Open Frame AC DC Converters 1 Output 48V 85 ~ 264 VAC Input

Mounting Fixings BASE ATTACHMENT R15A SERIES

Enclosed AC DC Converters 1 Output 3.3V - - - 3A 85 ~ 264 VAC Input

Open Frame AC DC Converters 1 Output 12V 12.5A 85 ~ 264 VAC Input

Mounting Fixings BASE ATTACHMENT R15A SERIES

Cosel Embedded Switch Mode Power Supply SMPS, 24V dc, 27A, 648W Enclosed, Number of Outputs: 1, Input Voltage: 85 → 264V ac, Mounting Type: Chassis Mount, Length: 152mm, Width: 89mm, Depth: 41mm, Weight: 840g, Maximum Temperature: +70°C, Medical Approved: Yes, Minimum Temperature: -20°C, MPN: PCA600F-24-T

Cosel Embedded Switch Mode Power Supply SMPS, 5V dc, 120A, 600W Enclosed, Input Voltage: 85 → 264V ac, Mounting Type: Chassis Mount, Length: 152mm, Width: 89mm, Depth: 41mm, Weight: 840g, Maximum Temperature: +70°C, Medical Approved: Yes, Minimum Temperature: -20°C, MPN: PCA600F-5

Cosel CHS 400W Isolated DC-DC Converter Through Hole, Voltage in 36 → 76 V dc, Voltage out 10V dc, Output Voltage Adjustment Range: ±10%, Input Voltage Nominal: 48 V dc, Isolation Voltage: 500V dc, Output Current: 40A, Efficiency: 94.5%, Package: DIP, Load Regulation: 20mV, Minimum Temperature: -40°C, Maximum Temperature: +85°C, Depth: 36.8mm, MPN: CHS4004810

Cosel MGF 80.4W Isolated DC-DC Converter PCB Mount, Voltage in 18 → 76 V dc, Voltage out 12V dc, Output Voltage Adjustment Range: ±10%, Input Voltage Nominal: 48 V dc, Isolation Voltage: 1.5kV dc, Output Current: 6.7A, Efficiency: 94%, Load Regulation: 48mV, Minimum Temperature: -40°C, Maximum Temperature: +85°C, Depth: 9.9mm, Length: 25.4mm, MPN: MGFS804812

Cosel MGF 81W Isolated DC-DC Converter PCB Mount, Voltage in 9 → 36 V dc, Voltage out 15V dc, Output Voltage Adjustment Range: ±10%, Isolation Voltage: 1.5kV dc, Output Current: 5.4A, Efficiency: 94%, Load Regulation: 60mV, Minimum Temperature: -40°C, Maximum Temperature: +85°C, Depth: 9.9mm, Length: 25.4mm, MPN: MGFS802415

Open Frame AC DC Converters 1 Output 36V 85 ~ 264 VAC Input

Mounting Fixings BASE ATTACHMENT R10A SERIES

Cosel MGXS1R5 1.32W Isolated DC-DC Converter Through Hole, Voltage in 6 → 60 V dc, Voltage out 3.3V dc, Input Voltage Nominal: 24 V dc, Isolation Voltage: 1kV dc, Output Current: 400mA, Efficiency: 77%, Load Regulation: 20mV, Minimum Temperature: -40°C, Maximum Temperature: +85°C, Depth: 12mm, Length: 17mm, MPN: MGXS1R5243R3

Cosel Embedded Switch Mode Power Supply (SMPS), 24V dc, 14A, 336W Enclosed, Series: PCA300F, Input Voltage: 85 → 264 V ac, 88 → 370 V dc, Mounting Type: Chassis Mount, Length: 89mm, Width: 152mm, Depth: 41mm, Weight: 840g, Efficiency: 91%, Maximum Temperature: +70°C, Medical Approved: Yes, MPN: PCA300F-24

Cosel Embedded Switch Mode Power Supply (SMPS), 32V dc, 10A, 320W Enclosed, Series: PCA300F, Input Voltage: 85 → 264 V ac, 88 → 370 V dc, Mounting Type: Chassis Mount, Length: 89mm, Width: 152mm, Depth: 41mm, Weight: 840g, Efficiency: 91%, Maximum Temperature: +70°C, Medical Approved: Yes, MPN: PCA300F-32

Cosel MGFS40 30W Isolated DC-DC Converter PCB Mount, Voltage in 4.5 → 13 V dc, Voltage out 5V dc, Output Voltage Adjustment Range: ±10%, Input Voltage Nominal: 5 V dc, Isolation Voltage: 1.5kV dc, Output Current: 6A, Efficiency: 87%, Package: 1 x 1 in, Load Regulation: 20mV, Minimum Temperature: -40°C, Maximum Temperature: +85°C, Depth: 9.9mm, MPN: MGFS400505

Cosel MGFS40 40.8W Isolated DC-DC Converter PCB Mount, Voltage in 9 → 36 V dc, Voltage out 12V dc, Output Voltage Adjustment Range: ±10%, Input Voltage Nominal: 24 V dc, Isolation Voltage: 1.5kV dc, Output Current: 3.4A, Efficiency: 92%, Package: 1 x 1 in, Load Regulation: 48mV, Minimum Temperature: -40°C, Maximum Temperature: +85°C, Depth: 9.9mm, MPN: MGFS402412

Mounting Fixings BASE ATTACHMENT R25A SERIES
