RF Transistor 2 NPN (Dual) 5.5V 32mA 150mW Surface Mount SOT-363

RF Amplifier IC DBS, LMDS, VSAT 20GHz ~ 32GHz 8-SMD (5x5)

Optoisolator Transistor Output 3750Vrms 1 Channel 8-SO

Optoisolator Power MOSFET 1500VDC 1 Channel 8-DIP

Optoisolator Transistor with Base Output 1500VDC 2 Channel 8-DIP

LED, 4MM, 50X100DEG, BLUE; LED Colour:Blue; LED Mounting:Through Hole; Forward Current If:20mA; Forward Voltage:3.2V; Wavelength Typ:480nm; Luminous Intensity:960mcd; Viewing Angle:100°; Lens Shape:Oval; MSL:-; SVHC:No SVHC (15-Jan-2018); Bulb Size:4mm; Dominant Wavelength:470nm; Dominant Wavelength Typ:470nm; Forward Current If Max:20mA; Forward Voltage VF Max:3.7V; LED / Lamp Size:4mm; LED Type:Standard; Luminous Intensity Max:960mcd; Luminous Intensity Min:380mcd; No. of Pins:2Pins; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C; PIV Max:5V; Viewing Angle X Axis Min:50°; Viewing Angle Y Axis:100°; Voltage Vf Min:2.7V; Voltage Vf Typ:3.2V

LED, SMD, RED/BLUE; LED Colour:Blue, Red; LED Mounting:SMD; Bulb Size:-; Viewing Angle:120°; Lens Shape:Round; Forward Current / Colour:R 30mA, B 20mA; Luminous Intensity / Colour:R 80mcd, B 10mcd; Forward Voltage / Colour:R 1.9V, B 3.9V; Wavelength / Colour:-; MSL:-; SVHC:No SVHC (12-Jan-2017); No. of LEDs:2LEDs; Operating Temperature Max:100°C; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +100°C

LED, 5MM, 30X70DEG, AMBER; LED Colour:Amber; LED Mounting:Through Hole; LED Case Size:T-1 3/4 (5mm); Forward Current If:20mA; Forward Voltage:2.2V; Wavelength Typ:592nm; Luminous Intensity:680mcd; Viewing Angle:70°; Lens Shape:Oval; Product Range:-; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (15-Jan-2018); Bulb Size:T-1 3/4 (5mm); Current If Luminous Intensity:20mA; Dominant Wavelength:592nm; External Diameter:5mm; External Length / Height:8.71mm; Forward Current If Max:20mA; Forward Voltage VF Max:2.4V; LED / Lamp Size:5mm / T-1 3/4; LED Colour Presentation:Diffused Tint; LED Type:Standard; Lead Cross-section Width:0.5mm; Lead Length:22.89mm; Lead Spacing:2.54mm; Luminous Intensity @ If Min:680mcd; Luminous Intensity Typ:680mcd; No. of Pins:2Pins; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C; PIV Max:5V; Peak Forward Current:50mA; Viewing Angle X Axis Min:70°; Viewing Angle Y Axis:35°; Voltage Vf Typ:2.4V

LED, 5MM, 15DEG, WHITE; LED Colour:White; LED Mounting:Through Hole; Forward Current If:20mA; Forward Voltage:3.2V; Wavelength Typ:-; Luminous Intensity:12cd; Viewing Angle:15°; Lens Shape:Round; MSL:-; SVHC:No SVHC (15-Jan-2018); Bulb Size:T-1 3/4 (5mm); Current If Luminous Intensity:20mA; External Diameter:5mm; External Length / Height:8.71mm; Forward Current If Max:20mA; Forward Voltage VF Max:3.6V; LED / Lamp Size:5mm / T-1 3/4; LED Type:Standard; Lead Cross-section Width:0.5mm; Lead Length:23mm; Lead Spacing:2.54mm; Lens Diameter:5mm; Luminous Intensity Max:12000mcd; Luminous Intensity Min:4200mcd; Luminous Intensity Typ:12000mcd; No. of Pins:2Pins; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C; PIV Max:5V; Peak Forward Current:30mA; Voltage Vf Typ:3.6V

LED, 5MM, 30DEG, WHITE; LED Colour:White; LED Mounting:Through Hole; Forward Current If:20mA; Forward Voltage:3.2V; Wavelength Typ:-; Luminous Intensity:7.2cd; Viewing Angle:30°; Lens Shape:Round; MSL:-; SVHC:No SVHC (15-Jan-2018); Bulb Size:T-1 3/4 (5mm); Current If Luminous Intensity:20mA; External Diameter:5mm; External Length / Height:8.71mm; Forward Current If Max:20mA; Forward Voltage VF Max:3.8V; LED / Lamp Size:5mm; Lead Cross-section Width:0.5mm; Lead Length:23mm; Lead Spacing:2.54mm; Lens Diameter:5mm; Luminous Intensity Max:7200mcd; Luminous Intensity Min:4200mcd; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C; PIV Max:5V; Peak Forward Current:30mA; Voltage Vf Typ:3.8V

LED, 5MM, 55DEG, AMBER; LED Colour:Amber; LED Mounting:Through Hole; Forward Current If:20mA; Forward Voltage:2.15V; Wavelength Typ:592nm; Luminous Intensity:1.15cd; Viewing Angle:55°; Lens Shape:Round; MSL:-; SVHC:No SVHC (15-Jan-2018); Bulb Size:T-1 3/4 (5mm); Current If Luminous Intensity:20mA; Dominant Wavelength:592nm; External Diameter:5mm; External Length / Height:8.71mm; Forward Current If Max:20mA; Forward Voltage VF Max:2.15V; LED / Lamp Size:5mm / T-1 3/4; LED Type:Standard; Lead Cross-section Width:0.5mm; Lead Length:23mm; Lead Spacing:2.54mm; Lens Diameter:5mm; Luminous Intensity Max:1150mcd; Luminous Intensity Min:400mcd; Luminous Intensity Typ:345mcd; No. of Pins:2Pins; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C; PIV Max:5V; Peak Forward Current:50mA; Peak Wavelength:594nm; Voltage Vf Typ:2.15V

LED, SIDE EMIT, 24W, RGB; LED Module Type:LED + Housing; LED Colour:Red, Green, Blue; Wavelength / Colour:-; Luminous Flux / Colour:R 200lm, G 125lm, B 30lm; No. of LEDs:50LEDs; Power Module Configuration:Rectangular; Supply Voltage:-; Forward Voltage @ Test:-; Power Rating:10.5W; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Product Range:-; MSL:-; SVHC:No SVHC (12-Jan-2017); Voltage Vf Red Typ:29V

IC, COLOUR CONTROLLER; IC Package Type:SOIC; No. of Pins:-; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; MSL:-; SVHC:No SVHC (12-Jan-2017); Operating Temperature Range:-40°C to +85°C; Termination Type:Surface Mount Device; Voltage Vcc:5V

DIODE, RF, PIN; Diode Case Style:DO-15; No. of Pins:2 Pin; Product Range:5082 Series; MSL:-; SVHC:No SVHC (12-Jan-2017); Alternate Case Style:DO-204AC; Breakdown Voltage:100V; Capacitance Ct:0.4pF; Device Marking:3081; Diode Series Resistance Rs:3.5ohm; Diode Type:RF; High Resistance Limit Min:1500ohm; Low Resistance Limit Max:8ohm; No. of Pins:2Pins; Termination Type:Axial Leaded; Vr Cd Measurement Voltage Typ:50V

DIODE, RF FAST SWITCHING DUAL; Resistance @ If:2.5ohm; Diode Case Style:SOT-23; Forward Current If(AV):1A; Product Range:HSMP Series; MSL:MSL 1 - Unlimited; SVHC:No SVHC (12-Jan-2017); Breakdown Voltage:35V; Capacitance Cd Max @ Vr F:0.3pF; Capacitance Ct:0.3pF; Current If @ Rs:5mA; Device Marking:G2; Diode Series Resistance Rs:2.5ohm; Diode Type:RF; Repetitive Reverse Voltage Vrrm Max:100V; Reverse Voltage Vr Max:5V; Termination Type:Surface Mount Device

LED, 5MM 90DEG GREEN; LED Colour:Green; LED Mounting:Through Hole; Forward Current If:10mA; Forward Voltage:2.1V; Wavelength Typ:569nm; Luminous Intensity:4.2mcd; Viewing Angle:60°; Lens Shape:Round; MSL:-; SVHC:No SVHC (15-Jan-2018); Bulb Size:T-1 3/4 (5mm); Current If Luminous Intensity:10mA; Dominant Wavelength:569nm; External Depth:9mm; External Length / Height:6.2mm; External Width:6.2mm; Forward Current If Max:10mA; Forward Voltage VF Max:2.1V; LED / Lamp Size:5mm / T1.3/4; LED Colour Presentation:Tinted Diffused; LED Type:Standard; Lead Cross-section Depth:0.45mm; Lead Cross-section Width:0.45mm; Lead Length:3.7mm; Lead Spacing:2.54mm; Luminous Intensity Typ:5.2mcd; No. of Pins:2Pins; PIV Max:5V; Peak Forward Current:25mA; Peak Wavelength:565nm

LED, 5MM 30DEG WHITE; LED Colour:White; LED Mounting:Through Hole; LED Case Size:T-1 3/4 (5mm); Forward Current If:20mA; Forward Voltage:3.2V; Wavelength Typ:-; Luminous Intensity:7.2cd; Viewing Angle:30°; Lens Shape:Round; Product Range:-; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (15-Jan-2018); Bulb Size:T-1 3/4 (5mm); External Length / Height:8.71mm; Forward Current If Max:20mA; Forward Current If(AV):30mA; Forward Voltage VF Max:4V; Head Diameter:5.8mm; LED / Lamp Size:5mm / T-1 3/4; Lead Length:22.89mm; Lens Colour:Untinted, Non-diffused; Lens/Filter Width:5mm; Luminous Intensity @ If Max:7200mcd; Luminous Intensity @ If Min:2500mcd; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +85°C; Reverse Protection Voltage:5V; Voltage Vf Typ:3.2V

Optoisolator Darlington Output 1500VDC 1 Channel 8-DIP

Green, Red 569nm Green, 637nm Red LED Indication - Discrete 2.2V Green, 1.9V Red 4-PLCC
