DCP CONTROLLER 24V 20-40C OC AL; Accessory Type:DCP Fan Controller; For Use With:EBM Pabst DC Compact PWM Controlled Fans; Product Range:-; SVHC:No SVHC (12-Jan-2017); External Depth:45mm; External Length / Height:8mm; External Width:57mm; Operating Temperature Max:75°C; Operating Temperature Min:-20°C; Output:Alarm; Output Type:Open Drain; Supply Voltage:24VDC; Supply Voltage Max:33VDC; Supply Voltage Min:15VDC; Temperature Controller Operating Type:20°C to 40°C; Thermocouple Type:NTC

DCP CONTROLLER 48V 35-55C OC AL; Accessory Type:DCP Fan Controller; For Use With:EBM Pabst DC Compact 4 Wire PWM Controlled Fans; Product Range:-; SVHC:No SVHC (12-Jan-2017); External Depth:45mm; External Length / Height:8mm; External Width:57mm; Operating Temperature Max:75°C; Operating Temperature Min:-20°C; Output:Alarm; Output Type:Open Drain; Supply Voltage:48VDC; Supply Voltage Max:55VDC; Supply Voltage Min:36VDC; Temperature Controller Operating Type:35°C to 55°C; Thermocouple Type:NTC

DC FAN CONTROLLER 24V RELAY ALARM; Accessory Type:DC Fan Speed Controller; For Use With:EBM Pabst 2 and 3 Wire DC Fans; Product Range:-; SVHC:No SVHC (12-Jan-2017); Contact Configuration:1NC; External Depth:72.4mm; External Length / Height:19.6mm; External Width:71.1mm; Fixing Centres LxW:61 x 60.3mm; Operating Temperature Max:+55°C; Operating Temperature Min:+20°C; Output:Alarm; Output Current Max:1A; Output Type:Relay; Output Voltage Max:50V; Supply Voltage:24VDC; Supply Voltage Max:25.2VDC; Supply Voltage Min:22.8VDC; Thermocouple Type:NTC

DC FAN CONTROLLER 48V RELAY ALARM; Accessory Type:DC Fan Speed Controller; For Use With:EBM Pabst 2 and 3 Wire DC Fans; Product Range:-; SVHC:No SVHC (12-Jan-2017); Contact Configuration:1NC; External Depth:72.4mm; External Length / Height:19.6mm; External Width:71.1mm; Fixing Centres LxW:61 x 60.3mm; Operating Temperature Max:+55°C; Operating Temperature Min:+20°C; Output:Alarm; Output Current Max:1A; Output Type:Relay; Output Voltage Max:50V; Supply Voltage:48VDC; Supply Voltage Max:49VDC; Supply Voltage Min:47VDC; Thermocouple Type:NTC

FAN EC 200MM 230VAC 500M3/H 41DBA; Supply Voltage:230V; Current Type:AC; Fan Frame Size:200mm; External Depth:79mm; Noise Rating:41dBA; Flow Rate - Imperial:294.29cu.ft/min; Flow Rate - Metric:500m³/h; Bearing Type:Ball; Power Connection Type:Power Cord; Current Rating:70mA; Product Range:W1G200 Series; Power Rating:-; IP Rating:IP54; SVHC:No SVHC (12-Jan-2017); Frame Dimensions:200mm x 78.5mm

AXIAL PROP 172X34"V"

AXIAL PROP 230X28"V"

BLOWER RADIAL 12VDC 105X59X79MM; Blower Type:Centrifugal; Supply Voltage:12V; Current Type:DC; Fan Frame Size:105mm; External Depth:58.85mm; Flow Rate - Metric:24m³/h; Flow Rate - Imperial:14.1cu.ft/min; Noise Rating:5dBA; Bearing Type:Ball; Power Connection Type:2 Lead Wires; Power Rating:4.5W; Product Range:RV 40 Series; IP Rating:-; SVHC:No SVHC (12-Jan-2017); External Height:79mm; External Width:105mm; Frame Dimensions:79mm x 105mm x 59mm; Material:Fibreglass-reinforced halogen free plastic; Operating Temperature Max:70°C; Operating Temperature Min:-20°C; Operating life Time:50000h; Power Consumption:4.5W; Speed Range Max:4800rpm; Weight:0.1kg

FAN 119X119X38MM 24VAC; Supply Voltage:24V; Current Type:AC; Fan Frame Size:119mm; External Depth:38mm; Noise Rating:50dBA; Flow Rate - Imperial:105.9cu.ft/min; Flow Rate - Metric:2.97m³/min; Bearing Type:Sleeve; Power Connection Type:Terminals; Current Rating:-; Product Range:4000N Series; Power Rating:18W; IP Rating:-; SVHC:No SVHC (12-Jan-2017); External Height:119mm; External Width:119mm; Frame Dimensions:119mm x 119mm x 38mm

AXIAL FAN 119MM 24VDC; Supply Voltage:24V; Current Type:DC; Fan Frame Size:119mm; External Depth:38mm; Noise Rating:70dBA; Flow Rate - Imperial:229.5cu.ft/min; Flow Rate - Metric:390m /h; Bearing Type:Ball; Current Rating:- ;RoHS Compliant: Yes

AC Fans AC Axial Fan, 130mm 230VAC, Ball, IP44

AXIAL FAN 92MM 24VDC; Frame Dimensions; AXIAL FAN 92MM 24VDC; Frame Dimensions:92mm x 92mm x 25mm; Supply Voltage:24VDC; Flow Rate - Imperial:55cu.ft/min; Flow Rate - Metric:94m /h; Noise Rating:36dBA; Bearing Type:Ball; Power Connection Type:Wire Leaded; Series:3400N

FAN 60MM 12VDC INSERT & CONN; Supply Voltage:12V; Current Type:DC; Fan Frame Size:60mm; External Depth:25mm; Noise Rating:38dBA; Flow Rate - Imperial:27.1cu.ft/min; Flow Rate - Metric:46m³/h; Bearing Type:Sleeve; Power Connection Type:2 Lead Wires with Connector; Current Rating:-; Product Range:Plug 'n' Play Series; Power Rating:-; IP Rating:IP20; SVHC:No SVHC (12-Jan-2017); External Height:60mm; External Width:60mm; Frame Dimensions:60mm x 60mm x 25mm; Power Consumption:2.6W

DC Fan Ball Bearing 12V 13W 5000RPM 167.7CFM 55dB Flange Mount

AC BACKWARD-CURVED MOTORIZED IMPELLER

AC MOTORIZED IMPELLER 220MMx 71MM 115VAC; Blower Type:Motorized Impeller; Supply Voltage:115V; Current Type:AC; Fan Frame Size:252mm; External Depth:71mm; Flow Rate - Metric:15m /min; Flow Rate - Imperial:530cu.ft/min ;RoHS Compliant: Yes

DC MOTORIZED IMPELLER 175 X 69MM 48V; Blower Type:Motorized Impeller; Supply Voltage:48V; Current Type:DC; Fan Frame Size:175mm; External Depth:69mm; Flow Rate - Metric:10m /min; Flow Rate - Imperial:353cu.ft/min; Bearing Type:Ball;RoHS Compliant: Yes

FAN 119X119X38MM 12V DC; Supply Voltage:12V; Current Type:DC; Fan Frame Size:119mm; External Depth:38mm; Noise Rating:37dBA; Flow Rate - Imperial:88.3cu.ft/min; Flow Rate - Metric:150m³/h; Bearing Type:Ball; Power Connection Type:2 Lead Wires; Current Rating:-; Product Range:4400 Series; Power Rating:2.5W; IP Rating:IP54; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CSA UL; External Height:119mm; External Width:119mm; Fixing Centres:82.5mm; Fixing Hole Diameter:4.5mm; Frame Dimensions:119mm x 119mm x 38mm; Input Voltage Max:14.5V; Input Voltage Min:7V; Operating Temperature Max:70°C; Operating Temperature Min:-20°C; Operating life Time:70000h; Panel Cutout Diameter:116mm; Power Consumption:3W; Standard:VDE0730; Supply Voltage DC Max:14.5V; Supply Voltage DC Min:7V; Type:Low Noise 119mm 38mm depth

FAN 60X60X25MM 12V DC; Supply Voltage:12V; Current Type:DC; Fan Frame Size:60mm; External Depth:25mm; Noise Rating:28dBA; Flow Rate - Imperial:20.6cu.ft/min; Flow Rate - Metric:0.58m³/min; Bearing Type:Sleeve; Power Connection Type:2 Lead Wires; Current Rating:-; Product Range:600NG Series; Power Rating:-; IP Rating:IP54 IP68; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CSA UL; External Height:60mm; External Width:60mm; Fixing Centres:50mm; Fixing Hole Diameter:4mm; Frame Dimensions:60mm x 60mm x 25mm; Input Voltage Max:15V; Input Voltage Min:8V; Operating Temperature Max:65°C; Operating Temperature Min:-20°C; Operating life Time:35000h; Panel Cutout Diameter:58mm; Power Consumption:1.6W; Standard:VDE0730; Supply Voltage DC Max:15V; Supply Voltage DC Min:8V; Type:Low Noise 60mm

FAN 80X80X25MM 12V DC; Supply Voltage:12V; Current Type:DC; Fan Frame Size:80mm; External Depth:25mm; Noise Rating:26dBA; Flow Rate - Imperial:34.1cu.ft/min; Flow Rate - Metric:58m³/h; Bearing Type:Sleeve; Power Connection Type:2 Lead Wires; Current Rating:-; Product Range:8400N Series; Power Rating:-; IP Rating:IP54 IP68; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CSA UL VDE; External Height:80mm; External Width:80mm; Fixing Centres:71.5mm; Fixing Hole Diameter:4.5mm; Frame Dimensions:80mm x 80mm x 25mm; Input Voltage Max:15V; Input Voltage Min:8V; Lead Length:310mm; Panel Cutout Diameter:77mm; Power Consumption:1.3W; Supply Voltage DC Max:15V; Supply Voltage DC Min:8V; Type:Low Noise 80mm
