RELAY CONTACTOR

RELAY 3PST-NO SPST-NC 250VAC 25A; Load Current Inductive:-; Relay Mounting:DIN Rail; Operating Voltage:250VAC; Contact Configuration:3PST-NO SPST-NC; No. of Poles:4 Pole; Switching Power AC3:4kW; Switching Current AC1:-; Coil Voltage VAC Nom:12V; Coil Voltage VDC Nom:12V; Switching Power AC1:-; Load Current Resistive:25A; Switching Current AC3:10A; Product Range:22 Series; SVHC:No SVHC (12-Jan-2017); Approvals & Standards:CE; Coil Voltage:12V; Contact Current:25A; Contact Current Max:25A; Contact Material:Silver Nickel; Contact Voltage AC Nom:250V; Contact Voltage VAC:250V; External Depth:60.8mm; External Height:84mm; External Width:35mm; Nom Operating Power:2VA; Operating Temperature Max:50°C; Operating Temperature Min:-20°C; Relay Terminals:Screw; Relay Type:Modular; Termination Type:Screw

SSR I/F MASTERBASIC 2A 12VDC; Contact Configuration:SPST-NO; Load Current:2A; Operating Voltage Max:24VDC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:-; Operating Voltage Min:1.5VDC; Control Voltage Min:9.6VDC; Control Voltage Max:13.2VDC; Product Range:39 Series; SVHC:No SVHC (12-Jan-2017); Control Voltage DC Max:13.2VDC; Control Voltage DC Min:9.6VDC; Control Voltage Range:9.6V DC to 13.2V DC; Control Voltage Type:DC; Input Current:20.7mA; Nom Voltage:12V; Operating Voltage Range:1.5V DC to 24V DC

SSR I/F MASTEROUTPUT 2A 12VDC; Contact Configuration:SPST-NO; Load Current:2A; Operating Voltage Max:24VDC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:-; Operating Voltage Min:1.5VDC; Control Voltage Min:9.6VDC; Control Voltage Max:13.2VDC; Product Range:39 Series; SVHC:No SVHC (12-Jan-2017); Control Voltage DC Max:13.2VDC; Control Voltage DC Min:9.6VDC; Control Voltage Range:9.6V DC to 13.2V DC; Control Voltage Type:DC; Input Current:20.7mA; Nom Voltage:12V; Operating Voltage Range:1.5V DC to 24V DC

RELAY SPST-NO 250VAC 6A; Contact Configuration:SPST-NO; Coil Voltage:6V; Contact Current:6A; Product Range:39 Series; Relay Mounting:DIN Rail; Coil Type:AC / DC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Voltage VAC Nom:6V; Coil Voltage VDC Nom:6V; Contact Current Max:6A; Contact Voltage AC Nom:250V; Input Current:35mA; Nom Voltage:6V; Relay Type:Interface

SSR I/F MASTERPLUS 24VAC/DC; Contact Configuration:SPST-NO; Load Current:2A; Operating Voltage Max:24VDC; Relay Mounting:DIN Rail; Relay Terminals:Screw; Switching Mode:-; Operating Voltage Min:1.5VDC; Control Voltage Min:19.2VDC; Control Voltage Max:26.4VDC; Product Range:39 Series; SVHC:No SVHC (12-Jan-2017); Control Voltage DC Max:26.4VDC; Control Voltage DC Min:19.2VDC; Control Voltage Range:19.2V DC to 26.4V DC; Control Voltage Type:AC DC; Input Current:10.5mA; Nom Voltage:24V; Operating Voltage Range:1.5V DC to 24V DC

RELAY SPDT 250VAC 6A; Contact Configuration:SPDT; Coil Voltage:60V; Contact Current:6A; Product Range:39 Series; Relay Mounting:DIN Rail; Coil Type:AC / DC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Voltage VAC Nom:60V; Coil Voltage VDC Nom:60V; Contact Current Max:6A; Contact Voltage AC Nom:250V; Input Current:5.7mA; Nom Voltage:60V; Relay Type:Interface

RELAY SPDT 250VAC 6A; Contact Configuration:SPDT; Coil Voltage:230VAC; Contact Current:6A; Product Range:39 Series; Relay Mounting:DIN Rail; Coil Type:AC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Voltage VAC Nom:230V; Contact Current Max:6A; Contact Voltage AC Nom:250V; Input Current:4.3mA; Nom Voltage:230V; Relay Type:Interface

RELAY SPDT 250VAC 6A; Contact Configuration:SPDT; Coil Voltage:6V; Contact Current:6A; Product Range:39 Series; Relay Mounting:DIN Rail; Coil Type:AC / DC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Voltage VAC Nom:6V; Coil Voltage VDC Nom:6V; Contact Current Max:6A; Contact Voltage AC Nom:250V; Input Current:35mA; Nom Voltage:6V; Relay Type:Interface

RELAY SPDT 250VAC 6A; Contact Configuration:SPDT; Coil Voltage:12V; Contact Current:6A; Product Range:39 Series; Relay Mounting:DIN Rail; Coil Type:AC / DC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Voltage VAC Nom:12V; Coil Voltage VDC Nom:12V; Contact Current Max:6A; Contact Voltage AC Nom:250V; Input Current:15mA; Nom Voltage:12V; Relay Type:Interface

RELAY SPDT 250VAC 6A; Contact Configuration:SPDT; Coil Voltage:230VAC; Contact Current:6A; Product Range:39 Series; Relay Mounting:DIN Rail; Coil Type:AC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Voltage VAC Nom:230V; Contact Current Max:6A; Contact Voltage AC Nom:250V; Input Current:4.3mA; Nom Voltage:230V; Relay Type:Interface

ADAPTOR 8WAY PLC O/P TO RIBBON CBL; Accessory Type:Adaptor 8 Way; Product Range:39 Series; SVHC:No SVHC (12-Jan-2017)

RELAY SPST-NO 250VAC 6A; Contact Configuration:SPST-NO; Coil Voltage:12VDC; Contact Current:6A; Product Range:32 Series; Relay Mounting:Through Hole; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Contact Voltage VDC:-; Contact Material:Silver Tin Oxide; Coil Resistance:720ohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:16mA; Coil Voltage VDC Nom:12V; Contact Current Max:15A; Contact Voltage AC Nom:250V; External Depth:20mm; External Height:10.7mm; External Width:10mm; Nom Operating Power:200mW; Relay Type:Power

RELAY SPDT 250VAC 6A; Contact Configuration:SPDT; Coil Voltage:48VDC; Contact Current:6A; Product Range:34 Series; Relay Mounting:Through Hole; Coil Type:DC Sensitive; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:12.3kohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:3.9mA; Coil Voltage VDC Nom:48V; Contact Current Max:10A; Contact Voltage AC Nom:250V; External Depth:28mm; External Height:15mm; External Width:5mm; Nom Operating Power:170mW

RELAY SPST-NO 24VDC 0.002A; Contact Configuration:SPST-NO; Load Current:2A; Operating Voltage Max:17VDC; Relay Mounting:PCB; Relay Terminals:Screw; Switching Mode:-; Operating Voltage Min:8VDC; Control Voltage Min:-; Control Voltage Max:-; Product Range:34 Series; SVHC:No SVHC (12-Jan-2017); Coil Resistance:1.94kohm; Coil Voltage:12VDC; Coil Voltage VDC Nom:12V; Contact Current:2mA; Contact Current Max:2mA; Contact Material:Silver Nickel; Contact Voltage AC Nom:240V; Contact Voltage DC Nom:24V; Contact Voltage VDC:24V; Control Voltage Type:DC; External Depth:5mm; External Height:15mm; External Width:28mm; Load Voltage Range:12V AC to 240V AC; Nom Operating Power:87mW

RELAY SPST-NO 24VDC 0.002A; Contact Configuration:SPST-NO; Load Current:2A; Operating Voltage Max:17VDC; Relay Mounting:PCB; Relay Terminals:Screw; Switching Mode:-; Operating Voltage Min:8VDC; Control Voltage Min:-; Control Voltage Max:-; Product Range:34 Series; SVHC:No SVHC (12-Jan-2017); Coil Resistance:1.94kohm; Coil Voltage:12VDC; Coil Voltage VDC Nom:12V; Contact Current:2mA; Contact Current Max:2mA; Contact Material:Silver Nickel; Contact Voltage DC Nom:24V; Contact Voltage VDC:24V; Control Voltage Type:DC; External Depth:5mm; External Height:15mm; External Width:28mm; Load Voltage Range:1.5V DC to 24V DC; Nom Operating Power:87mW

RELAY DPDT 250VAC 16A; Contact Configuration:DPDT; Coil Voltage:125V; Contact Current:16A; Product Range:38 Series; Relay Mounting:DIN Rail; Coil Type:AC / DC; Contact Voltage VAC:250VAC; Relay Terminals:Screw; Contact Voltage VDC:30V; Contact Material:Silver Nickel; Coil Resistance:-; Approvals & Standards:CE CSA UL; SVHC:No SVHC (12-Jan-2017); Average Power Consumption:0.6VA; Coil Voltage VAC Nom:125V; Coil Voltage VDC Nom:125V; Contact Current Max:30A; External Depth:77.1mm; External Height:89.7mm; External Width:14mm; Relay Type:Interface

RELAY SPST-NO 250VAC 16A; Contact Configuration:SPST-NO; Coil Voltage:12VDC; Contact Current:16A; Product Range:43 Series; Relay Mounting:Through Hole; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Contact Voltage VDC:-; Contact Material:Silver Cadmium Oxide; Coil Resistance:360ohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:33.3mA; Coil Voltage VDC Nom:12V; Contact Current Max:25A; Contact Voltage AC Nom:250V; External Depth:28.6mm; External Height:15.4mm; External Width:10.2mm; Nom Operating Power:400mW; Relay Type:Power

RELAY SPST-NO 250VAC 16A; Contact Configuration:SPST-NO; Coil Voltage:24VDC; Contact Current:16A; Product Range:43 Series; Relay Mounting:Through Hole; Coil Type:-; Contact Voltage VAC:250VAC; Relay Terminals:Solder; Contact Voltage VDC:-; Contact Material:Silver Cadmium Oxide; Coil Resistance:1.4kohm; Approvals & Standards:-; SVHC:No SVHC (12-Jan-2017); Coil Current:17.1mA; Coil Voltage VDC Nom:24V; Contact Current Max:25A; Contact Voltage AC Nom:250V; External Depth:28.6mm; External Height:15.4mm; External Width:10.2mm; Nom Operating Power:400mW; Relay Type:Power

RELAYS
