FEED-THROUGH 3A RJ45 IP67; Connector Type:RJ45; Product Range:-; Gender:Jack; No. of Contacts:-; No. of Positions:8Ways; No. of Ports:1Ports; LAN Category:-; Contact Termination Type:-; Contact Plating:-; Contact Material:-; ;RoHS Compliant: Yes

HEADER STRAIGHT 20WAY; Pitch Spacing:2.54mm; No. of Contacts:20Contacts; Gender:Header; Product Range:SEK 18 Series; Contact Termination Type:Through Hole; No. of Rows:2Rows; Contact Plating:Gold Plated Contacts; Contact Material:Brass; SVHC:No SVHC (12-Jan-2017); Approval Bodies:BS BT DIN F MIL Spec NFC; Colour:Grey; Contact Current Rating:1A; Contact Resistance:20mohm; Contact Termination:Through Hole Vertical; Current Rating:1A; Cut Thickness for PCBs Max:2.4mm; External Depth:9.2mm; External Length / Height:8.9mm; External Width:33mm; Flammability Rating:UL94V-0; Insulation Resistance:1Gohm; Lead Spacing:2.54mm; No. of Mating Cycles:200; Operating Temperature Max:105°C; Operating Temperature Min:-40°C; PCB Hole Diameter:0.9mm; Termination Method:Solder; Voltage Rating V DC:350V; Voltage Rating VAC:350V; Withstand Voltage:1050V; Working Voltage:350V

HEADER RIGHT ANGLE 16WAY; Pitch Spacing:2.54mm; No. of Contacts:16Contacts; Gender:Header; Product Range:SEK 18 Series; Contact Termination Type:Through Hole; No. of Rows:2Rows; Contact Plating:Gold Plated Contacts; Contact Material:Brass; SVHC:No SVHC (12-Jan-2017); Approval Bodies:BS BT DIN F MIL Spec NFC; Colour:Grey; Contact Current Rating:1A; Contact Resistance:20mohm; Contact Termination:Through Hole Right Angle; Current Rating:1A; Cut Thickness for PCBs Max:2.4mm; External Depth:9.2mm; External Length / Height:8.9mm; External Width:27.9mm; Flammability Rating:UL94V-0; Insulation Resistance:1Gohm; Lead Spacing:2.54mm; No. of Mating Cycles:200; Operating Temperature Max:105°C; Operating Temperature Min:-40°C; PCB Hole Diameter:0.9mm; Termination Method:Solder; Voltage Rating V DC:350V; Voltage Rating VAC:350V; Withstand Voltage:1050V; Working Voltage:350V

HEADER RIGHT ANGLE 34WAY; Pitch Spacing:2.54mm; No. of Contacts:34Contacts; Gender:Header; Product Range:SEK 18 Series; Contact Termination Type:Through Hole; No. of Rows:2Rows; Contact Plating:Gold Plated Contacts; Contact Material:Brass; SVHC:No SVHC (12-Jan-2017); Approval Bodies:BS BT DIN F MIL Spec NFC; Colour:Grey; Contact Current Rating:1A; Contact Resistance:20mohm; Contact Termination:Through Hole Right Angle; Current Rating:1A; Cut Thickness for PCBs Max:2.4mm; External Depth:9.2mm; External Length / Height:8.9mm; External Width:50.8mm; Flammability Rating:UL94V-0; Insulation Resistance:1Gohm; Lead Spacing:2.54mm; No. of Mating Cycles:200; Operating Temperature Max:105°C; Operating Temperature Min:-40°C; PCB Hole Diameter:0.9mm; Polarisation Type:Bump; Termination Method:Solder; Voltage Rating V DC:350V; Voltage Rating VAC:350V; Withstand Voltage:1050V; Working Voltage:350V

HEADER RIGHT ANGLE 50WAY; Pitch Spacing:2.54mm; No. of Contacts:50Contacts; Gender:Header; Product Range:SEK 18 Series; Contact Termination Type:Through Hole; No. of Rows:2Rows; Contact Plating:Gold Plated Contacts; Contact Material:Brass; SVHC:No SVHC (12-Jan-2017); Approval Bodies:BS BT DIN F MIL Spec NFC; Colour:Grey; Contact Current Rating:1A; Contact Resistance:20mohm; Contact Termination:Through Hole Right Angle; Current Rating:1A; Cut Thickness for PCBs Max:2.4mm; External Depth:9.2mm; External Length / Height:8.9mm; External Width:71.3mm; Flammability Rating:UL94V-0; Insulation Resistance:1Gohm; Lead Spacing:2.54mm; No. of Mating Cycles:200; Operating Temperature Max:105°C; Operating Temperature Min:-40°C; PCB Hole Diameter:0.9mm; Polarisation Type:Bump; Termination Method:Solder; Voltage Rating V DC:350V; Voltage Rating VAC:350V; Withstand Voltage:1050V; Working Voltage:350V

HEADER RIGHT ANGLE 20WAY; Pitch Spacing:2.54mm; No. of Contacts:20Contacts; Gender:Header; Product Range:SEK 18 Series; Contact Termination Type:Through Hole; No. of Rows:2Rows; Contact Plating:Gold Plated Contacts; Contact Material:Brass; SVHC:No SVHC (12-Jan-2017); Approval Bodies:BS BT DIN F MIL Spec NFC; Colour:Grey; Contact Current Rating:1A; Contact Resistance:20mohm; Contact Termination:Through Hole Right Angle; Current Rating:1A; Cut Thickness for PCBs Max:2.4mm; Flammability Rating:UL94V-0; Insulation Resistance:1Gohm; Lead Spacing:2.54mm; No. of Mating Cycles:200; Operating Temperature Max:105°C; Operating Temperature Min:-40°C; PCB Hole Diameter:0.9mm; Polarisation Type:Bump or Clip; Termination Method:Solder; Voltage Rating V DC:350V; Voltage Rating VAC:350V; Withstand Voltage:1050V; Working Voltage:350V

PLUG DIN41612 R/A B 32WAY; Product Range:Type B Series; No. of Contacts:32Contacts; Gender:Plug; Pitch Spacing:2.54mm; No. of Rows:1 Row; Rows Loaded:a; Contact Plating:Gold Plated Contacts; Contact Material:Copper; No. of Mating Cycles:400; SVHC:No SVHC (12-Jan-2017); Contact Termination:Through Hole Right Angle; Contact Termination Type:Through Hole; Current Rating:2A; Flammability Rating:UL94V-0; Lead Spacing:2.54mm; Material:Glass Filled Polyester; Mating Force:90N; No. of Rows:1Rows; Operating Temperature Max:125°C; Operating Temperature Min:-65°C; Pin Length:3mm; Standard:VG95324 / DIN53480 / IEC112; Termination Method:Solder; Working Voltage:250V

PLUG DIN41612 R/A B/2 16WAY; Product Range:Type 2B Series; No. of Contacts:16Contacts; Gender:Plug; Pitch Spacing:2.54mm; No. of Rows:1 Row; Rows Loaded:a; Contact Plating:Gold Plated Contacts; Contact Material:Copper; No. of ;RoHS Compliant: Yes

SENSOR CONNECTOR M12 PLUG 4POS CABLE; Product Range:HARAX Series; Sensor Connector Size:M12; Gender:Plug; No. of Contacts:4Contacts; Sensor Contact Type:IDC / IDT Pin; Sensor Connector Mounting:Straight Cable Mount ;RoHS Compliant: Yes

CONNECTOR HEADER 10POS 2.54MM; Connec; CONNECTOR HEADER 10POS 2.54MM; Connector Type:Wire to Board; Series:SEK 18; Contact Termination:Through Hole Vertical; Gender:Header; No. of Contacts:10; No. of Rows:2; Pitch Spacing:2.54mm

Wire-To-Board Connector Transition SEK 18 Series Through Hole Header 20 2.54 mm ;RoHS Compliant: Yes

SOCKET DIN41612 B 64WAY; Product Range:Type B Series; No. of Contacts:64Contacts; Gender:Receptacle; Pitch Spacing:2.54mm; No. of Rows:2 Row; Rows Loaded:a + b; Contact Plating:Gold Plated Contacts; Contact Material:Copper; No. of Mating Cycles:400; SVHC:No SVHC (12-Jan-2017); Contact Resistance:20mohm; Contact Termination:Through Hole Vertical; Contact Termination Type:Through Hole; Current Rating:2A; External Depth:8.1mm; External Length / Height:11.6mm; External Width:95mm; Insulation Resistance:1000Gohm; Lead Spacing:2.54mm; Material:Thermoplastic resin glass fibre filled UL 94-V0; No. of Rows:2Rows; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Pin Length:13mm; Row Pitch:2.54mm; Termination Method:Solder

Connector Backshell Jack Screw D Sub Connector ;RoHS Compliant: Yes

SOCKET DIN41612 24+8WAY; Product Range:Type M Series; No. of Contacts:32Contacts; Gender:Receptacle; Pitch Spacing:2.54mm; No. of Rows:3 Row; Rows Loaded:a + b + c; Contact Plating:Gold Plated Contacts; Contact Material:Copper; No.;RoHS Compliant: Yes

Rectangular Power Contact DIN 41612 Series Pin Solder ;RoHS Compliant: Yes

Rectangular Power Contact DIN 41612 Series Socket Solder ;RoHS Compliant: Yes

STRAIN RELIEF 64WAY; Accessory Type:Strain Relief Clamp; For Use With:Female Connectors; No. of Positions:64; Strain Relief Material:Thermoplastic; SVHC:No SVHC (16-Dec-2013); Series:SEK ;RoHS Compliant: Yes

USB TYPE A RECEPTACLE; USB Connector Type:USB Type A; USB Standard:-; Gender:Receptacle; No. of Positions:4Ways; Connector Mounting:Cable Mount; Orientation:Right Angle; Contact Material:-; Contact Plating:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Approval Category:DIN EN 61984; Connector Mounting Orientation:Cable; Connector Type:USB A; Contact Termination:Feed Through; Current Rating:1A; Degree of Pollution:3; Flammability Rating:UL94V-0; Insulation Resistance:10Mohm; Material:Polycarbonate; No. of Contacts:4Contacts; No. of Mating Cycles:500; Operating Temperature Max:+125°C; Operating Temperature Min:-40°C; Standard:USB 2.0; Voltage Rating VAC:50V

MODULE FIREWIRE FEMALE; No. of Contacts:6Contacts; Gender:Receptacle; Connector Type:Firewire IEEE-1394; Contact Termination Type:-; Product Range:-; Connector Mounting:Cable Mount; Contact Plating:-; Contact Material:-; SVHC:No SVHC (12-Jan-2017); Approval Category:DIN EN 61984; Connector Mounting Orientation:Cable; Contact Termination:Feed Through; Current Rating:1A; Degree of Pollution:3; Flammability Rating:UL94V-0; Insulation Resistance:10Mohm; Material:Polycarbonate; No. of Mating Cycles:500; Operating Temperature Max:+125°C; Operating Temperature Min:-40°C; Standard:USB 2.0; Voltage Rating VAC:50V

MODULE EEE 20WAY FEMALE; Product Range:Han Series; Connector Mounting:Cable Mount; Gender:Receptacle; No. of Contacts:20Contacts; Contact Gender:Socket; No. of Rows:5Rows; Contact Termination Type:Crimp; Connector Shell Size:-; Contact Material:Copper; Contact Plating:-; SVHC:No SVHC (12-Jan-2017); Connector Type:Rectangular Power; Contact Resistance:1mohm; Contact Termination:Crimp; Current Rating:16A; Degree of Pollution:3; Flammability Rating:UL94V-0; Insulation Resistance:10Mohm; Material:Polycarbonate; No. of Mating Cycles:500; Operating Temperature Max:+125°C; Operating Temperature Min:-40°C; Standard:DIN EN 61984; Termination Method:Crimp; Voltage Rating VAC:500V; Working Voltage:500V
