SWITCH PUSHBUTTON DPDT 5A 250V; Product Range:14 Series; Contact Configuration:DPDT; Switch Operation:(On); Contact Current Max:5A; Contact Voltage AC Nom:250V; Illumination Color:-; Contact Voltage DC Nom:24V; IP Rating:IP67 ;RoHS Compliant: Yes

SWITCH SPNO LED GREY; Accessory Type:Lens; For Use With:96 Series Pushbutton Switches and Indicators; Product Range:-; SVHC:No SVHC (15-Jun-2015); Actuator / Cap Colour:Grey; Colour:Grey; Contact Configuration:1NO; Contact Current @ Contact Voltage DC Max:100mA; Contact Current AC Max:100mA; Contact Current DC Max:100mA; Contact Resistance:1000mohm; Contact Voltage AC Max:42V; Contact Voltage DC Max:42V; External Depth:14mm; External Length / Height:17.4mm; External Width:12.4mm; LED Voltage:2.2V; Lens Colour:Grey; Lens Depth:12.4mm; Lens Length:17.4mm; Lens Shape:Rectangular; Lens Type:Panel Mount; No. of Mechanical Operations:5000000; Operating Temperature Max:85°C; Operating Temperature Min:-25°C; Switch Terminals:Solder

ACTUATOR MOMENTARY IP40; For Use With:Swisstac Series Illuminated Pushbutton switches; IP / NEMA Rating:IP40; Product Range:-; SVHC:No SVHC (15-Jun-2015); Approval Bodies:CSA SEMKO SEV UL VDE; Contact Current @ Contact Voltage AC Max:6A; External Depth:35mm; External Length / Height:18m; External Width:18mm; Operating Force Max:2N; Panel Cutout Diameter:16mm

LATCH ACTUATOR IP40; For Use With:Swisstac Series Illuminated Pushbutton switches; IP / NEMA Rating:IP40; Product Range:-; SVHC:No SVHC (15-Jun-2015); Contact Current @ Contact Voltage AC Max:6A; External Depth:35mm; External Width:24mm; Panel Cutout Diameter:16mm

LENS RED; Indicator Lens Colour:Red; Lens Shape:-; Mounting Hole Dia:-; Accessory Type:-; Product Range:-; SVHC:No SVHC (15-Jun-2015); For Use With:35mm Series

LENS RED; Indicator Lens Colour:Red; Lens Shape:-; Mounting Hole Dia:-; Accessory Type:-; Product Range:-; SVHC:No SVHC (15-Jun-2015); For Use With:35mm Series

LENS GREEN; Indicator Lens Colour:Green; Lens Shape:-; Mounting Hole Dia:-; Accessory Type:-; Product Range:-; SVHC:No SVHC (15-Jun-2015); For Use With:35mm Series

INDICATOR BLOCK; Lamp Base Type:-; Mounting Hole Dia:16mm; Current Rating:-; Supply Voltage:-; Lens Shape:-; Product Range:-; SVHC:No SVHC (15-Jun-2015); External Depth:35mm; Panel Cutout Diameter:16mm

SWITCH PUSHBUTTON DPDT 5A 250V; Product Range:31 Series; Contact Configuration:DPDT; Switch Operation:On-On; Contact Current Max:5A; Contact Voltage AC Nom:250V; Illumination Color:-; Contact Voltage DC Nom:250V; IP Rating:IP40

Switch Contact Blocks / Switch Kits

PUSHBUTTON SWITCH; Product Range:-; Contact Configuration:-; Switch Operation:-; Contact Current Max:-; Contact Voltage AC Nom:-; Illumination Color:-; Contact Voltage DC Nom:-; Switch Terminals:Solder

KEY SWITCH SPST-NC/SPST-NO 5A 250V; Product Range:-; Contact Configuration:SPST-NC SPST-NO; Switch Operation:Off-On; Switch Terminals:Quick Connect; Contact Current Max:5A; Contact Voltage AC Nom:250V; Contact Voltage DC Nom:250V

LED BULB BA9S WHITE BA9S; For Use With:04 Series Illuminated Flush Mount Pushbutton Switches; Product Range:-; Bulb Size:BA9S; Colour:White; Current Rating:5mA; Forward Current If:5mA; Forward Voltage:130V; LED Color:White

LAMP INCANDESCENT 60V; For Use With:02 & 03 Series Illuminated Pushbutton Switches; Product Range:-; Average Bulb Life:6000h; MSCP:0.18; Supply Voltage:60V ;RoHS Compliant: Yes

SWITCH ACTUATOR; For Use With:EAO 04 Series Keylock Switches; IP / NEMA Rating:-; Product Range:-; Angle of Throw:90 ; Contact Current AC Max:6A; Contact Current DC Max:10A; Contact Current Max:10A; Contact Voltage AC Max:500V ;RoHS Compliant: Yes

Pushbutton-actuator grey/blue mom D29 ;RoHS Compliant: Yes

SWITCH

LED; Bulb Size:-; LED Color:-; Luminous Intensity:-; Viewing Angle:-; Forward Current If:-; Forward Voltage:-; LED Mounting:-; Lens Shape:-; Wavelength Typ:-; Packaging:Each; MSL:- ;RoHS Compliant: Yes

LENS; Switch Lens Colour:Red; Product Range:-; For Use With:EAO 19 Series Pushbutton Switches; Lens Height:9mm; Lens Width:9mm ;RoHS Compliant: Yes

LENS RECTANGULAR RED; Lens Shape:Rectangular; Switch Lens Colour:Red; Product Range:-; Actuator Diameter:18mm; For Use With:EAO 51 Series Pushbutton Switches; Lens Height:18mm; Lens Width:24mm ;RoHS Compliant: Yes
