REED RELAY

REED RELAY SPST 5V MAG SHIELD ;ROHS COMPLIANT: YES

IN STOCK SHIP TODAY

RELAY SIP SPST 5VDC; Product Range:9000 Series; Coil Voltage:5VDC; Coil Resistance:500ohm; Switching Current Max:500mA; Switching Voltage Max:200V; Contact Configuration:SPST-NC; Relay Mounting:Through Hole; Carry Current:1.5A

RELAY REED SPST-NO 200V 0.5A THT; Contact Configuration:SPST-NO; Coil Voltage:5VDC; Product Range:9091 Series; Relay Mounting:Through Hole; Coil Resistance:500ohm; Switching Current Max:500mA; Switching Voltage Max:200V; Approvals & Standards:-; Approval Bodies:UL; Coil Voltage Max:6.5VDC; Coil Voltage VDC Nom:5V; Contact Current DC Max:500mA; Contact Resistance:125mohm; Contact Voltage DC Max:200V; Dielectric Strength VAC:1500V; External Depth:15.62mm; External Height:6.98mm; External Length / Height:6.98mm; External Width:3.81mm; Insulation Resistance:1000Gohm; Lead Spacing:3.81mm; Must Actuate Voltage:3.75VDC; Must Release Voltage:0.4VDC; No. of Pins:4Pins; Operating Temperature Max:85°C; Operating Temperature Min:-20°C; Operating Time:0.5ms; Release Time:0.3ms; Switch Current Max:500mA; Switch Power Max:10W; Type:Diode

RELAY REED SPST-NO 200V 0.5A THT; Contact Configuration:SPST-NO; Coil Voltage:12VDC; Product Range:9091 Series; Relay Mounting:Through Hole; Coil Resistance:1kohm; Switching Current Max:500mA; Switching Voltage Max:200V ;RoHS Compliant: Yes

Reed Relays REED RELAY SIP SPST 12V MAG SHLD

RELAY REED SPST-NO 200V 0.5A THT; Contact Configuration:SPST-NO; Coil Voltage:5VDC; Product Range:9007 Series; Relay Mounting:Through Hole; Coil Resistance:500ohm; Switching Current Max:500mA; Switching Voltage Max:200V; Approvals & Standards:CSA UL; Approval Bodies:CSA UL; Coil Voltage Max:6.5VDC; Coil Voltage VDC Nom:5V; Dielectric Strength VAC:1500V; External Depth:19.05mm; External Height:7.7mm; External Width:5.08mm; Must Actuate Voltage:3.75VDC; Must Release Voltage:0.4VDC; No. of Pins:4Pins; Operating Temperature Max:85°C; Operating Temperature Min:-20°C; Operating Time:0.5ms; Release Time:0.2ms; Switch Power Max:10W

RELAY REED SPST-NO 200V 0.5A THT; Contact Configuration:SPST-NO; Coil Voltage:12VDC; Product Range:9007 Series; Relay Mounting:Through Hole; Coil Resistance:1kohm; Switching Current Max:500mA; Switching Voltage Max:200V; Approvals & Standards:CSA UL; Approval Bodies:UL; Coil Voltage Max:15VDC; Coil Voltage VDC Nom:12V; Contact Current DC Max:500mA; Contact Resistance:200mohm; Contact Voltage DC Max:200V; Dielectric Strength VAC:1500V; External Depth:19.05mm; External Height:7.7mm; External Length / Height:7.6mm; External Width:5.08mm; Insulation Resistance:10Gohm; Lead Spacing:5.08mm; Must Actuate Voltage:9VDC; Must Release Voltage:1VDC; No. of Pins:4Pins; Operating Temperature Max:85°C; Operating Temperature Min:-20°C; Operating Time:0.5ms; Release Time:0.2ms; Switch Current Max:500mA; Switch Power Max:10W

RELAY REED SPST-NO 200V 0.5A THT; Contact Configuration:SPST-NO; Coil Voltage:5VDC; Product Range:9091 Series; Relay Mounting:Through Hole; Coil Resistance:500ohm; Switching Current Max:500mA; Switching Voltage Max:200V ;RoHS Compliant: Yes

SWITCH REED SPST 500mA 175VDC; Product Range:UM Series; Contact Configuration:SPST; Switch Mounting:-; Contact Current Max:500mA; Switching Voltage Max:175V; Switching Power Max:5VA; Contact Resistance Max:120mohm ;RoHS Compliant: Yes

LIQUID LEVEL SENSOR; Operating Pressure Max:-; Sensor Body Material:-; Output Current:1.5A; Product Range:LSH Series; Body Material:Polypropylene; Connection Size:1/2"; Contact Rating:10W; Operating Temperature Max:85 C ;RoHS Compliant: Yes

CONNECTORS

IN STOCK SHIP TODAY

REED RELAY ;ROHS COMPLIANT: YES

RELAY REED SPST-NO 125V 0.25A SMD; Contact Configuration:SPST-NO; Coil Voltage:3.3VDC; Product Range:B10 Series; Relay Mounting:SMD; Coil Resistance:55ohm; Switching Current Max:250mA; Switching Voltage Max:125V ;RoHS Compliant: No

MOSFET RELAY SPST-NO 0.05A 1.5KV SMD; Contact Configuration:SPST-NO; Load Current:45mA; Relay Terminals:SMD; Load Voltage Max:1.5kV; On State Resistance Max:200ohm; Isolation Voltage:3.75kV; Forward Current If:50mA

LIQUID LEVEL SWITCH; Operating Pressure Max:-; Sensor Body Material:PPS (Polypropylene Sulphide); Output Current:1.5A; Product Range:LSV Series; Response Time:0.5ms; Supply Voltage Max:200VDC ;RoHS Compliant: Yes

RELAY REED DPST-NO 200V 0.5A THT; Contact Configuration:DPST-NO; Coil Voltage:12VDC; Product Range:-; Relay Mounting:Through Hole; Coil Resistance:730ohm; Switching Current Max:500mA; Switching Voltage Max:200V ;RoHS Compliant: Yes

RELAY REED SPST-NO 200V 0.5A THT; Contact Configuration:SPST-NO; Coil Voltage:5VDC; Product Range:9091 Series; Relay Mounting:Through Hole; Coil Resistance:500ohm; Switching Current Max:500mA; Switching Voltage Max:200V ;RoHS Compliant: Yes
