RELAY 3PDT 250VAC 16A; Contact Configuration:3PDT; Coil Voltage:230VAC; Contact Current:16A; Product Range:62 Series; Relay Mounting:Panel; Coil Type:AC; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30V; Contact Material:Silver Cadmium Oxide; Coil Resistance:7.25kohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); AC Coil Power:2.2VA; Approval Bodies:CE IMQ SEMKO SEV UL VDE; Approval Category:IEC 720; Coil Current:10.5mA; Coil Operating Lower Percent Limit:80%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:230V; Contact Current AC Max:30A; Contact Current DC Max:16A; Contact Current Max:30A; Contact Voltage AC Max:400V; Contact Voltage AC Nom:250V; External Depth:35.3mm; External Height:45mm; External Length / Height:45mm; External Width:38mm; Fixing Centres:63.5mm; Nom Operating Power:2.2VA; Relay Type:Power - General Purpose

RELAY DPST-NO 250VAC 20A; Contact Configuration:DPST-NO; Coil Voltage:24VAC; Contact Current:20A; Product Range:22 Series; Relay Mounting:DIN Rail; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:-; Contact Material:Silver Tin Oxide; Coil Resistance:41ohm; Approvals & Standards:CE; SVHC:No SVHC (12-Jan-2017); Approval Bodies:GOST; Approval Category:IP20; Coil Current:135mA; Coil Operating Lower Percent Limit:85%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:24V; Contact Current AC Max:30A; Contact Current Max:20A; Contact Voltage AC Max:240V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:24V; Current Rating:20A; Dielectric Strength VDC:3.5kV; External Depth:84mm; External Height:58.4mm; External Length / Height:58.4mm; External Width:17.4mm; Nom Operating Power:3VA; Operating Temperature Max:40°C; Operating Temperature Min:-40°C; Relay Type:Power; Switched Current Max:20A; Switched Voltage Max:400V; Voltage Rating VAC:250V

RELAY DPST-NO 250VAC 20A; Contact Configuration:DPST-NO; Coil Voltage:110VAC; Contact Current:20A; Product Range:22 Series; Relay Mounting:DIN Rail; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:-; Contact Material:Silver Tin Oxide; Coil Resistance:970ohm; Approvals & Standards:CE; SVHC:No SVHC (12-Jan-2017); Approval Bodies:GOST; Approval Category:IP20; Coil Current:26mA; Coil Operating Lower Percent Limit:85%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:110V; Contact Current AC Max:30A; Contact Current Max:30A; Contact Voltage AC Max:240V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:30V; Current Rating:20A; Dielectric Strength VDC:3.5kV; External Depth:84mm; External Height:58.4mm; External Length / Height:58.4mm; External Width:17.4mm; Nom Operating Power:3VA; Operating Temperature Max:40°C; Operating Temperature Min:-40°C; Relay Type:Power; Switched Current Max:20A; Switched Voltage Max:400V; Voltage Rating VAC:250V

RELAY SPST-1NO/1NC 250VAC 20A; Contact Configuration:SPST-NO SPST-NC; Coil Voltage:230VAC; Contact Current:20A; Product Range:22 Series; Relay Mounting:DIN Rail; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:-; Contact Material:Silver Tin Oxide; Coil Resistance:4.2kohm; Approvals & Standards:CE; SVHC:No SVHC (12-Jan-2017); Approval Bodies:GOST; Approval Category:IP20; Coil Current:12.5mA; Coil Operating Lower Percent Limit:85%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:230V; Contact Current AC Max:30A; Contact Current Max:20A; Contact Voltage AC Max:240V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:30V; Current Rating:20A; Dielectric Strength VDC:3.5kV; External Depth:84mm; External Height:58.4mm; External Length / Height:58.4mm; External Width:17.4mm; Nom Operating Power:3VA; Operating Temperature Max:40°C; Operating Temperature Min:-40°C; Relay Type:Power; Switched Current Max:20A; Switched Voltage Max:400V

RELAY 4PDT 250VAC 7A; Contact Configuration:4PDT; Coil Voltage:24VDC; Contact Current:7A; Product Range:58 Series; Relay Mounting:DIN Rail; Coil Type:DC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:600ohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Approval Bodies:BEAB CSA DEMKO GOST IMQ NEMKO SEMKO SEV UTE VDE; Average Power Consumption:1.5VA; Coil Operating Lower Percent Limit:110%; Coil Operating Upper Percent Limit:80%; Coil Voltage VDC Nom:24V; Contact Current AC Max:7A; Contact Current Max:15A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Current Rating:5A; Dielectric Strength VDC:2kV; External Depth:73mm; External Height:76mm; External Length / Height:76mm; External Width:27mm; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Output Voltage:24V; Relay Type:Interface; Switch Current Max:5A; Switching Current Max:5A

RELAY SPDT 250VAC 8A; Contact Configuration:SPDT; Coil Voltage:24VDC; Contact Current:10A; Product Range:48 Series; Relay Mounting:DIN Rail; Coil Type:DC Sensitive; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:CSA UL VDE; SVHC:No SVHC (12-Jan-2017); Approval Bodies:BEAB CSA DEMKO IMQ SEMKO SETI SEV UL VDE; Coil Operating Lower Percent Limit:110%; Coil Operating Upper Percent Limit:80%; Coil Voltage VDC Nom:24V; Contact Resistance:1200ohm; Contact Voltage DC Max:24V; Current Rating:10A; DC Coil Power:-500mW; External Depth:76mm; External Height:78.8mm; External Length / Height:78.8mm; External Width:15.8mm; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Relay Type:Interface; Switch Current Max:10A; Switching Current Max:10A

RELAY SPDT 250VAC 6A; Contact Configuration:SPDT; Coil Voltage:24VDC; Contact Current:6A; Product Range:34 Series; Relay Mounting:Through Hole; Coil Type:DC; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Contact Voltage VDC:-; Contact Material:Silver Nickel; Coil Resistance:3.35kohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:7.1mA; Coil Voltage VDC Nom:24V; Contact Current Max:10A; Contact Voltage AC Max:400V; Contact Voltage AC Nom:250V; Current Rating:6A; External Depth:5mm; External Height:15mm; External Width:28mm; No. of Mechanical Operations:10000000; Nom Operating Power:170mW; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Relay Type:General Purpose; Switching Voltage AC / DC Min:250VAC

RELAY SPDT 250VAC 10A; Contact Configuration:SPDT; Coil Voltage:24VDC; Contact Current:10A; Product Range:36 Series; Relay Mounting:Through Hole; Coil Type:DC; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Contact Voltage VDC:30V; Contact Material:Silver Tin Oxide; Coil Resistance:1.6kohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Relay Type:Power

RELAY SPDT 250VAC 10A; Contact Configuration:SPDT; Coil Voltage:12VDC; Contact Current:10A; Product Range:36 Series; Relay Mounting:Through Hole; Coil Type:DC; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Contact Voltage VDC:30V; Contact Material:Silver Tin Oxide; Coil Resistance:400ohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:30mA; Coil Voltage VDC Nom:12V; Contact Current Max:15mA; Contact Voltage AC Nom:250V; Current Rating:10A; External Depth:15.2mm; External Height:15.5mm; External Width:19mm; Nom Operating Power:360mW; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Operating Time:10ms; Relay Type:Power; Release Time:5ms

RELAY SPST-NO 250VAC 16A; Contact Configuration:SPST-NO; Coil Voltage:24VAC; Contact Current:16A; Product Range:20 Series; Relay Mounting:DIN Rail; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:-; Contact Material:Silver Tin Oxide; Coil Resistance:27ohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:275mA; Coil Operating Lower Percent Limit:85%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:24V; Contact Current AC Max:16A; Contact Current Max:30A; Contact Voltage AC Max:240V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:30V; Current Rating:16A; Dielectric Strength VDC:3.5kV; External Depth:84mm; External Height:58.4mm; External Length / Height:58.4mm; External Width:17.4mm; Nom Operating Power:6.5VA; Operating Temperature Max:40°C; Operating Temperature Min:-40°C; Relay Type:Power; Switched Current Max:16A; Switched Voltage Max:400V; Voltage Rating VAC:250V

RELAY SPST 250VAC 20A; Contact Configuration:SPST; Coil Voltage:110VAC; Contact Current:20A; Product Range:22 Series; Relay Mounting:DIN Rail; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:-; Contact Material:Silver Tin Oxide; Coil Resistance:970ohm; Approvals & Standards:CE; SVHC:No SVHC (12-Jan-2017); Approval Category:IP20; Coil Current:26mA; Coil Operating Lower Percent Limit:85%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:110V; Contact Current AC Max:30A; Contact Current Max:20A; Contact Voltage AC Nom:250V; Current Rating:20A; Dielectric Strength VDC:3.5kV; External Depth:84mm; External Height:58.4mm; External Length / Height:58.4mm; External Width:17.4mm; Nom Operating Power:3VA; Operating Temperature Max:40°C; Operating Temperature Min:-40°C; Relay Type:Power; Switched Current Max:20A; Switched Voltage Max:400V; Voltage Rating VAC:250V

RELAY SPDT 250VAC 16A; Contact Configuration:SPDT; Coil Voltage:24VAC; Contact Current:16A; Product Range:48 Series; Relay Mounting:DIN Rail; Coil Type:AC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Cadmium Oxide; Coil Resistance:-; Approvals & Standards:CSA UL VDE; SVHC:No SVHC (12-Jan-2017); Approval Bodies:BEAB CSA DEMKO IMQ SEMKO SETI SEV UL VDE; Average Power Consumption:1.2VA; Coil Operating Lower Percent Limit:110%; Coil Operating Upper Percent Limit:80%; Coil Voltage VAC Nom:24V; Contact Current AC Max:16A; Contact Current Max:30A; Contact Resistance:320mohm; Contact Voltage AC Max:24V; Contact Voltage AC Nom:250V; Current Rating:16A; DC Coil Power:-500mW; External Depth:76mm; External Height:78.8mm; External Length / Height:78.8mm; External Width:15.8mm; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Relay Type:Interface; Switch Current Max:16A; Switching Current Max:16A

RELAY 1 FORM C, 24 V (DC), 1.15 K?, 16 A, 400 V (AC)

49.52.8.230.5062 ROHS COMPLIANT: YES

49.62.9.024.0050 ROHS COMPLIANT: YES

PWR OUTLET, W/GRN LED, 16A, GREY, PANEL;

PWR OUTLET, W/GRN LED, 16A, YEL, PANEL;

TIME SWITCH, DPDT, 16A, 230VAC;

RELAY DPDT 250VAC 16A; Contact Configuration:DPDT; Coil Voltage:240V; Contact Current:16A; Product Range:38 Series; Relay Mounting:DIN Rail; Coil Type:AC / DC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:CE CSA UL; SVHC:No SVHC (12-Jan-2017); Average Power Consumption:1VA; Coil Voltage VAC Nom:240V; Coil Voltage VDC Nom:240V; Contact Current Max:30A; External Depth:77.1mm; External Height:89.7mm; External Width:14mm; Relay Type:Interface

RELAY SPST-NO 250VAC 5A; Contact Configuration:SPST-NO; Load Current:3A; Operating Voltage Max:240VAC; Relay Mounting:PCB; Relay Terminals:Solder; Switching Mode:Zero Crossing; Operating Voltage Min:12VAC; Control Voltage Min:8VDC; Control Voltage Max:17VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Coil Resistance:360ohm; Coil Voltage:12VDC; Coil Voltage VDC Nom:12V; Contact Current:5A; Contact Current Max:40A; Contact Material:Silver Nickel; Contact Voltage AC Nom:240V; Contact Voltage VAC:250V; Control Voltage Type:DC; External Depth:12.7mm; External Height:15.7mm; External Width:29mm; Load Voltage Range:12V AC to 240V AC
