RELAY POWER DPDT 120VAC 16A SOCKET; Product Range:FINDER - 62 Series; Coil Voltage:120VAC; Contact Current:16A; Contact Voltage VAC:250V; Contact Voltage VDC:-; Contact Configuration:DPDT; Coil Resistance:1.94kohm; Coil Type:AC

RELAY 3PDT 250VAC 16A; Contact Configuration:3PDT; Coil Voltage:240VAC; Contact Current:16A; Product Range:62 Series; Relay Mounting:Socket; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect

RELAY 3PDT 250VAC 16A; Contact Configuration:3PDT; Coil Voltage:120VAC; Contact Current:16A; Product Range:62 Series; Relay Mounting:Socket; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect

RELAY DPDT 250VAC 30A; Contact Configuration:DPDT; Coil Voltage:120VAC; Contact Current:30A; Product Range:66 Series; Relay Mounting:Panel; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Coil Current:30mA

RELAY DPDT 250VAC 30A; Contact Configuration:DPDT; Coil Voltage:24VAC; Contact Current:30A; Product Range:66 Series; Relay Mounting:Panel; Coil Type:AC; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect; Contact Voltage VDC:30V; Contact Material:Silver Cadmium Oxide; Coil Resistance:50ohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CE CSA IMQ VDE; Approval Category:UL Recognised; Coil Current:150mA; Coil Voltage Max:26.4V; Coil Voltage Min:19.2V; Coil Voltage VAC Nom:24V; Contact Current AC Max:50A; Contact Current Max:50A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Current Rating:30A; Dielectric Voltage Contact to Contact:1500VAC; External Depth:33.5mm; External Height:31mm; External Length / Height:31mm; External Width:51.5mm; Fixing Centres:59.5mm; Nom Operating Power:3.6VA; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Operating Time:8ms; Relay Type:Power - General Purpose; Release Time:15ms; Termination Method:Tab

RELAY 4PDT 250VAC 12A; Contact Configuration:4PDT; Coil Voltage:120VAC; Contact Current:12A; Product Range:56 Series; Relay Mounting:Socket; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Quick Connect

TIMER OFF DELAY SPDT 240V; Product Range:80 Series; Timer Functions:Off-Delay; Time Min:0.1s; Time Max:24h; No. of Timing Ranges:6Ranges; Timer Output:1 Changeover Relay; Supply Voltage Max:240V; Current Rating Nom:500mA; Connection / Termination:Screw Terminals; SVHC:No SVHC (12-Jan-2017); Contact Configuration:SPDT; Nom Input Voltage:240V; Relay Mounting:DIN Rail; Supply Voltage Min:24V; Timing Adjustment:Screwdriver Slot

DIN-RAIL/PANEL MOUNT SCREW TERMINAL (BOX CLAMP) SOCKET FOR 60.13 RELAY(BLACK)

RELAY DPST-NO 250VAC 16A; Contact Configuration:DPST-NO; Coil Voltage:110VAC; Contact Current:16A; Product Range:20 Series; Relay Mounting:DIN Rail; Coil Type:AC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Tin Oxide; Coil Resistance:590ohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:64mA; Coil Operating Lower Percent Limit:85%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:110V; Contact Current AC Max:16A; Contact Current Max:30A; Contact Voltage AC Max:240V; Contact Voltage AC Nom:250V; Contact Voltage DC Max:30V; Current Rating:16A; Dielectric Strength VDC:3.5kV; External Depth:84mm; External Height:58.4mm; External Length / Height:58.4mm; External Width:17.4mm; Nom Operating Power:6.5VA; Operating Temperature Max:40°C; Operating Temperature Min:-40°C; Relay Type:Power; Switched Current Max:16A; Switched Voltage Max:400V; Voltage Rating VAC:250V

RELAY SPST-1NO/1NC 250VAC 20A; Contact Configuration:SPST-NO SPST-NC; Coil Voltage:110VAC; Contact Current:20A; Product Range:22 Series; Relay Mounting:DIN Rail; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:-; Contact Material:Silver Tin Oxide; Coil Resistance:970ohm; Approvals & Standards:CE; SVHC:No SVHC (12-Jan-2017); Approval Category:IP20; Coil Current:26mA; Coil Operating Lower Percent Limit:85%; Coil Operating Upper Percent Limit:110%; Coil Voltage VAC Nom:110V; Contact Current AC Max:30A; Contact Current Max:20A; Contact Voltage AC Nom:250V; Current Rating:20A; Dielectric Strength VDC:3.5kV; External Depth:84mm; External Height:58.4mm; External Length / Height:58.4mm; External Width:17.4mm; Nom Operating Power:3VA; Operating Temperature Max:40°C; Operating Temperature Min:-40°C; Relay Type:Power; Switched Current Max:20A; Switched Voltage Max:400V; Voltage Rating VAC:250V

JUMPER LINK 6 WAY; Accessory Type:Jumper Link; For Use With:-; Product Range:-; SVHC:No SVHC (12-Jan-2017)

RELAY SPST-NO 110VAC 10A; Contact Configuration:SPST-NO; Coil Voltage:230VAC; Contact Current:10A; Product Range:27 Series; Relay Mounting:Panel; Coil Type:-; Contact Voltage VAC:110VAC; Relay Terminals:Screw; Contact Voltage VDC:-; Contact Material:Silver Nickel; Coil Resistance:6.5kohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Voltage Max:253VAC; Coil Voltage Min:184VAC; Coil Voltage VAC Nom:230V; Relay Type:Power

KWH METER 1 PHASE 32A; Meter Function:Energy; Meter Range:-; Panel Cutout Height:-; Panel Cutout Width:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); External Depth:44mm; External Length / Height:85mm; External Width:17.5mm; IP / NEMA Rating:IP50; Input Voltage Max:230VAC; Meter Size/Dimensions:89.2mm x 17.5mm x 63mm; Operating Temperature Max:45°C; Operating Temperature Min:-10°C; Power Rating:400mW; Supply Current:5A

ELECTRODE CONNECTOR; Product Range:72 Series; SVHC:No SVHC (12-Jan-2017); Body Material:Stainless Steel; Level Sensor Type:Liquid

RELAY SPDT 250VAC 10A; Contact Configuration:SPDT; Coil Voltage:24VDC; Contact Current:10A; Product Range:49 Series; Relay Mounting:DIN Rail; Coil Type:DC Sensitive; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:22.2mA; Coil Voltage Max:400VAC; Coil Voltage Min:250VAC; Coil Voltage VDC Nom:24V; Contact Current AC Max:10A; Contact Current Max:20A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Current Max:20A; Current Rating:10A; External Depth:75mm; External Height:81.9mm; External Length / Height:81.9mm; External Width:15.5mm; IP / NEMA Rating:IP20; Input Voltage:24VDC; Input Voltage Max:24VDC; No. of Electrical Operations:200000; Nom Operating Power:500mW; Operating Current:10A; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Relay Type:Interface; Switch Power Max:300mW; Switching Power Max:300mW

RELAY DPDT 250VAC 8A; Contact Configuration:DPDT; Coil Voltage:12VDC; Contact Current:8A; Product Range:49 Series; Relay Mounting:DIN Rail; Coil Type:DC Sensitive; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:41mA; Coil Voltage Max:250VAC; Coil Voltage Min:250VAC; Coil Voltage VDC Nom:12V; Contact Current AC Max:8A; Contact Current Max:15A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Current Max:15A; Current Rating:8A; External Depth:75mm; External Length / Height:81.9mm; External Width:15.5mm; IP / NEMA Rating:IP20; Input Voltage:12VDC; Input Voltage Max:12VDC; No. of Electrical Operations:150000; Nom Operating Power:500mW; Operating Current:8A; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Relay Type:Interface; Switch Power Max:300mW; Switching Power Max:300mW

RELAY DPDT 250VAC 8A; Contact Configuration:DPDT; Coil Voltage:230VAC; Contact Current:8A; Product Range:49 Series; Relay Mounting:DIN Rail; Coil Type:AC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:7mA; Coil Voltage Max:250VAC; Coil Voltage Min:250VAC; Coil Voltage VAC Nom:230V; Contact Current AC Max:8A; Contact Current Max:15A; Contact Voltage AC Max:250V; Contact Voltage AC Nom:250V; Current Max:15A; Current Rating:8A; External Depth:75mm; External Length / Height:81.9mm; External Width:15.5mm; IP / NEMA Rating:IP20; Input Voltage:230VAC; Input Voltage Max:230VAC; No. of Electrical Operations:150000; Nom Operating Power:1.2VA; Operating Current:8A; Operating Temperature Max:70°C; Operating Temperature Min:-40°C; Relay Type:Interface; Switch Power Max:300mW; Switching Power Max:300mW

RELAY 3 PH SPDT 400VAC; Product Range:-; Contact Configuration:SPDT; Contact Current:10A; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Voltage Max:250VAC; Supply Voltage Max:400VAC; Phase Type:3 Phase; Power Consumption:4VA; Phase Monitoring Range Min:-; Phase Monitoring Range Max:400VAC; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Contact Current AC Max:10A; Contact Voltage AC Max:250V; External Depth:58mm; External Length / Height:85mm; External Width:35mm; Input Voltage:400VAC; Input Voltage Max:400VAC; Load Current:10A; Nom Input Voltage:400VAC; Operating Temperature Max:50°C; Operating Temperature Min:-20°C; Output Voltage:250VAC; Supply Voltage:400VAC; Switch Current Max:15A; Switching Current Max:15A

Temperature Controller (Thermistor, PTC) 24VAC/DC DIN Rail

RELAY LEVEL CONTROL 230-240VAC DIN; Supply Voltage:240V; Response Time:0.7s; Power Consumption:1.5W; Product Range:72.01 Series; SVHC:No SVHC (12-Jan-2017); AC Coil Power:750VA; Contact Configuration:SPDT; External Depth:58mm; External Length / Height:84mm; External Width:35mm; IP / NEMA Rating:IP20; Input Current:16mA; Load Power:4000VA; Operating Temperature Max:60°C; Operating Temperature Min:-20°C
