RELAY 1NO 1NC 250VAC 25A; Load Current Inductive:-; Relay Mounting:DIN Rail; Operating Voltage:250VAC; Contact Configuration:DPST-NO DPST-NC; No. of Poles:2 Pole; Switching Power AC3:-; Switching Current AC1:-; Coil Voltage VAC Nom:120V; Coil Voltage VDC Nom:120V; Switching Power AC1:1kW; Load Current Resistive:25A; Switching Current AC3:10A; Product Range:22 Series; SVHC:No SVHC (12-Jan-2017); Approvals & Standards:CE; Coil Voltage:120V; Contact Current:25A; Contact Current Max:25A; Contact Material:Silver Nickel; Contact Voltage AC Nom:250V; Contact Voltage VAC:250V; External Depth:60.8mm; External Height:84mm; External Width:17.5mm; Nom Operating Power:2VA; Operating Temperature Max:50°C; Operating Temperature Min:-20°C; Relay Terminals:Screw; Relay Type:Modular; Termination Type:Screw

RELAY 4PST-NO 250VAC 25A; Load Current Inductive:-; Relay Mounting:DIN Rail; Operating Voltage:250VAC; Contact Configuration:4PST-NO; No. of Poles:4 Pole; Switching Power AC3:4kW; Switching Current AC1:-; Coil Voltage VAC Nom:48V; Coil Voltage VDC Nom:48V; Switching Power AC1:-; Load Current Resistive:25A; Switching Current AC3:10A; Product Range:22 Series; SVHC:No SVHC (12-Jan-2017); Approvals & Standards:CE; Coil Voltage:48V; Contact Current:25A; Contact Current Max:25A; Contact Material:Silver Nickel; Contact Voltage AC Nom:250V; Contact Voltage VAC:250V; External Depth:60.8mm; External Height:84mm; External Width:35mm; Nom Operating Power:2VA; Operating Temperature Max:50°C; Operating Temperature Min:-20°C; Relay Terminals:Screw; Relay Type:Modular; Termination Type:Screw

RELAY 2NO 2NC 250VAC 25A; Load Current Inductive:-; Relay Mounting:DIN Rail; Operating Voltage:250VAC; Contact Configuration:DPST-NO DPDT-NC; No. of Poles:4 Pole; Switching Power AC3:4kW; Switching Current AC1:-; Coil Voltage VAC Nom:12V; Coil Voltage VDC Nom:12V; Switching Power AC1:-; Load Current Resistive:25A; Switching Current AC3:10A; Product Range:22 Series; SVHC:No SVHC (12-Jan-2017); Approvals & Standards:CE; Coil Voltage:12V; Contact Current:25A; Contact Current Max:25A; Contact Material:Silver Nickel; Contact Voltage AC Nom:250V; Contact Voltage VAC:250V; External Depth:60.8mm; External Height:84mm; External Width:35mm; Nom Operating Power:2VA; Operating Temperature Max:50°C; Operating Temperature Min:-20°C; Relay Terminals:Screw; Relay Type:Modular; Termination Type:Screw

RELAY SPST-NO 250VAC 6A; Contact Configuration:SPST-NO; Coil Voltage:230VAC; Contact Current:6A; Product Range:39 Series; Relay Mounting:DIN Rail; Coil Type:AC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Voltage VAC Nom:230V; Contact Current Max:6A; Contact Voltage AC Nom:250V; Input Current:4.3mA; Nom Voltage:230V; Relay Type:Interface

SSR I/F MASTERPLUS 125VAC/DC; Contact Configuration:SPST-NO; Load Current:2A; Operating Voltage Max:24VDC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:-; Operating Voltage Min:1.5VDC; Control Voltage Min:88VDC; Control Voltage Max:138VDC; Product Range:39 Series; SVHC:No SVHC (12-Jan-2017); Control Voltage DC Max:138VDC; Control Voltage DC Min:88VDC; Control Voltage Range:88V DC to 138V DC; Control Voltage Type:AC DC; Input Current:5.5mA; Nom Voltage:125V; Operating Voltage Range:1.5V DC to 24V DC

SSR I/F MASTERPLUS 6VDC; Contact Configuration:SPST-NO; Load Current:2A; Operating Voltage Max:24VDC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:-; Operating Voltage Min:1.5VDC; Control Voltage Min:4.8VDC; Control Voltage Max:6.6VDC; Product Range:39 Series; SVHC:No SVHC (12-Jan-2017); Control Voltage DC Max:6.6VDC; Control Voltage DC Min:4.8VDC; Control Voltage Range:4.8V DC to 6.6V DC; Control Voltage Type:DC; Input Current:7.5mA; Nom Voltage:6V; Operating Voltage Range:1.5V DC to 24V DC

RELAY SPDT 250VAC 6A; Contact Configuration:SPDT; Coil Voltage:6V; Contact Current:6A; Product Range:39 Series; Relay Mounting:DIN Rail; Coil Type:AC / DC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Voltage VAC Nom:6V; Coil Voltage VDC Nom:6V; Contact Current Max:6A; Contact Voltage AC Nom:250V; Input Current:35mA; Nom Voltage:6V; Relay Type:Interface

RELAY SPDT 250VAC 6A; Contact Configuration:SPDT; Coil Voltage:125V; Contact Current:6A; Product Range:39 Series; Relay Mounting:DIN Rail; Coil Type:AC / DC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Voltage VAC Nom:125V; Coil Voltage VDC Nom:125V; Contact Current Max:6A; Contact Voltage AC Nom:250V; Input Current:5.6mA; Nom Voltage:125V; Relay Type:Interface

SSR I/F MASTERINPUT 2A 125VAC/DC; Contact Configuration:SPST-NO; Load Current:2A; Operating Voltage Max:24VDC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:-; Operating Voltage Min:1.5VDC; Control Voltage Min:88VDC; Control Voltage Max:138VDC; Product Range:39 Series; SVHC:No SVHC (12-Jan-2017); Control Voltage DC Max:138VDC; Control Voltage DC Min:88VDC; Control Voltage Range:88V DC to 138V DC; Control Voltage Type:AC DC; Input Current:5.5mA; Nom Voltage:125V; Operating Voltage Range:1.5V DC to 24V DC

SSR I/F MASTERINPUT 2A 230VAC; Contact Configuration:SPST-NO; Load Current:2A; Operating Voltage Max:24VDC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:-; Operating Voltage Min:1.5VDC; Product Range:39 Series; SVHC:No SVHC (12-Jan-2017); Control Voltage Type:AC; Input Current:4.2mA; Nom Voltage:230V; Operating Voltage Range:1.5V DC to 24V DC

RELAY SPDT 250VAC 6A; Contact Configuration:SPDT; Coil Voltage:24V; Contact Current:6A; Product Range:39 Series; Relay Mounting:DIN Rail; Coil Type:AC / DC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Voltage VAC Nom:24V; Coil Voltage VDC Nom:24V; Contact Current Max:6A; Contact Voltage AC Nom:250V; Input Current:11mA; Nom Voltage:24V; Relay Type:Interface

TIMER AC SSR 24VADC; Relay Mounting:DIN Rail; Load Current:2A; Operating Voltage Min:240VAC; Operating Voltage Max:-; Switching Mode:-; Timer Functions:Multifunction; Control Voltage AC Min:-; Control Voltage AC Max:24VAC; Control Voltage DC Min:-; Control Voltage DC Max:24VDC; Product Range:-; SVHC:No SVHC (12-Jan-2017); Adjustment Type:Screwdriver Slot; Coil Voltage VAC Nom:24V; Coil Voltage VDC Nom:24V; Contact Configuration:SPST-NO; Contact Current DC Max:2A; Contact Voltage AC Max:240V; Delay Time Range:0.1s to 6h; External Depth:75.6mm; External Length / Height:87.9mm; External Width:6.2mm; Nom Input Voltage:24V; Timing Adjustment:Screwdriver Slot

RELAY DPST-NO 250VAC 16A; Contact Configuration:DPST-NO; Coil Voltage:110VAC; Contact Current:16A; Product Range:20 Series; Relay Mounting:DIN Rail; Coil Type:AC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Tin Oxide; Coil Resistance:590ohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:64mA; Coil Operating Lower Percent Limit:85%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:110V; Contact Current AC Max:16A; Contact Current Max:30A; Contact Voltage AC Max:240V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:30V; Current Rating:16A; Dielectric Strength VDC:3.5kV; External Depth:84mm; External Height:58.4mm; External Length / Height:58.4mm; External Width:17.4mm; Nom Operating Power:6.5VA; Operating Temperature Max:40°C; Operating Temperature Min:-40°C; Relay Type:Power; Switched Current Max:16A; Switched Voltage Max:400V; Voltage Rating VAC:250V

RELAY SPST-1NO/1NC 250VAC 20A; Contact Configuration:SPST-NO SPST-NC; Coil Voltage:110VAC; Contact Current:20A; Product Range:22 Series; Relay Mounting:DIN Rail; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:-; Contact Material:Silver Tin Oxide; Coil Resistance:970ohm; Approvals & Standards:CE; SVHC:No SVHC (12-Jan-2017); Approval Category:IP20; Coil Current:26mA; Coil Operating Lower Percent Limit:85%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:110V; Contact Current AC Max:30A; Contact Current Max:20A; Contact Voltage AC Nom:250V; Current Rating:20A; Dielectric Strength VDC:3.5kV; External Depth:84mm; External Height:58.4mm; External Length / Height:58.4mm; External Width:17.4mm; Nom Operating Power:3VA; Operating Temperature Max:40°C; Operating Temperature Min:-40°C; Relay Type:Power; Switched Current Max:20A; Switched Voltage Max:400V; Voltage Rating VAC:250V

JUMPER LINK 6 WAY; Accessory Type:Jumper Link; For Use With:-; Product Range:-; SVHC:No SVHC (12-Jan-2017)

RELAY SPST-NO 250VAC 6A; Contact Configuration:SPST-NO; Coil Voltage:24VDC; Contact Current:6A; Product Range:32 Series; Relay Mounting:Through Hole; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Contact Voltage VDC:-; Contact Material:Silver Tin Oxide; Coil Resistance:2.88kohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:8.3mA; Coil Voltage VDC Nom:24V; Contact Current Max:15A; Contact Voltage AC Nom:250V; External Depth:20mm; External Height:10.7mm; External Width:10mm; Nom Operating Power:200mW; Relay Type:Power

RELAY DPDT 250VAC 16A; Contact Configuration:DPDT; Coil Voltage:24V; Contact Current:16A; Product Range:38 Series; Relay Mounting:DIN Rail; Coil Type:AC / DC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:CE CSA UL; SVHC:No SVHC (12-Jan-2017); Coil Voltage VAC Nom:24V; Coil Voltage VDC Nom:24V; Contact Current Max:30A; Relay Type:Interface

SOCKET FOR 56.34 RELAY; Socket Mounting:DIN Rail Panel; Socket Terminals:Screw; No. of Pins:14Pins; Current Rating:12A; Voltage Rating:250V; Product Range:-; SVHC:No SVHC (12-Jan-2017); Accessory Type:Socket; For Use With:56.34 Relay

RELAY SPDT 250VAC 10A; Product Range:40 Series; Relay Type:Power - General Purpose; Coil Type:-; Contact Configuration:SPDT; Coil Voltage:24VDC; Contact Current:10A; Contact Voltage VAC:250V; Contact Voltage VDC:-

RELAY DPDT 250VAC 8A; Contact Configuration:DPDT; Coil Voltage:24VAC; Contact Current:8A; Product Range:48 Series; Relay Mounting:DIN Rail; Coil Type:-; Contact Voltage VAC:250VAC; Relay Type:Interface; Relay Terminals:Screw
