RI-90 SERIES REED SWITCH

MRB SERIES SOLID STATE RELAY ;ROHS COMPLIANT: YES

REED RELAY ;ROHS COMPLIANT: YES

Coto Classic Reed Relays

RELAY REED SPST-NO 200V 0.5A SMD; Contact Configuration:SPST-NO; Coil Voltage:12VDC; Product Range:9400 Series; Relay Mounting:SMD; Coil Resistance:825ohm; Switching Current Max:500mA; Switching Voltage Max:200V ;RoHS Compliant: Yes

REED RELAY DPST-NO 5VDC 0.5A THD; Co; REED RELAY DPST-NO 5VDC 0.5A THD; Coil Voltage VDC Nom:5V; Coil Resistance:375ohm; Switching Current Max:500mA; Switching Voltage Max:200V; Contact Configuration:DPST-NO; Relay Mounting:PCB; External Height:8.89mm

RELAY REED DPST-NO 200V 0.5A THT; Contact Configuration:DPST-NO; Coil Voltage:12VDC; Product Range:9092 Series; Relay Mounting:Through Hole; Coil Resistance:750ohm; Switching Current Max:500mA; Switching Voltage Max:200V; Approvals & Standards:-; Approval Bodies:UL; Coil Voltage Max:15VDC; Coil Voltage VDC Nom:12V; Contact Current DC Max:500mA; Contact Resistance:140mohm; Contact Voltage DC Max:200V; Dielectric Strength VAC:1500V; External Depth:15.24mm; External Height:8.89mm; External Length / Height:8.89mm; External Width:3.81mm; Insulation Resistance:1000Gohm; Lead Spacing:2.54mm; Must Actuate Voltage:9VDC; Must Release Voltage:1VDC; No. of Pins:6Pins; Operating Temperature Max:85°C; Operating Temperature Min:-20°C; Operating Time:0.75ms; Release Time:0.5ms; Switch Current Max:500mA; Switch Power Max:10W; Type:Diode and External shield

RELAY REED SPDT 30V 0.1A SMD; Contact Configuration:SPDT; Coil Voltage:5VDC; Product Range:-; Relay Mounting:SMD; Coil Resistance:110ohm; Switching Current Max:100mA; Switching Voltage Max:30V; Approvals & Standards:-; Approval Bodies:UL; Coil Voltage Max:6VDC; Coil Voltage VDC Nom:5V; Contact Resistance:150mohm; Dielectric Strength VAC:1000V; External Depth:10.16mm; External Height:4.95mm; External Length / Height:4.31mm; External Width:4.95mm; Insulation Resistance:1000Mohm; Lead Spacing:1.02mm; Must Actuate Voltage:3.8VDC; Must Release Voltage:0.4VDC; No. of Pins:8Pins; Operating Temperature Max:85°C; Operating Temperature Min:-20°C; Operating Time:0.26ms; Release Time:0.26ms; Row Pitch:12.06mm; Switch Current Max:100mA; Switch Power Max:3W; Type:Axial

RELAY REED SPDT 30V 0.1A SMD; Contact Configuration:SPDT; Coil Voltage:5VDC; Product Range:9852 Series; Relay Mounting:SMD; Coil Resistance:110ohm; Switching Current Max:100mA; Switching Voltage Max:30V; Approvals & Standards:- ;RoHS Compliant: Yes

SENSOR MAGNET; For Use With:LY-30 Series Sensor; Product Range:-

RELAY REED 3PST-NO 200V 0.5A THT; Contact Configuration:3PST-NO; Coil Voltage:12VDC; Product Range:2300 Series; Relay Mounting:Through Hole; Coil Resistance:1kohm; Switching Current Max:500mA; Switching Voltage Max:200V ;RoHS Compliant: Yes

RELAY REED SPDT 200V 0.5A THT; Contact Configuration:SPDT; Coil Voltage:12VDC; Product Range:2300 Series; Relay Mounting:Through Hole; Coil Resistance:1kohm; Switching Current Max:500mA; Switching Voltage Max:200V ;RoHS Compliant: Yes

REED RELAY ;ROHS COMPLIANT: YES

High Voltage RELAY RF SPST 500MA 5V 3.8 VDC

RELAY REED SPDT 150V 0.25A THT; Contact Configuration:SPDT; Coil Voltage:12VDC; Product Range:2900 Series; Relay Mounting:Through Hole; Coil Resistance:1.5kohm; Switching Current Max:250mA; Switching Voltage Max:150V; Approvals & Standards:-; Case Material:Epoxy coated Steel; Coil Voltage VDC Nom:12V; Contact Current DC Max:250mA; Contact Resistance:150mohm; Contact Voltage DC Max:150V; Dielectric Strength VAC:200VAC; External Depth:20.82mm; External Height:7.11mm; External Length / Height:7.11mm; External Width:6.35mm; Insulation Resistance:100Gohm; Must Actuate Voltage:9VDC; Must Release Voltage:1VDC; No. of Electrical Operations:100000000; No. of Mechanical Operations:100000000; No. of Pins:7Pins; Operating Temperature Max:85°C; Operating Temperature Min:-20°C; Operating Time:1ms; Release Time:2ms; Row Pitch:2.54mm; Switch Current Max:250mA; Switch Power Max:3W; Type:Co-axial Shield

High Voltage RELAY REED SPST 1A 5V 3.8 VDC

High Voltage RELAY REED DPST 500MA 12V 9 VDC

High Voltage RELAY REED SPST 500MA 5V 3.8 VDC

High Voltage RELAY REED DPST 500MA 12V 9 VDC

High Voltage RELAY REED DPST 500MA 5V 3.8 VDC
