Relay (Reed) 12Vdc With Diode , 7K Bv, Smd, Tr |Coto Technology 9105-12-01TR

Relay (Reed) 12Vdc With Diode , 7K Bv |Coto Technology 9105-12-31

Relay 1Fa, 5V, Sip, 10 Watts |Coto Technology 9117-05-10H

Relay 1Fa, 3V, Gull Wing, 10 Watts |Coto Technology 9814-03-00H

IN STOCK SHIP TODAY

SWITCH REED SPST 500mA 175VDC; Product Range:UM Series; Contact Configuration:SPST; Switch Mounting:-; Contact Current Max:500mA; Switching Voltage Max:175V; Switching Power Max:5VA; Contact Resistance Max:120mohm ;RoHS Compliant: Yes

LIQUID LEVEL SENSOR; Operating Pressure Max:-; Sensor Body Material:-; Output Current:1.5A; Product Range:LSH Series; Body Material:Polypropylene; Connection Size:1/2"; Contact Rating:10W; Operating Temperature Max:85 C ;RoHS Compliant: Yes

RELAY SIP SPST 5VDC; Product Range:9000 Series; Coil Voltage:5VDC; Coil Resistance:500ohm; Switching Current Max:500mA; Switching Voltage Max:200V; Contact Configuration:SPST-NC; Relay Mounting:Through Hole; Carry Current:1.5A

RELAY REED SPST-NO 200V 0.5A THT; Contact Configuration:SPST-NO; Coil Voltage:5VDC; Product Range:9091 Series; Relay Mounting:Through Hole; Coil Resistance:500ohm; Switching Current Max:500mA; Switching Voltage Max:200V; Approvals & Standards:-; Approval Bodies:UL; Coil Voltage Max:6.5VDC; Coil Voltage VDC Nom:5V; Contact Current DC Max:500mA; Contact Resistance:125mohm; Contact Voltage DC Max:200V; Dielectric Strength VAC:1500V; External Depth:15.62mm; External Height:6.98mm; External Length / Height:6.98mm; External Width:3.81mm; Insulation Resistance:1000Gohm; Lead Spacing:3.81mm; Must Actuate Voltage:3.75VDC; Must Release Voltage:0.4VDC; No. of Pins:4Pins; Operating Temperature Max:85°C; Operating Temperature Min:-20°C; Operating Time:0.5ms; Release Time:0.3ms; Switch Current Max:500mA; Switch Power Max:10W; Type:Diode

RELAY REED SPST-NO 200V 0.5A THT; Contact Configuration:SPST-NO; Coil Voltage:12VDC; Product Range:9091 Series; Relay Mounting:Through Hole; Coil Resistance:1kohm; Switching Current Max:500mA; Switching Voltage Max:200V ;RoHS Compliant: Yes

Reed Relays REED RELAY SIP SPST 12V MAG SHLD

RELAY REED SPST-NO 200V 0.5A THT; Contact Configuration:SPST-NO; Coil Voltage:5VDC; Product Range:9007 Series; Relay Mounting:Through Hole; Coil Resistance:500ohm; Switching Current Max:500mA; Switching Voltage Max:200V; Approvals & Standards:CSA UL; Approval Bodies:CSA UL; Coil Voltage Max:6.5VDC; Coil Voltage VDC Nom:5V; Dielectric Strength VAC:1500V; External Depth:19.05mm; External Height:7.7mm; External Width:5.08mm; Must Actuate Voltage:3.75VDC; Must Release Voltage:0.4VDC; No. of Pins:4Pins; Operating Temperature Max:85°C; Operating Temperature Min:-20°C; Operating Time:0.5ms; Release Time:0.2ms; Switch Power Max:10W

RELAY REED SPST-NO 200V 0.5A THT; Contact Configuration:SPST-NO; Coil Voltage:12VDC; Product Range:9007 Series; Relay Mounting:Through Hole; Coil Resistance:1kohm; Switching Current Max:500mA; Switching Voltage Max:200V; Approvals & Standards:CSA UL; Approval Bodies:UL; Coil Voltage Max:15VDC; Coil Voltage VDC Nom:12V; Contact Current DC Max:500mA; Contact Resistance:200mohm; Contact Voltage DC Max:200V; Dielectric Strength VAC:1500V; External Depth:19.05mm; External Height:7.7mm; External Length / Height:7.6mm; External Width:5.08mm; Insulation Resistance:10Gohm; Lead Spacing:5.08mm; Must Actuate Voltage:9VDC; Must Release Voltage:1VDC; No. of Pins:4Pins; Operating Temperature Max:85°C; Operating Temperature Min:-20°C; Operating Time:0.5ms; Release Time:0.2ms; Switch Current Max:500mA; Switch Power Max:10W

RELAY REED SPST-NO 200V 0.5A THT; Contact Configuration:SPST-NO; Coil Voltage:5VDC; Product Range:9091 Series; Relay Mounting:Through Hole; Coil Resistance:500ohm; Switching Current Max:500mA; Switching Voltage Max:200V ;RoHS Compliant: Yes

REED RELAY

REED RELAY

REED RELAY SPST 5V MAG SHIELD ;ROHS COMPLIANT: YES

RELAY REED SPST-NO 100V 0.25A SMD; Contact Configuration:SPST-NO; Coil Voltage:5VDC; Product Range:9814 Series; Relay Mounting:SMD; Coil Resistance:150ohm; Switching Current Max:250mA; Switching Voltage Max:100V

Tmr Sensor, Omnipolar, 1.7 To 5.5V, Lga; Magnetoresistive Sensor Technology:Tunneling Magneto Resistance (Tmr); Magnetoresistive Sensor Type:Omnipolar Switch; Supply Voltage Min:1.7V; Supply Voltage Max:5.5V; No. Of Pins:4Pins Rohs Compliant: Yes |Coto Technology RR142-1LD3-542
