 Series; Shell Type:-; For Use With:R 15 Inserts; Connector Body Material:Thermoplastic Body; Connector Shell Size:-; SVHC:No SVHC (12-Jan-2017); Body Diameter:28mm; Connector Mounting:Cable Mount; Connector Type:Circular Industrial; Contact Material:Copper; Contact Plating:Silver Plated Contacts; Contact Resistance:3mohm; Contact Termination:Crimp; Current Rating:10A; External Length / Height:70mm; IP / NEMA Rating:IP65; Insulation Resistance:10Gohm; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Voltage Rating V AC:250V; Voltage Rating V DC:300V

INSERT MALE HAN108DD CRIMP; Product Range:Han DD Series; Gender:Plug; Rectangular Shell Size:24B; No. of Contacts:109Contacts; Heavy Duty Contact Type:Crimp Pin - Contacts Not Supplied; Current Rating:10A; Wire Size AWG Max:-; Wire Size AWG Min:-; Contact Material:-; Contact Plating:-; SVHC:No SVHC (12-Jan-2017); Contact Termination:Crimp; For Use With:Han D Pin Crimp Contacts; Insert Type:Signal; No. of Positions:109Ways; No. of Rows:6 Row; No. of Rows:6Rows; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Range:24B; Voltage Rating:250V; Voltage Rating V AC:250V; Wire Area Size Max:2.5mm²; Wire Area Size Min:0.5mm²; Working Voltage:250V

SOCKET HAN3A 3+E WAY; Product Range:Han A Series; Gender:Receptacle; Rectangular Shell Size:3A; No. of Contacts:4Contacts; Heavy Duty Contact Type:Screw Socket; Current Rating:10A; Wire Size AWG Max:14AWG; Wire Size AWG Min:18AWG; Contact Material:Copper Alloy; Contact Plating:Silver Plated Contacts; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CSA SEV UL; Connector Type:Rectangular Power; Contact Gender:Socket; Contact Termination:Screw; Contact Termination Type:Screw; For Use With:Han 3A Housings and Hoods; IP / NEMA Rating:IP65; No. of Rows:2 Row; No. of Rows:2Rows; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Range:3A; Termination Method:Screw; Voltage Rating:230V; Voltage Rating V AC:250V; Working Voltage:230V

INSERT PLUG HAN A 18-14 AWG 16+E WAY; Product Range:Han A Series; Gender:Plug; Rectangular Shell Size:16A; No. of Contacts:17Contacts; Heavy Duty Contact Type:Screw Pin; Current Rating:16A; Wire Size AWG Max:14AWG; Wire Size AWG Min:18AWG; Contact Material:Copper Alloy; Contact Plating:Silver Plated Contacts; SVHC:No SVHC (12-Jan-2017); Connector Type:Rectangular Power; Contact Gender:Pin; Contact Termination:Screw; Contact Termination Type:Screw; For Use With:Han 16A Housings and Hoods; Insert Type:Power; No. of Rows:2 Row; No. of Rows:2Rows; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Voltage Rating:250V

INSERT FEMALE HAN A 16+E WAY SCREW; Product Range:Han A Series; Gender:Receptacle; Rectangular Shell Size:16A; No. of Contacts:17Contacts; Heavy Duty Contact Type:Screw Socket; Current Rating:16A; Wire Size AWG Max:14AWG; Wire Size AWG Min:18AWG; Contact Material:Copper Alloy; Contact Plating:Silver Plated Contacts; SVHC:No SVHC (12-Jan-2017); Connector Type:Rectangular Power; Contact Gender:Socket; Contact Termination:Screw; Contact Termination Type:Screw; For Use With:Han 16A Housings and Hoods; Insert Type:Power; No. of Rows:2 Row; No. of Rows:2Rows; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Voltage Rating:250V

INSERT MALE HAN7D CRIMP; Product Range:Han Series; Connector Mounting:Cable Mount; Gender:Plug; No. of Contacts:7Contacts; Contact Gender:Pin; No. of Rows:3Rows; Contact Termination Type:Crimp; Connector Shell Size:3A; Contact Material:Copper; Contact Plating:Silver Plated Contacts; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CSA UL VDE; Connector Type:Rectangular Power; Contact Termination:Crimp; Current Rating:10A; IP / NEMA Rating:IP65; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Range:3A; Termination Method:Crimp; Voltage Rating VAC:250V; Wire Area Size Max:2.5mm²; Wire Area Size Min:0.5mm²; Working Voltage:250V

INSERT FEMALE HAN25D CRIMP; Product Range:Han D Series; Gender:Receptacle; Rectangular Shell Size:16A; Heavy Duty Contact Type:Crimp Socket - Contacts Not Supplied; Current Rating:10A; Contact Material:-; Contact Plating:-; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CSA UL VDE; Contact Termination:Crimp; For Use With:Han D Socket Crimp Contacts; IP / NEMA Rating:IP65; No. of Positions:26Ways; No. of Rows:3 Row; No. of Rows:3Rows; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Range:16A; Voltage Rating:250V; Voltage Rating VAC:250V; Wire Area Size Max:2.5mm²; Wire Area Size Min:0.5mm²; Working Voltage:250V

INSERT FEMALE HAN40D CRIMP; Product Range:Han D Series; Gender:Receptacle; Rectangular Shell Size:16B; No. of Contacts:41Contacts; Heavy Duty Contact Type:Crimp Socket - Contacts Not Supplied; Current Rating:10A; Wire Size AWG Max:-; Wire Size AWG Min:-; Contact Material:-; Contact Plating:-; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CSA UL VDE; Contact Termination:Crimp; For Use With:Han D Socket Crimp Contacts; IP / NEMA Rating:IP65; No. of Positions:41Ways; No. of Rows:4 Row; No. of Rows:4Rows; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Range:16B; Voltage Rating:250V; Voltage Rating VAC:250V; Wire Area Size Max:2.5mm²; Wire Area Size Min:0.5mm²; Working Voltage:250V

INSERT FEMALE HAN64D CRIMP; Product Range:Han D Series; Gender:Receptacle; Rectangular Shell Size:24B; No. of Contacts:65Contacts; Heavy Duty Contact Type:Crimp Socket - Contacts Not Supplied; Current Rating:10A; Wire Size AWG Max:-; Wire Size AWG Min:-; Contact Material:-; Contact Plating:-; SVHC:No SVHC (12-Jan-2017); Contact Termination:Crimp; For Use With:Han D Socket Crimp Contacts; IP / NEMA Rating:IP65; Insert Type:Signal; No. of Positions:65Ways; No. of Rows:4 Row; No. of Rows:4Rows; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Range:24B; Voltage Rating:250V; Voltage Rating VAC:250V; Wire Area Size Max:2.5mm²; Wire Area Size Min:0.5mm²; Working Voltage:250V

Heavy Duty Connector Hood PG13.5 Top Entry 2 Pegs Low Profile Han B Series 180 6B ;RoHS Compliant: Yes
