Cable Assembly 3.28' (1.00m)

CONNECTOR

SEALED BOX SIZE 2

5x20mm FUSEHOLDER

Rocker Switches SWITCH R13-112B BLACK RED 230V

SWITCH, DPST, MOM; Switch Operation:(On)-Off; Contact Configuration:DPST; Contact Voltage AC Nom:250V; Contact Voltage DC Nom:-; Contact Current Max:16A; Switch Terminals:Quick Connect; Product Range:8300 Series; SVHC:No SVHC (27-Jun-2018); Actuator / Cap Colour:Black; Bezel Depth:21mm; Bezel Width:15mm; Colour:Black; Contact Current @ Contact Voltage AC Max:12A; Contact Current AC Max:16A; Contact Voltage VAC:250V; External Depth:25.5mm; External Length / Height:19mm; External Width:12.1mm; Illumination Colour:Non-illuminated; Insulation Resistance:20Mohm; No. of Mechanical Operations:10000; Operating Temperature Max:105°C; Operating Temperature Min:0°C; Panel Cutout (H x W):12.9mm x 19.3mm; Panel Cutout Width:13mm; Panel Cutout length:19.2mm; Pushbutton Actuator Style:Rectangular; Pushbutton Switch Type:Standard; Switch Mounting:Panel; Tab Blade Thickness:0.8mm; Tab Width:4.8mm

LED Panel Mount Indicators Indicator Light 24V LED Red IP67

Rocker Switches SWITCH R13-244A BLACK

Rocker Switches SWITCH R13-244A BLACK

Rocker Switches SWITCH R13-244A BLACK

ROCKER SWITCH

Rocker Switches SWITCH R13-244B BLACK RED 230V

FUSE HOLDER, 1"X1/4"; Fuse Holder Type:Cartridge Fuse Holder; Fuse Current:16A; Fuse Size Held:1/4" x 1", 6.3mm x 25.4mm, 8AG; Holder Terminals:Quick Connect, Screw; No. of Fuses:1Fuses; Product Range:-; Voltage Rating VAC:250V; Voltage Rating V DC:250V; SVHC:No SVHC (27-Jun-2018); Behind Panel Depth:54.4mm; Bezel Diameter:19.1mm; Breakdown Voltage Vbr:4kV; Colour:Black; Current Rating:13A; External Length / Height:60.4mm; Fuse Size Imperial:1/4" x 1"; Fuse Size Metric:6.3mm x 25.4mm; Height:60.4mm; Material:Nylon, glass filled, with phenolic sleeve; Operating Temperature Max:100°C; Operating Temperature Min:-20°C; Panel Cutout Diameter:16mm; Panel Thickness:5.5mm

ROCKER SWITCH, SPST, BLACK; Illumination:Non Illuminated; Contact Configuration:SPST; Switch Operation:Off-On; Actuator / Cap Colour:Black; Switch Mounting:Panel; Contact Current Max:20A; Contact Voltage AC Nom:250V; Contact Voltage DC Nom:-; Product Range:1500 Series; SVHC:No SVHC (27-Jun-2018); Bezel Height:14mm; Bezel Width:30.2mm; Colour:Black; Contact Current AC Max:16A; Contact Resistance:10Mohm; Contact Voltage AC Max:250V; External Depth:16.2mm; Insulation Resistance:20Mohm; No. of Electrical Operations:10000; No. of Mechanical Operations:50000; Operating Temperature Max:85°C; Operating Temperature Min:0°C; Panel Cutout Size:28.2 x 11.5 mm; Panel Cutout Width:11.5mm; Panel Cutout length:28.2mm; Tab Width:6.3mm

NEON INDICATOR, AMBER; Supply Voltage:250V; Lamp Base Type:Wire Leaded; Illumination Colour:Amber; Mounting Hole Dia:8mm; Lens Shape:Round with Flat Top; Current Rating:20mA; Product Range:2951 Series; SVHC:No SVHC (27-Jun-2018); Base Type:Wire Lead; Colour:Amber; External Length / Height:41mm; Panel Cutout Diameter:8mm; Panel Thickness Max:1.6mm; Panel Thickness Min:0.8mm; Supply Voltage V AC:250V

6 Position Circular Connector Receptacle, Male Pins Solder Cup

BUSS HIGH SPEED FUSE

FILAMENT INDICATOR, RED; Lamp Base Type:-; Mounting Hole Dia:6.35mm; Current Rating:20mA; Supply Voltage:14V; Lens Shape:-; Product Range:-; SVHC:No SVHC (27-Jun-2018); Bulb Size:7.6mm; Colour:Red; External Length / Height:14.5mm; LED / Lamp Size:7.6mm; Panel Cutout Diameter:6.3mm; Panel Thickness Max:6.3mm; Supply Voltage V AC:14V

FILAMENT INDICATOR, GREEN; Lamp Base Type:-; Mounting Hole Dia:6.35mm; Current Rating:20mA; Supply Voltage:14V; Lens Shape:-; Product Range:-; SVHC:No SVHC (27-Jun-2018); Bulb Size:7.6mm; Colour:Green; External Length / Height:14.5mm; LED / Lamp Size:7.6mm; Panel Cutout Diameter:6.3mm; Panel Thickness Max:6.3mm; Supply Voltage V AC:14V

SWITCH, SPDT, BLACK; Switch Operation:Momentary; Contact Configuration:SPST-NC; Contact Voltage AC Nom:50V; Contact Voltage DC Nom:-; Contact Current Max:500mA; Switch Terminals:Solder Lug; Product Range:0917 Series; SVHC:No SVHC (27-Jun-2018); Actuator / Cap Colour:Black; Colour:Black; Contact Current AC Max:500mA; Contact Voltage VAC:250V; External Length / Height:35.4mm; Illumination Colour:Non-illuminated; Panel Cutout Diameter:7.1mm; Pushbutton Actuator Style:Round; Pushbutton Switch Type:Standard; Shaft Diameter:10.3mm; Switch Mounting:Panel; Voltage Rating V DC:50V
